UNPACKING BOX CONTENTS
Important: For warranty verification, please do not remove line cord
sticker.
After you unpack your unit, verify that you received the following
parts (A):
A
1. Telescopic pole
2. Lint brush attachment
3. Flexible hose
4. Unit with water tank
5. Trouser clamps holder assembly
6. Trouser clamps
7. Steam nozzle/hanger holder and cord wrap assembly
Page 4
3

GETTING FAMILIAR WITH YOUR UNIT

B
† 1. Steam nozzle holder
(Part # GSR10-03)
2. Steam nozzle
3. Steam nozzle button
† 4. Lint brush attachment
(Part # GSR10-01)
5. Hanger holder
6. Clip for keeping hanger in place
7. Cord wrap
8. Telescopic pole
† 9. Flexible hose
(Part # GSR10-08)
† 10. Trouser clamps (Part # GSR10-02)
† 11. Trouser clamps holder
(Part # GSR10-05)
† 12. Lock nut for telescopic pole
(Part # GSR10-04)
† 13. Removable water tank
(Part # GSR10-06)
† 14. Water tank cap (not shown)
(Part # GSR10-07)
† 15. Wheel casters
(Part # GSR10-09)
16. Steam On/Off switch with
indicator lights
†Consumer replaceable
