Milltronics AIRANGER DPL PLUS Quick Start Manual

OPERATION

When the Quick Start procedure is complete...
1.
to enter the RUN mode
"----" is displayed briefly...
The AIRANGER DPL PLUS rapidly takes measurements,
verifies repeatability, and calculates Readings.
For one vessel, the Reading is displayed continuously.
For two vessels, Readings are scroll displayed.
Difference or Average Readings (if selected) are also scroll
displayed, as Point Number 3.
The Bar Graph indicates material level (0 to 100%),
regardless of the Operation selected.
If "L" is displayed the vessel level has exceeded 80% and
not yet fallen below 75% (Hi Alarm).
If "M" is displayed the vessel level has fallen below 20% and
not yet exceeded 25% (Lo Alarm).
When in alarm, the corresponding relay is de-energized.
Transducer # Alarm
1 Hi
1 Lo
2 Hi
2 Lo
2.
%
Readings are displayed in % (based upon Operation).
level space or distance
© © ©
Empty Span = 0 100% Empty
3.
View mA output values in the Auxiliary Reading display.
level space or distance
© © ©
Empty Span = 4 20mA Empty
4.
View the Failsafe Time Left in % (before "LOE" is displayed).
If the value reaches 0, the "old" Reading, Bar Graph, relays,
and mA outputs are "held" and "LOE" flashes.
When a valid measurement is made, the value resets to 100.
The AIRANGER DPL PLUS advances to the "new" level;
operating displays and outputs accordingly.
5
Transducer
1
Point Number
2
Reading
3
4 Filling
Percent
5
Hi Alarm
6
Bar Graph
7
Lo Alarm
8
Relay #
1
2
3
4
©
Span = 100 0%
%
©
Span = 20 4mA
Monitor system performance, under all operating conditions.
If alternate display, relay, or mA output operation is required,
or "LOE" is displayed, see instruction manual PL-421.
Connect (or enable) alarm/control equipment only after

RUN MODE DISPLAY FUNCTIONS

100
%
1 2 3 4
Emptying
9
Data Out
10
Point Scanned
11
12 Auxiliary Reading
Relay #4 energized
13
Relay #3 de-energized
14
Normal Operation
15
Failsafe Operation
16

RUN MODE KEYPAD FUNCTIONS

Display mA output in 12 .
Display temperature in 12 .
Display Empty / Fill Rate in 12 .
Display Failsafe Time Left in 12 .
Key in Parameter # to display value in 12 .
Display Material Level in 12 .
Display Distance in 12 .
Initiate program mode access ( see ).
%
Display Units / % in 3 (complete program mode access).
Stop / Start scroll display.
Display next Point Number (scroll display stopped).
Display previous Point Number (scroll display stopped).

PERFORMANCE EVALUATION

satisfactory performance is verified.
6
0
DUAL POINT LEVEL MONITOR
QUICK START GUIDE
LIQUID and SOLID LEVEL MEASUREMENT
CUSTOM GRAPHIC LCD,
VOLUME CONVERSION,
ANALOG mA OUTPUTS,
33454310
PRR 2.3
100
%
1 2 3 4
0
%
ACCURATE, RELIABLE
with
ALARM RELAYS,
& BIC-II SUPPORT
PL-431
September 1995
1
