Managing PCI
Adapters
REFERENCE
86 A1 58EV 04

Advertisement

Table of Contents
loading

Related Manuals for Bull Escala Power6

Summary of Contents for Bull Escala Power6

  • Page 1 Managing PCI Adapters REFERENCE 86 A1 58EV 04...
  • Page 3 ESCALA Managing PCI Adapters Hardware November 2008 BULL CEDOC 357 AVENUE PATTON B.P.20845 49008 ANGERS CEDEX 01 FRANCE REFERENCE 86 A1 58EV 04...
  • Page 4 Quoting of brand and product names is for information purposes only and does not represent trademark misuse. The information in this document is subject to change without notice. Bull will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material.

  • Page 5: Table Of Contents

    Contents Safety notices ....... . vii About this publication ......ix How to send your comments .
  • Page 6 Chapter 20. 4 Gigabit PCI Express Single Port Fibre Channel Adapter (FC 5773; CCIN 5773) ........73 Chapter 21.
  • Page 7 Chapter 43. 8-Port asynchronous EIA-232E/RS-422A PCI Adapter (FC 2943) ..157 Chapter 44. 64-bit/66MHz PCI ATM 155 UTP Adapter (FC 4953) ... 159 Chapter 45. PCI-X Cryptographic Coprocessor (FC 4764; CCIN 4764) ..161 Chapter 46.
  • Page 8 Managing PCI Adapters...

  • Page 9: Safety Notices

    Safety notices Safety notices may be printed throughout this guide. v DANGER notices call attention to a situation that is potentially lethal or extremely hazardous to people. v CAUTION notices call attention to a situation that is potentially hazardous to people because of some existing condition.
  • Page 10 Power and cabling information for NEBS (Network Equipment-Building System) GR-1089-CORE The following comments apply to the servers that have been designated as conforming to NEBS (Network Equipment-Building System) GR-1089-CORE: The equipment is suitable for installation in the following: v Network telecommunications facilities v Locations where the NEC (National Electrical Code) applies The intrabuilding ports of this equipment are suitable for connection to intrabuilding or unexposed wiring or cabling only.

  • Page 11: About This Publication

    About this publication This publication contains reference information that information technology (IT) personnel and service representatives can use to learn about using and managing Peripheral Component Interconnect (PCI) adapters. You can also find specifications and installation notes for specific adapters in this publication. For information about the accessibility features of this product, for users who have a physical disability, see “Accessibility features,”...
  • Page 12 Managing PCI Adapters...

  • Page 13: Chapter 1. Managing Pci Adapters

    Chapter 1. Managing PCI adapters Learn about using and managing Peripheral Component Interconnect (PCI) adapters. Find specifications and instructions for specific adapters. The adapter information shown here is used during nondirected service activities. This information is used to: v Identify an adapter v Find specific technical information about an adapter v Where applicable, show special installation or cabling instructions v Show signal names for the output pins of the adapter connectors...
  • Page 14 Table 1. PCIe slot compatibility x1 slot x4 slot x8 slot x16 slot x1 adapter Supported Supported Supported Supported x4 adapter Not supported Supported Supported Supported x8 adapter Not supported Not supported Supported Supported Not supported Not supported Not supported Supported x16 adapter Safety information...
  • Page 15 To prevent a possible shock from touching two surfaces with different protective ground (earth), use one hand, when possible, to connect or disconnect signal cables. (D001) Note: This system might be equipped with a second power supply. Before continuing with this procedure, ensure that the power source to the system has been completely disconnected.
  • Page 16 v If you need to lay the device down while it is out of the antistatic bag, lay it on the antistatic bag. Before picking it up again, touch the antistatic bag and the metal frame of the system at the same time. v Handle the devices carefully to prevent permanent damage.

  • Page 17: Chapter 2. 10 Gigabit Ethernet-Sr Pci Express Adapter (Fc 5771; Ccin 576D)

    Chapter 2. 10 Gigabit Ethernet-SR PCI Express Adapter (FC 5771; CCIN 576D) Learn about the features, operating system requirements, and installation notes for the 5771 adapter. Overview The 10 Gigabit Ethernet-SR PCI Express Adapter is a low-profile, fiber, network interface controller (NIC). This adapter is based on the dual port 82598 EB 10 GbE controller.
  • Page 18 Wrap plug LC fiber optic, part number 12R9314 Cables Customers supply the cables. Optional LC-SC 62.5 micron converter cable, part number 12R9322, FC 2459, is available. For 50 micron LC-SC connections, use converter cable part number 12R9321, FC 2456. Operating system or partition requirements The 10 Gigabit Ethernet-SR PCI Express Adapter and 10 Gigabit Ethernet-LR PCI Express Adapter are ®...
  • Page 19 Table 3. 10 Gigabit Ethernet-LR PCI Express Adapter cable information Fiber cable type Connector type Operating range in meters 9 µm SMF 10 Km Verifying your software requirements Ensure that your operating system supports this adapter before you install it. See “Operating system or partition requirements”...
  • Page 20 v For the 10 Gigabit Ethernet-LR PCI Express Adapter, type devices.pciex.8680c71014108003.rte 9. Press Enter. The system finds and highlights this device driver software. 10. Press F7 to select the highlighted device driver software. 11. Press Enter. The INSTALL ADDITIONAL DEVICE SOFTWARE window is shown. The entry fields are automatically updated.
  • Page 21 3. Press Enter. A list of PCI devices are displayed. If the adapter is installed correctly, an Available status for each port indicates that the adapter is installed and ready to use. If the message on your screen indicates that any of the ports are DEFINED instead of AVAILABLE, shut down your server and verify that the adapter was installed correctly.
  • Page 22 Managing PCI Adapters...

