How to display the results of the PV test
1. At the default display, press [F7] to display the Disp menu.
2. Press [6].
3. Press [2] key. The results of the PV test appear on the display.
4. To escape, press any key. The default display appears.
The test result can be printed out by pressing [P] while pressing and holding down
[Ctrl].
Interpreting the PV Test Results Display
Test Date & Time:
Attempts:
BBER:
Shore-to-Ship Attempts:Number of tests initiated by LES.
Ship-to-Shore Attempts:Number of tests initiated by MES.
Distress Alert:
Signal Strength:
Overall Result:
Options
1. PV Test
2. PV Test Result
3. Self Test
4. Distress Alarm Button Test
Options
Test
PV Test Result
Test Date & Time
Attempts
BBER
Shore - to - Ship Attempts First attempt
Ship - to - Shore Attempts First attempt
Distress Alert
Signal strength
Overall Result Pass (Applicable tests pass)
Date and time of test
Number of times the PV test was conducted.
Bulletin Board Error Rate (%). "Pass" appears for no error.
"Pass (Test OK)" appears for successful testing.
"Pass" appears if Tx signal strength is greater than +6dB
(standard).
"Pass" appears for satisfactory completion of test.
Test
Ctrl + P : print ESC : quit
97-12-12 01 : 58 (UTC)
First attempt
Pass
Pass (Test OK)
Pass (Greater than Std level + 6dB)
5-3
