KIP 7000 Parts Manual page 62

Item Part Number
1 3506800060
2 7706800010
3 3505700350
4 3504400680
5 1710441650
6 1710441640
7 1710441070
8 3504400720
9 6813032332
10 3504400210
11 1410441010
12 6803015231
13 Z034400040
14 Z034400070
15 Z034400080
16 Z034400030
17 3504400730
18 9000800153
19 3505700310
20 9000780008
21 3505720020
22 9000820024
23 3504400330
24 9000780029
25 3505700330
26 7704420050
27 Z036400170
28 9000450456
29 Z034400060
30 9000660111
＊
31 1410441330
32 9000790002
33 9000820008
34 3504400040
35 9000310097
36 Z034400430
＊
37 7704400610
38 3504400030
Description
IR Lamp
IR Lamp
Spur Gear,50T
Collar 1
Isolate Bushing
Ball Bearing
Collar E
Collar 4
Retaining Ring-C,S
Lamp GP 1
Lamp Mount
Flat Washer
Fixing Plate L
Fixing Pin
Support Bracket L
Support Plate
Shaft 5
Woodruff Key
Spur Gear,30T
Ball Bearing
Spur Gear,30T
Thrust Washer
Collar L2
Ball Bearing
Spur Gear,40T
Cam
Fuser Heater Lead
Wire Saddle
Reinforcement Plate
Spur Gear,50T
Spur Gear,30T
Oilless Metal
Thrust Washer
Shaft 1
Lead Switch
SENSOR BRACKET
Collar
Boss
Type
QIR220-1750KIC
QIR220-1350KIAG
35×47×7NR,TYPE2
C32,BK
4.Fe+ZC
10×26×8NR,TYPE2
φ10.1×16×1.0,BS
8×16×5NR,TYPE2
LWS-1S-F
S6×10×10,TYPE1
φ6.1×12×0.5,BS
RS-801EA
Qty SC
1 C
1 C
1 C
1 D
2 C
2 C
1 D
1 D
1 D
1 D
2 D
1 D
1 D
1 D
1 D
1 D
1 D
1 D
1 C
1 D
1 C
2 D
1 D
3 D
1 C
1 D
1 D
3 D
1 D
1 C
1 D
2 D
2 D
1 D
1 C
1 D
1 D
1 D
