Page 1 Customer-Installable Features for PL1660R REFERENCE 86 A1 36EV 01...
Page 2 BLANK...
Page 3 ESCALA POWER6 Customer-Installable Features for PL1660R Hardware November 2007 BULL CEDOC 357 AVENUE PATTON B.P.20845 49008 ANGERS CEDEX 01 FRANCE REFERENCE 86 A1 36EV 01...
Page 4 Linus Torvalds in the U.S. and other countries The information in this document is subject to change without notice. Bull will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material.
Page 5: Table Of Contents
Contents Safety notices ... vii Prepare to remove the disk drive . . 45 Remove the disk drive . . 47 Replace the disk drive . . 50 About this publication ..ix Complete the procedure .
Page 6 Chapter 3. Expansion units ..89 Install attached expansion-unit PCI adapters with the system power off . . 155 Prepare to connect your expansion units . . 89 Remove attached expansion-unit PCI Plan where you will install the new expansion adapters .
Page 7 Connecting the power distribution system Remove the model SMP processor cable . . 264 Checking the ac outlets . . 209 Replace the model system backplane . 268 Attaching the front or back ac electrical Replace the system backplane . .
Page 8 Locate a failing part in a Linux system or Verify the installed part on a Linux system or logical partition . 300 logical partition (run AIX diagnostics) . . 324 Activate the indicator light for the failing Verify an installed part using stand-alone part .
Page 9: Safety Notices
Safety notices Safety notices may be printed throughout this guide. v DANGER notices call attention to a situation that is potentially lethal or extremely hazardous to people. v CAUTION notices call attention to a situation that is potentially hazardous to people because of some existing condition.
Page 10 Power and cabling information for NEBS (Network Equipment-Building System) GR-1089-CORE The following comments apply to the servers that have been designated as conforming to NEBS (Network Equipment-Building System) GR-1089-CORE: The equipment is suitable for installation in the following: v Network telecommunications facilities v Locations where the NEC (National Electrical Code) applies The intrabuilding ports of this equipment are suitable for connection to intrabuilding or unexposed wiring or cabling only.
Page 11: About This Publication
About this publication This book contains information regarding the customer tasks that are involved with installing options on your 17M/MA system. The customer tasks that are included in this book are predominantly focused on installing hardware features. Those sections are designed to assist you when installing hardware features in your 17M/MA or in an attached expansion unit.
Page 12 Customer-Installable Features for the 17M/MA...
Page 13: Customer-Installable Features For The 17M/Ma
Customer-Installable Features for the 17M/MA This book contains information regarding the customer tasks that are involved with installing options on your 17M/MA system. The customer tasks that are included in this book are predominantly focused on installing hardware features. Those sections are designed to assist you when installing hardware features in your 17M/MA or in an attached expansion unit.
Page 14 Customer-Installable Features for the 17M/MA...
Page 15: Chapter 1. Control Panel, Signal Cable, Or Control Panel Fillers
Chapter 1. Control panel, signal cable, or control panel fillers You might need to remove, install, or replace the control panel (operator panel), signal cable, or control panel fillers in the server. This section includes procedures so that you can perform these tasks. Model control panel You might need to remove, install, or replace the control panel in the server.
Page 16: Remove The Control Panel With Power On
Figure 1. Control panel replacement 5. Access the Advanced System Management Interface (ASMI). For instructions, refer to Managing the Advanced System Management Interface (ASMI). 6. In the navigation area of the ASMI, select Concurrent maintenance and then Control panel. 7. At the control panel window, select Install and click Continue. 8.
Page 17 To remove a control panel with the system power on, you must first gain access to the Advanced System Management Interface (ASMI). For instructions, refer to Managing the Advanced System Management Interface (ASMI). Remove the control panel To remove the control panel with the system or logical partition powered on, follow these steps from the system or logical partition that controls the media device: 1.
Page 18: Install Or Replace The Control Panel With Power Off
“Managing the Advanced System Management Interface (ASMI)” on page 293 Understand how to manage the Advanced System Management Interface (ASMI). Install or replace the control panel with power off Use the procedure in this section to perform this task. To install or replace the control panel with the power off, complete the following procedure: 1.
Page 19: Remove The Control Panel With Power Off
Remove the control panel with power off You might need to remove the control panel from the server with the power off. Use the procedure in this section to perform this task. If your system is managed by the Hardware Management Console (HMC), use the HMC to complete the steps for removing a control panel.
Page 20: Model Control Panel Filler
Figure 4. Control panel removal 6. If you are removing the control panel as part of another procedure, return to that procedure now. Attention: If you are not immediately installing or replacing the control panel, a control panel filler must be in place when the system power is on for proper air flow and cooling. For instructions on installing a control panel filler, refer to “Model control panel filler.”...
Page 21: Chapter 2. Disk Drive
Chapter 2. Disk Drive You might need to install, remove, or replace a disk drive, a disk-drive backplane, or an enclosure. This section includes procedures so that you can perform these tasks. You can choose to perform these tasks yourself, or contact a service provider to perform the task for you. You might be charged a fee by the service provider for this service.
Page 22: Prepare The System
DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 23: Install The Disk Drive
4. Determine the next available disk drive position in your system or expansion unit. For information, see “Disk drive locations” on page 66. Note: When you have a system with an expansion unit, fill the slot positions in the system unit first. However, you can choose a different disk drive placement depending on your data protection strategy.
Page 24 Figure 5. Removing a disk-drive filler from a model . 10. If the slot you want to use contains a disk-drive filler, complete the following step. Remove the disk-drive bezel latch A from the front of the filler, as shown in the following figure. Figure 6.
Page 25 12. Find the package that contains the new disk drive. Attention: Disk drives are fragile. Handle with care. 13. Remove the disk drive from the static-protective package. 14. Unlock the disk drive handle by squeezing it and pulling it out toward you. If the handle is not all the way out, the disk drive will not slide into the system or expansion unit.
Page 26: Complete The Procedure
Figure 8. Installing a disk drive in a model 20. Press Enter. 21. If you are installing more than one disk drive, repeat step 1 on page 11 through step 20 until all disk drives are installed. 22. Cancel to get to the SCSI and SCSI RAID Hot Plug Manager menu. 23.
Page 27 DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 28: Install A Disk Drive Using Linux Kernel 2.4
3. Remove the front cover. For instructions on removing the cover, select the appropriate procedure from the following list: v “Remove the front cover from the model ” on page 311 v “Remove the front cover from the 11D/20 expansion unit” on page 309 v If you have a front cover from any other models, remove the front cover.
Page 29 Figure 9. Removing a disk-drive filler from model b. Pull off the disk-drive bezel latch A from the front of the filler, as shown in the following figure. Figure 10. Removing the disk-drive bezel c. Loosen, and then pull out on the thumbscrew C to release the disk-drive bezel B from the front edge of the filler.
Page 30 3. Remove the disk drive from the static-protective package. Record the serial number (use the last 4 digits) of the disk drive. 4. Unlock the disk drive handle by squeezing and pulling it out toward you. If the handle is not all the way out, the disk drive will not slide into the system or expansion unit.
Page 31 Figure 12. Installing a disk drive in a model Note: The concurrent maintenance light stops blinking and remains on when you have installed the disk drive correctly. To view the locations of the concurrent maintenance lights, select the appropriate model from the following list: v “Disk-drive concurrent maintenance lights for models ”...
Page 32: Complete The Procedure
Display Disk Hardware Status Serial Vendor Product Resource Hardware Number Model Name Status 03132041 IBM 2780001 /dev/ipr3 Operational 000015A5 IBM ST373453LC DPY/Active E3V1WEAB IBM IC35L036UCDY10-0 DPY/Active E3V0J55B IBM IC35L036UCDY10-0 DPY/Active E3V1W1UB IBM IC35L036UCDY10-0 DPY/Active 04B81193 IBM 3C98D203 /dev/sdi Operational 000227CE IBM ST336605LC /dev/sdh Operational...
Page 33 A display similar to the following figure, is shown. x0537p1:~ # lsslot # Slot Description Linux Name Device(s) U787A.001.DNZ00XV-P1-C1 Logical I/O Slot 0000:00:02.0 ethernet U787A.001.DNZ00XV-P1-C2 Logical I/O Slot 0000:00:02.2 pci U787A.001.DNZ00XV-P1-C3 Logical I/O Slot 0001:00:02.2 pci1069,b166 U787A.001.DNZ00XV-P1-C4 Logical I/O Slot 0000:00:02.6 pci1069,b166 U787A.001.DNZ00XV-P1-C5 Logical I/O Slot 0001:00:02.6 pci1014,0180 U787A.001.DNZ00XV-P1-T5...
Page 34 Figure 16. Removing a disk-drive filler from model b. Pull off the disk-drive bezel latch A from the front of the filler, as shown in the following figure. Figure 17. Removing a disk-drive bezel from the disk drive. c. Loosen, and then pull out on the thumbscrew C to release the disk-drive bezel B from the front edge of the filler.
Page 35 11. Remove the disk drive from the static-protective package. Record the serial number (use the last 4 digits) of the disk drive. 12. Unlock the disk drive handle by squeezing and pulling it out toward you. If the handle is not all the way out, the disk drive cannot slide into the system or expansion unit.
Page 36: Operational
Figure 19. Installing a disk drive in a model 17. Press Enter. The concurrent maintenance light stops blinking and remains on when you have installed the disk drive properly. To view the locations of the concurrent maintenance lights, select the appropriate model from the following list: v “Disk-drive concurrent maintenance lights for models ”...
Page 37: Complete The Procedure
Display Hardware Status Type option, press Enter. 1=Display hardware resource information details OPT Name PCI/SCSI Location Description Status --- ------ -------------------------- ------------------------- ---------------- 0000:01:01.0.0/ PCI-X SCSI Adapter Operational 0000:41:01.0.1/ PCI-X SCSI Adapter Operational 0000:41:01.0.1/0:3:0 Physical Disk Active 0000:41:01.0.1/0:4:0 Physical Disk Active 0000:41:01.0.1/0:8:0 Physical Disk...
Page 38: Prepare The System
DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 39: Install The Disk Drive
5. Stop the system or the logical partition that controls the disk drive location. For instructions, see “Stop the system or logical partition” on page 303. 6. If you stopped the logical partition, do not disconnect the power source. If you stopped the system, disconnect the power source from the system by unplugging the system.
Page 40 Figure 21. Removing a disk-drive filler from a model b. Pull off the disk-drive bezel latch A from the front of the filler, as shown in the following figure. Figure 22. Removing a disk-drive bezel c. Loosen, and then pull out on the thumbscrew C to release the bezel B from the front edge of the filler.
Page 41 3. Remove the disk drive from its protective package. Record the serial number (use the last 4 digits) of the disk drive. 4. Unlock the disk drive handle by squeezing and pulling it out toward you before you install the disk drive.
Page 42: Complete The Procedure
Figure 24. Installing a disk drive in a model 9. If you are installing more than one disk drive, repeat step 1 on page 27 through step 8 on page 29 until all disk drives are installed. Complete the procedure 1.
Page 43: Replace A Disk Drive
Remove a disk drive from a system or expansion unit that is controlled by different operating systems. v “Replace a disk drive with the AIX system or logical partition powered on.” v “Replace a disk drive with the Linux system or logical partition powered on” on page 37. Replace a disk drive You might need to replace a Small Computer System Interface (SCSI) or Serial Attached SCSI (SAS) disk drive in the server or expansion unit.
Page 44: Prepare The System
DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 45: Remove The Disk Drive
v “Expansion unit cover or door” on page 305 4. Remove the front cover. For instructions on removing the cover, select the appropriate procedure from the following list: v “Remove the front cover from the model ” on page 311 v “Remove the front cover from the 11D/20 expansion unit”...
Page 46 Figure 25. Removing a disk drive from a model 13. Support the bottom of the disk drive as you slide it out of the system or expansion unit. Do not hold the disk drive by the handle. The concurrent maintenance light for the slot turns off when you remove the disk drive. 14.
Page 47: Replace The Disk Drive
Figure 26. Removing a disk-drive bezel Replace the disk drive 1. Find the package that contains the new disk drive. Attention: Disk drives are fragile. Handle with care. 2. Remove the disk drive from its protective package. 3. Unlock the handle of the replacement disk drive by squeezing and pulling it out toward you. If the handle is not all the way out, the disk drive cannot slide into the system.
Page 48 Figure 27. Installing a disk-drive bezel 6. Install the disk drive as shown in Figure 28 on page 37. a. Support the bottom of the disk drive as you align it with the guide rails in the system unit. Do not hold the disk drive by the handle.
Page 49: Complete The Procedure
Figure 28. Installing a disk drive in a model 7. Press Enter. The disk drive slot exits the Remove state and enters the Normal state. 8. Exit to the RAID Hot-Plug Devices menu. Press F3 to return. 9. Exit to the Task selection display. 10.
Page 50 DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 51: Replace The Disk Drive Using Linux Kernel 2.4
v If no, your drive is configured as Just a Bunch of Disks (JBOD) or is configured within a degraded array. Proceed to the next step. 3. If the disk drive you are replacing is in a redundant array of independent disk (RAID) Level 0 disk array or in a failed RAID Level 5 or RAID Level 10 disk array, you must delete the disk array before replacing the disk.
Page 52: Remove The Disk Drive
11. On the Display Disk Unit Details display, type 5 (Display hardware resource information details) next to the disk drive you want to replace. The Disk Unit Hardware Resource Information Details display is shown, similar to the following display. Disk Unit Hardware Resource Information Details Manufacturer.
Page 53 Device Concurrent Maintenance Type the choices, then press Enter. Specify either Physical Location or PCI/SCSI location. Physical Location: U0.1-P1-I4/Z1-A8 PCI/SCSI . . . PCI Bus: PCI Device: SCSI Channel: SCSI Id: SCSI Lun: Specify action as 1=Remove device 2=Install device Action to be performed .
