- Page 1 6AL445XANR 4MP Starlight Network PTZ 45x PTZ Laser Network Camera with Analytics+ Installation Manual V1.0.1...
-
Page 2: Cybersecurity Recommendations
Cybersecurity Recommendations Mandatory actions to be taken towards cybersecurity Change Passwords and Use Strong Passwords The number one reason systems get “hacked” is due to having weak or default passwords. It is recommended to change default passwords immediately and choose a strong password whenever possible. - Page 3 different username and password for your security system will make it more difficult for someone to guess their way into your system. Limit Features of Guest Accounts: If your system is set up for multiple users, ensure that each user only has rights to features and functions they need to use to perform their job.
-
Page 4: Foreword
Foreword General This Installation Manual (hereinafter referred to be "the Manual") introduces installation preparation, speed dome installation, bracket dimension, and bracket installation including wall-mounted bracket installation, hang-mounted bracket installation, corner-mounted bracket installation, and pole-mounted bracket installation. Safety Instructions The following categorized signal words with defined meaning might appear in the Manual. Signal Words Meaning Indicates a high potential hazard which, if not avoided, will... - Page 5 About this Manual The Manual is for reference only. If there is inconsistency between the Manual and the actual product, the actual product shall prevail. We are not liable for any loss caused by the operations that do not comply with the Manual. ...
-
Page 6: Important Safeguards And Warnings
Important Safeguards and Warnings The Manual helps you to use our product properly. Read the Manual carefully before installing and using the product, and we highly recommend you to keep it well for future reference. CAUTION Avoid heavy stress, violent vibration, and water splash during transportation, storage, and ... - Page 7 Qualified Engineer Needed The installation engineer or maintenance engineer shall have corresponding CCTV system installation certificate or maintenance qualification certificate, including qualification certificate for work at height. The installation engineer or maintenance engineer shall have the basic knowledge and installation technique for CCTV system.
-
Page 8: Table Of Contents
Table of Contents Cybersecurity Recommendations ....................... I Foreword ............................. III Important Safeguards and Warnings....................V Table of Contents ..........................VII 1 Installation Preparation ........................1 Basic Requirements........................1 Installation Check ........................1 Cable Preparation ........................1 2 IR Speed Dome Installation ......................2 Checking Accessories ....................... -
Page 9: Installation Preparation
Installation Preparation Basic Requirements All installation and operation here should conform to your local electrical safety regulations, fire protection regulations, and relevant regulations. Make sure the application scenarios conform to the installation requirements. Contact your local retailer or customer service center if there is any problem. Use the product according to the operating environment. -
Page 10: Ir Speed Dome Installation
IR Speed Dome Installation Checking Accessories Before installation, check the accessories according to the packing list, and make sure all the components listed are included. Opening the Package Open the package, and take out the speed dome. See Figure 2-1. IR Speed Dome The speed dome appearances might be different depending on the model you purchased, ... -
Page 11: Reset Button And Micro Sd Card
Reset Button and Micro SD Card Open the cover on the speed dome and you can see the Reset button on the PTZ mainboard. See Figure 2-10. Open the front dome component and you can see the Micro SD card slot on the ISP board of speed dome module. -
Page 12: Speed Dome Installation
Speed Dome Installation The installation steps are applicable for both analog speed domes and network speed domes. Various types of brackets are supported for the speed domes in different installation conditions. For details about speed dome installation, see "3 Wall-mounted Bracket Installation"... - Page 13 Cables Speed dome cables might vary depending on the model you purchased, and the actual product shall prevail. The Manual introduces the complete cables for you. Do not drag or pull the cables to lift the speed dome when moving it. See Figure 2-14 for wrong way.
- Page 14 2.4.2.2 Cable Connection Buckle the safety hook of the speed dome on the quick mounting connector, and connect the cables reserved on the wall-mounted bracket with the corresponding cables of the speed dome as you need. Then twine the cable connection with insulated rubber tape to ensure waterproof.
