Location and Function of Controls
Location and Function of Controls
REMOTE
CONTROL IN
AUDIO
RS-232C IN
(RGB/DVI)
HDMI/DVI IN
(CONTROL&SERVICE)
RGB IN
1
2
1. RS-232C IN(CONTROL&SERVICE) PORT
2. HDMI/DVI IN / AUDIO IN / RGB IN SOCKETS
3. POWER CORD SOCKET
8 PLASMA TV
RGB OUT
R
L
RGB
(PC/DTV)
VARIABLE
AUDIO OUT
Connect to the RS-232C port on a PC.
Connect the set output socket of the PERSONAL
COMPUTER to this socket.
Note: If you want to use RGB/DVI audio, we strongly
recommend that you use the cable that has a core, or the EMI Filter core along
with separate cable.
RGB OUTPUT SOCKET
You can watch the RGB signal on another set, connect RGB OUT to another set's
PC input port.
REMOTE CONTROL IN
VARIABLE AUDIO OUT SOCKETS
This set operates on an AC power. The voltage is
indicated on the Specifications page. Never attempt to
operate the set on DC power.
<Back Panel>
AC IN
