- Page 1 N42BJ62 4MP Fixed Network Eyeball Camera Quick Installation Guide V1.0.1 Dahua Technology USA Inc.
-
Page 2: Foreword
General This manual offers reference material and general information about the basic operation, maintenance, and troubleshooting for a Dahua Camera. Read, follow, and retain the following safety instructions. Heed all warning on the unit and in the operating instructions before operating the unit. - Page 3 Please contact the customer service for the latest program and supplementary documentation. Video loss is inherent to all digital surveillance and recording devices; therefore Dahua cannot be held liable for any damage that results from missing video information. To minimize the occurrence of lost digital information, Dahua recommends multiple, redundant recording systems, and adoption of backup procedure for all data.
- Page 4 Legal Notices Copyright This user guide is ©2020, Dahua Technology USA Inc. This user guide is the intellectual property of Dahua Technology USA Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered...
-
Page 5: Important Safeguards And Warnings
Important Safeguards and Warnings This chapter describes the contents covering proper handling of the device, hazard prevention, and prevention of property damage. Read these contents carefully before using the device, comply with them when using, and keep it well for future reference. Installation and Maintenance Professionals Requirements All installation and maintenance professionals must have adequate qualifications or ... - Page 6 have the same characteristics as the original parts. Unauthorized parts may cause fire, electrical shock, or other hazards. Dahua is not liable for any damage or harm caused by unauthorized modifications or repairs. Perform safety checks after completion of service or repairs to the unit.
- Page 7 Contact the manufacturer or a qualified service representative to service the camera or to replace a component, including the desiccant. Dahua recommends the use of a thunder-proof device in concert with the unit. Do not touch the CCD or the CMOS optic sensor. Use a blower to clean dust or dirt on the ...
-
Page 8: Cybersecurity Recommendations
Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity Change Passwords and Use Strong Passwords The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible. - Page 9 Change ONVIF Password Older IP camera firmware does not automatically change the ONVIF password when the system credentials are changed. Update the camera’s firmware to the latest revision or manually change the ONVIF password. Forward Only Ports You Need ...
- Page 10 Connect IP Cameras to the PoE Ports on the Back of an NVR Cameras connected to the PoE ports on the back of an NVR are isolated from the outside world and cannot be accessed directly. Isolate NVR and IP Camera Network ...
-
Page 11: Table Of Contents
Table of Contents Foreword ............................... I Important Safeguards and Warnings....................IV Cybersecurity Recommendations ....................VII Table of Contents ..........................X 1 Overview ............................1 Parts List ..........................1 Dimensions..........................1 Cables and Connectors ......................2 2 Installing the Camera ........................3 Preparing for Installation ......................3 Unpacking .......................... -
Page 12: Overview
Overview The Dahua 4 MP Lite Series cameras offer high-resolution video and cutting-edge technology in a compact and accessible package. The cameras feature Smart H.265+ video compression, reducing bandwidth and storage requirements without sacrificing video quality. The camera's elegant blend of aesthetics combined with a range of easy mounting solutions provides an excellent choice for a variety of small to mid-size applications at an affordable price. -
Page 13: Cables And Connectors
Cables and Connectors Cable type might vary with device. Waterproof all cable joints with insulating and waterproof tape to avoid short circuit and water damage. Ref. Port Name Connector Description Connect to standard Ethernet cable. Note: Certain devices support Power over Ethernet. Network Port RJ-45 Check the specific device to determine if the device... -
Page 14: Installing The Camera
Note: Dahua recommends attaching a “drip loop” (flex or hard conduit) during installation to ensure condensation does not form in the mount or the conduit. -
Page 15: Installing An Sd Card
Installing an SD Card Disconnect power to the camera. Remove the panel at the rear of the camera. Gently insert the SD card into the slot until it clicks in place. Replace the panel. Press the Reset button for 10 seconds to reset the device. Using the Waterproof Ethernet Connector Attach the waterproof network connector if the camera is used outdoors. -
Page 16: Mounting The Camera
Pull the waterproof cable end without the Ethernet connector through the body of the Waterproof Connector. Thread the cable through the Fixing Rubber Ring and the Waterproof Locking Cover. Attach the male Ethernet connector to the network cable coming from the camera. Ensure the Waterproof Connector shroud covers the Ethernet connection. -
Page 17: Mounting To A Wall: Cables Through Surface
2.5.1 Mounting to a Wall: Cables through Surface... -
Page 18: Mounting To A Wall: Cables Through Camera Base Conduit
2.5.2 Mounting to a Wall: Cables through Camera Base Conduit 2.5.3 Adjusting the Lens Angle... -
Page 19: Network Configuration
Network Configuration Initialize the device configure the IP setting with the Dahua ConfigTool or via the device’s web interface. Device initialization is available on select models, and it is required at first use and after device is being reset. -
Page 20: Modifying The Ip Address
Select the options according to your needs and then click OK. Click Finish. Modifying the IP Address Modify the IP address of one or multiple devices at one time. This section provides instructions for modifying IP addresses in batch. Modifying IP addresses in batch is available only when the corresponding devices have ... - Page 21 Tap the “+” icon at the upper-left corner of the screen and then tap SN/Scan to add the device. Select Wired Camera. Scan the QR code on the the back or bottom of the device. If the QR code does not work, tap Manually enter SN.
- Page 22 Input the device for easy identification. It's required to input the password for the added device then select the save icon located on the top right corner.
- Page 23 Dahua Technology USA 23 Hubble Irvine, CA 92618 Tel: (949) 679-7777 Fax: (949) 679-5760 Support: 877-606-1590 Sales: sales.usa@dahuatech.com Support: support.usa@dahuatech.com © 2020 Dahua Technology USA. All rights reserved. Design and specifications are subject to change without notice.