  • Page 23: Chapter 3. 10 Gigabit Ethernet-Lr Pci Express Adapter (Fc 5772; Ccin 576E)

    Chapter 3. 10 Gigabit Ethernet-LR PCI Express Adapter (FC 5772; CCIN 576E) Learn about the features, operating system requirements, and installation notes for the 5772 Adapter. Overview The 10 Gigabit Ethernet-LR PCI Express Adapter is a low-profile, fiber network interface controller (NIC). This adapter is based on the dual port 82598EB 10 GbE controller.
  • Page 24 Cables Customers supply the cables. Operating system or partition requirements The 10 Gigabit Ethernet-SR PCI Express Adapter and 10 Gigabit Ethernet-LR PCI Express Adapter are supported on the following versions of the AIX operating system: v AIX 5L Version 5.3 with the 5300-07 Technology Level and Service Pack 4, or later v AIX 5L Version 5.3 with the 5300-08 Technology Level, or later v AIX Version 6.1 with the 6100-00 Technology Level and Service Pack 5, or later v AIX Version 6.1 with the 6100-01 Technology Level, or later...

  • Page 25: Chapter 4. 10 Gb Ethernet-Sr Pci-X 2.0 Ddr Adapter (Fc 5721; Ccin 573A)

    Chapter 4. 10 Gb Ethernet-SR PCI-X 2.0 DDR Adapter (FC 5721; CCIN 573A) Learn about the features, operating system requirements, and installation notes for the 10 Gb Ethernet-SR PCI-X 2.0 DDR Adapter. Overview The 10 Gb Ethernet-SR PCI-X 2.0 DDR Adapter is designed to provide a PCI-X based server connection. The adapter conforms to the IEEE 802.3ae 10 Gigabit Ethernet standard and supports jumbo frames.
  • Page 26 Preparing for installation This section helps you prepare to install your adapter. Preparing to install the adapter involves the following tasks: v Verifying your hardware requirements v Verifying your software requirements v Gathering tools and documentation If you are installing your operating system at this time, install your adapter before you install the operating system.
  • Page 27 v If you should install your device driver software first, go to step 1 of this section. v If you should install your adapter hardware first, go to “Installing the adapter” on page 16. When you install AIX 5L, your adapter device driver automatically installs. If you already have a supported level of AIX 5L installed, the device driver is already installed and you can go to “Installing the adapter”...
  • Page 28 Fileset Level State Description Path: /usr/lib/objrepos 5.2.xx COMMITTED Ethernet adapter software devices.pci.1410EB02.rte Verify that the devices.pci.1410EB02.rte filesets are installed at the AIX 5L version 5.2 with the 5200-08 Recommended Maintenance package or later level. If this information displays but you continue to have problems, go to “Installing the adapter.”...
  • Page 29 Table 6. Adapter LEDs (continued) Light Description No activity Blinking green Receive activity Link No link Green Link established Chapter 4. 10 Gb Ethernet-SR PCI-X 2.0 DDR Adapter (FC 5721; CCIN 573A)
  • Page 30 Managing PCI Adapters...

  • Page 31: Chapter 5. 10 Gb Ethernet-Lr Pci-X 2.0 Ddr Adapter (Fc 5722; Ccin 576A)

    Chapter 5. 10 Gb Ethernet-LR PCI-X 2.0 DDR Adapter (FC 5722; CCIN 576A) Learn about the features, operating system requirements, and installation notes for the 10 Gb Ethernet-LR PCI-X 2.0 DDR Adapter. Overview The 10 Gb Ethernet-LR PCI-X 2.0 DDR Adapter is designed to provide a PCI-X based server connection. The adapter conforms to the IEEE 802.3ae 10 Gigabit Ethernet standard and supports Jumbo frames.
  • Page 32 If you are installing your operating system at this time, install your adapter before you install the operating system. See “Installing the adapter” on page 22 for instructions. If you are installing only the device driver for this adapter, install your device driver software before you install the adapter.
  • Page 33 2. Insert the media containing the device driver software (for example; CD-ROM) into the appropriate media device. 3. Type the following System Management Interface Tool (SMIT) fast path: smitty devinst 4. Press Enter. The Install Additional Device Software screen highlights the INPUT device/directory for software option.
  • Page 34 If no data displays on your screen, the adapter device driver did not install correctly. Try reinstalling the driver. Installing the adapter Refer to the customer-installable features publication for instructions on installing PCI adapters. After you have installed the adapter, continue on to Verifying the adapter installation. Verifying the adapter installation To verify that your system unit recognizes the PCI adapter, do the following steps: 1.

  • Page 35: Chapter 6. 2-Port 10/100/1000 Base-Tx Ethernet Pci-X Adapter (Fc 1983, 1990, 5706; Ccin 5706)

    Chapter 6. 2-Port 10/100/1000 Base-TX Ethernet PCI-X Adapter (FC 1983, 1990, 5706; CCIN 5706) Learn about the specifications and LEDs for the 2-Port 10/100/1000 Base-TX Ethernet PCI-X Adapter. The 2-Port 10/100/1000 Base-TX Ethernet PCI-X Adapter is a full duplex, dual ported, gigabit Ethernet adapter that can be configured to run each port at 10, 100, or 1000 Mbps data rates.
  • Page 36 Adapter Specifications Item Description FRU number 5706 is 03N5297 or 00P6131 1983 is 03N5298 or 80P6450 1990 is 03N5531 or 03N4701 (low profile bracket) Designed to comply with RoHS requirement. Not designed to comply with the RoHS requirement. I/O bus architecture PCI 2.2 and PCI-X V1.0a compliant Busmaster Maximum number...

  • Page 37: Chapter 7. Dual Port Gigabit Ethernet-Sx Pci-X Adapter (Fc 5707; Ccin 5707)

    Chapter 7. Dual port gigabit Ethernet-SX PCI-X Adapter (FC 5707; CCIN 5707) Learn about the specifications and LEDs for the dual port gigabit Ethernet-SX PCI-X Adapter. The dual port gigabit Ethernet-SX PCI-X Adapter is a high-performance, highly integrated, universal, Ethernet LAN adapter for PCI-X and PCI systems. The adapter presents one electrical load but appears as two independent devices to software.
  • Page 38 I/O bus architecture PCI 2.2 and PCI-X V1.0a compliant Busmaster Maximum number For system-specific adapter placement information, see the PCI adapter placement or the PCI adapter placement. Adapter size PCI short form Connector information LC fiber optic Wrap plug LC fiber optic, part number 12R9314 Cables Customer supplied.

