Page 5
DESCRIPTION 1 Steam basket e Soup 2 Graduation for water and rice f Clay Pot 3 Removable ceramic bowl g Slow Cook 4 Measuring cup h Quick Cooking 5 Rice spatula i Steam 6 Soup spoon j Menu 7 Lid k Reheat 8 Removable inner lid l Start...
Page 6
appliance and its cord out of reach of children aged less than 8 years. • Appliances can be used by persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 7
• If your appliance is fitted with fixed power cord: if the power supply cord is damage, it must be replaced by the manufacturer, the manufacturer’s after-sales service department or similarly qualified person in order to avoid any danger. • The appliance must not be immersed in water or any other liquid.
the appliance, the hot water, steam or the food. • During cooking, the appliance gives out heat and steam. Keep face and hands away. • Do not obstruct the steam outlet. • For any problems or queries please contact our Customer Relations Team or consult our web site.
USING • Use a flat, stable, heat-resistant work surface away from any water splashes. • Do not allow the base of the appliance to come into contact with water • Never try to operate the appliance when the pot is empty or without the pot.
Environment protection first! Your appliance contains valuable materials which can be recovered or recycled. Leave it at a local civic waste collection point. BEFORE FIRST USE • Open the lid by pressing the opening button on the housing – Fig. 1 •...
COOKING GUIDE -White RICE For Example Measuring cups Water level in the bowl Serving per person of white rice (+ rice) 2 cup white rice mark 4 cup white rice mark 5.5 cup white rice mark Note: Always add the rice first otherwise you will have too much water. COOKING PROGRAMS White Rice, Jasmine Rice, Congee, Soup, Slow Cook –...
Page 12
Delayed Start – Available for all cooking modes (except “Reheat”, “Keep Warm”, “Clay Pot” and “Slow Cook” mode). – After selecting “Congee”and “Soup”, press the “Delayed Start / Timer” key button twice (the delayed start indicator will turn on), and then use the “+/-” buttons to set the timer. Cooking will finish after the preset time has elapsed.
COOKING PROGRAM TABLE Cooking time Temperature Delayed SF30FC866A Programs Keep warm Start Default Range Default White Rice Auto Auto Jasmine Rice Auto Auto Congee 1h30min 1h-2h Auto Soup 1h30min-3h Auto Slow Cook 2h-10h 95°C Clay Pot Auto Auto Steam Auto Auto Quick Cooking Auto...
Page 14
• To avoid any risk of corrosion, do not pour vinegar into the pot. Cleaning the micro pressure valve • When clean the micro-pressure valve, please remove it from the lid and open it by rotating in the direction of “open” – Fig. 4a-4b. After cleaning it, please wipe dry it and meet the two triangle in the two parts together and rotate it in the direction of “close”, then put it back to the lid of the rice cooker – Fig.5a-5b.
TROUBLESHOOTING Malfunction description Cause Solution Any indicator light off and no Check the power cord is plugged Appliance not plugged in. heating. in the socket and on the Mains. Any indicator light off and Indicator light is damaged or Send to authorized service heating.
Page 16
The repair process may require a longer time if the product is not locally sold by TEFAL/T-FAL in th e country of usage. If the product is not repairable in the new country of usage, the international TEFAL/T-FAL guarantee i s limited to a replacement by a similar or alternative product at similar cost, where possible.
Page 17
PERIHALAN 1 Bakul kukus e Soup (Sup) 2 Penanda untuk air dan nasi f Clay Pot (Periuk Tanah) 3 Mangkuk seramik mudah alih g Slow Cook (Masak Perlahan) 4 Cawan penyukat h Quick Cooking (Memasak Segera) 5 Senduk nasi i Steam (Kukus) 6 Senduk sup j Menu 7 Tudung...
Page 18
penggunaan tidak boleh dilakukan oleh kanak- kanak kecuali mereka berumur 8 tahun ke atas dan diselia. Simpan alat perkakas dan kordnya jauh daripada jangkauan kanak-kanak berumur kurang daripada 8 tahun. • Alat perkakas boleh digunakan oleh seseorang yang kurang upaya secara fizikal, sensori atau keupayaan mental atau kurang berpengalaman jika mereka telah diberi penyeliaan atau arahan berkenaan penggunaan alat perkakas dengan...
