9. Perform a Test

9.1 Entering Test Mode

9.2 Insert a Test Strip

If the input of patient ID is set to ON, go to Section 9.3 for entering the
patient ID; otherwise, jump directly to Section 9.5 for entering the Strip
Code.
qLabs.ElectroMeter.manual.Q-2 Plus.indd 15
When the qLabs ElectroMeter Plus is
®
turned on by pressing the "OK" button, the
display screen will prompt the user to insert
a test strip. Go to Section 9.2 for test strip
insertion.
When the qLabs ElectroMeter Plus is
®
turned on by inserting a new test strip, the
display screen will prompt the user to enter
patient ID or enter the Strip Code if patient ID
function is turned off.
Remove a fresh test strip from its foil pouch.
Insert the strip into the test strip guide.
The following two observations indicate that
you inserted the strip correctly:
1) The electrode leads go in first.
2) You can read test strip name clearly on
the end of strip, left to right.
15
