The PDRP-1002/PDRP-1002E
Agent Release Control System
Manual
Document 51135
I56-1358-00
03/11/99
PN 51135:A
System Sensor
3825 Ohio Avenue
St. Charles, IL 60174
1-800-SENSOR2
Fax: 630-377-6495
A
Revision:
ECN 99-017

Advertisement

loading
Need help?

Need help?

Do you have a question about the PDRP-1002E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for System Sensor PDRP-1002E

Summary of Contents for System Sensor PDRP-1002E

  • Page 1 System Sensor 3825 Ohio Avenue St. Charles, IL 60174 1-800-SENSOR2 Fax: 630-377-6495 The PDRP-1002/PDRP-1002E Agent Release Control System Manual Document 51135 I56-1358-00 03/11/99 Revision: PN 51135:A ECN 99-017...

  • Page 2: Installation Precautions

    Installation Precautions – Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be connected to the Like all solid state electronic devices, this system may operate fire alarm control panel. Disconnect all sources of power before erratically or can be damaged when subjected to lightning induced servicing.
  • Page 3 The PDRP-1002 PN 51135:A 03/11/99...
  • Page 4 The PDRP-1002 PN 51135:A 03/11/99...

  • Page 5: Nfpa Standards

    NFPA Standards This control panel complies with the following NFPA standards: NFPA 12 CO Extinguishing Systems (High Pressure Only) NFPA 12A Halon 1301 Extinguishing Systems NFPA 12B Halon 1211 Extinguishing Systems NFPA 72 Central Station Signaling Systems (Automatic, Manual, and Waterflow). Protected Premises Unit (Requires NOTI•FIRE 911AC DACT or MS-5012 Slave Communicator)* NFPA 72 Local (Automatic, Manual, Waterflow and Sprinkler Supervisory) Fire Alarm Systems NFPA 72 Auxiliary (Automatic, Manual, and Waterflow) Fire Alarm Systems.

  • Page 6: Input Circuits

    1 The PDRP-1002/PDRP-1002E Input Circuits 1 The PDRP-1002/PDRP-1002E Features • Microprocessor-controlled • Power-limited on all circuits except Municipal Box output • Alarm and trouble resound • Four Class A (Style D)/Class B (Style B) Initiating Device Circuits • Two Class A (Style Z)/Class B (Style Y) Notification Appliance circuits •...

  • Page 7: Front Panel Control Switches

    1 2 3 4 5 6 OPT 2 BATT EARTH Cross Zone Abort Option Supervisory Abort Option Micro Fail LED Delay Timer Delay Timer Battery Fail LED Ground Fault LED Figure 1 PDRP-1002/PDRP-1002E Installation Diagram The PDRP-1002 PN 51135:A 03/11/99...

  • Page 8: Optional Boards

    1 The PDRP-1002/PDRP-1002E Transmitter Module (4XTM - NOTIFIER) Optional Boards The PDRP-1002/PDRP-1002E has mounting slots for two option boards. Any two of the three option modules may be installed. Transmitter Module (4XTM - NOTIFIER) The Transmitter Module provides a supervised output for...

  • Page 9: Remote Annunciator

    Transmitter Module (4XTM - NOTIFIER) 1 The PDRP-1002/PDRP-1002E Transmitter Module (4XTM - NOTIFIER) For Local Energy Municipal Box service (NFPA 72 Auxiliary Fire Alarm System) Supervisory current: 5.0 mA Trip current: 0.35 amps. (Subtracted from Notification Appliance power) Coil Voltage: 3.65 VDC Coil resistance: 14.6 ohms...

  • Page 10: Specifications

    Specifications AC Power For the PDRP-1002: 120 VAC, 50/60 Hz, 1.2 amps AC Circuit For the PDRP-1002E: 220/240 VAC, 50 Hz, 0.6 amps Breaker Wire size: minimum #14 AWG with 600V insulation Battery (lead acid only) Maximum Charging Circuit: 27.6V, 1.5 amps Maximum Battery Capacity: 15 AH.
  • Page 11 RMS Regulated Power 1 The PDRP-1002/PDRP-1002E Cabinet = 5.375 in. (136.53 mm) Backbox = 4.750 in. Door = 14.625 in. (120.65 mm) (371.48 mm) Backbox = 14.5 in. (368.3 mm) Door = 16.125 in. (409.58 mm) Backbox = 16 in.