Page 19
digunakan walaupun dalam penggunaan berikut dan jaminan tidak akan terpakai untuk: – Kakitangan dapur di kedai, pejabat dan lain- lain persekitaran bekerja – Rumah ladang – Oleh pelanggan di hotel, motel dan lain-lain jenis persekitaran kediaman – Persekitaran untuk tempat menginap •...
Page 20
• Awas: terdapat risiko disebabkan oleh penggunaan alat perkakas. • Awas: jika alat perkakas anda mempunyai kord kuasa boleh tanggal, jangan tumpahkan cecair pada penyambung. • Selalu cabut alat perkakas daripada soket: – selepas digunakan – apabila menggerakkannya – sebelum membasuh atau penyelenggaraan –...
Page 21
• Semak voltan sumber kuasa adalah bersesuaian dengan yang tertera pada alat perkakas (aliran bertukar). • Disebabkan terdapat pelbagai tahap standard, jika alat perkakas digunakan di negara selain dari di mana ia dibeli, semak dengan pusat perkhidmatan yang diperakui. SAMBUNG KEPADA SUMBER KUASA •...
• Jangan letak alat perkakas berdekatan sumber haba atau di dalam ketuhar panas, kerana ia boleh menyebabkan kerosakan yang teruk. • Jangan letakkan sebarang makanan atau air ke dalam perkakas sehingga periuk berada di tempatnya. • Ikuti tahap yang ditunjukkan dalam resipi. •...
Page 23
MENGGUNAKAN PEMASAK NASI ANDA Menyukat bahan-bahan - Kapasiti maksimum mangkuk • Penanda aras di dalam mangkuk adalah dalam cawan, ini digunakan untuk menyukat jumlah air apabila memasak nasi dan bijirin lain. Terdapat 2 jenis penanda paras air untuk 2 jenis beras yang berbeza: beras putih, beras Jasmine.
Page 24
Clay Pot (Periuk Tanah) – Pengguna perlu menambah beras dan air terlebih dahulu dan menggunakan butang Menu untuk memilih program periuk tanah dan menekan “Start (Mula)” untuk mula memasak. Tambah jenis bahan yang lain seperti ikan masin, sosej apabila perkakas berbunyi “bip” dan tekan butang “Start (Mula)”...
Page 25
Laraskan masa memasak – Anda boleh melaraskan masa memasak untuk mod bubur nasi, sup, masak perlahan. Apabila anda memilih mod memasak, masa memasak lalai akan ditunjukkan pada paparan digital. Tekan kekunci “Masa Tertunda / Pemasa” sekali (penunjuk pemasa akan menyala) dan kemudian gunakan butang +/- untuk melaraskan masa memasak.
Nota: Kira-kira 45 minit diperlukan untuk memasak 4 cawan beras putih di bawah keadaan normal dan jika anda menggunakan fungsi Quick Cooking (Memasak Segera), anda akan menjimatkan kira-kira 7 minit. PEMBERSIHAN DAN PENYELENGGARAAN • Untuk memastikan periuk pemasak nasi telah dicabut palam dan disejukkan sebelum pembersihan dan penyelenggaraan.
Page 27
Membersihkan tudung dalaman • Tanggalkan tudung dalam dengan menolak keluar kepala tudung atas – Rajah 3a-3b. Bersihkannya dengan span dan cecair pencuci. Kemudian lap sehingga kering dan letakkan semula di belakang dua rusuk dan tekan pada bahagian atas sehingga ia tetap. Pembersihan dan penjagaan bahagian perkakas yang lain •...
MENYELESAIKAN MASALAH Perihalan pincang tugas Punca Penyelesaian Sebarang lampu penunjuk tidak Periksa kord kuasa dipasang Alat perkakas tidak pasang. menyala dan tiada pemanasan. pada soket dan Sesalur. Sebarang lampu penunjuk tidak Lampu penunjuk rosak atau Hantar ke pusat servis untuk menyala dan ada pemanasan.
Page 29
The repair process may require a longer time if the product is not locally sold by TEFAL/T-FAL in th e country of usage. If the product is not repairable in the new country of usage, the international TEFAL/T-FAL guarantee i s limited to a replacement by a similar or alternative product at similar cost, where possible.