  • Page 39: Chapter 8. Gigabit Ethernet-Sx Pci-X Adapter (Fc 6800, 5700; Ccin 5700)

    Chapter 8. Gigabit Ethernet-SX PCI-X Adapter (FC 6800, 5700; CCIN 5700) Learn about the specifications and LEDs for the Gigabit Ethernet-SX PCI-X Adapter. The Gigabit Ethernet-SX PCI-X Adapter is a high-performance, highly integrated, universal, Ethernet LAN adapter for PCI-X and PCI systems. The adapter provides 1000 Mbps throughput on a standard shortwave (850 nm) 50 or 62.5 micron multimode optical cable and conforms to the IEEE 802.3z standards and supports distances of 260 meters for 62.5u MMF and 550 meters for 50.0u MMF.
  • Page 40 Maximum number For system-specific adapter placement information, see the PCI adapter placement or the PCI adapter placement. . Adapter size PCI short form Connector information LC fiber optic Wrap plug LC fiber optic, part number 12R9314 Cables Customer supplied. Optional LC-SC converter cables are available: v LC-SC 62.5 micron converter cable , part number 12R9322, FC 2459 v LC-SC 50 micron use converter cable, part number 12R9321, FC 2456 Managing PCI Adapters...

  • Page 41: Chapter 9. 4-Port 10/100 Base-Tx Ethernet Pci Adapter (Fc 4961)

    Chapter 9. 4-Port 10/100 Base-TX Ethernet PCI Adapter (FC 4961) Learn about specifications and LEDs for the 4-Port 10/100 Base-TX Ethernet PCI Adapter. The 4-Port 10/100 Base-TX Ethernet PCI Adapter provides attachment at 10 Mbps or 100 Mbps to a carrier sense multiple access/collision detection (CSMA/CD) Ethernet local area network (LAN) for systems designed to operate with the PCI bus interface.
  • Page 42 Figure 8. Adapter LEDs Managing PCI Adapters...

  • Page 43: Chapter 10. 4-Port 10/100/1000 Base-Tx Pci-X Adapter (Fc 5740, 1954)

    Chapter 10. 4-Port 10/100/1000 Base-TX PCI-X Adapter (FC 5740, 1954) Learn about the features, operating system requirements, and installation notes for the 4-Port 10/100/1000 Base-TX PCI-X Adapter. Overview The 4-Port 10/100/1000 Base-TX PCI-X Adapter is a 64-bit Ethernet card. It is a full height PCI-X 1.0a adapter, which supports four gigabit ports on a single adapter delivering increased bandwidth for PCI-X slot-constrained systems.
  • Page 44 Figure 9. 4-Port 10/100/1000 Base-TX PCI-X adapter Operating system or partition requirements AIX 5L Version 5.3 with the 5300-04 Technology Level, or later AIX 5L Version 5.2 with the 5200-08 Technology Level, or later Red Hat Enterprise Linux version 4 U2, or later SUSE Linux Enterprise Server 9 SP3, or later Preparing for installation This section helps you prepare to install your 4-Port 10/100/1000 Base-TX PCI-X adapter.
  • Page 45 Verifying Your Software Requirements Ensure that your operating system supports this adapter before you install it. See “Operating system or partition requirements” on page 32. Gathering tools and documentation To install the 4-Port 10/100/1000 Base-TX PCI-X adapter, make sure you have access to the following steps: The 4-Port 10/100/1000 Base-TX PCI-X adapter v The operating system documentation...
  • Page 46 10. Press F7 to select the highlighted device driver software. 11. Press Enter. The INSTALL ADDITIONAL DEVICE SOFTWARE screen displays. The entry fields are automatically updated. 12. Press Enter to accept the information. The ARE YOU SURE window displays. 13. Press Enter to accept the information. The COMMAND STATUS screen displays. v The term RUNNING is highlighted to indicate that the installation and configuration command is in progress.
  • Page 47 A list of PCI devices displays. If the 4-Port 10/100/1000 Base-TX PCI-X adapter is installed correctly, an available status for each port indicates that the adapter is installed and ready to use. If the message on your screen indicates that any of the ports is DEFINED instead of AVAILABLE, shut down your server and verify that the adapter was installed correctly.
  • Page 48 Managing PCI Adapters...

  • Page 49: Chapter 11. 2-Port 10/100/1000 Base-Tx Ethernet Pci Express Adapter (Fc 5767; Ccin 5767)

    Chapter 11. 2-Port 10/100/1000 Base-TX Ethernet PCI Express Adapter (FC 5767; CCIN 5767) Learn about features, requirements, and specifications for the 2-Port 10/100/1000 Base-TX Ethernet PCI Express Adapter. The 2-Port 10/100/1000 Base-TX Ethernet PCI Express Adapter is a full duplex, dual ported, gigabit Ethernet adapter.
  • Page 50 Maximum number For system-specific adapter placement, see the PCI adapter placement or PCI adapter placement. Adapter size PCIe short form Connector information v Two RJ-45 ports v Two LED adapter status indicators per port, for link activity and speed Wrap plug RJ-45, part number 10N7405 Cabling Customers supply their own cables.

  • Page 51: Chapter 11. 2-Port 10/100/1000 Base-Tx Ethernet Pci Express Adapter (Fc 5767; Ccin

    Operating system or partition requirements The adapter is supported under the following operating systems: v AIX 5L Version 5.3 with the 5300-06 Technology Level or later v AIX 5L Version 5.2 with the 5200-10 Technology Level or later v Red Hat Enterprise Linux version 4, update 5 v Red Hat Enterprise Linux version 5 v SUSE Linux Enterprise Server 9, SP4 v SUSE Linux Enterprise Server 10, SP1...
  • Page 52 Installing the device driver software This section explains how to install device driver software. The device driver is provided for the AIX 5L operating system on the AIX base operating system CD, which includes the device driver, or the AIX device driver CD.