Page 54 Device Concurrent Maintenance Action In Progress Please remove the device located in: Location: U0.1-P1-I4/Z1-A8 Figure 33. Example Device Concurrent Maintenance Action In Progress display Attention: v Attach a wrist strap to an unpainted metal surface of your hardware to prevent electrostatic discharge from damaging your hardware.
Page 55: Replace The Disk Drive
Figure 35. Removing a disk-drive bezel Replace the disk drive: 1. Find the package that contains the new disk drive. Attention: Disk drives are fragile. Handle with care. 2. Remove the disk drive from its protective package. 3. Unlock the disk drive handle by squeezing and pulling it out toward you before you install the disk drive.
Page 56 Figure 36. Attaching a bezel to the disk drive b. Press in and then tighten the thumbscrew B to secure the bezel to the disk drive. 5. Select Device Concurrent maintenance from the Work with Disk Unit Recovery display. Press Enter. 6.
Page 57: Complete The Procedure
A Device Concurrent Maintenance Action In Progress display similar to the following is shown. Device Concurrent Maintenance Action In Progress Please insert the device located in: Location: U0.1-P1-I4/Z1-A8 Figure 38. Example Device Concurrent Maintenance Action In Progress display 11. Support the bottom of the disk drive as you align it with the guide rails in the system or expansion unit.
Page 58 1. Log in as root user. 2. Type iprconfig on the command line of the Linux session and press Enter. The Configuration Utility display is shown. 3. Select Analyze log. Press Enter. The Kernel Messages Log display is shown. Kernel Messages Log Select one of the following: 1.
Page 59: Remove The Disk Drive
Display Hardware Status Type option, press Enter. 1=Display hardware resource information details OPT Name PCI/SCSI Location Description Status --- ------ -------------------------- ------------------------- ---------------- 0000:01:01.0.0/ PCI-X SCSI Adapter Operational 0000:41:01.0.1/ PCI-X SCSI Adapter Operational 0000:41:01.0.1/0:3:0 Physical Disk Active 0000:41:01.0.1/0:4:0 Physical Disk Active 0000:41:01.0.1/0:8:0 Physical Disk...
Page 60 1. From the Configuration Utility display, select Work with disk unit recovery. Press Enter. 2. From the Work with Disk Unit Recovery display, select Concurrent remove device. Press Enter. A Concurrent Device Remove display is shown, similar to the following display. Concurrent Device Remove Choose a single location for remove operations 1=Select...
Page 61 Figure 44. Removing a disk drive from a model or 11D/20 8. Support the bottom of the disk drive as you slide it out of the system or expansion unit. Do not hold the disk drive by the handle. 9. If your replacement disk drive does not have a bezel preinstalled, then perform the following step. Loosen and pull out on the thumbscrew B to release the disk-drive bezel C from the disk drive, as shown in the following figure.
Page 62: Replace The Disk Drive
Figure 45. Removing a disk-drive bezel 10. Press Enter on the Configuration Utility to indicate that you have removed the disk drive. Replace the disk drive: 1. Find the package that contains the new disk drive. Attention: Disk drives are fragile. Handle them with care. 2.
Page 63 Figure 46. Attaching a bezel to the disk drive 5. From the Configuration Utility display, select Work with disk unit recovery. Press Enter. 6. From the Work with Disk Unit Recovery display, select Concurrent add device. Press Enter. A Concurrent Device Add display similar to the following is shown. Concurrent Device Add Choose a single location for add operations 1=Select...
Page 64: Complete The Procedure
Figure 48. Installing a disk drive in a model or 11D/20 11. Press Enter on the Complete Device Concurrent Add display to indicate that the disk drive is installed. 12. Rebuild the data on the replacement disk drive. For instructions, go to “Rebuild data on a replacement disk drive using Linux”...
Page 65: Prepare The System
DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 66: Remove The Disk Drive
6. If you stopped the logical partition, do not disconnect the power source. If you stopped the system, disconnect the power source from the system by unplugging the system. Note: This system might be equipped with a second power supply. Before continuing with this procedure, ensure that all power sources to the system have been completely disconnected.
Page 67 Attention: v Attach a wrist strap to an unpainted metal surface of your hardware to prevent electrostatic discharge from damaging your hardware. v When using a wrist strap, follow all electrical safety procedures. A wrist strap is for static control. It does not increase or decrease your risk of receiving electric shock when using or working on electrical equipment.
Page 68: Replace The Disk Drive
Figure 50. Removing a disk-drive bezel Replace the disk drive 1. Find the package that contains the new disk drive. Attention: Disk drives are fragile. Handle with care. 2. Remove the disk drive from its protective package. 3. Unlock the disk drive handle by squeezing and pulling it out toward you before you install the disk drive.
Page 69 Figure 51. Attaching a disk-drive bezel 5. Support the bottom of the disk drive as you align it with the guide rails in the system or expansion unit. Do not hold the disk drive by the handle. 6. Slide the disk drive into the system or expansion unit until it stops. Note: It is important to ensure that when installing a disk drive, that the drive is fully seated and all the way into the system.
Page 70: Complete The Procedure
Figure 52. Installing a disk drive in a model or 11D/20 Complete the procedure 1. Replace the front cover. For instructions on replacing the cover, select the appropriate procedure from the following list: v hwip2frontbezelon.dita#hwip2frontbezelon v “Install the front cover on the model ” on page 311 v “Install the front cover on the 11D/20 expansion unit”...
Page 71: Remove The Disk Drive
Remove the disk drive 1. Log in as root user. 2. At the command line, type diag and press Enter. 3. Press Enter to continue. 4. On the Function Selection display, select Task Selection. 5. On the Task Selection display, select Hot Plug Task. 6.
Page 72: Replace The Disk Drive
Note: The concurrent maintenance light for the slot turns off when you remove the disk drive. 14. Loosen and pull out on the thumbscrew B to release the bezel C from the disk drive. Figure 54. Removing a disk-drive bezel Replace the disk drive 1.
Page 73 Figure 55. Attaching a disk-drive bezel 5. Press in and then tighten thumbscrew B to secure bezel A to the disk drive. 6. Install the disk drive as follows: a. Support the bottom of the disk drive as you align it with the guide rails in the system unit. Do not hold the disk drive by the handle.
Page 74: Complete The Procedure
Figure 56. Installing a disk drive in a model a model or 11D/20 7. Press Enter. 8. Exit to the SCSI and SCSI RAID Hot-Plug Manager menu. 9. Select Configure Added/Replaced Devices. Press Enter. 10. Select the disk drive that you replaced and then press Enter. The disk drive is now configured.
Page 75: Remove A Disk-Drive Filler
Note: Refill the disk drive slots with either another disk drive or a disk-drive filler. Filling the disk drive slot will help ensure proper air flow for cooling and help maintain optimal EMI compliance. Remove a disk-drive filler You might need to remove a Small Computer System Interface (SCSI) disk-drive filler from the server or expansion unit.
Page 76: Install A Disk-Drive Filler
5. Gently pull off the disk-drive bezel latch A from the front of the filler, as shown in the following figure. Figure 58. Removing a disk-drive bezel 6. Loosen and then pull out on the thumbscrew C to release the bezel B from the front edge of the filler. Install a disk-drive filler You might need to install a Small Computer System Interface (SCSI) disk-drive filler in the server or expansion unit.
Page 77 Figure 59. Attaching a bezel to a disk-drive filler 4. Install the disk-drive filler in the system or expansion unit, as shown in the following figure. Figure 60. Installing a disk-drive filler 5. Replace the front cover. For instructions on replacing the cover, select the appropriate procedure from the following list: v “Install the front cover on the model ”...
Page 78: Disk Drive Locations
v “Install the front cover on the 11D/20 expansion unit” on page 310 v If you have a front cover from any other models, remove the front cover. 6. Install or close the system, expansion unit or rack front door. Disk drive locations Find out where the disk drives are located on different models.
Page 79: 57/86, 57/87, 31D/24 Or 31T/24 Scsi Disk-Drive Enclosure
The available disk drive locations depends on the number of SCSI interface cards installed in the SCSI disk-drive enclosure. If the next available disk drive position is the first slot in a disk-drive enclosure such as D21, D26, or D46, look at the disk-drive controller to verify that the enclosure is connected to a SCSI bus port.
Page 80: Connect And Configure The 57/86, 57/87, 31D/24
This SCSI disk-drive enclosure can hold up 24 disk drives. The enclosure is organized into 4 groups, with each group containing 6 disk drive slots. The enclosure can be used as a stand-alone tower or a rack-mounted drawer. When connecting with your server, you can connect your SCSI cables to either a single initiator repeater card or to a dual initiator repeater card on your SCSI disk drive enclosure.
Page 81 Figure 65. SCSI cable to single repeater card v Two SCSI adapters connected to dual repeater cards: if in this case you are sharing resources (disk-drives) between systems or partitions ensure you understand the SCSI addressing and cabling order for more information see, “Connecting and configuring the 57/86, 57/87, 31D/24 or 31T/24 SCSI disk-drive enclosure in an AIX clustered environment”...
Page 82 SCSI disk-drive enclosure in an AIX clustered environment” on page 72. Figure 67. SCSI cable to dual repeater card connected with four SCSI cards v Single SCSI adapter connected to a combination of single and dual repeater cards: if in this case you are sharing resources (disk-drives) between systems or partitions ensure you understand the SCSI addressing and cabling order for more information see, “Connecting and configuring the 57/86, 57/87, 31D/24 or 31T/24 SCSI disk-drive enclosure in an AIX clustered environment”...
Page 83 Figure 68. SCSI cable to dual repeater card connected to single repeater card 3. Use the information you printed for the SCSI adapter to complete the configuration of your disk drives. For more information see the SCSI PCI Adapters (http://publib.boulder.ibm.com/infocenter/ pseries/v5r3/index.jsp?topic=/com.ibm.pseries.doc/hardware_docs/scsipciadapters.htm) web page and locate the file for the adapter you are using to attach the enclosure to your system.
Page 84: Connecting And Configuring The 57/86, 57/87, 31D/24 Or 31T/24 Scsi Disk-Drive Enclosure In An Aix Clustered Environment
------------------------------------------------------------------ #!/bin/ksh #Name:run_ses_healthcheck #Location:/usr/lpp/diagnostics/bin #Function: SCSI SES hourly heathcheck for i in ’lsdev -Cc container -t ses -s scsi -F name -S available’ diag -cd $i > /dev/null done #any registered "external notification" will be notified of errors #(such as HMC or Electronic Service Agent) ------------------------------------------------------------------ Note: On a partitioned system, it is only necessary to have the CRON job and script running on one partition associated with the enclosure, though it is acceptable to have the same CRON job and scripts...
Page 85 1. Ensure that each SCSI device connected to the shared SCSI bus has a unique ID. A common configuration is to set the SCSI ID of the adapters on the nodes to be higher than the SCSI IDs of the shared devices.
Page 86: Connect And Configure The Disk Drive Enclosure In A System With The Linux Operating System
This creates a set of shared disks and a shared SCSI bus (such as scsi0) between Host A and Host B. The important thing to consider at this point is that you connect the cables in descending order of the SCSI address on the host adapter.
Page 87 Figure 71. SCSI cable to dual repeater card connected with two SCSI cards Figure 72. SCSI cable to dual repeater card connected with four SCSI cards v If you are using a combination of single and dual repeater cards, install a SCSI cable to the dual initiator repeater card A.
Page 88 Figure 73. SCSI cable to dual repeater card connected to single repeater card 3. Install the other end of the SCSI cable C to the SCSI adapter D on the server. For more details, see Figure 74. Important: The SCSI adapter or the system or partition must be powered off before making this connection.
Page 89: Scsi Repeater Card
v librtas v lsvpd ppc64-utils v diagela b. If your partitions are managed by a Hardware Management Console (HMC), install the src, rsct.core.utils, rsct.core, csm.core, csm.client, and devices.chrp.base.ServiceRM packages in order to report errors to the Service Focal Point on the attached HMC. Instructions for installing the packages are located on the previous Web site.
Page 90 Figure 75. Repeater card location of 57/86, 57/87, 31D/24 or 31T/24 SCSI disk-drive enclosure Customer-Installable Features for the 17M/MA...
Page 91 Figure 76. Repeater card location of tower 57/86, 57/87, 31D/24 or 31T/24 SCSI disk-drive enclosure If you only have dual repeater cards, place as follows: Important: On tower models the locations C3 and C5 are located on top, C2 and C4 are located on bottom.
Page 92 Table 1. Repeater card placement for (continued) Type and number of repeater cards Single repeater card placement Dual repeater card placement 2 single repeater cards and 1 dual Place in C5 then C2 then place dual repeater cards repeater card 2 single repeater cards and 2 dual Place in C5 then C2 then place dual Place in order C4 then C3...
Page 93: Remove And Replace Scsi Repeater Card
Figure 78. Back view of 57/86, 57/87, 31D/24 or 31T/24 SCSI disk-drive enclosure The following list describes how the repeater card locations affect the disk drive bays. v The top left repeater card (C2) drives the front right 6 bays (D07 to D12). Figure 77 on page 80 v The top right repeater card (C3) drives the front left 6 bays (D01 to D06).
Page 94: Related Information
Figure 79. Removing SCSI cable from repeater card 3. Lift the handle C to unseat the repeater card from the enclosure. 4. Pull the repeater card out of the enclosure. 5. Align the replacement repeater card with the empty slot on the enclosure and insert the card until it is firmly seated.
Page 95: Disk-Drive Concurrent Maintenance Lights For Model 11D/20
Figure 80. Model disk-drive concurrent maintenance lights Disk-drive concurrent maintenance lights for model 11D/20 Learn where the disk-drive concurrent maintenance lights are located on your system. The following figure shows the locations of the disk-drive concurrent maintenance light A for the model 11D/20.
Page 96: Prepare A Disk Drive For Use In An Aix System Or Logical Partition
Figure 82. Front view of model 57/86, 57/87, 31D/24 or 31T/24 SCSI disk-drive enclosure concurrent maintenance lights Figure 83. Back view of model 57/86, 57/87, 31D/24 or 31T/24 SCSI disk-drive enclosure SCSI disk-drive enclosure concurrent maintenance lights Prepare a disk drive for use in an AIX system or logical partition Configure the newly installed disk drive for your environment.
Page 97: Rebuild Data On A Replacement Disk Drive Using Linux
