Programmer Keypad Summary

—
1 9
Calibrate mode: numeric entries
Run mode: 1 = H.TOT; press to view high total, P-2 = 4 or 5 (P-55)
Calibrate mode: decimal point entry
.
Run mode: HRS 3; press to view pump 3 running time (P-26)
Calibrate mode: negative entry
—
Run mode: HRS 4; press to view pump 4 running time (P-27)
Calibrate mode: clears display
CLR
Run mode: HRS 5; press to view pump 5 running time (P-28)
Calibrate mode: used to initiate parameter display after having entered
*
Run mode: READ; press to view reading (P-76)
Alternates operating modes
RUN
CAL
Calibrate mode: press to take a measurement
MEAS
Run mode: press to view distance (P-78)
advance to next parameter
↑
go back to previous parameter
↓
PL-399
press to view level at DLD transducer #1, P-2 =3
2 = L.TOT; press to view low total, P-2 = 4 or 5 (P-54)
press to view level at DLD transducter #2, P-2 =3
3 = HEAD; press to view head reading, P-2 = 5
4 = FLOW; press to view flow rate, P-2 = 5
5 = mA; press to view mA output
6 = TEMP; press to view temperature (P-65)
7 = RATE; press to view rate of level change (P-70)
8 = CONF; press to view echo confidence (P-80)
9 = HRS 1; press to view pump 1 running time (P-24)
0 = HRS 2; press to view pump 2 running time (P-25)
the calibrate mode or used to calibrate for percent reading
4 – 2
