- Page 1 PDRP-1002 Series Agent Release Control System Instruction Manual 3825 Ohio Avenue St. Charles, IL 60174 1-800-SENSOR2 Fax: (630) 377-6495 Document 51135 I56-1358-01 04/06/2001 Rev: PN 51135:B0 ECN 00-543...
-
Page 2: Fire Alarm System Limitations
Fire Alarm System Limitations An automatic fire alarm system–typically made up of smoke detectors, heat detectors, manual pull stations, audible warn- ing devices, and a fire alarm control with remote notification capability–can provide early warning of a developing fire. Such a system, however, does not assure protection against property damage or loss of life resulting from a fire. -
Page 3: Installation Precautions
Installation Precautions WARNING - Several different sources of power can be con- nected to the fire alarm control panel. Disconnect all sources of power before servicing. Control unit and associated equip- ment may be damaged by removing and/or inserting cards, modules, or interconnecting cables while the unit is energized. -
Page 4: Nfpa Standards
NFPA Standards This control panel complies with the following NFPA standards: • NFPA 2001 - Clean Agent Fire Extinguishing Systems • NFPA 17 - Dry Chemical Extinguishing Systems • NFPA 17A - Wet Chemical Extinguishing Systems • NFPA 12 - CO2 Extinguishing Systems (High Pressure Only) •... -
Page 5: Table Of Contents
NFPA Standards... 4 NFPA Standards ... 4 Underwriters Laboratories Documents ... 4 Other... 4 1. Product Description Overview ... 7 Features ... 7 Options ... 7 Circuits ... 8 Input Circuits... 8 Output circuits... 8 Front Panel Control Switches ... 8 Suplemental Documentation ... - Page 6 Table of Contents Zone Relay Module - 4XZM ... 26 LED Interface Module - 4XLM ... 27 Setting Mode of Operation ... 28 DIP Switch Functions... 28 Switch #1 - Cross Zone ... 28 Switch #2 - Supervisory/Releasing Service ... 29 Switch #3 and #4 - Timer Delay ...
-
Page 7: Product Description
1. Product Description Overview The PDRP-1002 Agent Release Control System has been designed as a control center for use in automatic fire supression systems. The panel is a feature-packed control unit suitable to perform detection and control functions associated with the release of gaseous agent/special hazard fire protection systems. The PDRP- 1002 is designed for maximum reliability with 100% solid state circuitry and isolated relay contacts for outside interfacing and features programmable options to allow on-site customization of the unit for various operating configurations. -
Page 8: Circuits
1. Product Description Circuits Input Circuits Detector Zone 1 (Style B/D) Detector Zone 2 (Style B/D) Abort (Style B/D) Manual Release (Style B/D) Note: Optional auxiliary relay module 4XZM tracks these four circuits. Output circuits Notification Appliance Circuit 1 (Style Y/Z) Notification Appliance Circuit 2 (Style Y/Z) Releasing Circuit 1 (Style Y) Releasing Circuit 2 (Style Y) / Supervisory Input (StyleB) -
Page 9: Control Panel
Control Panel Control Panel Notification Appliance Circuits Style Z (Class A) / Style Y (Class B) 24VDC Regulated Nonresettable Regulated Resettable RMS-Regulated O U T #1 B + A+ A – B – TB 1 TB 5 AM P Battery Fail LED Ground Fault LED PDRP-1002 Instruction Manual PN 51135:B0 04/06/01 Releasing Circuits... -
Page 10: Dip Switch Functions
1. Product Description DIP Switch Functions The table below describes the DIP switch functions. For a more detailed explaination see "Setting Mode of Operation" on page 28. #3 & #4 #5 & #6 Note: See “Setting Mode of Operation” on page 28 for a more detailed explanation of DIP switch functions. -
Page 11: Remote Annunciator - Rza-4X
Options Remote Annunciator - RZA-4X The Remote Annunciator mounts on a standard single-gang box, and provides LED indication of the same functions as the zone relay module. For example, with DIP switch #1 ‘ON’ and DIP switch #2 ‘OFF’: • One zone in alarm (red) •... -