For more information, see the AIX System Management Guide: Operating System and Devices. Rebuild data on a replacement disk drive using Linux To rebuild data on the replacement disk drive, complete the steps listed here. For an unprotected disk drive If the disk drive you are replacing is in a RAID Level 0 disk array or in a failed RAID Level 5 or RAID Level 10 disk array, perform these tasks: 1.
Page 98: Rebuild Data On A Disk Drive Using Linux Kernel 2.6
A Confirm Rebuild Disk Unit Data display similar to the following figure shown below. Confirm Rebuild Disk Unit Data Rebuilding the disk unit data could take several minutes for each unit selected. Press Enter to confirm having the data rebuilt. Press q=Cancel to return and change your choice.
Page 99 Rebuild Disk Unit Data Select the disks to be rebuilt Type choice, press Enter. 1=Rebuild OPT Name PCI/SCSI Location Description Status --- ------ -------------------------- ------------------------- ------------- 0000:58:01.0.0/0:4:0 RAID Array Member Failed e=Exit q=Cancel t=Toggle Figure 86. Example Rebuild Disk Unit Data display 5.
Page 100 Customer-Installable Features for the 17M/MA...
Page 101: Chapter 3. Expansion Units
Chapter 3. Expansion units This topic provides information on setting up your expansion units, including connecting your expansion ™ units with Remote Input/Output (High-Speed Link) (RIO) or InfiniBand cables to your system unit. RIO and InfiniBand adapters enable expansion units to be attached to system units. This topic collection refers to both the remote input/output (RIO) and high-speed link (HSL) as the RIO.
Page 102: Plan Where You Will Install The New Expansion Units
This topic collection provides information about connecting your expansion units with RIO (remote I/O or high-speed link), InfiniBand and system power control network (SPCN) cables. This is a customer task. You can perform this task yourself or contact a service provider for this service. You should be familiar with the system, display, and keyboards.
Page 103: Plan Your Cable Layout
Table 3. InfiniBand cables (continued) Cable feature Cable type Length Part number 1840 12x InfiniBand 3.0 meters 42V2132 Table 4. SPCN cables Cable feature CCIN Length Part number 6001 6001 2 meters 87G6235 6006 6006 3 meters 09P1251 6007 6007 15 meters 21F9358 6008...
Page 104: System Unit Cable Options
Figure 89. Maximum number of expansion units per loop System unit cable options Learn which RIO and InfiniBand cables are supported on which system units. Use the following table to identify the RIO cables for the model numbers and machine types identified. Table 5.
Page 105 Table 6. Expansion unit RIO cable options (continued) Cable feature IXA card 50/74, 50/79 05/88, 50/88 50/94, 52/94, 50/95, 05/95 57/90 0694, 91/94 1482 (copper) 1483 (copper) 1485 (copper) 1832 1833 1834 1835 1836 1837 1838 1839 3146 (copper) 3147 (copper) 3148 (copper) 3156 (copper) 3168 (copper)
Page 106: Expansion Unit Configuration Rules For Rio And Infiniband
Table 8. Expansion unit RIO cable options (continued) Cable feature HCA card 11D/11 11D/20 1308 (copper) 1460 (copper) 1461 (copper) 1462 (copper) 1470 (fiber optic) 1471 (fiber optic) 1472 (fiber optic) 1473 (fiber optic) 1474 (copper) 1475 (copper) 1481 (copper) 1482 (copper) 1483 (copper) 1485 (copper)
Page 107: Connect Your Expansion Units
Table 10. RIO and InfiniBand configuration rules for expansion units Configuration Maximum number Maximum number of Maximum Maximum of ports loops number of number of expansion units supported per loop expansion units 11D/11 11D/20 (RIO) 57/90 50/95 05/95 (RIO-12X) 57/96 Connect your expansion units Follow these instructions to verify readiness to add the expansion units and add the expansion units to the system.
Page 108 Important: When simultaneously adding multiple expansion units to an existing SPCN loop, it is required that the units be adjacent to each other so the existing loop is broken at only one spot. 4. Set the SPCN Firmware Update Policy. The SPCN Firmware Update Policy controls when and how SPCN firmware on expansion units will be updated.
Page 109: Connect The Expansion Unit With Rio Cables
on. After the green power indicators are lit on the control panels of all of the expansion units that were just powered on, wait ten additional minutes for hardware initialization to complete before proceeding to 12. 11. Go to “Start the system or logical partition” on page 300. 12.
Page 110: Add Expansion Units To An Existing Rio Loop
Unused RIO connectors might be covered with metal clips. Remove the clips before you install the RIO cables. 1. On the system unit to which you are going to connect the new RIO , identify connectors 0 and 1 of the RIO connector pair that you are going to use.
Page 111: Examples: Rio Expansion Unit Connections
2) Connect another cable to connector 1 on the expansion unit from step 6c1 on page 98. 3) Repeat step 6c on page 98 for each additional expansion unit. d. Connect the other end of the cable from connector 1 on the last expansion unit added to connector 0 on the expansion unit that was disconnected in step 6a on page 98.
Page 112 Customer-Installable Features for the 17M/MA...
Page 113: Verify That The New Configuration Is Functioning
Verify that the new configuration is functioning Use the procedures in this section to verify that the new configuration functioning. To verify the new configuration is functioning for servers that are managed by an HMC, do the following: 1. “Viewing information about the managed system” on page 102 a.
Page 114: Viewing Information About The Managed System
Complete the following steps to verify the RIO loops using an HMC and the system unit power on: 1. Use the HMC to verify that there are no B700 69xx errors by completing the following steps: a. In the navigation area of the HMC, select Service Management. b.
Page 115: Verify The System Power Control Network (Spcn)
The information provided in the memory tab (for example, deconfigured resources), along with the information provided on the I/O tab, is useful for planning for processors and dynamic logical partitions. Verify the System Power Control Network (SPCN) Use the procedures in this section to check for SPCN (System Power Control Network) errors, check for inactive enclosures, and fix any MTMS (Machine, Type, Model, and Serial Number) problems.
Page 116: Setting I/O Enclosure Configuration Id And Mtms Value
a. Access the ASMI using an authority level of Administrator or Authorized service provider. See “Managing the Advanced System Management Interface (ASMI)” on page 293 for information about using ASMI. b. In the ASMI navigation area, expand System Configuration and select Configure I/O Enclosures. c.
Page 117 v The server must be powered on to a firmware standby or a firmware running state. v The enclosure must have ac power and be correctly installed in the system power control network. v Your authority level must be one of the following: –...
Page 118 9. If the server is powered on to the firmware running state, go to step 10. If the server is powered on to the firmware standby state, go to step 11. 10. If the configuration ID must be changed, see the following notes, and go to “Powering off an I/O enclosure”...
Page 119 2) If the values you just entered are not immediately reflected in the location code of the enclosure in the Power On/Off Unit utility, restart the utility periodically for up to ten minutes until the values you entered are reflected. Go to “Start or stop the system or logical partition”...
Page 120 If you want to replace the I/O backplane with the server powered off, but configuration changes might be lost, powering off the server and then powering it on to firmware standby state before performing the procedure might be a satisfactory alternative. The activated firmware level of the server is displayed in the upper-right corner of the ASMI utility.
Page 121 7. Determine if the enclosure is configured as a switchable unit, either by asking the customer or ™ referring to Determining if an enclosure is configured as switchable under iSeries OptiConnect. Switchable enclosures exist only if the server makes use of Switchable Independent Disk Pools. Is the enclosure configured as switchable? No: The enclosure is configured as private to this system.
Page 122 – Work with the customer to vary off all configuration descriptions (for example, ctl, device, line, network server, and so on) that use resources in the enclosure. Use the vrycfg command. The system will not allow the enclosure to be powered off unless all configuration descriptions that use resources in the enclosure are varied off.
Page 123 Reporting partition type: RPA Return code type: Failure (hard stop or user intervention required). Message: com.ibm.hsc.client.rmc.HSCRMCException: Query operation for slot resource has failed on partition 2. The partition command is: drmgr -Q -c slot -s U0595.001.435DF30-CB1-C02 -w 0 -d 3 The partition standard output is: drslot_chrp_slot: slot_type=1 all slots=0x20042ca8 The partition standard error is:...
Page 124 Attention: – Before beginning, read this entire procedure. If there are procedural steps that cannot be performed at this time, the entire procedure must be delayed until a later time. – If the server is managed by a HMC, the power off and power on functions must be performed using the Power On/Off Unit utility on the HMC.
Page 125: Using The Control Panel To Set The Configuration Id
Yes: Go to step 17. 17. Is this an enclosure with ac power cords connected from this unit’s ac module or the battery charger to an SPCN controlled enclosure (for example: a 7311 I/O enclosure)? No: This enclosure can be serviced without affecting an SPCN controlled enclosure. Return to the procedure that sent you here.
Page 126: Connect The Expansion Unit With Spcn Cables
3. Select subfunction A6 to display the address of all attached units. The frame address is displayed on all units for 30 seconds. Make a note of the frame address on the enclosure that you are servicing. Note: If the enclosure does not immediately appear on the service utility used to power off the enclosure, refresh the utility periodically until it does.
Page 127: Examples: Rio Spcn Connections
1) Connect the other end of the cable from connector J16 on the expansion unit just added to connector J15 on the next expansion unit. 2) Connect another cable to connector J16 on the expansion unit from step 1e1. 3) Repeat step 1e on page 114 for each additional expansion unit. f.
Page 128 Customer-Installable Features for the 17M/MA...
Page 129: Connector Locations
Connector locations Learn about RIO and SPCN connector locations. Model connector locations Learn about connector locations. Figure 90. Model connector locations Chapter 3. Expansion units...
Page 130: Model 57/9011D/11 Or 11D/10 Connector Locations
Model 57/9011D/11 or 11D/10 connector locations Learn about connector locations. Figure 91. Model 57/9011D/11 or 11D/10 connector locations Model 05/9511D/20 connector locations Learn about connector locations. Figure 92. Model 05/9511D/20 connector locations Customer-Installable Features for the 17M/MA...
Page 131: Model 14G/30 Connector Locations
Model 14G/30 connector locations Learn about connector locations. Figure 93. Model 14G/30 connector locations Chapter 3. Expansion units...
Page 132 Customer-Installable Features for the 17M/MA...
Page 133: Chapter 4. Pci Adapter
Chapter 4. PCI adapter You might need to place, install or remove Peripheral Component Interconnect (PCI), PCI-E, or PCI-X features. Use the procedures in this section to perform these tasks. Important: v If you are exchanging a 2766, 2787, or 280E Fibre Channel IOA, the external storage subsystem must be updated to use the world-wide port name of the new 2766, 2787, or 280E IOA.
Page 134 3. To determine in which slot to place the PCI adapter, refer to arebdhowtodecide.dita for information regarding slot restrictions for the adapters that can be used in this system. 4. If you are installing a PCI adapter in a rack-mounted system or expansion unit, follow these steps: a.
Page 135 Figure 95. Rotate the EMC shield into the open position 11. Lift up the lower cassette handle B as shown in the following figure. Pull the PCI cassette C out of the system. Chapter 4. PCI adapter...
Page 136 Figure 96. PCI adapter cassette removed from the system unit. 12. Install the adapter into the PCI adapter cassette using the following instructions: v “Place a PCI adapter in a single-width cassette” on page 171 v “Remove an adapter from the PCI adapter single-width cassette” on page 177 13.
Page 137 Figure 97. PCI adapter cassette removed from the system unit 18. Lower the PCI adapter EMC shield A into the closed position, close the shield latch, then close the rear rack door. Chapter 4. PCI adapter...
Page 138: Install A Pci Adapter Contained In A Cassette With The Power On In Linux
Figure 98. PCI adapter EMC shield in the closed position 19. Verify that the new resource is functional. Refer to “Verify the installed part” on page 319. Install a PCI adapter contained in a cassette with the power on in Linux You might need to install a PCI adapter.
Page 139 4. If you are installing a PCI adapter in a rack-mounted system or expansion unit, follow these steps: a. Open the rear rack door. b. Remove the units cover or covers if applicable. 5. Log in to the system console as the root user. 6.
Page 140 Figure 100. Rotate the EMC shield into the open position 8. Remove the cassette. Lift up the lower cassette handle B as shown in the following figure. Pull the PCI cassette C out of the system. Customer-Installable Features for the 17M/MA...
Page 141 Figure 101. PCI adapter cassette removed from the system unit 9. Install the adapter into the PCI adapter cassette using the following instructions: v “Place a PCI adapter in a single-width cassette” on page 171 v “Remove an adapter from the PCI adapter single-width cassette” on page 177 10.
Page 142 Figure 102. PCI adapter cassette removed from the system unit 16. Lower the PCI adapter EMC shield A into the closed position, close the shield latch, then close the rear rack door. Customer-Installable Features for the 17M/MA...
Page 143: Install A Pci Adapter Contained In A Cassette With The Power Off
Figure 103. PCI adapter EMC shield in the closed position 17. Use the lsslot command to verify that U7879.001.DQD014E-P1-C3 is occupied. Enter lsslot -c pci -s U7879.001.DQD014E-P1-C3 The following is an example of the information displayed by this command: # Slot Description Device(s) U7879.001.DQD014E-P1-C3 PCI-X capable, 64 bit, 133MHz slot 0001:40:01.0...
Page 144 2. Take appropriate precautions for avoiding electric shock and handling static-sensitive devices. For information, see “Avoiding electric shock” on page 190 and “Handling static-sensitive devices” on page 191. 3. To determine in which slot to place the PCI adapter, refer to arebdhowtodecide.dita for information regarding slot restrictions for the adapters that can be used in this system.
Page 145 Figure 105. Rotate the EMC shield into the open position 10. Lift up the lower cassette handle B as shown in the following figure. Pull the PCI cassette C out of the system. Chapter 4. PCI adapter...
Page 146 Figure 106. PCI adapter cassette removed from the system unit 11. Install the adapter into the PCI adapter cassette using the following instructions: v “Place a PCI adapter in a single-width cassette” on page 171 v “Remove an adapter from the PCI adapter single-width cassette” on page 177 12.
Page 147 Figure 107. PCI adapter cassette removed from the system unit 16. Lower the PCI adapter EMC shield A into the closed position, close the shield latch, then close the rear rack door. Chapter 4. PCI adapter...
Page 148: Remove A Pci Adapter Contained In A Cassette From The System
