IMET Perfect 250 User Instructions

Manual metal cutting circular saw
Hide thumbs

Advertisement

Table of Contents

Manual Metal Cutting Circular Saws ,
Perfect 250 - Perfect 275 – Perfect 300
USER'S INSTRUCTION
PERFECT 250-275-300eng ED.2010 rev.00
TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS
IMET Spa
Loc. Tre Fontane - Cisano Bergamasco
Tel. 035/4387911 - Fax. 035/787066
Web site: www.imetsaws.com
E-mail: imet@imetsaws.com
1/40

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Perfect 250 and is the answer not in the manual?

Questions and answers

Related Manuals for IMET Perfect 250

Summary of Contents for IMET Perfect 250

  • Page 1 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS IMET Spa Loc. Tre Fontane - Cisano Bergamasco Tel. 035/4387911 - Fax. 035/787066 Web site: www.imetsaws.com E-mail: imet@imetsaws.com Manual Metal Cutting Circular Saws , Perfect 250 - Perfect 275 – Perfect 300 USER’S INSTRUCTION PERFECT 250-275-300eng ED.2010 rev.00 1/40...
  • Page 2 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 2/40...
  • Page 3 The covers, the door and the frame must be suitably closed when the plant is operating. Under no circumstances the plant must be modified except for adjusting and changing established by the manifacturer. Follow the maintenance schedule PERFECT 250-275-300eng ED.2010 rev.00 8/40...
  • Page 4 =========================================================================== CE DECLARATION OF CONFORMITY (encl. II A DIR 2006/42/CE) / 02 =========================================================================== THE MANUFACTURER : IMET S.p.A Località Tre Fontane 24034 - CISANO BERGAMASCO –BG- ITALIA HEREBY DECLARES THAT in designing and manufacturing the machine described here below , we have considered the most important requirements of safety and health dictated by the European Directives of the Machine Security.
  • Page 5 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 10/40...
  • Page 6 Vibrations emitted during cutting may be amplified by the material, by its dimensions and its positioning/clamping in the vice. PERFECT 250-275-300eng ED.2010 rev.00 11/40...

  • Page 7: Guarantee Norms

    4.3 - The components replaced during the assistance operated by the manufacturer have a warranty of 6 months from the installation date indicated on the Technical Service paper, one copy of which is given to the owner. PERFECT 250-275-300eng ED.2010 rev.00 12/40...

  • Page 8: Table Of Contents

    19 – Machine running-in 20 – Draining of used/produced substances 21 – Trouble-shooting 22 – Machine demolition 23 – Spare parts 24 – Maintenance – for qualified technicians Electrical drawings Hydraulic diagram Spare Parts drawings PERFECT 250-275-300eng ED.2010 rev.00 13/40...

  • Page 9: Technical Characteristics

    400 V / 50 Hz THREEPHASE or 230 V / 50 Hz in case of SINGLEPHASE version. PERFECT 250 = Manual circular saw, mitre cutting from 0° to 45° left, max. blade dimension 250 mm dia - Suited to cut metal profiles (steel with cutting resistance up to 42 kg/mm²)

  • Page 10: Installation - Minimum Requirements

    The included electrical schemes reproduces the necessary details to arrange the connections, to be predisposed for 2 Kw power request, (Perfect 300 and 275) or 1,5 Kw for Perfect 250.. At the top of the supplying cables it is necessary to set up a sectionalizing device provided with a protection .
  • Page 11 . Pedestal - type PA for PERFECT 250 - it is a simple and economic support that allows to have the machine at the right height . It is supplied in a assembling box.

  • Page 12: Blade Choice

    The blade you have to use must have the following dimensions (in mm.): overall diameter = 300 max./250 min. ( for PERFECT 300 ) overall diameter = 275 max./225 min. ( for PERFECT 275 ) overall diameter = 250 max./200 min. ( for PERFECT 250 ) hole diameter = 32...
  • Page 13 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 18/40...
  • Page 14 20. never change the working conditions when cutting, use a controlled downfeed force 21. do not move the saw while cutting and avoid its instability. 22. wear personal safety equipment, if required for a safe operation. ALWAYS OPERATE THE MACHINE SAFELY, USING COMMON SENSE AND ALERTNESS PERFECT 250-275-300eng ED.2010 rev.00 19/40...
  • Page 15 On some parts of the machine there are some stickers which warn about the safety measures that have to be taken by the operator who runs it. Their meaning (easy to understand) is indicated in the following chart PERFECT 250-275-300eng ED.2010 rev.00 20/40...
  • Page 16 An inadequate lighting can cause accidents to the operator, who consequently needs a suited lighting in the working area. In case of a lack of precise indications (for example, norm ISO 8995) for special areas, we advise to supply a lighting equal to 750 LUX. PERFECT 250-275-300eng ED.2010 rev.00 21/40...

