Page 1: Instructions For Use
INSTRUCTIONS FOR USE HI-LIGHT COOKTOP FCE905B1... -
Page 2: Table Of Contents
Dear customer, Thank you for having chosen our ceramic cooktop In order to make the best use of your appliance, we would advise you to read carefully the following notes and to keep them for later consulting. SUMMARY ............................3 SAFETY ....................... -
Page 3: Safety
SAFETY Precautions before using • Unpack all the materials. • The installation and connecting of the appliance have to be done by approved specialists. The manufacturer cannot be responsible for damage caused by building-in or connecting errors. • To be used, the appliance must be well-equipped and installed in a kitchen unit and an adapted and approved work surface. - Page 4 • Make sure no cable of any fixed or moving appliance contacts with the glass or the hot saucepan. • Magnetically objects (credit cards, floppy disks, calculators) should not be placed near to the engaged appliance. • Metallic objects such as knives, forks, spoons and lids should not be placed on the cooktop surface since they can get hot.
-
Page 5: Precautions Not To Damage The Appliance
• WARNING: Accessible parts may become hot during use. Young children should be kept away. • Danger of fire: Do not store items on the cooking surface • WARNING: Unattended cooking on a cooktop with fat or oil can be dangerous and may result in a fire. •... -
Page 6: Precautions In Case Of Appliance Failure
Precautions in case of appliance failure • If a defect is noticed, switch off the appliance and turn off the electrical supplying. • If the ceramic glass is cracked or fissured, you must unplug the appliance and contact the after sales service. •... -
Page 7: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Technical data Type FCE905B1 6000 W Total power Energy consumption for the cooktop EC 175 Wh/kg Ø 220 mm Front left heating zone 2300 W Nominal power Standardised cookware category** Energy consumption EC 174.4 Wh/kg Rear left heating zone Ø... -
Page 8: Use
Sensitive touches Your ceramic cooktop is equipped with electronic controls with sensitive touch keys. When your finger touches the key, the corresponding command is activated. This activation is validated by a control light, a letter or a number in the display and/or a “beep” sound. Touch only one key on the same time. -
Page 9: Starting-Up And Appliance Management
STARTING-UP AND APPLIANCE MANAGEMENT Before using your new cooktop Clean your cooktop with a damp cloth, and then dry the surface thoroughly. Do not use detergent which risks causing blue-tinted colour on the glass surface. Starting-up Start-up/ switch off the cooktop •... -
Page 10: Timer
Timer The timer is able to be used simultaneous with all heating zones and this with different time settings (from 1 to 99 minutes) for each heating zone. • Setting and modification of the cooking time : Action Control panel Display Zone selection Press on the “SLIDER“... -
Page 11: Automatic Cooking
Automatic cooking All the cooking zones are equipped with an automatic cooking device. The cooking zone starts at full power during a certain time, and then reduces automatically its power on the preselected level. • Start-up Action Control panel Display Power level selection Slide to the position [ 7 ] and stay 3s [ 7 ] Is blinking... -
Page 12: Cooking Advices
COOKING ADVICES Examples of power setting (The values below are indicative) Melting Sauces, butter, chocolate, gelatine 1 to 2 Reheating Dishes prepared beforehand Simmering Rice, pudding, sugar syrup 2 to 3 Defrosting Dried vegetables, fish, frozen products 3 to 4 Steam Vegetables, fish, meat Steamed potatoes, soups, pasta,... -
Page 13: Environment Protection
One or all cooking zones cut-off: • The safety system has engaged • You forgot to cut-off the cooking zone for a long time. • One or more sensitive keys are covered. • The pan is empty and has overheated. The automatic cooking system «... -
Page 14: Installation Instructions
Fitting - installing: • Cut out sizes of the worktop: Reference Cut-size FCE905B1 850 x 490 mm Ensure that there is a distance of 50 mm between the cooktop and the wall or sides. • The cooktops are classified as “Y” class for heat protection. Ideally the cooktop should be •... -
Page 15: Electrical Connection
ELECTRICAL CONNECTION • The installation of this appliance and the connection to the electrical network should be entrusted only to an electrician perfectly to the fact of the normative regulations and which respects them scrupulously. • Protection against the parts under tension must be ensured after the building-in. •... - Page 16 PR Kitchen & Washroom Systems 83 Bangholme Rd, Dandenong South VIC 3122 Australia Phone: +61 3 9700 9100 Fax: +61 3 9700 9191 info@prks.com.au www.franke.com 25811-0...