Figure 108. PCI adapter EMC shield in the closed position 17. “Start the system or logical partition” on page 300. 18. Verify that the new resource is functional. Refer to “Verify the installed part” on page 319. Remove a PCI adapter contained in a cassette from the system You might need to remove a PCI adapter.
Page 149 operation. Before taking an adapter offline, the devices attached to the adapter must be taken offline as well. This action prevents a service representative or user from causing an unexpected outage for system users. To remove an adapter, do the following: 1.
Page 150 Figure 109. Lift up the EMC shield Customer-Installable Features for the 17M/MA...
Page 151 Figure 110. Rotate the EMC shield into the open position 24. Remove the cassette. Lift up the lower cassette handle B as shown in the following figure. Pull the PCI cassette C out of the system. Attention: A cassette containing either a PCI adapter or filler panel must be placed in the PCI adapter slot of the system unit for proper air flow and cooling.
Page 152: Remove A Pci Adapter Contained In A Cassette From The System With The Power On In Linux
Figure 111. PCI adapter cassette removed from the system unit 25. Place the cassette with the cover facing up on an approved ESD surface. Note: The cover will have a label on it. 26. Continue to follow the screen instructions until you receive a message that the adapter removal is successful.
Page 153 If your system is managed by the Hardware Management Console (HMC), use the HMC to complete the steps for removing a PCI adapter. For instructions, see “Remove a part using the Hardware Management Console” on page 318. To remove an adapter do the following: 1.
Page 154 Figure 113. Rotate the EMC shield into the open position 11. Lift up the lower cassette handle B as shown in the following figure. Pull the PCI cassette C out of the system. Attention: A cassette containing either a PCI adapter or filler panel must be placed in the PCI adapter slot of the system unit for proper air flow and cooling.
Page 155: Remove A Pci Adapter Contained In A Cassette From The System With The System Power Off
Figure 114. PCI adapter cassette removed from the system unit 12. Place the cassette with the cover facing up on an approved ESD surface. Note: The cover will have a label on it. 13. “Remove an adapter from the PCI adapter single-width cassette” on page 177. Remove a PCI adapter contained in a cassette from the system with the system power off You might need to remove a PCI adapter.
Page 156 b. Remove the units cover or covers if applicable. 6. If you are removing a PCI adapter in a stand-alone expansion unit, remove the units back cover, if applicable. 7. Determine the location of PCI adapter in the system. 8. Lift and hold the PCI adapter EMC shield A in the open position. Figure 115.
Page 157: Attached Expansion-Unit Pci Adapters
Figure 116. PCI adapter cassette removed from the system unit 10. Place the cassette with the cover facing up on an approved ESD surface. Note: The cover will have a label on it. 11. “Remove an adapter from the PCI adapter single-width cassette” on page 177. Attached expansion-unit PCI adapters You might need to remove, replace, or install PCI adapters.
Page 158 If your system is managed by the Hardware Management Console (HMC), use the HMC to complete the steps for installing a PCI adapter. For instructions, see “Install a feature using the Hardware Management Console” on page 318. To install a PCI adapter with the system power on in AIX, do the following: 1.
Page 159 12. Rotate the adapter locking latches counterclockwise as shown in Figure 117 or Figure 118 on page 148. 13. Lift the black tab attached to the adapter retainer assembly, and keep the black tab in a vertical position. 14. Remove the adapter filler plate if one is present. Figure 117.
Page 160 Figure 118. PCI adapter or filler plate removed from the stand-alone unit 15. Follow the instructions on the screen to install the adapter until the LED for the specified PCI slot is set to the Action state. See “Component LEDs” on page 192. 16.
Page 161 Figure 119. PCI adapter replaced in the rack-mounted system unit Chapter 4. PCI adapter...
Page 162: Install Attached Expansion-Unit Pci Adapter With System Power On In Linux
Figure 120. PCI adapter replaced in the stand-alone unit 19. Connect any adapter cables. 20. Replace or close the covers. 21. “Place the rack-mounted system or expansion unit in the operating position” on page 316 if you are servicing a rack-mounted system. 22.
Page 163 To install a PCI adapter with the system power on in Linux, do the following: 1. Ensure that the system meets the “Prerequisites for hot-plugging PCI adapters in Linux” on page 192. 2. “Verify that the Linux, hot-plug PCI tools are installed” on page 192. 3.
Page 164 12. Rotate the adapter locking latch A counterclockwise as shown in Figure 121 or Figure 122 on page 153. 13. Lift the black tab B attached to the adapter retainer assembly, and keep the black tab in a vertical position. 14.
Page 165 Figure 122. PCI adapter or filler plate removed from the stand-alone unit 15. Run the drslot_chrp_pci command to enable an adapter to be installed. For example, to install an adapter into PCI slot U7879.001.DQD014E-P1-C3, enter the following command: drslot_chrp_pci -a -s U7879.001.DQD014E-P1-C3 The following displays: The visual indicator for the specified PCI slot has been set to the identify state.
Page 166 Attention: When you install an adapter into the system, be sure that it is completely and correctly seated in its connector. 19. Secure the adapter. Lower the tab onto the PCI adapter faceplate. Rotate the adapter locking latches clockwise as shown in Figure 123 or Figure 124 on page 155. 20.
Page 167: Install Attached Expansion-Unit Pci Adapters With The System Power Off
Figure 124. PCI adapter replaced in the stand-alone unit Install attached expansion-unit PCI adapters with the system power off: You might need to install a PCI adapter. Use the procedure in this section to perform this task. If your system is managed by the Hardware Management Console (HMC), use the HMC to complete the steps for installing a PCI adapter.
Page 168 v Determine if the adapter will be placed in the base system unit or an expansion unit. – If the adapter is to be placed into the base system unit, continue with this procedure by going to the next numbered step. –...
Page 169 Figure 125. PCI adapter or filler plate removed from the rack-mounted system unit Chapter 4. PCI adapter...
Page 170 Figure 126. PCI adapter or filler plate removed from the stand-alone system unit 14. Carefully grasp the adapter by its top edge, and align the adapter with the expansion slot and its connector on the system backplane. 15. Press the adapter firmly into its connector. 16.
Page 171 Figure 127. PCI adapter replaced in the rack-mounted system unit Chapter 4. PCI adapter...
Page 172: Remove Attached Expansion-Unit Pci Adapters
Figure 128. PCI adapter replaced in the stand-alone system unit 17. Connect any adapter cables. 18. If you are servicing a rack-mounted system, route the cables through the cable-management arm. 19. Replace or close the covers. 20. On a rack-mounted system, close the rear rack door. 21.
Page 173: Remove Attached Expansion-Unit Pci Adapters With The System Power On In Aix
v If you are exchanging a 2766, 2787, or 280E Fibre Channel IOA, the external storage subsystem must be updated to use the world-wide port name of the new 2766, 2787, or 280E IOA. For instructions, see rrcardsupdateport.dita. v If you are replacing a 2748, 2757, 2763, 2767, 2778, 2780, 2782, 5702, 5709, or 570B storage IOA, take note of the following: Depending on the configuration of the system, the storage IOA cache might have been disabled to allow the attachment of OEM storage that emulates a load source drive.
Page 174 7. Follow these steps to place the adapter in the action state using the PCI Hot-Plug Manager: a. Enter the system diagnostics by logging in as root user or as the celogin user, type diag at the AIX command line. b.
Page 175 Figure 129. PCI adapter removed from the rack-mounted system unit Chapter 4. PCI adapter...
Page 176 Figure 130. PCI adapter removed from the stand-alone system unit 12. Seal the expansion slot using an expansion-slot cover. 13. Lower the plastic retainer seat over the PCI adapter faceplate. 14. Rotate the locking latch clockwise until it clicks into the locked position. 15.
Page 177: Remove Attached Expansion-Unit Pci Adapters With The System Power On In Linux
20. On a rack-mounted system, close the rear rack door. 21. “Place the rack-mounted system or expansion unit in the operating position” on page 316 if you are servicing a rack-mounted system. If you are servicing a stand-alone system, continue to the next step.
Page 178 10. Rotate the adapter locking latch A counterclockwise as shown in Figure 131 or Figure 132 on page 167. 11. Lift the black tab B attached to the adapter retainer assembly, and keep the black tab in a vertical position. 12.
Page 179: Remove Attached Expansion-Unit Pci Adapters With The System Power Off
Figure 132. PCI adapter removed from the stand-alone system unit 13. If you are removing a PCI adapter as part of another procedure, return to that procedure. If not, continue to the next step. 14. Seal the expansion slot using an expansion-slot cover. 15.
Page 180 If your system is managed by the Hardware Management Console (HMC), use the HMC to complete the steps for removing a PCI adapter. For instructions, see “Remove a part using the Hardware Management Console” on page 318. To remove a PCI adapter with the system power off, do the following: 1.
Page 181 Figure 133. PCI adapter removed from the rack-mounted system unit Chapter 4. PCI adapter...
Page 182: Pci Adapter Single-Width Cassette
Figure 134. PCI adapter removed from the stand-alone system unit 11. If you are removing a PCI adapter as part of another procedure, return to that procedure. If not, continue to the next step. 12. Seal the expansion slot using an expansion-slot cover. 13.
Page 183: Place A Pci Adapter In A Single-Width Cassette
Place a PCI adapter in a single-width cassette You might need to place a PCI adapter in a single-width cassette. Use the procedure in this section to perform this task. To place a PCI adapter in a cassette, do the following: 1.
Page 184 Figure 136. Adapter retainers c. Place the tailstock clamp in the open position by rotating the tailstock clamp into the open position. Figure 137. Tailstock clamp in the open position 6. Place the adapter in the cassette by doing the following: a.
Page 185 c. Close the tailstock clamp B . See Figure 138. Figure 138. Adapter removed from the PCI adapter single-width cassette d. Position the adapter retainers to support the adapter, and then rotate the retainer clip into the closed position. Note: 1) Two retainers are located at the top of the cassette, along the top edge of the adapter.
Page 186 Figure 139. Long adapter in the PCI adapter cassette with the supports and stabilizer in place Adapter-cassette retainer placement for mid-sized adapters a) Remove the adapter stabilizer C . See Figure 140 on page 175. b) Place and lock the retainers B . c) Ensure the adapter edge is seated in each retainer groove A .
Page 187 Figure 140. Medium-length adapter in the PCI adapter cassette with the supports in place Adapter-cassette retainer placement for small adapters a) Remove the adapter stabilizer C . See Figure 141 on page 176. b) Place the hookarm D into the hole in the corner of the adapter. This supports the card when it is undocked from the connector on the system backplane.
Page 188 Figure 141. Short adapter in the PCI adapter cassette with the supports and the hookarm in place 7. Replace the cassette cover by doing the following: a. Slide the cover B into position on the cassette as shown in the following figure. b.
Page 189: Remove An Adapter From The Pci Adapter Single-Width Cassette
Figure 142. PCI adapter cassette cover replaced Remove an adapter from the PCI adapter single-width cassette You might need to remove a PCI adapter from a single-width cassette. Use the procedure in this section to perform this task. To remove an adapter from the single-width cassette, do the following: 1.
Page 190 Figure 143. PCI adapter cassette cover removed 5. Remove the adapter from the cassette by doing the following: a. Unlock the adapter retainers by rotating the retainer clip A into the horizontal position. See Figure 144 on page 179. Note: 1) The edge of the adapter located at the end of the cassette that contains the cassette handles is called the adapter tailstock.
Page 191 Figure 144. Adapter removed from the PCI adapter cassette f. Put the adapter in a safe place. Attention: A cassette containing either a PCI adapter or filler panel must be placed in the PCI adapter slot of the system unit for proper air flow and cooling. g.
Page 192: Pci Adapter Placement For Servers System Units And Expansion Units
Figure 145. PCI adapter cassette cover replaced PCI adapter placement for servers system units and expansion units Some adapters must be placed in specific PCI slots to function correctly or perform optimally. Use this information to determine where to install PCI adapters. Model 17M/MA server Some adapters must be placed in specific PCI, Peripheral Component Interconnect-X (PCI-X), or PCI Express (PCIe) slots in order to function correctly or perform optimally.
Page 193: Expansion Units
Table 11. PCI slot locations and descriptions Slot # Location code Description Adapter size Slot 1 P1-C1 PCIe x8 PCIe PHB0 long Slot 2 P1-C2 PCIe x8 PCIe PHB1 long Slot 3 P1-C3 PCIe x8 PCIe PHB2 long Slot 4 P1-C4 PCI-X DDR, PCI-X PHB0...
Page 194: Pci And Pci-X Adapters
- With four processors, the system unit enclosure supports up to 8 I/O drawers. – Systems with two system unit enclosures support up to 16 I/O drawers. – Systems with three system unit enclosures support up to 24 I/O drawers. –...
Page 195: Pcie Adapters
Table 12. Adapter slot priorities and maximums for PCI and PCI-X adapters (continued) System unit enclosure slot Feature Description priority Maximum number of adapters allowed 5736 PCI-X DDR 2.0 Dual Channel 4, 5 v 2 per system unit enclosure (internal) Ultra320 SCSI Adapter v 58/88/118/148 per system 5712...
Page 196: Performance Notes
Table 13. Adapter slot priorities and maximums for PCIe adapters (continued) System unit enclosure slot Feature Description priority Maximum number of adapters allowed 5773 4 Gigabit PCI Express Single Port 1, 2, 3, 6 v 4 per system unit enclosure (internal) Fibre Channel Adapter v 4/8/12/16 per system 5774...
Page 197 High bandwidth storage adapters Table 15. Maximum number of high bandwidth storage adapters for best performance Adapters in Adapters in system unit Adapters in system unit Adapters in I/O enclosures plus 14G/30 I/O enclosures expansion units I/O expansion expansion units including both connected to a units connected...
Page 198: 11D/11 Expansion Unit
Table 17. Maximum number of high bandwidth Ethernet adapters for best performance (continued) Adapters in Adapters in system unit system unit Adapters in I/O enclosures plus Adapters in I/O enclosures expansion units I/O expansion expansion units including both connected to a units connected connected to a System...
Page 199: 11D/20 Expansion Unit
Slot priority for all adapters is 1, 4, 2, 5, 3, and 6. For a list of supported adapters, refer to the placement information for the base system unit to which the expansion unit is attached. If the adapter is supported by the base unit, it is supported by the expansion unit.
Page 200: 14G/30 Expansion Unit