  • Page 53: Chapter 11. 2-Port 10/100/1000 Base-Tx Ethernet Pci Express Adapter (Fc 5767; Ccin

    Installing the adapter This section explains how to install the adapter. If you are installing the operating system at this time, install the adapter before you install the operating system. If the operating system is already installed and you need to install the device driver for this adapter, install the device driver software before you install the adapter.
  • Page 54 Managing PCI Adapters...

  • Page 55: Chapter 12. 2-Port Gigabit Ethernet-Sx Pci Express Adapter (Fc 5768; Ccin 5768)

    Chapter 12. 2-Port Gigabit Ethernet-SX PCI Express Adapter (FC 5768; CCIN 5768) Learn about features, requirements, and specifications for the 5768 adapter. The 2-Port Gigabit Ethernet-SX PCI Express Adapter provides two 1 Gbps (1000 Base-SX) full-duplex Ethernet LAN connections. The adapter connects to a network using a standard shortwave multimode optical cable that conforms to the IEEE 802.3z standard.
  • Page 56 Adapter size PCIe short form Connector information Two fiber optic ports, LC connector LED status indicators for link activity and speed Wrap plug LC fiber optic, part number 12R9314 Cabling Optional LC-SC converter cables are available: v LC-SC 62.5 micron converter cable , part number 12R9322, FC 2459. v LC-SC 50 micron use converter cable, part number 12R9321, FC 2456.
  • Page 57 v SUSE Linux Enterprise Server 10, SP1 If you are using another release of AIX, ensure that the adapter is supported on that release before you install the adapter. Contact service and support for assistance. Preparing for installation If you are installing the operating system at this time, install the adapter before you install the operating system.
  • Page 58 To install device driver software, do the following steps: 1. Log in to the system unit as root user. 2. Insert the media containing the device driver software (for example, the CD) into the media device. If your system does not have a CD-ROM drive, refer to your system documentation for performing a Network Installation Management (NIM) installation.
  • Page 59 Installing the adapter This section explains how to install the adapter. If you are installing the operating system at this time, install the adapter before you install the operating system. If the operating system is already installed and you need to install the device driver for this adapter, install the device driver software before you install the adapter.
  • Page 60 Managing PCI Adapters...

  • Page 61: Chapter 13. 4-Port 10/100/1000 Base-Tx Pci Express Adapter (Fc 5717; Ccin 5717)

    Chapter 13. 4-Port 10/100/1000 Base-TX PCI Express Adapter (FC 5717; CCIN 5717) Learn about features, requirements, and specifications for the 5717 adapter. The 4-Port 10/100/1000 Base-TX PCI Express Adapter is a full duplex, four ported, Gigabit Ethernet adapter that can be configured to run either port at 1000, 100, or 10 Mbps data rate. This adapter interfaces to the system through a PCIe bus and connects to a network using a 4-pair CAT-5 Unshielded Twisted Pair (UTP) cable for distances of up to 100 m.
  • Page 62 Maximum number For system-specific adapter placement, see the PCI adapter placement or PCI adapter placement. Adapter size PCIe short form Connector information v Four RJ-45 ports v Two LED adapter status indicators per port, for link activity and speed Wrap plug RJ-45, part number 10N7405 Cabling Customers supply their own cables.
  • Page 63 Operating system or partition requirements The adapter is supported under the following operating systems: v AIX 5L Version 5.3 with the 5300-06 Technology Level or later v AIX 5L Version 5.2 with the 5200-10 Technology Level or later v Red Hat Enterprise Linux version 4, update 6 v Red Hat Enterprise Linux version 5, update 1 v SUSE Linux Enterprise Server 10, SP1 If you are using another release of AIX, ensure that the adapter is supported on that release before you...
  • Page 64 Installing the device driver software This section explains how to install device driver software. The device driver is provided for the AIX 5L operating system on the AIX base operating system CD, which includes the device driver, or the AIX device driver CD.
  • Page 65 Installing the adapter This section explains how to install the adapter. If you are installing the operating system at this time, install the adapter before you install the operating system. If the operating system is already installed and you need to install the device driver for this adapter, install the device driver software before you install the adapter.
  • Page 66 Managing PCI Adapters...

  • Page 67: Chapter 14. 10/100/1000 Base-Tx Ethernet Pci-X Adapter (Fc 1959, 1979, 5701, 6801; Ccin 5701)

    Chapter 14. 10/100/1000 Base-TX Ethernet PCI-X Adapter (FC 1959, 1979, 5701, 6801; CCIN 5701) Learn about the specifications and LEDs for 10/100/1000 Base-TX Ethernet PCI-X Adapter. The 10/100/1000 Base-TX Ethernet PCI-X Adapter is a high-performance, highly integrated, universal Ethernet LAN adapter for PCI-X and PCI systems. The adapter provides 10/100/1000 Mbps connectivity using standard unshielded twisted pair (UTP) cable for distances of up to 100 meters.
  • Page 68 FRU number 5701 is 03N6524 or 00P6130 1979 is 03N6525 or 80P6445 1959 is 03N6526 or 03N4700 Designed to comply with RoHS requirement. Not designed to comply with the RoHS requirement. I/O bus architecture PCI 2.2 and PCI-X V1.0a compliant Busmaster Maximum number For system-specific adapter placement information, see the PCI adapter placement or the PCI...

  • Page 69: Chapter 15. 10/100 Mbps Ethernet Pci Adapter Ii (Fc 4962; Ccin 4962)

    Chapter 15. 10/100 Mbps Ethernet PCI Adapter II (FC 4962; CCIN 4962) Learn about the specifications and LEDs for the 10/100 Mbps Ethernet PCI Adapter II. The 10/100 Mbps Ethernet PCI Adapter II is a 32-bit, 33 MHz high performance expansion adapter for systems adhering to the Peripheral Component Interconnect (PCI) and IEEE 802.3 standards.
  • Page 70 Wrap plug RJ-45, part number 00G2380 Cables For best performance, use cables that meet Cat 5e cabling standards, or later. Managing PCI Adapters...

