IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed
including the following:
READ AND FOLLOW ALL
SAFETY INSTRUCTIONS
1.
DANGER- Risk of shock- Disconnect power before installation.
DANGER – Risque de choc – Couper l'alimentation avant l'installation.
2.
This luminaire must be installed in accordance with the NEC or your local
electrical code. If you are not familiar with these codes and requirements,
consult a qualified electrician.
Ce produit doit être installé conformément à NEC ou votre code électrique
local. Si vous n'êtes pas familier avec ces codes et ces exigences, veuillez
contacter un électricien qualifié.
3.
SUITABLE FOR CONTINUOUS ROW MOUNTING.
PEUT ÊTRE MONTÉ EN RANGÉE CONTINUE.
4.
Make sure the equipment is properly grounded.
5.
Always de-energize the circuit and/or equipment before connecting to,
disconnecting from or servicing the equipment
SAVE THESE INSTRUCTIONS
FOR FUTURE REFERENCE
NOTES:
• CAUTION - It is the installers responsibility to ensure that ceiling is structurally capable of supporting the weight of luminaire/luminaire row.
• Endcap kits and joining hardware are packaged separately for continuous rows.
• To Prevent Luminaire Row From Over-Current: By adding the input current of each luminaire section marked on the luminaire, the total current per
power feed must not exceed the maximum line wire amperage rating in the luminaire and the power feed cord/wire amperage rating whichever is
least.
1 of 6
INSTALLATION INSTRUCTIONS
INSTRUCTIONS D'INSTALLATION
Installation Instructions are divided into
3 sections:
1. Surface Mounting - Individual Luminaire
2. Surface Mounting - Continuous Row
3. Electrical Connections
ST3-SF
Stylus Series
LED Ambient Luminaire
Ceiling/Surface Mount
LPN00644X0007A0_A
Advertisement
Related Manuals for CREE LIGHTING Stylus Series
Summary of Contents for CREE LIGHTING Stylus Series
- Page 1 Stylus Series LED Ambient Luminaire Ceiling/Surface Mount IMPORTANT SAFEGUARDS INSTALLATION INSTRUCTIONS INSTRUCTIONS D’INSTALLATION When using electrical equipment, basic safety precautions should always be followed including the following: READ AND FOLLOW ALL SAFETY INSTRUCTIONS DANGER- Risk of shock- Disconnect power before installation.
- Page 2 TO INSTALL: Chalk Line LED Reflector Tray Fasteners (Supplied By Others) Lens Fasteners Extrusion Lens Slide Plastic Card or Putty Knife Here SECTION 1: SURFACE MOUNTING-INDIVIDUAL LUMINAIRE CAUTION: Luminaires should be secured harness. Set lens and LED Reflector tray STEP 4: aside.
- Page 3 LUMINAIRE ROW LAYOUT: SINGLE UNIT 2' - 12' 2’ FIXTURE 24.25" 0.13" Endcap 0.13" Thickness 4’ FIXTURE 48.25" 0.13" Endcap 0.13" Endcap Thickness Thickness 6’ FIXTURE 72.25" 0.13" Endcap 0.13" Endcap Thickness Thickness 8’ FIXTURE 96.25" 0.13" Endcap 0.13" Endcap Thickness Thickness 10’...
- Page 4 5/8" Mounting Hole Male End End Plate Cap (With Female Joiner Bracket Alignment Pins) Female End Slide Screw w/ Lock Nuts End-Plate Lock Nuts Alignment Pins Chalk Line Female End Male End Second Luminaire First Luminaire SECTION 2: SURFACE MOUNTING - CONTINUOUS ROW MOUNTING CAUTION: Ceiling contractor must provide lens inward until the lens come free.
- Page 5 LUMINAIRE ROW LAYOUT: EXAMPLE OF A TWO AND THREE UNIT 16', 20' - 24' (CAN BE MOUNTED IN OTHER CONFIGURATIONS) 16’ FIXTURE 192-1/4" End Cap to End Cap 96 -1/8" 96 -1/8” 8’ UNIT 8’ UNIT 92” Mounting Center 92” Mounting Center 20’...
-
Page 6: Fcc Notice
© 2019 Cree Lighting, A company of IDEAL INDUSTRIES. All rights reserved. For informational purposes only. Content is subject to change. See www.creelighting.com/warranty for warranty and specifications. Cree ®...