Page 12: Specifications
1. Product Description Specifications AC Power PDRP-1002: 110/120 VAC, 50/60 Hz, 1.2 amps PDRP-1002E: 220/240 VAC, 50/60 Hz, 0.6 amps Wire size: minimum #14 AWG with 600V insulation Battery (lead acid only) Maximum Charging Circuit: 27.6V, 1.5 amps Maximum Battery Capacity: 18 AH. Note: Batteries larger than 12 AH require Fire•Lite BB-17 or other UL-listed external battery cabinet. -
Page 13: Installation
Cabinet Mounting Carefully unpack the system and check for shipping damage. Select a suitable location in a clean, dry, vibration-free environment that is not subject to extreme temperatures. Locate the top of the cabinet approximately five feet above the floor with the hinge on the left. -
Page 14: Reinstallation Of Circuit Board
2. Installation The figure below shows the exterior dimensions and mounting hole locations for the cabinet backbox and dimensions of the optional trim ring: 1 6.12 5 ” (4 0.96 cm ) 1 .0 0” (2 .5 4cm ) (3 6.83 cm ) 1 .0 0”... -
Page 15: Installing Optional Voltmeter/Ammeter
Installing Optional Voltmeter/Ammeter Installing Optional Voltmeter/Ammeter To monitor battery voltage and battery charging current, a 4XMM Meter Module is required. To install the power meter module follow the steps below: Step The figure below shows the mounting location and connections for the Voltmeter/Ammeter. PDRP-1002 Instruction Manual PN 51135:B0 04/06/01 Action Cut the jumper wire labeled “AMP”. -
Page 16: Power Connections
2. Installation Power Connections WARNING: Do not apply any type power to this control panel until all connections have been made and verified. AC Connections Disconnect (open) the circuit breaker in the AC main breaker panel and tag it “Out of Service”. Note: Refer to "Power-Up Procedure"... -
Page 17: Power-Limited Wiring Requirements
Power-limited Wiring Requirements Observe polarity when connecting the batteries. Connect the battery cable (p/n 75203 or 75202, depending on terminal size of battery) to terminal J9 on the main circuit board using the plug-in connector provided. Connect red wire to positive (+) terminal and black wire to negative (–) terminal on opposing batteries. Do NOT connect battery interconnect wire at this time. -
Page 18: Initiating Device Circuits
2. Installation Initiating Device Circuits The control panel provides two Initiating Device Circuits (#1 and #2) and they may be configured as either Style D (Class A) or Style B (Class B). Circuit #3 is designated as an Abort Switch Circuit and Circuit #4 is a Manual Release Circuit. -
Page 19: Four-Wire Smoke Detector Connections
Initiating Device Circuits Four-Wire Smoke Detector Connections A maximum of 200mA is available from the 24VDC Resettable Power circuit on TB1 (+24VR terminals). Any power that is drawn from the 24VDC Nonresettable Power on TB2 (+24VNR terminal) must be subtracted from available resettable power. See "Specifications" on page 12 and "Powering External Devices"... -
Page 20: Output Circuits
2. Installation Output Circuits Notification Appliance Circuits The control panel provides two Style Z (Class A) or Style Y (Class B) Notification Appliance Circuits, which are supervised and power-limited. Each circuit is capable of 1.5 amps of current. Total current drawn from both NACs and both Releasing Circuits (see "Releasing Circuits"... -
Page 21: Releasing Circuits
Output Circuits Releasing Circuits CAUTION: To prevent accidential discharge, connect releasing devices after initial panel tests are completed. The control panel provides two Style Y (Class B) Releasing Circuits, which are nonpower-limited. Circuit #2 can be configured for a Supervisory Circuit (see "Setting Mode of Operation" on page 28) and will then be power-limited. -