  • Page 71: Chapter 16. Pci-X Ddr Dual -X4 Port Sas Raid Adapter (Fc 5902; Ccin 572B)

    Chapter 16. PCI-X DDR Dual –x4 Port SAS RAID Adapter (FC 5902; CCIN 572B) Learn about the specifications and operating system requirements for the 5902 adapter. Overview The PCI-X DDR Dual –x4 Port SAS RAID Adapter is a long-form factor adapter for high-performance, serial attached SCSI (SAS) applications.
  • Page 72 Slot requirement One long, 64-bit, 3.3 V, PCI-X slot for each adapter. Adapters are installed in pairs. Adapter pairs do not need to be in the same enclosure. For higher availability, place adapters in separate enclosures. See the PCI adapter placement for supported placement rules. Cables SAS device attachment requires specific cables that are provided with the subsystem or device features being attached.

  • Page 73: Chapter 17. Pci Express X8 Ext Dual-X4 3Gb Sas Adapter And Cable Card (Fc 5909; Ccin 57B9)

    Chapter 17. PCI Express x8 Ext Dual-x4 3Gb SAS Adapter and Cable Card (FC 5909; CCIN 57B9) Learn about the specifications and operating system requirements for feature 5909. Overview The PCI Express x8 Ext Dual-x4 3Gb SAS Adapter and Cable Card is a x8 PCI Express (PCIe) SAS adapter combined with a cable card in a single cassette assembly.
  • Page 74 Figure 15. PCI Express x8 Ext Dual-x4 3Gb SAS Adapter and Cable Card in a cassette Cable card SAS adapter 4x SAS port provides connection to the internal SAS disk slots 4x SAS port for the SAS adapter Figure 16 on page 63 shows a back view of model 17M/MA with feature 5909 installed and cabled. Managing PCI Adapters...
  • Page 75 Figure 16. Back view of system unit with feature 5909 installed and cabled Cassette containing feature 5909 SAS 4x AI-cable. Specifications Item Description Adapter FRU number 44V4813 (Designed to comply with RoHS requirement.) I/O bus architecture PCIe x8 Slot requirement PCIe slot P1-C3 in a model 17M/MA system unit Cables SAS 4x AI-cable:...
  • Page 76 v 440-500 Mhz PPC v Optimized for SAS disk configurations that use dual paths through dual expanders for redundancy and reliability. Operating system or partition requirements This adapter is supported for the following operating systems: v AIX Version 6.1 with the 6100-01 Technology Level, or later v AIX 5L Version 5.3 with the 5300-08 Technology Level v Red Hat Enterprise Linux version 4, with update 7, or later v Red Hat Enterprise Linux version 5, with update 2, or later...

  • Page 77: Chapter 18. Pci-X Ddr External Dual - X4 Port Sas Adapter (Fc 5900 And 5912; Ccin 572A)

    Chapter 18. PCI-X DDR External Dual – x4 Port SAS Adapter (FC 5900 and 5912; CCIN 572A) Learn about the specifications and operating system requirements for the 5900 and 5912 adapter. Overview The PCI-X DDR External Dual – x4 Port SAS Adapter is a low-profile adapter for high-performance and high-density, Serial Attached SCSI (SAS) applications.
  • Page 78 I/O bus architecture PCI-X DDR Slot requirement One available PCI-X slot If the adapter is used with the feature 3650 or 3651 cable card, the cable card occupies slot P1-C3 in the 17M/MA system unit. Features 3650 and 3651 are only supported in the model 17M/MA. Cables SAS device attachment requires specific cables that are provided with the subsystem or device features being attached.
  • Page 79 Note: Backplane daughter cards and RAID enablement cards that are not in the PCI form factor are not covered in this topic. To find part numbers and location codes for these types of cards, see the Parts Information topic. A link to that topic can be found in this topic under Related references. Chapter 18.
  • Page 80 Managing PCI Adapters...

  • Page 81: Chapter 19. 8 Gigabit Pci Express Dual Port Fibre Channel Adapter (Fc 5735; Ccin 577D)

    Chapter 19. 8 Gigabit PCI Express Dual Port Fibre Channel Adapter (FC 5735; CCIN 577D) Learn about the specifications and operating system requirements for the 5735 adapter. Overview The 8 Gigabit PCI Express Dual Port Fibre Channel Adapter is a high-performance adapter based on the Emulex LPe12002 PCIe Host Bus Adapter (HBA).
  • Page 82 Voltage 3.3V Form factor Short, low-profile with standard size bracket FC compatibility 2, 4, 8 gigabit Cables Cables are the responsibility of the customer. Use multimode fibre optic cables with short-wave lasers that adhere to the following specifications: v OM3: Multimode 50/125 micron fibre, 2000 MHz*km bandwidth v OM2: Multimode 50/125 micron fibre, 500 MHz*km bandwidth v OM1: Multimode 62.5/125 micron fibre, 200 MHz*km bandwidth Because core sizes are different, OM1 cables can only be connected to other OM1 cables.
  • Page 83 Table 15. Normal LED states (continued) Green LED Yellow LED State 2 fast blinks 2 Gbps link rate - normal, link active 3 fast blinks 4 Gbps link rate - normal, link active 4 fast blinks 8 Gbps link rate - normal, link active Power-on self test (POST) conditions and results are summarized in Table 16.
  • Page 84 Managing PCI Adapters...

