Replacement Parts - Swisher WB80042F Owner's Manual

When ordering painted parts, please indicate with corresponding letters: C = Red Parts;
TK = Textured Black Parts (ex. 4207TK, 4237C)
Item #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45

REPLACEMENT PARTS

Description
Motor Base
Wire Link
Link Spring
5/16-18 Serrated Flange Nut
5/16-18 x 21/2 Grade 5 Bolt
Shift Linkage
Blade Driver Housing
Brake Spring
Brake Pad
Blad Engage Idler
1/2 -13 Nut
Brake Pad Clip
5/16 Flat Washer
3/8 -16 2-way Locknut
5" Chain Links
3/8-16 x 2 Grade 2 bolt
1/2-13 x 5 Grade 5 bolt
Blade Engage Idler Kit
1/8 x 1 Cotter Pin
Center & Left Blade Driver Kit
Blade Bearing
Center & Left Blade Shaft
Washer
1/4-20 x 1 Grade 5 Bolt
1/4-20 Nylock Nut
15" Blade
Serrated Belleville Washer
3/8 - 24 x 1 1/4 Grade 5 Bolt
Blade Mounting Plate
3/8-24 2 Way Lock Nut
3/8-24 x 1 Grade 5 Bolt
Lower Blade Pulley
Pulley Spacer
Upper Blade Pulley (Center & Left Only)
3/4-16 2 Way Lock Nut
Right Blade Shaft
Right Blade Driver Kit
Transmission Idler Pulley
Transmission Idler
3/8-16 x 1 1/2 Grade 5 Bolt
1/2-13 x 2 1/2 Grade 5 Bolt
3/8 SAE Washer
Transmission Idler Kit
Tension Idler Pulley
Tension Idler
Part #
4270
BRS6H
T2SM
NB170
NB138
4282
B99
BT297
BP370
4262
NB213Z
BP370S
NB556
NB280
AS080
NB231
NB155
4280
NB126
9080
B98
9075
B98W
NB102
NB180
4221
NB607
NB166
9008
NB216
NB238N
B4104
6104RS
B104
NB629
9077
9079
B27
4276
NB107
NB588
NB272
4281
B527
6681