Page 22: Alarm Relay Circuit
2. Installation Alarm Relay Circuit One Form-C dry contact alarm relay is provided in the basic panel for controlling supplementary devices. Contacts are rated 2 amps at 30 VDC and 0.5 amps at 30 VAC (resistive) and are non-silenceable when an alarm occurs. -
Page 23: Optional Modules
Optional Modules Optional Modules Overview The control panel has two module connectors - J5 (upper position) and J8 (lower position). Three modules are available for the panel and they can be used in any combination, including duplicate modules. The corresponding option jumper must be cut before installation of an optional module, to enable module supervision. -
Page 24: Installation - Lower Position
2. Installation Installation - Lower Position To install either the 4XTM, 4XZM or 4XLM module in the lower position follow these instructions: Step Action Cut jumper ‘OPT2’ on main circuit board. Remove the lower-right screw securing the main board to the lower rail. Replace with a stand-off and tighten securely. -
Page 25: Setup And Configuration
Optional Modules Setup and Configuration Transmitter Module - 4XTM Connect a Remote Alarm circuit, Remote Trouble circuit or a Municipal Box to the Transmitter Module as shown below. Polarities shown in activated positions. Note: Dummy load terminals 6 and 7 (4.7K, 1/4 W resistor) if Municipal Box is not connected. Note: Remote Alarm, Remote Trouble and Municipal Box wiring can leave the building. -
Page 26: Zone Relay Module - 4Xzm
2. Installation Zone Relay Module - 4XZM Relay #1 through #4 on this module have specific functions based on the configuration of DIP switches #1 and #2 on the control panel. See “Zone Relay Module Configuration” on page 30 for a more detailed explaination of the conditions that will activate each relay under the different DIP switch setings. -
Page 27: Led Interface Module - 4Xlm
Optional Modules LED Interface Module - 4XLM Connect the terminals on TB1 of the LED Interface Module to the corresponding terminals of the RZA- 4X Remote Annunciator. Make wiring connections with system power off. Maximum wire impedance is 50 ohm per wiring connection. The wiring of this module must follow the requirements as specified under "Power-limited Wiring Requirements"... -
Page 28: Setting Mode Of Operation
2. Installation Setting Mode of Operation Select operating mode by setting the SW1 DIP switches as described below; basic programming options are shown in this section. After any changes are made to the configuration of the switches, the panel must be reset. For Canadian use, refer to "Sprinkler Supervisory Tracking"... -
Page 29: Switch #2 - Supervisory/Releasing Service
Setting Mode of Operation Switch #2 - Supervisory/Releasing Service Set the function of Releasing Circuit #2 by setting this switch. REL #2 Will function as a solenoid releasing circuit. Note: This circuit is nonpower- limited. Switch #3 and #4 - Timer Delay Select the desired timer setting and set these switches accordingly. -
Page 30: Zone Relay Module Configuration
2. Installation Zone Relay Module Configuration Relay #1, #2, #3 and #4 of the the 4XZM Zone Relay Module have specific functions based on the configuration of DIP Switches #1 and #2 on the control panel. The table below provides a description of these functions. -
Page 31: Power-Up Procedure
Power-Up Procedure Power-Up Procedure WARNING: Prior to energizing this panel, notify all personnel and authorities, including any personnel who may be working on, around, or near this unit. WARNING: Battery contains sulfuric acid which can cause severe burns to the skin and eyes and can destroy fabrics. - Page 32 2. Installation Power-Up Procedure Notes PDRP-1002 Instruction Manual PN 51135:B0 04/06/01...
