2. Installation
The figure below shows the exterior dimensions and mounting hole locations for the cabinet backbox and
dimensions of the optional trim ring:
1 6.12 5 "
(4 0.96 cm )
1 .0 0"
(2 .5 4cm )
1 .0 0"
(2 .5 4cm )
9 .5 0"
(2 4.13 cm )

Reinstallation of Circuit Board

Reinstall the printed circuit board as follows:
14
1 4.62 5 "
(3 7.15 cm )
1 4.50 "
(3 6.83 cm )
1 2.50 "
(3 1.75 cm )
Figure 2 Cabinet Mounting Dimensions
Step Action
1 Position circuit board over stand-offs on backbox rail and secure with four
(4) phillips screws. Tighten securely.
2 Connect transformer wires to J1 connector on circuit board.
5 .3 75 "
(1 3.65 cm )
1 6.00 "
(4 0.64 cm )
4 .7 5"
(1 2.07 cm )
(40.96cm )
14.625"
(37.15cm )
PDRP-1002 Instruction Manual PN 51135:B0 04/06/01
Cabinet Mounting
1.5"
(3.81cm )
16.125"