  • Page 85: Chapter 20. 4 Gigabit Pci Express Single Port Fibre Channel Adapter (Fc 5773; Ccin 5773)

    Chapter 20. 4 Gigabit PCI Express Single Port Fibre Channel Adapter (FC 5773; CCIN 5773) Learn about the specifications and operating system requirements for the 5773 adapter. Overview The 4 Gigabit PCI Express Single Port Fibre Channel Adapter is a 64-bit, short form factor x4, PCIe adapter with an LC-type external fiber connector that provides single initiator capability over an optical fiber link or loop.
  • Page 86 v Link management and recovery handled by firmware v Onboard diagnostic capability accessible by optional connection v Parts and construction compliant with the European Union Directive of Restriction of Hazardous Substances (RoHS) v Performance up to 4.25 Gbps full duplex Figure 19.
  • Page 87 v 4.25 Gb/sec 2m – 150m 6.25/125 micron fiber v 1.0625 Gb/sec 2m – 300m v 2.125 Gb/sec 2m – 150m v 4.25 Gb/sec 2m – 70m Maximum number For system-specific adapter placement information, see the PCI adapter placement or PCI adapter placement.
  • Page 88 Table 18. POST conditions and results (continued) Green LED Yellow LED State Failure while functioning Slow blink Normal, link down Slow blink Not defined Slow blink Slow blink Offline for download Slow blink Fast blink Restricted offline mode, waiting for restart Slow blink Flashing...
  • Page 89 ™ Replacing hot swap HBAs in the System Storage DS4000 Storage Manager Version 9, Installation and Support Guide for AIX, HP-UX, Solaris, and Linux on POWER, order number GC26-7848. Chapter 20. 4 Gigabit PCI Express Single Port Fibre Channel Adapter (FC 5773; CCIN 5773)
  • Page 90 Managing PCI Adapters...

  • Page 91: Chapter 21. 4 Gigabit Pci Express Dual Port Fibre Channel Adapter (Fc 5774; Ccin 5774)

    Chapter 21. 4 Gigabit PCI Express Dual Port Fibre Channel Adapter (FC 5774; CCIN 5774) Learn about the specifications and operating system requirements for the 5774 adapter. Overview The 4 Gigabit PCI Express Dual Port Fibre Channel Adapter is a 64-bit, short form factor x4, PCIe adapter with an LC-type external fiber connector that provides single initiator capability over an optical fiber link or loop.
  • Page 92 v Link management and recovery handled by firmware v Onboard diagnostic capability accessible by optional connection v Parts and construction compliant with the European Union Directive of Restriction of Hazardous Substances (RoHS) v Performance up to 4.25 Gbps full duplex Figure 21.
  • Page 93 v 4.25 Gb/sec 2m – 150m 6.25/125 micron fiber v 1.0625 Gb/sec 2m – 300m v 2.125 Gb/sec 2m – 150m v 4.25 Gb/sec 2m – 70m Maximum number For system-specific adapter placement information, see the PCI adapter placement or PCI adapter placement.
  • Page 94 Table 20. POST conditions and results (continued) Green LED Yellow LED State Failure while functioning Slow blink Normal, link down Slow blink Not defined Slow blink Slow blink Offline for download Slow blink Fast blink Restricted offline mode, waiting for restart Slow blink Flashing...
  • Page 95 Replacing hot swap HBAs in the System Storage DS4000 Storage Manager Version 9, Installation and Support Guide for AIX, HP-UX, Solaris, and Linux on POWER, order number GC26-7848. Chapter 21. 4 Gigabit PCI Express Dual Port Fibre Channel Adapter (FC 5774; CCIN 5774)
  • Page 96 Managing PCI Adapters...

  • Page 97: Chapter 22. 2 Gigabit Fibre Channel Pci-X Adapter (Fc 1957, 1977, 5716; Ccin 574C)

    Chapter 22. 2 Gigabit Fibre Channel PCI-X Adapter (FC 1957, 1977, 5716; CCIN 574C) Learn about the specifications and operating system requirements for the 2 Gigabit Fibre Channel PCI-X Adapter. The 2 Gigabit Fibre Channel PCI-X Adapter is a 64-bit address/data, short form factor PCI-X adapter with an LC type external fiber connector that provides single or dual initiator capability over an optical fiber link or loop.
  • Page 98 Maximum number For system-specific adapter placement information, see the PCI adapter placement or the PCI adapter placement. Operating system or partition requirements AIX 5L Version 5.2 with the 5200-04 Technology Level AIX 5L Version 5.3 with the 5300-03 Technology Level Red Hat Enterprise Linux version 3 U3 SUSE Linux Enterprise Server 9 Note: Backplane daughter cards and RAID enablement cards that are not in the PCI form factor are not...

  • Page 99: Chapter 23. 2 Gigabit Fibre Channel Pci And Pci-X Adapters (Fc 6228, 6239)

    Chapter 23. 2 Gigabit Fibre Channel PCI and PCI-X Adapters (FC 6228, 6239) Learn about the specifications and operating system requirements for the 2 Gigabit Fibre Channel PCI and PCI-X adapters. The 2 Gigabit Fibre Channel PCI and PCI-X Adapters are 64-bit address/data, short form factor PCI and PCI-X adapters with an LC type external fiber connector that provides single or dual initiator capability over an optical fiber link or loop.
  • Page 100 2.125Gb/sec: 2m – 300m Multimode 62.5/125 micron fiber with LC connectors: 1.0625Gb/sec: 2m – 300m 2.125Gb/sec: 2m – 150m Maximum number For system-specific adapter placement information, see the PCI adapter placement or the PCI adapter placement. Operating system or partition requirements AIX 5L Version 5.2 with the 5200-04 Technology Level AIX 5L Version 5.3 with the 5300-03 Technology Level Red Hat Enterprise Linux version 3 U3...

  • Page 101: Chapter 24. 4 Gb Single-Port Fibre Channel Pci-X 2.0 Ddr Adapter (Fc 1905, 5758, 5761; Ccin 1910, 280D)

    Chapter 24. 4 Gb Single-Port Fibre Channel PCI-X 2.0 DDR Adapter (FC 1905, 5758, 5761; CCIN 1910, 280D) Learn about the specifications and operating system requirements for the 4 Gb Single-Port Fibre Channel PCI-X 2.0 DDR Adapter. The 4 Gigabit Single-Port Fibre Channel PCI-X 2.0 DDR Adapter is a 64-bit address/data, short form factor PCI-X adapter with an LC type external fiber connector that provides single initiator capability over an optical fiber link or loop.
  • Page 102 Operating system or partition requirements AIX 5L Version 5.2 with the 5200-08 Technology Level AIX 5L Version 5.3 with the 5300-04 Technology Level Red Hat Enterprise Linux version 4 U2 SUSE Linux Enterprise Server 9 SP3 V5R3M0 with PTFs, V5R3M5 with PTFs V5R4M0 Note: If you are installing a new feature, ensure that you have the software required to support the new feature and that you determine if there are any existing prerequisites.

