6.2 Description of Status Monitor Display

This section shows how to interpret the System Status Monitor.
File Edit Transmit
Date
Time
Position
Waypoint
Course
Speed
Current NCS
Current Channel
Current TDM
MES Status
GPS Status
DCE Memory
Current State : TESTING
TESTING -- RECEVING MESSAGE
DCE Ver 0x Oct - 199x
Interpreting the Status Monitor Display
Date:
Time:
Position:
Waypoint:
Course:
Speed:
Current NCS:
Current Channel:
Current TDM:
MES Status:
EGC Reports Logs
97-12-24
06:12 (UTC)
LAT 35:00.00N
LON 135:00.00E
LAT
LON
DEG
KTS
344 (IOR) LOGIN
LES TDM
LES TDM
Busy
3D
32818 Bytes free
SYNC (LES)
NCS : IOR LOGIN
Current date
Current time
Vessel's position (either manual entry or automatic input by
navigation aid)
Position of waypoint selected on navigation aid
Heading
Ship's speed
NCS which your vessel is logged in with
Channel in use, such as NCS common channel, MES message
channel etc.
Current TDM (NCS Commom TDM or CES TDM)
Operational status of MES
6-3
Options Setup Position
BBER 000
C/N OK (38dB)
Send Level OK ( 0)
RxIF AGC Level OK (133)
REF Offset Freq OK ( 0Hz)
Synthe 1st-1 Local OK
1st-2 Local OK
RX2nd Local OK
Antenna Power Supply OK
Water Temperature
Water Current DEG
Direction DEG
Speed KTS
Depth
97-12-24 06:12 (UTC)
LAT : 35:00.00N
StopAlarm
LON : 135:00.00
