Franke FRE604B1 Quick Start Manual

FRANKE
DESIGNER CERAMIC COOKTOP 60 CM
Dimensions are nominal measurements only.

SPECIFICATIONS

Recommended use
Material
Colour availability
Weight
Dimensions
Zones
Control type
Voltage
Max power KW
FR Capacity (KW)
BR Capacity (KW)
FL Capacity (KW)
BL Capacity (KW)
Highlight
Auto shut-off
Overheat indicator
Power connection

CLEANING RECOMMENDATIONS

• Switch-off the appliance before cleaning.
• Do not clean the hob if the glass is too hot because there is a risk of burn.
• Remove light marks with a damp cloth with washing up liquid diluted in a little water. Then rinse with cold water and dry the
surface thoroughly.
• Highly corrosive or abrasive detergents and cleaning equipment likely to cause scratches must be absolutely avoided.
• Do not ever use any steam-cleaner or pressure washer.
• Do not use any object that may scratch the ceramic glass.
• Ensure that the pan is dry and clean. Ensure that there are no grains of dust on your ceramic hob or on the pan. Sliding rough
saucepans will scratch the surface.
• Spillages of sugar, jam, jelly, etc. must be removed immediately. You will thus prevent the surface being damaged.
• Damage caused by any improper treatment is not covered by the product warranty. Refer to Warranty Conditions.
Disclaimer: Products in this specification manual must by regulation be installed by licensed and registered trade people. The manufacturer/distributor
reserves the right to vary specifications or delete models from their range without prior notification. Dimensions are nominal measurements only.
Dimensions and set-outs listed are correct at time of publication however the manufacturer/distributor takes no responsibility for printing errors.
Tech Page Version 1
40mm
Domestic
Black Glass
Black
9kg
40 x 590 x 520mm
4
Touch
220-240V/50-60
6.0
1.8
1.2
1.8
1.2
Yes
Yes
Yes
Hardwired
To see the complete FRANKE range go to
www.reece.com.au/bathrooms
page 1 of 3