  • Page 103: Chapter 25. 4 Gb Dual-Port Fibre Channel Pci-X 2.0 Ddr Adapter (Fc 1910, 5759; Ccin 1910, 5759)

    Chapter 25. 4 Gb Dual-Port Fibre Channel PCI-X 2.0 DDR Adapter (FC 1910, 5759; CCIN 1910, 5759) Learn about the specifications and operating system requirements for the 4 Gb Dual-Port Fibre Channel PCI-X 2.0 DDR Adapter. The 4 Gb Dual-Port Fibre Channel PCI-X 2.0 DDR Adapter is a 64-bit address/data, short form factor PCI-X adapter with an LC type external fiber connector that provides single or dual initiator capability over an optical fiber link or loop.
  • Page 104 Operating system or partition requirements AIX 5L Version 5.2 with the 5200-08 Technology Level AIX 5L Version 5.3 with the 5300-04 Technology Level Red Hat Enterprise Linux version 4 U2 SUSE Linux Enterprise Server 9 SP3 Note: Backplane daughter cards and RAID enablement cards that are not in the PCI form factor are not covered in this topic.

  • Page 105: Chapter 26. Pci-X Ultra Raid Disk Controller (Fc 2757; Ccin 2757)

    Chapter 26. PCI-X Ultra RAID Disk Controller (FC 2757; CCIN 2757) Learn about the specifications for the PCI-X Ultra RAID Disk Controller. This adapter is a PCI-X SCSI controller with a maximum compressed write cache of 757 MB. The 2757 provides RAID-5 protection for internal disks and also supports internal tape units, internal CD/DVD-ROM and internal DVD-RAM units.
  • Page 106 Managing PCI Adapters...

  • Page 107: Chapter 27. Pci-X Ultra4 Raid Disk Controller (Fc 0627, 0641, 2780; Ccin 2780)

    Chapter 27. PCI-X Ultra4 RAID Disk Controller (FC 0627, 0641, 2780; CCIN 2780) Learn about the specifications for the PCI-X Ultra RAID Disk Controller. This adapter is an Ultra4 (Ultra320) SCSI controller with a maximum compressed write cache of 757 MB and a maximum compressed read cache size of 1 GB that provides RAID-5 protection for internal disks and also supports internal tape units, CD-ROM and DVD units.
  • Page 108 Managing PCI Adapters...

  • Page 109: Chapter 28. Pci-X Ddr Dual-Channel Ultra320 Scsi Adapter (Fc 0647, 1912, 5736, 5775; Ccin 571A)

    Chapter 28. PCI-X DDR Dual-Channel Ultra320 SCSI Adapter (FC 0647, 1912, 5736, 5775; CCIN 571A) Learn about the specifications for the PCI-X DDR Dual-Channel Ultra320 SCSI Adapter. The PCI-X DDR Dual-Channel Ultra320 SCSI Adapter is a high-performance SCSI adapter for PCI-X and PCI systems.
  • Page 110 Managing PCI Adapters...

  • Page 111: Chapter 29. Pci-X Ddr Dual-Channel Ultra320 Scsi Raid Adapter (Fc 5737, 5776; Ccin 571B)

    Chapter 29. PCI-X DDR Dual-Channel Ultra320 SCSI RAID Adapter (FC 5737, 5776; CCIN 571B) Learn about the specifications for the PCI-X DDR Dual-Channel Ultra320 SCSI RAID Adapter. The PCI-X DDR Dual-Channel Ultra320 SCSI RAID Adapter is a high-performance SCSI adapter for PCI-X and PCI systems.
  • Page 112 AIX 5L Version 5.3 with the 5300-03 Technology Level, or later Red Hat Enterprise Linux version 4, Update 2 or newer SUSE Linux Enterprise Server 9 Service Pack 2 or newer V5R3 or later Required software or drivers AIX - devices.pci.1410be02 device driver package Linux - ipr driver Version 2.0.10.3 (or later) for SLES 9 kernels, Version 2.0.11.1 (or later) for RHEL4 kernels, or Version 2.0.13 (or later) for kernel.org kernels (kernel version 2.6.12 or later) Tools...

  • Page 113: Chapter 30. Auxiliary-Write Cache Ioa (Fc 5580, 5581; Ccin 5708)

    Chapter 30. Auxiliary-write cache IOA (FC 5580, 5581; CCIN 5708) Learn about the specifications and installation notes for the auxiliary-write cache IOA adapter and the PCI-X Ultra4 RAID disk-controller adapters used with it. Feature 5580 includes a 2780 PCI-X Ultra4 RAID disk-controller adapter, a CCIN 5708 auxiliary-write cache IOA adapter, and the required connection cable.
  • Page 114 Read the following questions in relation to your system: v Are you converting from feature 2780 to feature 5580? v Are you converting from feature 2757 to feature 5581? v Are you replacing any other existing storage adapters with features 5580 and 5581? v Is your server partitioned (LPAR)? If the answer to any of these questions is yes, or you are unsure of the answers, contact your authorized service provider for planning and deployment services.
  • Page 115 Installing the SCSI cable The disk controller adapter and the auxiliary-write cache adapter are connected by a SCSI cable. Attention: Do not install or remove the adapter cable if the adapters have the power on. Use the service procedures to turn off the power to the adapter slots or shut down the system or partition in which the adapters are placed.
  • Page 116 Managing PCI Adapters...