  • Page 12: System Operation

    2 System Operation RMS Regulated Power 2 System Operation WARNING:When used for CO releasing applications, observe proper precautions as stated in NFPA 12. Do not enter the protected space unless physical lockout and other safety procedures are fully completed. Do not use software disable functions in the panel as lockout.

  • Page 13: Control Switches

    RMS Regulated Power 2 System Operation Control Switches Tone Silence Acknowledge alarms, troubles and supervisories. The panel has alarm and trouble resound with LED flash of new conditions. The flashing trouble LED(s) illuminate steadily on TONE SILENCE and the piezo sounder silences. A second trouble will resound the piezo.

  • Page 14: Zone Disable

    2 System Operation RMS Regulated Power Supervisory Output circuit #4 is used as an input for monitoring supervisory devices such as valve tamper switches (note that SW1 DIP switch #2 must be set “ON” -- see section “Setting Mode of Operation”) By setting Switch short circuit on this input (activation of a N.O. contact) will cause the supervisory LED to flash.

  • Page 15: Installation Procedure

    Furthermore, all power limited circuit wiring and non-power limited circuit wiring must enter and exit the cabinet through different knockouts and/or conduits. A typical wiring diagram for the PDRP-1002/ PDRP-1002E is shown below. Power Limited Non-Power...

  • Page 16: Initiating Device Circuits

    3 Installation Procedure Zones Initiating Device Circuits Zones Wire all alarm initiating devices sequentially for proper supervision. Initiating devices include: heat, photoelectric, and ionization type detectors; and waterflow alarm devices. Refer to the Compatibility Chart in Appendix B. Note: • Observe polarity when connecting polarized devices.
  • Page 17 Zones 3 Installation Procedure 4-Wire Smoke Detector Connections Refer to the Device Compatibility Document for suitable 4-wire smoke detectors. 24 VDC (+) 24 VDC (+) Common (-) Common (-) Black IDC (+) IDC (+) IDC (-) IDC (-) UL listed 4.7K, 1/2-Watt Listed UL listed 24 VDC...

  • Page 18: Output Circuits

    3 Installation Procedure Notification Appliance Circuits Output Circuits Notification Appliance Circuits This control panel can provide two Class A (Style Z)/Class B (Style Y) Notification Appliance Circuits and two Class B (Style Y) Releasing Circuits (see section “Setting Mode of Operation” for DIP switch configuration). Each circuit is capable of 1.5 amps of current.

  • Page 19: Alarm Relay

    Alarm Relay 3 Installation Procedure Alarm Relay One Form-C dry alarm contact is provided in the basic panel for controlling supplementary devices. It is rated 2 amps at 30 VDC and 0.5 amps at 30 VAC (resistive), and is non-silenceable when an alarm occurs. See below for terminal location.

  • Page 20: Battery Power

    Primary power required for the PDRP-1002 panel is 120 VAC, 50/60 Hz, 1.2 amps and primary power for the PDRP-1002E is 220/240 VAC, 50 Hz, 0.6 amps. Overcurrent protection for this circuit must comply with Article 760 of the National Electrical Code (NEC) and/or local codes.

  • Page 21: Optional Modules

    Voltmeter/Ammeter 3 Installation Procedure Optional Modules The fire control panel has two module connectors - J5 and J8. Three modules are available for the panel and they can be used in any combination, including duplicate modules. The corresponding option jumper must be cut before installation of an optional module.

