Sloan ESD-200 Installation Instructions Manual

SENSOR ACTIVATED ELECTRONIC SOAP DISPENSER
Model ESD-200
Deck Mounted
Plug-in Adapter Powered
Sensor Activated
Electronic Soap Dispenser
Model ESD-250
Deck Mounted
Battery Powered
Sensor Activated
Electronic Soap Dispenser
Sloan Valve Company warrants its ESD-200, ESD-250, ESD-300 and ESD-350 Electronic Soap Dispensers to be made of first class materials, free from defects of
material or workmanship under normal use and to perform the service for which they are intended in a thoroughly reliable and efficient manner when properly installed
and serviced, for a period of three years (1 year for special finishes) from date of purchase. During this period, Sloan Valve Company will, at its option, repair or replace
any part or parts which prove to be thus defective if returned to Sloan Valve Company, at customer's cost, and this shall be the sole remedy available under this
warranty. No claims will be allowed for labor, transportation or other incidental costs. This warranty extends only to persons or organizations who purchase Sloan Valve
Company's products directly from Sloan Valve Company for purpose of resale. This warranty does not cover the life of the batteries (Models ESD-250 and ESD-350).
THERE ARE NO WARRANTIES WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE HEREOF. IN NO EVENT IS SLOAN VALVE COMPANY RESPONSIBLE FOR ANY
CONSEQUENTIAL DAMAGES OF ANY MEASURE WHATSOEVER.
For Soap Replenishment use:
Sloan Part # Description
• ESD-217 — 800 ml. bottle of Lotion Soap
• ESD-232 — 1600 ml. bottle of Lotion Soap
• ESD-231 — 800 ml. bottle of Anti-bacterial Soap
• ESD-233 — 1600 ml. bottle of Anti-bacterial Soap
Can also be used with TC ® OneShot
for TC Stock Numbers)
To order Replacement Soap Cartridges:
1-866-700-CLEAN (1-866-700-2532)
Or go to our website: www.optimasoap.com
Refills are also available through your local plumbing or janitorial
supply distributor.
Please take the time to read this manual to ensure proper product installation and longevity. Also, please visit our website
If you have questions about how to install your Sloan Flushometer, consult your local Sloan Representative or call
INSTALLATION INSTRUCTIONS FOR
LIMITED WARRANTY
® Soap Cartridges (refer to Page 6
to download our most recent documentation for this product.
Sloan Installation Engineering Department at:
1-888-SLOAN-14 (1-888-756-2614)
Model ESD-300
Deck Mounted
Plug-in Adapter Powered
Sensor Activated
Electronic Soap Dispenser
with Chrome Throat Plate
Model ESD-350
Deck Mounted
Battery Powered
Sensor Activated
Electronic Soap Dispenser
with Chrome Throat Plate
PRIOR TO INSTALLATION
New Soap Dispenser Installation:
• Locate position of soap dispenser using rough-in diagrams and
template on Pages 2 and 3
• Ensure that soap dispenser does not interfere with anything above
or below the lavatory/counter top area (refer to Pages 2 and 3)
• Drill a 1" diameter hole in counter top (use template on Page 3)
• Clean area around hole
Replacing Existing Soap Dispenser:
• Remove old components
• Clean Area around hole
• Ensure that hole is 15/16" to 1-1/4" diameter
Code No. 0816549
Rev. 1 (07/08)