  • Page 17: Machine Description

    Remove the lock flask between saw frame and base, and insert in the hole of the head, the rod with the starting device. Lock it with the upper grub screw ( in the model PERFECT 250 also unscrew the threaded bar , in its place screw the control rod, guide it and lock it with the nut ).

  • Page 18: Moving And Transit

    Be sure that coolant is sucked in by the tank and it arrives in the cutting area, if not please control the cock position. f) stop the working by releasing the button placed inside the handle. PERFECT 250-275-300eng ED.2010 rev.00 23/40...
  • Page 19 Unscrew of 2 turns ab. The front screw -pos. 6- that fix the complete blade guard. To reach the spindle it is necessary rotate to the back this cover blade, around the pivot pin -pos.5-. Now it is possible unscrew the screw of the spindle. PERFECT 250-275-300eng ED.2010 rev.00 24/40...
  • Page 20 Reset the initial position of the protection guard and lock it. 14.3 - MODEL PERFECT 250 , see dr. RI0155 Unscrew of 1 turn ab. the screw -pos1- and turn completely the movable part -pos.2- into the fixed blade guard -pos.3.
  • Page 21 This norm of September 2003, concerning bandsaws and circular saws, confirms what specified previously in the norms EN 418, EN 60204, prEN13898. IMET has always respected these regulations, to be able to apply the CE mark, Declaration of Conformity, on its own products At any time it is possible to stop the cycle: - by releasing the pushbutton inside the handle-pos.4/dr.RI0128- the control circuit of the machine stops;...
  • Page 22 Only for PERFECT 300 : there is the possibility to adjust the locking force of the anti-burr arm-pos.10/dr.RI0128 - ( by the screw-pos.12/dr.RI0128- that has to be unscrewed or screwed after loosening the screw-pos.2/dr.RI0130 ), in the case that the cutpiece is not rightly teightened. PERFECT 250-275-300eng ED.2010 rev.00 27/40...

  • Page 23: Maintenance - For The User

    Lock again the jam nut -pos.2- and control the efficacy of the adjustment, then repeat if necessary. - 17 - MAINTENANCE - for the user - Follow regularly the above mentioned operations to keep at best the technical features, the productive features and the security one, anticipated by the manufacturer. PERFECT 250-275-300eng ED.2010 rev.00 28/40...

  • Page 24: Machine Running-In

    We recommend to replace the both oil seal rings ( marked with P ) after each dismantling of the reducer head. The steel endless screw ( mounted in the motor shaft ) suffers not so much the wear and tear so it is not compulsory to replace it with the wheel. PERFECT 250-275-300eng ED.2010 rev.00 29/40...
  • Page 25 Idle the motor some seconds, discharge the cleaning liquid and put in new oil- 0.5 litres about- until restoring its level ( with the head down the oil must reach the half of the pilot light-pos.13/dr.RI0128- ). The PERFECT 250 model not have the inlet/outlet oli plugs: it is necessary keep out the side pilot light to drain the exhaust oil.

  • Page 26: Draining Of Used/Produced Substances

    6 =Ccoolant filters too full 7 = Pump of the coolant 8 = The tank is empty or dirty 9 = Excessive heating that determins the interventation of the thermoprotectors 10 = Excessive gap of the head guides PERFECT 250-275-300eng ED.2010 rev.00 31/40...

  • Page 27: Machine Demolition

    This paragraph may give some informations about the macrooperations of machine disassembly for its scrapping. Special procedures are not required but it is necessary to take only some cares to avoid damages in the last phase of the machine life. PERFECT 250-275-300eng ED.2010 rev.00 32/40...

  • Page 28: Spare Parts

    - the serial number indicated on the identification plate - model, version, type - voltage and power frequency - code number of the spare-parts - requested quality - eventually the fittings settled later too. 17.2 OILS AND LUBRICANTS (Comparation table marked RI0108): PERFECT 250-275-300eng ED.2010 rev.00 33/40...

  • Page 29: Maintenance - For Qualified Technicians

    If the user wants to know his machine in details, he can study this manual and use it carefully, but he has not to make direct interventations for modifying or elaborating the machine, because in this way he would make the DECLARATION OF CONFORMIITY invalid. PERFECT 250-275-300eng ED.2010 rev.00 34/40...
  • Page 30 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 35/40...
  • Page 31 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS xxxxxxxxxxxxxxxxxxxxxx PERFECT 250-275-300eng ED.2010 rev.00 36/40...
  • Page 32 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS xxxxxxxxxxxx PERFECT 250-275-300eng ED.2010 rev.00 37/40...
  • Page 33 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS XXXXX PERFECT 250-275-300eng ED.2010 rev.00 38/40...
  • Page 34 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 8/40...
  • Page 35 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 8/40...
  • Page 36 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 8/40...
  • Page 37 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 8/40...
  • Page 38 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 8/40...
  • Page 39 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 8/40...
  • Page 40 TRADUCTION OF THE ORIGINAL USER INSTRUCTIONS PERFECT 250-275-300eng ED.2010 rev.00 9/40...