  • Page 22: Installing Option Modules

    3 Installation Procedure Installing Option Modules Installing Option Modules Insert the two stand-offs (provided) into the holes located on the right-side edge of the main board. Carefully align the pins on the main board with J1 and/or J2 on the option board.
  • Page 23 Transmitter Module - 4XTM (NOTIFIER) 3 Installation Procedure Transmitter Module - 4XTM (NOTIFIER) Polarities shown in activated positions. The wiring of this module must follow the requirements as specified in the “General” section, “UL Power Limited Wiring Requirements.” Remote Alarm Power Limited Circuit Remote Trouble No Connection...
  • Page 24 3 Installation Procedure Zone Relay Module - 4XZM (NOTIFIER) Zone Relay Module - 4XZM (NOTIFIER) Non-power limited and power limited wiring must have a minimum distance of 0.25 in. (6.35 mm) wire to wire. If this module is used to drive non-power limited and power limited circuits, please follow the instructions below.
  • Page 25 LED Interface Module - 4XLM (NOTIFIER) 3 Installation Procedure LED Interface Module - 4XLM (NOTIFIER) The wiring of this module must follow the requirements as specified in section”UL Power Limited Wiring Requirements.” +24V Out#1 Out#2 Out#3 Out#4 System Trouble Sound Resound Connect to corresponding terminals of RZA-4X Remote Annunciator.

  • Page 26: Setting Mode Of Operation

    Setting Mode of Operation DIP Switch The DIP switch is located at the bottom of the PDRP-1002/PDRP-1002E main board. To set a switch to the “ON” position, slide the switch up until it stops. The flush- surface switches are designed to prevent accidentally changing a switch setting and may therefore require use of a pen or screwdriver to set them.
  • Page 27 Output 4 Supervisory/Releasing Service 3 Installation Procedure Output 4 Supervisory/Releasing Service Set the function of Output 4 via SW1 DIP switch 2. Switch 2 Output 4 will function as a Output 4 will function as a supervisory input solenoid releasing circuit. This circuit.

  • Page 28: Appendix A: Power Calculations

    Appendix A: Power Calculations Standby Battery Requirements Appendix A: Power Calculations Standby Battery Requirements The Standby Battery Current figure obtained in the following table (Table 1) represents the amount of current that must be supplied by the secondary power source (batteries) to sustain control panel operation for one hour.
  • Page 29 Ampere-Hour Calculations Appendix A: Power Calculations Ampere-Hour Calculations StandbyTime Standby Battery Current 24, 60, or 90 Convert the total from Table 1 to amps and enter hours here Standby hours = amps X amp/hours Alarm Enter 0.25 for 5 minutes in alarm amp/hours or 0.5 for 10 minutes in alarm Total amp/...

  • Page 30: Appendix B: Device Compatibility

    Current (mA) System Sensor 2424 Photoelectric 0.10 System Sensor 2424TH Photoelectric 0.10 System Sensor 2451 Photoelectric 0.10 System Sensor 2451TH (with/B402B Base) Photoelectric 0.10 System Sensor 1424 Ionization 0.10 System Sensor 1451 (w/B402B Base) Ionization 0.10 System Sensor 2412 Photoelectric 0.12...
  • Page 31 Wall Mount Surface Wiring FM998-24 Wall Mount Concealed Wiring Table 4 24 VDC Door Holders Vendor Model Current(mA) System Sensor A77-716B Air Products & Controls, LTD MR-101/C MR-201/C Table 5 UL Listed 24 VDC Relays The PDRP-1002 PN 51135:A 03/11/99...
  • Page 32 System Sensor MA-12/24D Electronic Sounder 24VDC System Sensor SS24 Strobe 24VDC note 5 System Sensor SS24LO Strobe 24VDC System Sensor SS24LOC Ceiling Strobe (SS24LOBC - beige) 24VDC System Sensor SS24M Strobe 24VDC System Sensor SS24MC Ceiling Strobe 24VDC System Sensor MASS24D Electronic Sounder/Strobe...
  • Page 33 24VDC System Sensor SP101R24M Speaker/Strobe, 5" square grille 24VDC System Sensor SP100W24MC Ceiling Speaker/Strobe, 8" round grille 24VDC System Sensor MA12/24EH Multi Alert Horn with Mechanical Tone 12VDC/ 20/64 38/43 24VDC System Sensor MAEH24LO Multi Alert Horn with Mechanical Tone/Strobe...
  • Page 34 Appendix B: Device Compatibility FM-Approved Releasing Devices System Sensor P2475 SpectrAlert Horn/Strobe3 24VDC System Sensor P24110 SpectrAlert Strobe3 24VDC System Sensor RP1215ADAARetrofit Strobe Plate 12VDC System Sensor RP121575ADAARetrofit Strobe Plate 12VDC System Sensor RP2415ADAARetrofit Strobe Plate 24VDC System Sensor RP241575ADAARetrofit Strobe Plate...
  • Page 35 Detectors Per Zone Model Det. Detector Type Base Model Base Standby PDRP-1002/ Current PDRP-1002E (uA) System Sensor 1400 Ionization System Sensor 1451 Ionization B401B / B406B 15 / 1 System Sensor 1851DH Ionization DH1851DC System Sensor 2400 Photoelectric System Sensor 2400AIT...

