Setting Mode of Operation

Switch #2 - Supervisory/Releasing Service

Set the function of Releasing Circuit #2 by setting this switch.
REL #2

Switch #3 and #4 - Timer Delay

Select the desired timer setting and set these switches accordingly.

Switch # 5 and #6 - Abort Function

Select the desired Abort Functions for delaying the activation of releasing circuits, and set these switches
accordingly. If 'Cross Zone' is selected, both IDC #1 and IDC #2 must be activated to start timer.
Switch #5
Switch #6
PDRP-1002 Instruction Manual PN 51135:B0 04/06/01
OFF
Will function as a solenoid releasing
circuit.
Note: This circuit is nonpower-
limited.
No Delay*
Switch #3 OFF
Switch #4 OFF
* Abort timer will not operate when timer is set for 'No Delay'.
OFF
OFF
Standard UL-type
delay timer
Continues to count
down upon ABORT, but
stops and holds at 10
seconds until release of
the ABORT switch.
Upon release of the
ABORT switch, the
timer resumes the
countdown at 10
seconds.
These modes are the only ones that
comply with UL Standard 864.
Note: Abort timer will not operate when timer is set for 'No Delay'. Manual pull station does not use
abort mode.
REL #2
10 Second 20 Second
OFF
ON
OFF
ON
IRI-type delay NYC-type delay
timer
Functions the same as When an alarm exists,
the UL-type timer with pressing ABORT
the exception that the changes timer value to
ABORT will function the Timer Delay plus 90
only if pressed and held seconds. The timer will
before 2nd zone goes not start while ABORT
into alarm. is held. SYSTEM
RESET restores timer to
origional Timer Delay.
Each time ABORT is
pressed again adds 90
seconds to Timer Deley.
2. Installation
ON
Will function as a supervisory input
circuit.
• A short condition on this circuit
will light the Supervisory LED
and sound the supervisory tone on
the control panel piezo.
• An open condition generates a
circuit trouble condition.
Note: This circuit will now be power-
limited.
30 Second
ON ON
OFF ON
ON ON
OFF ON
Local Jurisdiction
timer delay timer
Once the timer has
started, pressing
ABORT resets the timer
to full Timer Delay. The
timer will not start
while ABORT is held.
Releasing the ABORT
switch continues the
countdown; pressing
ABORT again restores
Timer Delay to its full
value.