14G/30 expansion unit Use this information to learn about the PCI slots in the 14G/30 expansion unit. System description: The 14G/30 expansion unit is a rack-mountable, I/O expansion drawer that is designed to be attached to the system unit using the InfiniBand bus and InfiniBand cables. The 14G/30 can accommodate 6, generation 3 blind swap adapter cassettes.
Page 201: Slot Priorities
Table 21. Slot properties (continued) Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Long Long Long Long Long Long 64-bit 3.3V, 266 64-bit 3.3V, 266 64-bit 3.3V, 266 64-bit 3.3V, 266 64-bit 3.3V, 266 64-bit 3.3V, 266 v Each PCI-X DDR slot is a separate PCI host bus (PHB).
Page 202: Avoiding Electric Shock
Avoiding electric shock Observe the follow precautions in order to avoid electric shock when working on or around the system. DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord.
Page 203: Handling Static-Sensitive Devices
Handling static-sensitive devices Electronic boards, adapters, media drives, and disk drives are sensitive to static electricity discharge. These devices are wrapped in antistatic bags to prevent this damage. Take the following precautions to prevent damage to these devices from static electricity discharge. v Attach a wrist strap to an unpainted metal surface of your hardware to prevent electrostatic discharge from damaging your hardware.
Page 204: Component Leds
Note: For an adapter to be serviced with the system power on, both the adapter and the system unit must support hot-plug procedures. To identify adapters that are hot-pluggable in the system you are servicing, refer to the following placement information: v PCI Adapter Placement Guide Component LEDs Individual LEDs are located on or near the failing components.
Page 205: Open The Model 05/95 Or 50/9511D/20 Service Access Cover
The directory should contain data. If the directory is empty, the driver is not loaded or the system does not contain hot-plug PCI slots. The following is an example of the information displayed by this command: drwxr-xr-x 15 root root 0 Feb 16 23:31 . drwxr-xr-x 5 root root 0 Feb 16 23:31 ..
Page 206 Customer-Installable Features for the 17M/MA...
Page 207: Chapter 5. Media Device
Chapter 5. Media device Learn how to install, or remove and replace a media device to add a device, replace a failed device, or as a part of another service action. Select the appropriate procedure from the instructions in this section. Installing or replacing these features is a customer task.
Page 208 Figure 150. Slimline media-device installation 6. Start the system. For instructions on starting the system, see “Start the system or logical partition” on page 300. 7. Verify that the new resource is functional. Refer to “Verify the installed part” on page 319. 8.
Page 209: Chapter 6. Installing Rack Features
Chapter 6. Installing rack features You might need to install a rack feature. This section includes procedures so that you can perform these tasks. You can perform these tasks or contact a service provider to perform the tasks for you. You might be charged a fee by the service provider for this service.
Page 210: Leveling The Rack
1 Caster 2 Locking screw Figure 151. Tightening the locking screw. Use the following to determine the next step: v If the rack is being bolted to a concrete floor, go to “Attaching the rack to a concrete floor” on page 200.
Page 211: Attaching The Stabilizer Brackets
1 Rack Front (base) 2 Leveling Foot (quantity 4) 3 Jam Nut (quantity 4) Figure 152. Adjusting the leveling feet. Attaching the stabilizer brackets You might need to attach the stabilizer brackets to the rack. Use the procedure in this section to perform this task.
Page 212: Attaching The Rack To A Concrete Floor
1 Rack front (base) 3 Stabilizer bracket 2 Stabilizer mounting screws 4 Rack rear (base) Figure 153. Attaching the stabilizer brackets. 4. To install the second stabilizer bracket on the back of the rack, repeat steps 1 through 3. Attaching the rack to a concrete floor You might need to attach the rack to a concrete floor.
Page 213 1 Rack chassis 4 Right-side trim panel 2 Top trim panel 5 Spring clip 3 Left-side trim panel Figure 154. Removing the trim panels. 3. If installed, remove the front and back doors. To remove a rack door, go to “Attaching the rack doors”...
Page 214 Figure 155. Installing ac-power mounting plates 1 Rack chassis 7 Jam nut 2 Rack-mounting bolt 8 Leveling foot 3 Thin washer 9 Lower plastic isolator bushing (used only on dc powered systems) 4 Top plastic isolator bushing AC Typical leveling foot installation for an ac-powered rack 5 Thick washer DC Typical leveling foot installation for...
Page 215 1 Rack-mounting bolt 7 Leveling foot 2 Thin washer 8 Lower plastic isolator bushing (Used only on dc powered systems) 3 Top plastic isolator bushing 9 Mounting plate 4 Thick washer 10 Threaded hole (Used to secure the rack to stabilizer bracket.) 5 Spacer 11 Anchor bolt hole 6 Jam nut...
Page 216 Note: You must use a minimum of two anchor bolts for each rack-mounting plate to securely attach the plate to the concrete floor. Because some of the holes in each rack-mounting plate may align with concrete reinforcement rods embedded in the concrete, some of the rack-mounting plate holes may not be usable.
Page 217: Attaching The Rack To The Concrete Floor Beneath A Raised Floor
32. If you have multiple racks that are connected in a suite (bolted to each other), go to “Connecting multiple racks with rack-to-rack attachment kit” on page 253. Otherwise, torque the four bolts to 40-50 ft-lbs (54-67 nm). 33. If you are not installing doors on your rack, install the top, left, and right trim panel. 34.
Page 218 3 Left-side trim panel Figure 158. Removing the trim panels. 3. If installed, remove the front and rear doors. To remove a rack door, go to “Attaching the rack doors” on page 244. After the rack doors have been removed, go to the next substep. 4.
Page 219 6 Spacer 6. Position the two mounting plates in the approximate mounting location under the rack. 7. Create a rack-mounting bolt assembly by adding the following items, in the order listed, to each rack-mounting bolt. a. Thin flat washer b. Top plastic isolator bushing c.
Page 220 1 Rack-mounting bolt 7 Leveling foot 2 Thin washer 8 Lower plastic isolator bushing (used only on dc-powered systems) 3 Top plastic isolator bushing 9 Stabilizer brackets 4 Thick washer 10 Threaded hole (used to secure the rack to mounting plate.) 5 Spacer 11 Anchor bolt hole 6 Jam nut...
Page 221: Connecting The Power Distribution System
39. Connect the power distribution system as described in “Connecting the power distribution system.” 40. After the rack is bolted down and you are going to attach a front electrical outlet, go to “Attaching the front or back ac electrical outlet.” 41.
Page 222: Installing The Ac Outlet-Mounting Plates With Ac Outlets
v The ac outlet-mounting plates for installing customer-supplied ac electrical outlets on the front or back of the rack. The ac outlet-mounting place provides the mounting location for an ac electrical outlet. v The brass ground lug for an electrostatic discharge (ESD) connection. Note: The customer is responsible for providing both the outlets and the power cables that attach to the power source.
Page 223 1 Ground cable lug 7 Ground lug 2 Star washer 8 Ground connector (short end of ground cable) 9 ″Y″ End of ground cable 3 Front of rack 4 Power cable from the power source 10 Ground lug nut (quantity 2) 5 Mounting plate 11 Long end of ground cable 6 Long end of ground cable...
Page 224: Installing The Ac Outlet-Mounting Plate Without Ac Outlets
3 Button-head screw 6 Long end of ground cable Figure 162. Installing the front mounting plate. 18. Connect the ″Y″-shaped end of the ground cable to the rack frame, either near the center in the back of the rack or to the ground bus bar at the back of the rack. 19.
Page 225: Installing The Model 31D/2457/86 Into A Rack
If you do not want any ac outlets installed on the front or rear ac outlet-mounting plate, perform only “Attaching the rack to the concrete floor beneath a raised floor” on page 205 through “Connecting the power distribution system” on page 209. For front or rear ac outlet-mounting plates, refer to “Installing the ac outlet-mounting plates with ac outlets”...
Page 226: Completing A Parts Inventory
Figure 164. Parts inventory 4. Determine where you will locate the expansion unit in the rack. See “Determining the location.” This system unit is 4 EIA units high. 5. Mark the location. See “Marking the location using rack-mounting template” on page 216. If you do not have the rack-mounting template, see “Marking the location without a rack-mounting template”...
Page 227: Marking The Location Without A Rack-Mounting Template
Figure 165. Removing the filler panels. 4. Remove the front and back rack doors if necessary. 5. Use the rack-mounting template to mark the location (see Mark location using rack-mounting template). If you do not have a rack-mounting template, follow the instructions for marking the location without a template (see Mark location without rack-mounting template).
Page 228: Marking The Location Using Rack-Mounting Template
3. Facing the front of the rack and working from the left side, place a supplied self-adhesive dot next to the top hole B of the first EIA unit that you selected. Figure 166. Marking the installation locations. Note: The self-adhesive dots are used to aid in identifying locations on the rack. If do not have any of the dots, use some other form of marking tool to aid you in identifying hole locations (for example, tape, a marker, or pencil).
Page 229: Attaching The Mounting Hardware To The Rack
2. Note the following when using the rack-mounting template: v Each black or white unit on the template is equal to one EIA unit. v Each EIA unit consists of three holes. v The EIA units illustrated on the template must be aligned with the EIA units located on the rack. v It is not necessary to align like-colored EIA units.
Page 230 CAUTION: Installing the rails in the rack is a complex procedure. To install the rails correctly, you must perform each task in the following order. Failure to do so might cause rail failure and potential danger to yourself and the system unit. To install the mounting hardware into the rack, follow these steps: 1.
Page 231: Installing The 31D/2457/86 On The Rail Assembly
Figure 170. Attaching the system rails. 7. Using two M5 screws D, secure the right rail to the front of the rack. 8. Moving to the back of the rack and using two M5 screws D, secure the left rail to the back of the rack.
Page 232 Figure 171. Removing the bezel. 2. Using three people, lift the system unit and position it the over front of the rails. Attention: Three people are required to safely lift the system. Using fewer than three people to lift the system can result in injury. 3.
Page 233 Figure 173. Securing the system to the back of the rack. 7. Install the bezel onto the system. Figure 174. Installing the bezel. For instructions on how to connect and configure the system when you have completed installing the 31D/2457/86 into the rack, see “Connect and configure the 57/86, 57/87, 31D/24 or 31T/24 SCSI disk-drive enclosure to a system or partition with the AIX operating system”...
Page 234: Installing A System Or Expansion Unit Into A Rack
Installing a system or expansion unit into a rack You might need to install a system or expansion unit into a rack. This section includes procedures so that you can perform these tasks. The following procedures describe how to install system units or expansion units into a rack. You can perform this task or contact a service provider to perform the task for you.
Page 235: Determining The Location
3. Complete a parts inventory (See “Completing a parts inventory” on page 214). 4. Determine where you will locate the expansion unit in the rack. See Locate in rack. 5. Mark the location. See “Marking the location using a rack-mounting template” on page 224. If you do not have the rack-mounting template, see “Marking the location without a rack-mounting template”...
Page 236 4. Use the rack-mounting template to mark the location. See “Marking the location using a rack-mounting template.” If you do not have a rack-mounting template, follow the instructions for marking the location without a template, see “Marking the location without a rack-mounting template”...
Page 237 Figure 177. EIA units To use the rack-mounting template, complete the following steps: a. Remove the protective coating from each adhesive strip located on the back of the rack-mounting template. Lightly press the template into position on the rack. Ensure that both the left and right sides are at the corresponding EIA locations.
Page 238: Installing The 50/95 Or 05/9511D/20 Rails Into The Rack
Note: The self-adhesive dots are used to aid in identifying locations on the rack. If you no longer have any of the dots, use some other form of marking tool to aid you in identifying hole locations (for example, tape, a marker, or pencil). 4.
Page 239: Installing The 50/95 Or 05/9511D/20 Expansion Unit Into A Rack
Figure 179. Attaching the rails to the back of the rack. 6. Using two screws B, attach the right rail assembly to the back of the rack. Installing the 50/95 or 05/9511D/20 expansion unit into a rack: You might need to install an expansion unit into a rack. Use the procedure in this section to perform this task.
Page 240 Figure 180. Attaching the rail-mounting guides. 2. Extend the rails from the rack until they lock into place. 3. Using at least three people, lift the expansion unit onto the rails. The rail guides B go over the rails. 4. Align the mounting holes on the chassis with their corresponding holes on the rail. 5.
Page 241 6. Remove the four screws A securing the rail-mounting guides B to the expansion unit and remove the rail mounting guides. Figure 182. Removing the rail-mounting guides. 7. Slide the system approximately three-quarters of the way into the rack. 8. Move to the back of the rack. 9.
Page 242 Figure 183. Attaching the cable-management arm. 10. Attach the securing screw mounts G with two screws F to the left and right rack rails. Figure 184. Attaching the securing screw mounts. 11. Slide the expansion unit into the rack. Customer-Installable Features for the 17M/MA...
Page 243: Installing The 57/90 Or 57/9611D/11 Or 14G/30 Expansion Unit In A Rack
Figure 185. Sliding the expansion unit into the rack. 12. If the system will be transported, install the two securing screws though the front of the expansion unit and into the securing screw mounts. Installing the 57/90 or 57/9611D/11 or 14G/30 expansion unit in a rack You might need to install an expansion unit into the rack.
Page 244: Marking The Location Using The Rack-Mounting Template
Figure 186. Rack-mounting template for the expandable rails. Figure 187. Expandable rails with extension brackets. Note: There are two versions of the rail kits for the 57/90 or 57/9611D/11 or 14G/30. Figure 190. Front bezel. Figure 189. Filler plate and screws. Figure 188.
Page 245 If you do not have a rack-mounting template, go to “Marking the location without a rack-mounting template” on page 234. Note: 1. Read the “Rack Safety Notices” on page 245. 2. The rack-mounting template has printed illustrations located on the front and back of the template. Each illustration is designed to aid you in identifying the EIA (Electronics Industries Association ) location holes used when planning to populate your rack.
Page 246: Marking The Location Without A Rack-Mounting Template
B Nut clip Figure 191. Attaching the dots and nut clips for the standard rails. A Folded self-adhesive dot B Nut clip Figure 192. Attaching the dots and nut clips for the expandable rails. d. Attach the nut clips B directly across from the template’s printed nut clips onto the rack’s EIA strip.