-
Page 33: System Operation
WARNING: When used for CO NFPA 12. Do not enter the protected space unless physical lockout and other safety procedures are fully completed. Do not use software disable functions in the panel as lockout. System Status LEDs Alarm, Trouble and Supervisory LEDs will flash on and off until the event(s) has been acknowledged (TONE or ALARM SILENCE), at which point the LED will illuminate steadily. -
Page 34: Control Switches
3. System Operation Control Switches Tone Silence - Pressing this switch acknowledges alarms, troubles and supervisories. The panel has alarm and trouble resound with LED flash of new conditions. The flashing trouble LED(s) illuminate steadily and the piezo turns off. A second trouble will resound the piezo. Trouble conditions are self- restoring. -
Page 35: Piezo
Piezo Piezo The piezo (local buzzer) generates different tone patterns for different event conditions: • Alarm - Generates a steady tone, no pulse. • Trouble - Pulses one second on, one second off. Repeats 30 pulses per minute. • Supervisory - Pulses one-half second on, one-half second off. Repeats 60 pulses per minute. Supervisory Service Releasing circuit #2 can be used as an input for monitoring supervisory devices (such as valve tamper switches) by setting SW1 DIP switch 2 to “ON”... -
Page 36: Last Event Recall
3. System Operation Last Event Recall Last Event Recall allows the user to display the previous panel status. The Last Event Recall makes use of the four panel switches as follows: Press and hold in the TONE SILENCE switch. With the TONE SILENCE switch held in, press (in sequence) the SYSTEM RESET switch, the ALARM ACTIVATE switch, and then the ALARM SILENCE switch. -
Page 37: Single Zone In Alarm (Cross Zone) Condition
System Events Single Zone in Alarm (Cross Zone) Condition Upon actuation of a single-zone initiating device, a red alarm LED will illuminate to indicate whether Zone 1 or Zone 2 is in alarm. In addition to the LED, a single-zone alarm will activate the Alarm Relay; the piezo and NAC #1 will start sounding. - Page 38 3. System Operation System Events Notes PDRP-1002 Instruction Manual PN 51135:B0 04/06/01...
-
Page 39: Appendix A: Secondary Power Calculations
Appendix A: Secondary Power Calculations Standby Battery Requirements The Standby Battery Current obtained in the table below represents the amount of current that must be supplied by the secondary power source (batteries) to sustain control panel operation for one hour. Note: The control panel will support the installation of one or two optional modules, including two of the same type of module. -
Page 40: Calculating The Battery Capacity
Appendix A: Secondary Power Calculations Calculating the Battery Capacity Use this table to determine the battery capacity required by the system. Standby Battery Current (from Table 1) ] amps 1. NFPA 72 Central Station and Local and Proprietary Fire Alarm Systems require 24 hours of standby time. 2. -
Page 41: Appendix B: Compatible Devices
Appendix B: Compatible Devices Two-wire Smoke Detectors, UL Listed Use the two-wire detectors listed below. Detector Model System Sensor 1400 System Sensor 1451 System Sensor 1851DH System Sensor 2400 System Sensor 2400AIT System Sensor 2400AT System Sensor 2400TH System Sensor 2451... -
Page 42: Four-Wire Smoke Detectors, Ul Listed
Four-wire Smoke Detectors, UL Listed Use the four-wire detectors listed below. Detector/Base System Sensor 2424 System Sensor 2424TH System Sensor 2451 System Sensor 2451TH w/B402 Base System Sensor 1424 System Sensor 1451 w/B402 Base System Sensor 2412 System Sensor 2412AT System Sensor 2412TH... -
Page 43: Notification Appliances, Ul Listed
Product System Sensor MA-12/24D Electronic Sounder System Sensor SS24 Strobe System Sensor SS24LO Strobe System Sensor SS24LOC Ceiling Strobe (SS24LOBC - beige) System Sensor SS24M Strobe System Sensor SS24MC Ceiling Strobe System Sensor MASS24D Electronic Sounder/Strobe System Sensor MASS24LO Electronic Sounder/Strobe... - Page 44 System Sensor SP101R24M Speaker/Strobe, 5” square grill System Sensor SP100W24MC Ceiling Speaker/Strobe, 8” round grill System Sensor MA12/24EH Multi Alert Horn with Mechanical Tone System Sensor MAEH24LO Multi Alert Horn with Mechanical Tone/Strobe System Sensor MAEH24LOC Multi Alert Horn with Mechanical Tone/Strobe...
-
Page 45: Door Holders, Ul Listed
Floor Mount, Single FM-986-24 Wall Mount, Surface Wiring FM-998-24 Wall Mount, Concealed Wiring Table 7 Door Holders Vendor Model System Sensor A77-716B Air Products & Controls, LTD MR-101/C MR-201/C Table 8 24 VDC Relays Appendix B: Compatible Devices Current (mA) - Page 46 Appendix B: Compatible Devices 24 VDC Relays, UL Listed Notes PDRP-1002 Instruction Manual PN 51135:B0 04/06/01...