-
Page 15: Installing The Speed Dome
2.4.2.4 Speed Dome GND Cable Connection Connect the YELLOW/GREEN power cable to the lightning protection device, and make sure the lightning protection device is well grounded. 2.4.3 Installing the Speed Dome To install the speed dome, do the following: Buckle the safety hook, and route the cables into the wall-mounted bracket. Align the speed dome flange with that on the quick mounting connector, and push the speed dome to the quick mounting connector. - Page 16 Installation finished...
-
Page 17: Wall-Mounted Bracket Installation
Wall-mounted Bracket Installation Dimension See Figure 3-1 for wall -mounted bracket, and see Figure 3-2 and Figure 3-3 for dimension of the bracket and the quick mounting connector. Wall-mounted bracket Dimension of wall-mounted bracket (mm) -
Page 18: Installing Wall-Mounted Bracket
Dimension of quick mounting connector (mm) Installing Wall-mounted Bracket 3.2.1 Installation Conditions The wall-mounted bracket is applicable to hard wall in both indoor and outdoor environments. Make sure: The wall shall be thick enough to install expansion bolts. The wall shall sustain at least eight times the weight of the speed dome and its mounting ... - Page 19 Installing the speed dome with wall-mounted bracket...
-
Page 20: Hang-Mounted Bracket Installation
Hang-mounted Bracket Installation Dimension See Figure 4-1 for hang-mounted bracket, and see Figure 4-2 for dimension of the bracket. Hang-mounted bracket Dimension of hang-mounted bracket (mm) The length of the hang-mounted bracket is 200 mm by default, and 400 mm optional. Select different sizes of the connection poles as you need. -
Page 21: Installing Hang-Mounted Bracket
Installing Hang-mounted Bracket 4.2.1 Installation Conditions The hang-mounted bracket is applicable to hard wall in both indoor and outdoor environments. Make sure: The wall shall be thick enough to install expansion bolts. The wall shall sustain at least eight times the weight of the speed dome and its mounting ... - Page 22 Installing hang-mounted bracket (2) For outdoor environment, twine Teflon tape on the thread of the connection pole first, and then fix the connection pole on the connection plate. Install the speed dome on the hang-mounted bracket, see Figure 4-5. For details about speed dome installation, see "2.6 Speed Dome Installation".
-
Page 23: Corner-Mounted Bracket Installation
Corner-mounted Bracket Installation Dimension See Figure 5-1 for corner-mounted bracket, and see Figure 5-2 for dimension of the bracket. Corner-mounted bracket Dimension of corner-mounted bracket (mm) -
Page 24: Installing Corner-Mounted Bracket
Installing Corner-mounted Bracket 5.2.1 Installation Conditions The corner-mounted bracket is applicable to hard wall which forms an included angle of 90° in both indoor and outdoor environments. Make sure: The wall shall be thick enough to install expansion bolts. The wall shall sustain at least eight times the weight of the speed dome and its mounting ... - Page 25 Installing the speed dome with corner-mounted bracket...
-
Page 26: Pole-Mounted Bracket Installation
Pole-Mounted Bracket Installation Dimension See Figure 6-1 for pole-mounted bracket, and see Figure 6-2 for dimension of the bracket. Pole-mounted bracket... -
Page 27: Installing Pole-Mounted Bracket
Dimension of pole-mounted bracket (mm) Installing Pole-mounted Bracket 6.2.1 Installation Conditions The pole-mounted bracket is applicable to hard wall in both indoor and outdoor environments. Make sure: The diameter of the pole where you want to install the speed dome shall match with the ... -
Page 28: Installation Procedure
6.2.2 Installation Procedure Route the cables through the pole-mounted bracket pedestal. Install the clamp on the pole where you want to install the speed dome, and adjust the diameter of the clamp to fix it on the pole. See Figure 6-3. Pole-mounted bracket CAUTION Make sure the clamp is firmly fixed on the pole. - Page 29 Installing the speed dome with pole-mounted bracket...