Page 247 evenly spaced. If your rack has no color or line separation between EIAs, assume that each EIA section begins where the hole spacing is closest together. Figure 193. EIA units with the standard rails. A EIA hole spacing B Self-adhesive dot placement C Nut clip Figure 194.
Page 248: Installing The Expandable Rails And Extension Bracket Into The Rack
7. Begin with the hole identified by the dot, or mark, placed in substep 6, count up two holes and place the second dot, or mark, next to the hole. 8. Begin with the top dot, count up three holes and place a nut clip in that location. 9.
Page 249 Important: Do not install a screw in the top location at this time. It will secure the shell to the assembly. Figure 196. Attaching the system rails to the front of the rack. 7. Using one M5 screw D, secure the right rail to the front of the rack into the lower location E. 8.
Page 250: Installing The Shell
Figure 197. Attaching the extension brackets and rails to the back of the rack. 13. Using three M5 screws G, secure the extension bracket F through the rack and into the right rail. 14. Tighten the two screws in the middle of the left rail and the two screws in the middle of the right rail.
Page 251 Figure 198. Installing the shell into the rack on the expandable rails. A Shell B Retaining screws (four) 2. Install and tighten the four retaining screws B into the front of the shell, securing the shell A to the rack. 3.
Page 252 Figure 199. Securing the shell to the rack with the standard rails. A Shell C Retaining screw Customer-Installable Features for the 17M/MA...
Page 253: Installing The System
Figure 200. Securing the shell to the rack with the expandable rails. A Shell C Retaining screw Installing the system: You might need to install the system into the rack. Use the procedure in this section to perform this task. To install the system into a rack, complete the following steps: 1.
Page 254: Attaching The Rio, Power Controller (Spcn), And Power Cables
A Filler plate screws B Filler plate C Shell D Drawer E Drawer screws Figure 201. Removing the filler plate. 3. Carefully move any existing cables that are blocking the drawer location. 4. Slide the drawer D into the shell. 5.
Page 255: Replacing A 14T/00, 14T/42, 0551, And 0553 Side Panel
The rack might have optional side panels. To remove and replace a side panel, complete the following procedure: 1. Unlock the side panels by pressing down on both locking latches to release the latches. Figure 202. Removing the side panel. Note: If your rack uses a ruggedized kit, you must remove the securing screw to allow each side panel to be removed.
Page 256: Attaching The Rack Doors
2. Place the bottom of the side panel onto the ridge on the bottom of the rack. Figure 203. Replacing the side panel. 3. Slide the top of the side panel into place and close the locking latches. Note: If your rack uses ruggedized kit, you must install a securing screw into each side panel that was installed.
Page 257: Rack Safety Notices
1 Rack chassis 2 Top trim panel 3 Left side trim panel 4 Right side trim panel 5 Spring clip Figure 204. Removing the trim panels. 3. Install the door latch on the right and the door hinges on the left. 4.
Page 258 DANGER Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
Page 259: Installing The Rack Security Kit
Installing the rack security kit You might need to install the rack security kit. Use the procedure in this section to perform this task. To install a rack security kit that consists of the security lock and security slide bars, complete the following procedure: 1.
Page 260 1 Two lock hardware kits. Each kit contains: - Rack lock - Bracket - Screw - Two keys 2 Two security slide bars 3 Two locked/unlocked stickers Figure 205. Rack security kit inventory. 3. Remove the existing door latch. Figure 206. Removing the existing door latch. a.
Page 261 5. Repeat steps 3 on page 248 and 4 on page 248 to install the second lock on the back rack door. 6. Install a security slide bar on the right side of the rack. Figure 207. Installing a security slide bar. Note: Each slide bar rail has two long tabs on the bottom of the rail.
Page 262: Ruggedized Kit
Figure 208. Placing the locked/unlocked sticker on the cover panel. f. Repeat the above procedure for the left side of the rack. Ruggedized kit You might need to remove or replace a part in the ruggedized kit. This section includes procedures so that you can perform these tasks.
Page 263: Releasing The Ruggedized Brace
Figure 209. Ruggedized kit parts. 1 Rack 9 Brace hinges 2 Spacer 10 Brace 3 Brace hinge 11 Side-door securing screw mount 4 Hinge pivot studs 12 Spacer 5 Brace latch bracket 13 Screw 6 Spacer 14 Washer 7 Screw 15 Side door securing screw 8 Brace thumbscrew Releasing the ruggedized brace...
Page 264: Releasing The Side Panel With A Ruggedized Kit
Figure 210. Releasing the brace to access systems. 2. Swing the brace 10 out of the rack. 3. Access the system and reinstall the brace. Releasing the side panel with a ruggedized kit You might need to release the side panel on the rack. Use the procedure in this section to perform this task.
Page 265: Connecting Multiple Racks With Rack-To-Rack Attachment Kit
Figure 211. Removing the securing screws on the side panel. 3. Using a screwdriver, remove the securing screw 15 and washer 14 from the side panel. To remove the side panel, see “Removing and replacing 14T/00, 14T/42, 0551, and 0553 side panels” on page 242. Connecting multiple racks with rack-to-rack attachment kit You might need to connect multiple racks together.
Page 266 4. Install the first two standoffs in the upper-left and lower-right corners of the first rack as shown in Figure 212. 5. Install the second two standoffs in the upper-left and lower-right corners of the second rack as shown in Figure 212. 6.
Page 267: Rack Status Beacon
10. After all racks are bolted together, level the racks. 11. Tighten all four screws. 12. Snap on the trim pieces that go between the front and back racks. 13. Snap on the trim piece that goes on top and between the racks. 14.
Page 268 Figure 214. Connecting the rack status beacon to the system unit through the junction box. 2. Plug one end of the rack status beacon cable 1 into the port on the back of the rack status beacon assembly. Figure 215. Connecting the rack status beacon and system unit to the junction box. 3.
Page 269: Connecting Multiple Junction Boxes
6. Plug the other end of the second rack status beacon cable into the beacon port on the system unit. This port is labeled with a beacon symbol. Note: On some system units, the orientation of the port is rotated. Figure 216.
Page 270: Installing Or Removing A Rack-Mounted System-Unit Latch Bracket
Figure 217. Connect the rack status beacon and system unit to the junction box. 2. Plug a junction box cable into the output port of the additional junction box. 3. Connect additional system units to the additional junction box as described in “Installing the rack status beacon”...
Page 271 Figure 218. Reinstalling the latch brackets. 4. Secure the latch bracket with two retaining screws C, on the side of the latch bracket. 5. Replace the front cover. See “Install the front cover on the 11D/20 expansion unit” on page 310See hwip2rackbezelon.dita.
Page 272 Figure 219. Removing the retaining screws. 4. Remove the latch bracket from the system unit. Customer-Installable Features for the 17M/MA...
Page 273: Chapter 7. Backplanes And Cards
Chapter 7. Backplanes and cards You might need to remove, replace, or install a Redundant Array of Independent Disks (RAID) enablement card or system backplane in the server. This section includes procedures so that you can perform these tasks. Replacing this feature is a customer task. You can perform this task yourself, or contact a service provider to perform the task for you.
Page 274: Remove The System Backplane
5. Remove the front cover. For instructions, see “Remove the front cover from the model ” on page 311. Attention: v Attach a wrist strap to an unpainted metal surface of your hardware to prevent electrostatic discharge from damaging your hardware. v When using a wrist strap, follow all electrical safety procedures.
Page 275 Figure 220. Slide the model system backplane assembly out of the system unit 3. If you are removing the system backplane as a part of another procedure, return to that procedure. If you are removing the system backplane because it is damaged or failing to operate correctly, continue to the next step.
Page 276: Remove The Model Smp Processor Cable
Figure 221. Remove the processor assembly from model backplane assembly 6. Place the processor assembly on a surface that is safe from electrostatic discharge. 7. Replace the system backplane. For instructions, see “Replace the model system backplane” on page 268. Remove the model SMP processor cable You might need to remove the SMP processor cable.
Page 277 DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 278 Figure 222. Remove power cords Note: The system units might be equipped with secondary power supplies. Before continuing with this procedure, ensure that all power sources to the system units have been disconnected completely. (L003) Customer-Installable Features for the 17M/MA...
Page 279 Attention: v Attach a wrist strap to an unpainted metal surface of your hardware to prevent electrostatic discharge from damaging your hardware. v When using a wrist strap, follow all electrical safety procedures. A wrist strap is for static control. It does not increase or decrease your risk of receiving electric shock when using or working on electrical equipment.
Page 280: Replace The Model System Backplane
Figure 223. Remove the SMP Cable Replace the model system backplane If you removed the system backplane as a part of another procedure, you might need to replace the system backplane. Use the procedure in this section to perform this task. You must have already completed the procedure “Remove the model system backplane”...
Page 281 Figure 224. Replace the model backplane assembly 2. Align the system backplane assembly with the slot in the system. 3. Slide the system backplane assembly into the system A, as shown in Figure 225 on page 270. 4. Push the blue lever B to the right and in toward the system to lock the system backplane assembly. Chapter 7.
Page 282: Complete The Procedure
Figure 225. Slide the model system backplane assembly into the system unit Complete the procedure 1. Reinstall the voltage regulator modules. For instructions, see “Install the model voltage regulator assembly with power off” on page 286. 2. Reinstall the control panel. For instructions, see “Install or replace the control panel with power off” on page 6.
Page 283 DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 284 Attention: v Attach a wrist strap to an unpainted metal surface of your hardware to prevent electrostatic discharge from damaging your hardware. v When using a wrist strap, follow all electrical safety procedures. A wrist strap is for static control. It does not increase or decrease your risk of receiving electric shock when using or working on electrical equipment.
Page 285 Figure 226. Installing the SMP Cable 4. Install the front cover. For more information, see “Install the front cover on the model ” on page 311. 5. Reconnect all system power cables. Install the cords in the following order. See Figure 227 on page 274 for a description. a.
Page 286 Figure 227. Install power cords 6. “Start the system or logical partition” on page 300. 7. If you replaced the SMP processor cable as part of another procedure, return to that procedure now. If you replaced it because it was not functioning correctly, verify that the new cable is functional. See “Verify the installed part”...
Page 287: Chapter 8. Rio Or Gx Dual-Port 12X Channel Attach Adapteradapters And Cables
Chapter 8. RIO or GX Dual-Port 12X Channel Attach adapteradapters and cables The information and procedures in this topic are for remote input/output (RIO), or GX Dual-Port 12X Channel Attach adapter adapters and cables, including connector locations and installing, removing, or replacing the RIO or GX Dual-Port 12X Channel Attach adapter adapters.
Page 288 Attention: v Attach a wrist strap to an unpainted metal surface of your hardware to prevent electrostatic discharge from damaging your hardware. v When using a wrist strap, follow all electrical safety procedures. A wrist strap is for static control. It does not increase or decrease your risk of receiving electric shock when using or working on electrical equipment.
Page 289: Remove A Model Rio Or Gx Dual-Port 12X Channel Attach Adapter Adapter
12. Close the back rack door. 13. Start the system. See “Start the system or logical partition” on page 300. 14. Verify that the new resource is working correctly. For instructions, see “Verify the installed part” on page 319. Remove a model RIO or GX Dual-Port 12X Channel Attach adapter adapter Learn more about removing a model RIO or GX Dual-Port 12X Channel Attach adapter adapter.
Page 290: Replace A Model Rio Or Gx Dual-Port 12X Channel Attach Adapter Adapter
Figure 229. Removal of RIO or GX Dual-Port 12X Channel Attach adapter adapter in a model Replace a model RIO or GX Dual-Port 12X Channel Attach adapter adapter Learn more about replacing a model RIO or GX Dual-Port 12X Channel Attach adapter adapter. The following procedure describes the replacement of the model RIO or GX Dual-Port 12X Channel Attach adapter adapter.
Page 291 Attention: v Attach a wrist strap to an unpainted metal surface of your hardware to prevent electrostatic discharge from damaging your hardware. v When using a wrist strap, follow all electrical safety procedures. A wrist strap is for static control. It does not increase or decrease your risk of receiving electric shock when using or working on electrical equipment.
Page 292 Customer-Installable Features for the 17M/MA...
Page 293: Chapter 9. Voltage Regulator
Chapter 9. Voltage regulator You might need to remove or replace a voltage regulator. This section includes procedures so that you can perform these tasks. Replacing this feature is a customer task. You can perform this task yourself or contact a service provider to perform the task for you.
Page 294 A voltage regulator assembly can be removed with the system power on if, when you start the removal procedure, at least one more voltage regulator assembly is installed than the number of system processor assemblies installed. That is, one system processor assembly requires two voltage regulator assemblies to be installed, and two system processor assemblies require three voltage regulator assemblies to be installed.
Page 295: Install The Model Voltage Regulator Assembly With Power On
Select the appropriate instructions from this list: v “Install the model voltage regulator assembly with power on.” v “Remove and replace the model voltage regulator assembly with power on” on page 284. To remove and replace the voltage regulator assembly with the power on, you need to have at least one more voltage regulator assembly installed than the number of system processor assemblies installed.
Page 296: Remove And Replace The Model Voltage Regulator Assembly With Power On
8. “Install or replace the control panel with power on” on page 3. 9. “Install the front cover on the model ” on page 311. 10. Verify that the system processor assembly is functional. Refer to “Verify the installed part” on page 319.
Page 297: Replace The Model Voltage Regulator Assembly With Power On
