6CE445XANR
Quick Installation Guide
V1.0.1
Dahua Technology Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6CE445XANR and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Dahua 6CE445XANR

  • Page 1 6CE445XANR Quick Installation Guide V1.0.1 Dahua Technology Co., Ltd...
  • Page 2: Foreword

    General This manual offers reference material and general information about the basic operation, maintenance, and troubleshooting for a Dahua Network Camera. Read, follow, and retain the following safety instructions. Heed all warning on the unit and in the operating instructions before operating the unit.
  • Page 3 Please contact the customer service for the latest program and supplementary documentation. Video loss is inherent to all digital surveillance and recording devices; therefore Dahua  cannot be held liable for any damage that results from missing video information. To minimize the occurrence of lost digital information, Dahua recommends multiple, redundant recording systems, and adoption of backup procedure for all data.
  • Page 4 Legal Notices Copyright This user guide is ©2017, Dahua Technology Company, LTD. This user guide is the intellectual property of Dahua Technology Company, LTD and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered...
  • Page 5: Important Safeguards And Warnings

    Important Safeguards and Warnings This chapter describes the contents covering proper handling of the device, hazard prevention, and prevention of property damage. Read these contents carefully before using the device, comply with them when using, and keep it well for future reference. Installation and Maintenance Professionals Requirements All installation and maintenance professionals must have adequate qualifications or ...
  • Page 6  have the same characteristics as the original parts. Unauthorized parts may cause fire, electrical shock, or other hazards. Dahua is not liable for any damage or harm caused by unauthorized modifications or repairs. Perform safety checks after completion of service or repairs to the unit.
  • Page 7  Use attachments and accessories only specified by the manufacturer. Any change or  modification of the equipment, not expressly approved by Dahua, could void the warranty. Internal and external ground connection should be stable.  Do not supply power via the Ethernet connection (PoE) when power is already supplied ...
  • Page 8: Cybersecurity Recommendations

    Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity Change Passwords and Use Strong Passwords  The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible.
  • Page 9 Change ONVIF Password  Older IP camera firmware does not automatically change the ONVIF password when the system credentials are changed. Update the camera’s firmware to the latest revision or manually change the ONVIF password. Forward Only Ports You Need ...
  • Page 10 Connect IP Cameras to the PoE Ports on the Back of an NVR  Cameras connected to the PoE ports on the back of an NVR are isolated from the outside world and cannot be accessed directly. Isolate NVR and IP Camera Network ...
  • Page 11: Table Of Contents

    Table of Contents Foreword ..............................I Important Safeguards and Warnings ....................IV Cybersecurity Recommendations ......................VII Table of Contents ............................. X 1 Unpacking .............................. 1 Parts List ............................1 2 Installation and Configuration ......................2 Framework and Dimension ......................2 Wiring ............................
  • Page 12: Unpacking

    Unpacking This equipment should be unpacked and handled with care. If an item appears to have sustained damage during shipping, notify the shipper immediately. Verify that all the parts listed below are included. If an item is missing, contact customer support or your local representative.
  • Page 13: Installation And Configuration

    Installation and Configuration Framework and Dimension Use this process to plan, install, and configure the security network and the IP devices. Figure 2-1: 6CE445XANR Dimension Installation and Configuration 2...
  • Page 14 Figure 2-2: PFB305W Dimensions Installation and Configuration 3...
  • Page 15: Wiring

    Wiring Figure 2-3: Cable Detail Label Function Wire Color Connection 24 VAC (positive) Power Input Yellow/Green Earth Ground Black 24 VAC (negative) Yellow RS485 + RS485 Orange RS485 - Analog Video Output — BNC (1.0 Vp-p, 75 Ω) — Network —...
  • Page 16: Alarm Setup

    Alarm Setup Certain devices support alarm inputs and outputs, check your specific device for alarm capability. 2.3.1 Alarm Input Refer to the figure below for alarm input configuration. The device collects that status of the alarm input port when the input signal is idle or grounded. If the input signal is connected to the 3.3 V or it is idle then the device receives the alarm input signal.
  • Page 17: Alarm Output - Switch Application

    Certain cameras include a SDHC card slot for onboard storage that support a 128 GB Micro SD card. Dahua recommends using a SanDisk Extreme Micro SD card (or an equivalent substitute) as these cards have been fully tested without issue and the SanDisk Extreme line is better suited for constant recording.
  • Page 18: Camera Installation

    A readily accessible 2-pole disconnect device with a contact separation of at least 3 mm must be incorporated. Note: Dahua recommends attaching a “drip loop” (flex or hard conduit) during installation to ensure condensation does not form in the mount or the conduit.
  • Page 19: Preparing The Camera

    Preparing the Camera The Network PTZ camera comes with the PFB305W Wall Mount, the installer must supply the following hardware: Four (4) bolts, washers or other fastening hardware to secure the wall mount to the  installation medium. The hardware must be capable of supporting eight (8) times the weight of the camera and mount.
  • Page 20: Mounting The Camera To A Wall

    Mounting the Camera to a Wall Place the Wall Mount against the wall and mark the location of the center hole and mark the four (4) perimeter mounting holes. Pre-drill the four perimeter holes as marked on the wall for the expansion bolts, using a drill bit that is no wider than the expansion bolt.
  • Page 21: Network Configuration

    Network Configuration Dahua IP cameras feature a built-in Web interface to control all aspects of camera operation. This section includes details about the supported network protocols, configuring IP addresses, and configuring alarms and local recording options. Refer to the camera’s Operations Manual for full details.
  • Page 22: Modifying The Ip Address

    Port – A port is an endpoint to a logical connection in an IP network.  Dahua supplies the ConfigTool to access and to modify the network settings of a device. Refer to the Operation Manual, available on the CD included with the camera or on Dahuasecurity.com, for complete information.
  • Page 23: Accessing The Web Interface

    Click the Net icon at the top of the ConfigTool. Modify the IP Address and any other applicable network parameter. Click Save to finish modification and store the modified network parameters. Accessing the Web Interface Each camera can be accessed directly from the Internet Explorer Web browser. The Web Interface allows you to set camera parameter, configure alarm inputs and outputs, view live camera images, and review recorded video.
  • Page 24: Configuring Alarms

    Configuring Alarms The device’s Web Interface offers a Relay Activation page to configure alarms and to set alarm responses. Figure 4-1: Alarm Configuration Access the Web Interface for the device and click the Setup tab. Expand the Event menu, then choose the Alarm page. Set the alarm input and output parameters in the Relay Activation page.
  • Page 25: Configuring Local Sd Card Recording

    Configuring Local SD Card Recording The devices Web interface contains settings to control the recording medium and to configure an alarm that triggers once the Micro SD card passes a pre-determined storage. Access the Web Interface for the device and click the Setup tab. Expand the Storage menu, then choose the Destination page.
  • Page 26 Check the Relay-out box to enable a relay alarm. Then, specify the time in seconds to delay the alarm relay output (10 s to 300 s). Check the Send Email box to send an email to a specified user after the device triggers an alarm.
  • Page 27 Dahua Technology USA 23 Hubble Irvine, CA 92618 Tel: (949) 679-7777 Fax: (949) 679-5760 Support: 877-606-1590 Sales: sales.usa@dahuatech.com Support: support.usa@dahuatech.com © 2019 Dahua Technology USA. All rights reserved. Design and specifications are subject to change without notice.