-
Page 47: Appendix C: Nfpa Standard-Specific Requirements
Appendix C: NFPA Standard-Specific Requirements Minimum System Requirements The control panel has been designed for use in commercial, industrial, and institutional applications and meets the requirements for service under the National Fire Protection Association (NFPA) Standards outlined in this appendix. The minimum system components required for compliance with the appropriate NFPA standard are listed below. -
Page 48: Digital Alarm Communicator/Transmitter - Noti-Fire 911Ac
Appendix C: NFPA Standard-Specific Requirements Digital Alarm Communicator/Transmitter - Noti-Fire 911AC Note: This application is not FM approved Using the Noti-Fire 911AC DACT for connection to a Central Station Receiver or Protected Premises Receiving Unit. • AC Wiring for DACT/FACP must be connected to the same circuit. •... -
Page 49: Universal Digital Alarm Communicator - 411Udac
Universal Digital Alarm Communicator - 411UDAC Universal Digital Alarm Communicator - 411UDAC The following figure illustrates an example of Central Station/Remote Station Receiver or Protected Premises Receiving Unit reporting using a 411UDAC. The relay contacts of the PDRP-1002 may be used to trip any dialer listed for Central Station/Remote Station services. -
Page 50: Local Energy Municipal Box
Appendix C: NFPA Standard-Specific Requirements Local Energy Municipal Box Using the 4XTM Transmitter Module for connection to a Local Energy Municipal Box. • The Municipal Box circuit supervises for ground faults and opens (i.e. missing wire) but not for direct short between two wires. It is not a power-limited circuit. •... -
Page 51: Remote Station Receiver - Rs82-9
Remote Station Receiver - RS82-9 Remote Station Receiver - RS82-9 Using the 4XTM Transmitter Module for connection to a Fire•Lite RS82-9 Remote Station Receiver. • Intended for connection to a polarity reversal circuit of a remote station receiving unit having compatible ratings. - Page 52 Appendix C: NFPA Standard-Specific Requirements Remote Station Receiver - RS82-9 Notes PDRP-1002 Instruction Manual PN 51135:B0 04/06/01...
-
Page 53: Appendix D: Testing & Maintenance
Appendix D: Testing & Maintenance Testing Inspection Perform the following prior to applying power to the system. • Check the actual wiring hookup with the wiring diagrams. • Insure that no pieces of wire have fallen into the circuitry. • Check for missing or damaged parts. Alarm Test An initial alarm test should be conducted following installation to determine that all parts of the system are functioning properly. - Page 54 Appendix D: Testing & Maintenance Symptom Circuit trouble LED ON Any of the right column yellow LEDs flashing Any of the right column yellow System trouble LEDs steady LED ON Power trouble LED ON Power LED ON Yellow LED on 4XTM ON Any of the right column red LEDs Disconnecting Municipal Box...
- Page 55 Numerics 110/120 VAC 12 220/240 VAC 12 411UDAC 47, 49 4XLM LED Interface Module 11, 23 4XMM Meter Module 11, 15 4XTM Transmitter Module 10, 23, 47 4XTMF Transmitter Module 50, 51 4XZM Zone Relay Module 10, 23 4XZMF Zone Relay Module 30 911AC DACT 47, 48 Abort Function 29 Abort Switch Circuit 18...
- Page 56 Index General Alarm 30 ground fault 33, 50 Indicating Circuit #1 53 initial alarm test 53 initiating circuits 34 initiating device 37, 47 Initiating Device Circuit 36 inspection 53 interconnect wire, battery 31 Interface Module 11 interruption of circuits 36 IRI-type delay timer 29 J1 connector 13, 14 J2 Connector 15...
- Page 57 rail 24 rail, backbox 13, 14 red wire 17 regulated power 22 relay contacts 49 Relay, System Alarm 34 release 33 releasing 21 Releasing Circuit 20, 21 Releasing Circuit #2 29 Releasing Devices 47 Remote Alarm circuit 25 Remote Annunciator 11 Remote Station 47, 49 Remote Station Service 10 Remote Trouble circuit 25...
- Page 58 PDRP-1002 Instruction Manual PN 51135:B0 04/06/01...
- Page 59 PDRP-1002 Instruction Manual PN 51135:B0 04/06/01...
-