  • Page 36: Appendix C: Nfpa Standard-Specific Requirements

    FM-Approved Releasing Devices Appendix C: NFPA Standard-Specific Requirements The PDRP-1002/PDRP-1002E has been designed for use in commercial, industrial, and institutional applications and meets the requirements for service under the National Fire Protection Association (NFPA) Standards outlined in this appendix. The minimum system components required for compliance with the appropriate NFPA standards are listed below.
  • Page 37 The Maximum standby load shall be 125 mA. • The Standby by Battery Requirement: 24VDC, 7Amp-Hour-Max. • The PDRP-1002/PDRP-1002E is not suitable for transmission of a supervisory signal to the DACT. NOTE on STD DACT: Place jumper over pins 2 and 3, marked DACT, when employing a Note: The PDRP-1002/ DACT.
  • Page 38 NFPA 72 Signaling Systems for Central Station Service Using the MS-5012 as a DACT Reference the MS-5012 manual for additional information. Program the MS-5012 for slave applications. The PDRP-1002/PDRP-1002E is not suitable for transmission of a supervisory signal to the DACT. Secondary Phone Line...

  • Page 39: Nfpa 72 Auxiliary Fire Alarm System

    NFPA 72 Auxiliary Fire Alarm System Appendix C: NFPA Standard-Specific Requirements NFPA 72 Auxiliary Fire Alarm System All connections are power limited and supervised. This application is not suitable for separate transmission of sprinkler supervisory or trouble conditions. Note: Maximum loop resistance allowed for wiring from control panel to Municipal Box is 3 ohms. FIRE Municipal Box Circuit 4XTB...

  • Page 40: Nfpa 72 Remote Station Fire Alarm System

    Appendix C: NFPA Standard-Specific Requirements NFPA 72 Remote Station Fire Alarm System NFPA 72 Remote Station Fire Alarm System Intended for connection to a polarity reversal circuit of a remote station receiving unit having compatible ratings. All connections are power limited and supervised with the exception of the reverse polarity loop.

  • Page 41: Troubleshooting Table

    NFPA 72 Remote Station Fire Alarm System Appendix C: NFPA Standard-Specific Requirements Troubleshooting Table SYMPTOM PROBLEM SOLUTION 1. Check TB2 for proper connections. (TB3 for 4XB panels) 2. Remove all field wiring and install dummy ELR at output circuit. Check for supervisory voltage across it.
  • Page 42 Appendix C: NFPA Standard-Specific Requirements NFPA 72 Remote Station Fire Alarm System Notes The PDRP-1002 PN 51135:A 03/11/99...
  • Page 43 NFPA 72 Remote Station Fire Alarm System Appendix C: NFPA Standard-Specific Requirements Notes The PDRP-1002 PN 51135:A 03/11/99...

  • Page 44: Limited Warranty

    ® which they are installed or intended. Buyer acknowledges that System Sensor not an insurer and assumes no risk for loss or damages or the cost of any inconve- nience, transportation, damage, misuse, abuse, accident or similar incident.