2. If necessary, open the front rack door. 3. “Remove the front cover from the model ” on page 311. 4. Identify the voltage regulator assembly that you need to replace. For instructions, see “Identify a failing part” on page 299. 5.
Page 298: Install The Model Voltage Regulator Assembly With Power Off
c. When the voltage regulator assembly is almost all the way into the enclosure, rotate the latch up into the locked position. 3. “Install or replace the control panel with power on” on page 3. 4. “Install the front cover on the model ” on page 311. 5.
Page 299: Remove And Replace The Model Voltage Regulator Assembly With Power Off
6. Remove the voltage regulator assembly from its antistatic package. 7. Install the voltage regulator assembly by doing the following. a. Remove the space filler from the card slot. Press the thumb tab on the space filler, and pull the space filler from the card slot.
Page 300: Remove The Model Voltage Regulator Assembly With Power Off
If there is not one more voltage regulator assembly installed than the number of system processor assemblies installed, follow these steps: Remove the model voltage regulator assembly with power off You might need to remove a voltage regulator assembly with the system power off. Use the procedure in this section to perform this task.
Page 301: Replace The Model Voltage Regulator Assembly With Power Off
Replace the model voltage regulator assembly with power off You might need to replace a voltage regulator assembly with the system power off. Use the procedure in this section to perform this task. If your system is managed by the Hardware Management Console (HMC), you can use the HMC to complete the steps for replacing a voltage regulator module.
Page 302 Customer-Installable Features for the 17M/MA...
Page 303: Chapter 10. Common Procedures
Chapter 10. Common Procedures This section contains all the common procedures related to installing, removing and replacing features. Before you begin Understand prerequisites for installing, removing, or replacing features and parts. DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous.
Page 304 Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
Page 305: Managing The Advanced System Management Interface (Asmi)
Blue or terra-cotta on a part of the hardware indicates a touch point where you can grip the hardware to remove it from or install it in the system, open or close a latch, and so on. Terra-cotta might also indicate that the part can be removed and replaced with the system or logical partition power on.
Page 306 2. Select a PC or mobile computer that has Microsoft Internet Explorer 6.0, Netscape 7.1, or Opera 7.23 to connect to your server. If you do not plan to connect your server to your network, this PC or mobile computer will be your ASMI console.
Page 307: Setting The Ip Address On Your Pc Or Mobile Computer
Table 25. Fields and values for network configuration (continued) Field Value IP address This is a set IP address obtained from the network administrator Subnet mask This is a set subnet mask obtained from the network administrator Note: For information about the other fields and values, refer to “Configuring network interfaces” on page 297.
Page 308: Asmi Authority Levels
Setting the IP address in Linux To set the IP address in Linux, complete these steps. You will need the information from step 4 on page 294 in Accessing the ASMI using a Web Browser to complete step 4 in the following procedure. 1.
Page 309: Configuring Network Interfaces
During the initial administrator and general user logins, the only menu option available is Change Password. In order to gain access to additional ASMI menus, you must change the administrator and general user default passwords. If you are an authorized service provider, you cannot change your password.
Page 310: Changing The Time Of Day
2. In the navigation area, expand Network Services. 3. Select Network Configuration. Important: If you are attempting to configure a network connection on a multi-drawer system, you must select the primary or secondary service processor, and then click Continue. 4. In the right pane, locate the interface that you want to change. Select the box corresponding to the Configure this interface? field of the identified interface.
Page 311: Identify A Failing Part
3. Click Servers. A list of the servers managed by this HMC displays. 4. Select the server whose ASMI you want to access using the checkbox next to the managed server’s name. 5. Select Tasks > Operations > Advanced System Management (ASM). 6.
Page 312: Locate A Failing Part And Activate The Indicator Light
Locate a failing part and activate the indicator light If the service aids have been installed on a system or logical partition running Linux, you can use the instructions in this section to locate the failing part, and then activate the indicator light for that part. Locate a failing part in a Linux system or logical partition: If you do not know the location code of the failing part, use the instructions in this section to locate the failing part.
Page 313: Powering The System On And Off
2. Before you press the power button on the control panel, ensure that power is connected to the system unit as follows: v All system power cables are connected to a power source. v The power-on light F, as shown in the following figure, is slowly blinking. v The top of the display D, as shown in the following figure, shows 01 V=F.
Page 314: Start The System Or Logical Partition Using The Hardware Management Console
server to a state where it is ready to operate, which means the server is ready to install or boot an operating system. Firmware also enables the handling of exception conditions in the hardware and provides extensions to the functions of the server hardware platform. You can view the server’s current firmware level on the Advanced System Management Interface (ASMI) Welcome pane.
Page 315: Powering On A Managed System
For instructions on working with the HMC, see Powering on a Managed System, or you can also find instructions at Activating a partition using the HMC in the Logical Partitioning Guide (http:// www.ibm.com/servers/resourcelink/lib03030.nsf/pages/LogicalPartitioningGuide/$file/sa76- 0098.pdf#IPHBLACTIVATEP6). Progress indicators, also referred to as checkpoints, appear on the control panel display while the system is being started.
Page 316 Stop the system To stop a system, follow these steps: 1. Log in to the system as a user with the authority to run the shutdown or pwrdwnsys (Power Down System) command. 2. At the command line, enter one of the following commands: v If your system is running AIX, type shutdown.
Page 317: Stop The System Or Logical Partition Using The Hardware Management Console
Stop the system or logical partition using the Hardware Management Console You can use the Hardware Management Console (HMC) user interface to stop the system or a logical partition. For instructions on stopping the system, see Powering off a managed system, or you can also find instructions at Using a partition (http://www.ibm.com/servers/resourcelink/lib03030.nsf/pages/ LogicalPartitioningGuide/$file/sa76-0098.pdf#IPHBLUSINGI5OSP6).
Page 318: Remove The Front Cover On A Model 14G/3057/96
Figure 232. Front cover on a model 14G/3057/96 3. Push the cover onto the chassis and release the latches. The cover should securely snap into place. 4. Replace the two thumbscrews B into the slots on the left and right of the front cover. Remove the front cover on a model 14G/3057/96 You might need to remove the front cover to perform service to the system.
Page 319: Remove The Front Cover From The 11D/1157/91 Or 57/94 Expansion Unit
Figure 233. Front cover for model 14G/3057/96 2. Press in on the two latches C located left and right of the cover to release the cover. 3. Lift the cover A out and away from the chassis. Tip: If an air flow block is present on an unpopulated side of the chassis do not remove it unless you are populating that side of the chassis.
Page 320: Install The Front Cover On The 11D/1157/91 Or 57/94 Expansion Unit
2. Pull in the knobs on the left and right of the front cover as shown in the following figure: 3. Pull the cover out and away from the expansion unit. Install the front cover on the 11D/1157/91 or 57/94 expansion unit You might need to install the cover after accessing components or performing service.
Page 321: Front Cover
1. Position the cover on the front of the expansion unit so that the pins on the cover line up with the slots on the front of the expansion unit as shown in the following figure: 2. Pull in the knobs on the left and right of the front cover. 3.
Page 322: Install The Front Cover On The 11D/20 Expansion Unit
4. Pivot the cover from the bottom and swing the top of the cover out. 5. Pull the bottom of the cover up and then away from the expansion unit. This releases the two tabs located on the bottom of the cover. 6.
Page 323: Remove The Front Cover From The Model
Remove the front cover from the model You might need to remove the cover to access components or perform service. Use the procedure in this section to accomplish this task. To remove the front cover follow these steps: 1. If necessary, open the front rack door. 2.
Page 324: Place The Rack-Mounted System Or Expansion Unit In The Service Position Or Operating Position
2. Tighten the thumbscrew on the right side of the cover. 3. Close the front rack door. Place the rack-mounted system or expansion unit in the service position or operating position You might need to place a system or expansion unit into the service position or operating position to perform service or gain access to internal components.
Page 325 DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 326 Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
Page 327 3. Release the rack latches A on both the left and right sides as shown in the following figure. 4. Review the following note, and then slowly pull the system or expansion unit out from the rack until the rails are fully extended and locked. Note: Chapter 10.
Page 328: Place The Rack-Mounted System Or Expansion Unit In The Operating Position
v If the procedure you are performing requires you to unplug cables from the back of the system or expansion unit, do so before you pull the unit out from the rack. v Ensure that the cables at the rear of the system or expansion unit do not catch or bind as you pull the unit out from the rack.
Page 329 2. Replace and tighten the two thumbscrews B that secure the system or expansion unit A to the rack as shown in the following figure. 3. Close the front rack door. Chapter 10. Common Procedures...
Page 330: Viewing Existing Firmware Levels
Viewing existing firmware levels Find out how to view the level of firmware that currently runs on your server. You can view the current and backup levels of server firmware on the managed system. Using the HMC to view the existing firmware levels Learn how to view the level of firmware that currently runs on your server using the HMC.
Page 331: Exchange A Part Using The Hardware Management Console
Remove a part using the HMC Version 7 or later 1. In the navigation area, expand Systems Management. 2. Expand Servers. 3. Select the managed system from which you are removing a part. 4. In the Tasks area expand Serviceability. 5.
Page 332: Verify An Installed Feature Or Replaced Part On An Aix System Or Logical Partition
Verify an installed feature or replaced part on an AIX system or logical partition If you installed feature or replaced a part you might want to use the tools in AIX to verify that the feature or part is recognized by the system or logical partition. Use the procedure in this section to accomplish this task.
Page 333 If the system is partitioned, note the logical partition in which you replaced the part. Contact your service provider for assistance. 4. At the command prompt, type diag —a and press Enter to check for missing resources. If you see a command prompt, go to step 5.
Page 334: Using The Hmc To Perform A Slow Boot
resource has an entry in the AIX error log, if the test on the resource was successful, the Resource Repair Action menu appears. After replacing that part, you must select the resource for that part from the Resource Repair Action menu. This updates the AIX error log to indicate that a system-detectable part has been replaced.
Page 335: Using The Control Panel To Collect Reference Codes And System Information
10. After you are done, return to the step in the procedure that caused you to perform a slow boot. This ends the procedure. Using the control panel to collect reference codes and system information Learn how to use the control panel to collect reference codes and other system information. Follow these steps to collect reference codes and system information (functions 11 through 20) using the control panel: 1.
Page 336: Changing Service Indicators
3. If you have a console with Type and Reference Code columns on it, record the data under the Type column as the first 4 characters of function 11 on the problem reporting form. If an A, B, C, or D is displayed as the first character in the Type column, use the data in the Reference Code column as the last 4 characters of function 11.
Page 337 information on running diagnostics from the Network Installation Management (NIM) server, see “Running stand-alone diagnostics from a Network Installation Management server” on page 326. Prerequisites v If this server is directly attached to another server or attached to a network, be sure communication with the other servers is stopped.
Page 338: Running Stand-Alone Diagnostics From A Network Installation Management Server
a. Select Identify and Attention Indicators from the Task Selection menu to turn off the system attention and indicator lights. Press Enter. b. Select Set System Attention Indicator to NORMAL and press Enter. c. Select Set All Identify Indicators to NORMAL and press Enter. d.
Page 339 Note: The ClientName is the name of the system on which you want to run stand-alone diagnostics. System response Client status #name:Cstate:ClientName:diagnostic boot has been The client system is registered on the NIM server and enabled: enabled to run diagnostics from the NIM server. #name:Cstate:ClientName:ready for a NIM operation:or The client is registered on the NIM server but not #name:Cstate:ClientName:B0S installation has been...
Page 340: Verify The Presence Of An Installed Part Using Hardware Management Console (Hmc)
Note: If the ping fails, refer to the ″Troubleshooting NIM″ section of the AIX Installation and Migration guide (http://publib.boulder.ibm.com/infocenter/pseries/v5r3/topic/ com.ibm.aix.install/doc/insgdrf/insgdrf.pdf) 12. Exit the SMS Main screen. 13. Select Select Boot Options → Install or Boot a Device → Network. 14. Record the current bootlist settings. You will need to set the bootlist back to the original settings after running diagnostics from the NIM server.
Page 341: Viewing Serviceable Events
5. Select and highlight the service action event from the Error Associated With This Serviceable Event window. 6. Click Close Event. 7. Add comments for the serviceable event. Include any unique additional information. Click OK. 8. Did you replace, add, or modify a FRU of the open service action event? v No: Select the No FRU Replaced for this Serviceable Event option and click OK to close the service action event.
Page 342: Deactivate A System Attention Led Or Partition Led
v “Activate or deactivate identify LED” Deactivate a system attention LED or partition LED You can deactivate a system attention LED or a logical partition LED. For example, you might determine that a problem is not a high priority and decide to repair the problem at a later time. However, you want to be alerted if another problem occurs, so you must deactivate the system attention LED so that it can be activated again if another problem occurs.
