Operation - AL-KO Snow Line 620E III Manual

Snow Line 620E III

Operation

Danger - risk of injury!
Wear work clothing and protective gear.
▪ Winter clothing
▪ Non-slip winter shoes
▪ Eye protection (safety glasses or visor)
▪ Hearing protection
Starting operation
1. Prepare the snow blower for operation.
2. Check the position of the snow discharge
chute and adjust the snow discharge direc-
tion using the hand crank (
3. Adjust the snow discharge height (
4. Start the engine.
5. Set the wheel drive speed (
6. The forward speeds range from 1 to 6, 1
being the slowest speed and 6 the fastest
speed.
7. The reverse speeds are R1 and R2, R1 being
the slower speed and R2 the faster speed.
8. Press the auger drive clutch lever (
Danger – risk of severe injury!
Keep away from the augers while they are
in motion. Keep other persons or animals
away.
9. Press the wheel drive clutch lever (
x The snow blower starts moving.
Stopping operation
1. Release (disengage) the auger and wheel
drive clutch levers in (
„ In order to prevent freezing, continue running
the auger and impeller until they are largely free
of snow.
x The snow blower stops moving and the auger
and impeller stop running.
469370_a
24 -1).
24 -2).
25 -3):
25-4).
26-5).
27).
Changing the wheel drive speed
1. Release (disengage) the auger and wheel
drive clutch levers in (
Change the drive speed only when disengaged
„
in order to avoid damaging the machine.
2. Change the drive speed using the speed se-
lector
( 28 -1).
Unclogging the snow discharge chute
If snow does not discharge properly, the augers
or the discharge chute may be clogged with snow
or ice.
1. Release (disengage) the auger and wheel
drive clutch levers in (
2. Switch off the engine.
3. Disconnect the spark plug connector.
4. Carefully remove the snow from the snow
discharge chute and auger using the snow
cleaning tool ( 29-1).
If snow still does not discharge properly, contact
a qualified workshop.
GB
27).
27).
29