Page 343: Squadrons Common Content
Squadrons Common content Attention: v Attach a wrist strap to an unpainted metal surface of your hardware to prevent electrostatic discharge from damaging your hardware. v When using a wrist strap, follow all electrical safety procedures. A wrist strap is for static control. It does not increase or decrease your risk of receiving electric shock when using or working on electrical equipment.
Page 344 CAUTION: The battery is a lithium ion battery. To avoid possible explosion, do not burn. Exchange only with the approved part. Recycle or discard the battery as instructed by local regulations. (C007a) CAUTION: This part or unit is heavy but has a weight smaller than 18 kg (39.7 lb). Use care when lifting, removing, or installing this part or unit.
Page 345 CAUTION: The system contains circuit cards, assemblies, or both that contain lead solder. To avoid the release of lead (Pb) into the environment, do not burn. Discard the circuit card as instructed by local regulations. (C014) CAUTION: Refrigeration components are pressurized. Eye protection must be worn when servicing the Modular Cooling System (MCS).
Page 346 CAUTION: This product might contain one or more of the following devices: CD-ROM drive, DVD-ROM drive, DVD-RAM drive, or laser module, which are Class 1 laser products. Note the following information: v Do not remove the covers. Removing the covers of the laser product could result in exposure to hazardous laser radiation.
Page 347 CAUTION: To reduce the risk of fire, use only No. 26 AWG or larger (for example, 24 AWG) UL-listed or CSA certified telecommunication line cord. (C035) DANGER To prevent a possible shock from touching two surfaces with different protective ground (earth), use one hand, when possible, to connect or disconnect signal cables.
Page 348 When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 349 Uninterruptible power supply (UPS) units contain specific hazardous materials. Observe the following precautions if your product contains a UPS: v The UPS contains lethal voltages. All repairs and service must be performed only by an authorized service support representative. There are no user serviceable parts inside the UPS. v The UPS contains its own energy source (batteries).
Page 350 (L004) (L005) (L006) (L007) Customer-Installable Features for the 17M/MA...
Page 351 (L008) (L009) (L010) (L011) Chapter 10. Common Procedures...
Page 352 (L012) (L013) Customer-Installable Features for the 17M/MA...
Page 353 DANGER Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
Page 354 CAUTION: Removing components from the upper positions in the rack cabinet improves rack stability during relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a room or building: v Reduce the weight of the rack cabinet by removing equipment starting at the top of the rack cabinet.
Page 355: Chapter 11. Upgrades
Chapter 11. Upgrades You can migrate or upgrade AIX to a new release, upgrade your server model to a new servers model, or upgrade to a new hardware feature. Upgrade concepts Learn about supported upgrade paths, upgrade considerations, and upgrade terminology. An upgrade is the process of changing from one server model, hardware feature, or software version to a new servers model, hardware feature, or software version while retaining the serial number of the source server.
Page 356 The following timeline describes common stages that occur during an upgrade. The timeline incorporates the entire process from when you first start planning for an upgrade until the time when you have finished preparing your target server for production. Listed next to each stage are more detailed descriptions that describe what the stage entails and what must be accomplished when you have finished the stage.
Page 357 Table 26. Upgrade stages (continued) Stage Stage description Time required Preinstallation Tasks in this stage include the following: 1 day v Examine what you have done so far and determine whether you are now ready for the upgrade. v Gather all necessary server information for the authorized service provider.
Page 358: Upgrade Considerations
If you do not plan for the removal or replacement of unsupported I/O devices but realize during your upgrade that you have unsupported I/O devices, you must remove those devices, and perhaps replace those devices with supported I/O devices, which increases your timeline. v Unsupported software If your software is not properly planned, it might add several unexpected hours by forcing you to reschedule your upgrade to another time, or require that your upgrade be removed and rescheduled,...
Page 359: Upgrading The Server
Before you begin __ The following checklist is broken into stages. Ensure that you understand the stages involved when upgrading your server before completing this checklist. To understand the basics of each stage and where certain tasks will fall, see “Upgrade timeline” on page 343. Server upgrade tasks Responsibility __ “Upgrade planning tasks”...
Page 360: Upgrade Planning Tasks
you have finished preparing your target server for production. These tasks are also separated into various stages, which are described in the upgrades concepts topic. See “Upgrade timeline” on page 343 for information about what each upgrade stage entails. To see all of these tasks, including who is responsible for each task, in a checklist format, see the “Upgrade checklist”...
Page 361: Validating Your Order
Your reseller assists you when using the configurator tool. Related concepts “Upgrade checklist” on page 346 Use this checklist as a guide to complete your upgrade. The checklist contains a list of tasks for upgrading your server and also lists who is responsible for each task. Validating your order Ensure that your order is complete.
Page 362: Preparation Tasks
Place your order with your reseller or authorized service provider after you have configured and validated it. Your reseller or authorized service provider ensures that your order has been properly placed and that everything is correct. They also ensure that you sign your contract. Your reseller or authorized service provider confirms with you what parts or features will be returned at the conclusion of the upgrade.
Page 363: Developing Your Test Plan
If your target server or partition has already been set up and you realize there is inadequate processor or memory, you can adjust these without having to re-create the partition. If the target server has fewer processors than the source server, you must adjust the configuration on the source server to reflect the target server’s processing resources.
Page 364: Scheduling Your Acceptance Review
“Upgrade checklist” on page 346 Use this checklist as a guide to complete your upgrade. The checklist contains a list of tasks for upgrading your server and also lists who is responsible for each task. Scheduling your acceptance review Understand why you need an acceptance review and who should be involved. The acceptance review is a meeting where you can evaluate whether the hardware configuration matches your plan.
Page 365: System Backup Requirements
System backup requirements Understand the options to back up your current server before you perform an upgrade. Before performing an upgrade, you can back up your server using a mksysb image or alternate disk installation. Before you perform any upgrade tasks, verify that you have a current system backup in the AIX environment of your rootvg and all of your data.
Page 366: Running The Aix Pre_Migration Command
Discuss your target hardware configuration with your reseller or marketing representative. Focus on any changes that you want to make because they need to be examined to determine if additional services are required and if they might cause any problems with the configuration. In the event that you experience problems during an upgrade, ensure that you understand your recovery or installation backout plan when reviewing your contingency plans.
Page 367: Saving Your Existing Partition Profiles From A Hardware Management Console
“Upgrade checklist” on page 346 Use this checklist as a guide to complete your upgrade. The checklist contains a list of tasks for upgrading your server and also lists who is responsible for each task. Saving your existing partition profiles from a Hardware Management Console Saving your existing partition profiles allows for an easier restoration of your partitions following your upgrade.
Page 368: Updating Aix With A New Maintenance Level
Updating AIX with a new maintenance level Your current version and release of AIX must match the level of AIX to which you are updating. Learn how to update your current maintenance level of AIX. Attention: This procedure requires that you restart AIX. Whenever you restart AIX, schedule your downtime when it least impacts your workload to protect yourself from a possible loss of data or functionality.
Page 369: Migrating Aix To A New Version Or Release
When you press Enter to start the installation, the COMMAND STATUS panel is displayed. As the installation proceeds, a series of messages is displayed. The amount of time that the installation takes varies depending on your server and the software that you are installing and updating. When the installation is complete, the panel returns to the top of the list of messages that are displayed during installation.
Page 370 Attention: This procedure requires shutting down and reinstalling the base operating system. Whenever you reinstall any operating system, schedule your downtime when it least impacts your workload to protect yourself from a possible loss of data or functionality. Before you perform a migration installation, ensure that you have reliable backups of your data and any customized applications or volume groups.
Page 371 1. Verify that migration is the method of installation. If migration is not already selected as the method of installation, select it now. Select the disk or disks that you want to install. 1 System Settings: Method of Installation.....Migration Disk Where You Want to Install..hdisk0 2.
Page 372: Backing Up Aix To A Cd
Related concepts “Upgrade checklist” on page 346 Use this checklist as a guide to complete your upgrade. The checklist contains a list of tasks for upgrading your server and also lists who is responsible for each task. Related information Creating system backups (http://publib.boulder.ibm.com/infocenter/pseries/v5r3/topic/com.ibm.aix.install/doc/insgdrf/ create_sys_backup.htm) Migrating AIX...
Page 373: Restoring An Aix System Backup From A Cd
9. Select No for the Remove final images after creating CD option. 10. Select No for the Create the CD now option. 11. Press Enter to begin the system backup creation when you finish making selections. When the operation completes successfully, there is a file or files located in the /mkcd/cd_images directory. 12.
Page 374 Firmware ------------------------------------------------------------------------------- Main Menu 1. Select Language 2. Setup Remote IPL (Initial Program Load) 3. Change SCSI Settings 4. Select Console 5. Select Boot Options ------------------------------------------------------------------------------- Navigation Keys: X = eXit System Management Services ------------------------------------------------------------------------------- Type the number of the menu item and press Enter or select Navigation Key: 5 2.
Page 375: Testing Your Server
System Backup Installation Summary Disks: hdisk0 Use Physical Location Maps: No Shrink File System: No Import User Volume Groups: Yes Recover Devices: No >>> 1 Continue with Install 88 Help ? 99 Previous Menu >>> Choice [1]: 1 5. Type 1 in the Choice field, and then press Enter to confirm the installation options and begin the installation.
Page 376 Customer-Installable Features for the 17M/MA...
Page 377: Appendix. Accessibility Features
Appendix. Accessibility features Accessibility features help users who have a physical disability, such as restricted mobility or limited vision, to use information technology products successfully. The following list includes the major accessibility features: v Keyboard-only operation v Interfaces that are commonly used by screen readers v Keys that are tactilely discernible and do not activate just by touching them v Industry-standard devices for ports and connectors v The attachment of alternative input and output devices...
Page 378 Customer-Installable Features for the 17M/MA...
Page 379: Notices
Notices This information was developed for products and services offered in the U.S.A. The manufacturer may not offer the products, services, or features discussed in this document in other countries. Consult the manufacturer’s representative for information on the products and services currently available in your area.
Page 380: Trademarks
The manufacturer’s prices shown are the manufacturer’s suggested retail prices, are current and are subject to change without notice. Dealer prices may vary. This information is for planning purposes only. The information herein is subject to change before the products described become available. This information contains examples of data and reports used in daily business operations.
Page 381 equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense. Properly shielded and grounded cables and connectors must be used in order to meet FCC emission ®...
Page 382 This product is a Class A Information Technology Equipment and conforms to the standards set by the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.
Page 383: Terms And Conditions
Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG zur Angleichung der Rechtsvorschriften über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse A ein. Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben.
Page 384 Except as expressly granted in this permission, no other permissions, licenses or rights are granted, either express or implied, to the publications or any data, software or other intellectual property contained therein. The manufacturer reserves the right to withdraw the permissions granted herein whenever, in its discretion, the use of the publications is detrimental to its interest or, as determined by the manufacturer, the above instructions are not being properly followed.
Page 385 If you require a written reply, please include your complete mailing address below. NAME : Date : COMPANY : ADDRESS : Please give this technical publication remarks form to your BULL representative or mail to: ept. Bull - Documentation D 1 Rue de Provence BP 208...
Page 386 : The latest revision will be provided if no revision number is given. [ _ _ ] NAME: Date: COMPANY: ADDRESS: PHONE: FAX: E-MAIL: For Bull Subsidiaries: Identification: For Bull Affiliated Customers: Customer Code: For Bull Internal Customers: Budgetary Section: For Others: Please ask your Bull representative.
Page 387 BLANK...
Page 388 BULL CEDOC 357 AVENUE PATTON B.P.20845 49008 ANGERS CEDEX 01 FRANCE REFERENCE 86 A1 36EV 01...

Bull ESCALA POWER6 PL1660R Manual

Safety Notices

About this Publication

Chapter 1. Control Panel, Signal Cable, or Control Panel Fillers

Chapter 2. Disk Drive

Chapter 3. Expansion Units

Chapter 4. PCI Adapter

Chapter 5. Media Device

Chapter 6. Installing Rack Features

Chapter 7. Backplanes and Cards

Chapter 8. RIO or GX Dual-Port 12X Channel Attach Adapteradapters and Cables

Chapter 9. Voltage Regulator

Chapter 10. Common Procedures

Chapter 11. Upgrades

Quick Links

Related Manuals for Bull ESCALA POWER6 PL1660R

Summary of Contents for Bull ESCALA POWER6 PL1660R