  • Page 117: Chapter 31. 1 Gigabit Iscsi Toe Pci-X Adapter (Fc 5714, 1987, 5713, 1986)(Ccin 573B, 573C)

    Chapter 31. 1 Gigabit iSCSI TOE PCI-X Adapter (FC 5714, 1987, 5713, 1986)(CCIN 573B, 573C) Learn about the 1 Gigabit iSCSI TOE PCI-X Adapter. Description and technical overview The 1 Gigabit iSCSI TOE PCI-X Adapter encapsulates SCSI commands and data into TCP packets and transports them over a 1-gigabit-Ethernet network through IP.
  • Page 118 Figure 25. 1 Gigabit-SX iSCSI TOE PCI-X Adapter 1 Gigabit-TX iSCSI TOE PCI-X Adapter (copper connector), FC 5713 and FC 1986 (CCIN 573B) v FRU part number 03N6056 or 30R5219 Designed to comply with RoHS requirement. Not designed to comply with the RoHS requirement.) v 133 MHz PCI-X version 1.0a support and version 2.0 mode 1 v PCI 2.3 compliant v Low profile...
  • Page 119 Preparing to install the adapter Preparing to install the adapter involves the following tasks. v Verifying your hardware requirements v Verifying your software requirements v Checking prerequisites v Gathering tools and documentation Note: If you are installing your operating system at this time, install the adapter before you install the operating system.
  • Page 120 v AIX Base Operating System CD, which includes the device driver, or the AIX device driver CD If an item is missing or damaged, contact your vendor. Note: Be sure to retain your proof of purchase as it might be required to receive warranty service. Gathering tools and documentation To install the adapter, you need the following tools and documentation.
  • Page 121 7. Press F4 to display the SOFTWARE to install window. 8. Type a forward slash (/) to display the Find window. 9. For the 1 Gigabit-SX iSCSI TOE PCI-X Adapter, type the following device package name: devices.pci.1410cf02 10. Press Enter. The system finds and highlights this device driver software. 11.
  • Page 122 v If you should install your adapter hardware first, go to“Installing the 1 Gigabit iSCSI TOE PCI-X Adapter” on page 111. When you install AIX, your adapter device driver automatically installs. Note: You only need to install device driver for the first instance of the 1 Gigabit-TX iSCSI TOE PCI-X Adapter.
  • Page 123 Verifying AIX software installation Use this procedure to verify that the device driver for the adapter is installed. 1. If necessary, log in as root user. 2. At the command line, type: lslpp -l devices.pci.1410d002.rte 3. Press Enter. Possible results are as follows: v If the 1 Gigabit-TX iSCSI TOE PCI-X Adapter device driver is installed, the following is an example of the data that displays on your screen: Fileset...
  • Page 124 Running adapter diagnostics Diagnostics are provided with the device driver software. To run diagnostics, refer to your system unit documentation for instructions. Configuring the 1 Gigabit iSCSI TOE PCI-X adapter Use the following information to configure the 1 Gigabit iSCSI TOE PCI-X adapter in AIX. Note: You must complete this configuration in order for the adapter to function correctly.
  • Page 125 Apply change to DATABASE only sc+1=Help Esc+2=Refresh Esc+3=Cancel Esc+4=List sc+5=Reset Esc+6=Command Esc+7=Edit Esc+8=Image sc+9=Shell Esc+0=Exit Enter=Do Note: v Set the value for the Maximum number of Commands to Queue to Adapter to be greater than the queue depth times the number of LUNs. For example, for 20 LUNs with a queue depth of 20, the value should be greater than 400.
  • Page 126 Understanding the adapter LED The LED on the 1 Gigabit-SX iSCSI TOE PCI-X Adapter provides information about the card’s link status. The LED is visible through the card’s mounting bracket and indicates the following conditions. Light State Description Green Good Link Green No link: could be the result of a bad cable, bad connector, or configuration mismatch...
  • Page 127 To connect the adapter to an unshielded twisted pair (UTP) network, do the following steps: 1. Insert the RJ-45 jack of the UTP cable into the RJ-45 connector on the adapter. 2. Insert the RJ-45 jack of the other end of the UTP cable into the network switch. Understanding the adapter LED The LED on the 1 Gigabit-TX iSCSI TOE PCI-X Adapter provides information about the card’s link status.
  • Page 128 alog -L -t cfg If config logging is not enabled, it can be enabled as follows: export CFGLOG="" echo "Create cfglog" | alog -t cfg A useful debug method is to perform the following steps: rmdev -Rl ics<x> rm /usr/adm/ras/cfglog echo "Create cfglog"...
  • Page 129 iSCSI TOE adapter error log information (ICS_ERR template) Learn about the error log entries made by the iSCSI TOE adapter. v Table 24 shows the detail sense data layout. v Table 25 shows the detail sense data descriptions. v Special detail sense data and Table 26 on page 119 show a special format that is used for logging bulk data such as a crash record or an IOCB request or completion queue.
  • Page 130 Table 25. Detail sense data descriptions (continued) Data Description Type of data in the error log. Possible values: v 0 - None v 1 - Mailbox v 2 - IOCB v 3 - Register data v 4 - Driver data v 5 - qlisc_cmd data v 6 - Raw data v 7 - Return code data...
  • Page 131 Table 25. Detail sense data descriptions (continued) Data Description Transmitted iSCSI data bytes Received iSCSI PDU count Received iSCSI data bytes Special detail sense data(AAAA AAAA is the general error field.) This format is used for logging bulk data such as a crash record or an IOCB request or completion queue. The first line of the detail data has a special format and all remaining lines of the detail data contain the bulk data being logged.
  • Page 132 Table 27. Error Number Values (continued) Error Number Error Template Description of Error Received unsolicited IOCB and protocol driver does not handle unsolicited 0x2F ICS_ERR6 IOCBs Adapter reported fatal error 0x30 ICS_ERR2 Invalid command entry type, command provided. 0x31 ICS_ERR6 Invalid command opcode, command provided.
  • Page 133 Table 27. Error Number Values (continued) Error Number Error Template Description of Error Cannot get init firmware control block data because of invalid mode. Mode, 0x9B ICS_ERR6 origin provided. Cannot get firmware state because of invalid mode. Mode, origin provided. 0x9A ICS_ERR6 Received Mailbox completion, but do not have any mailboxes active.
  • Page 134 Table 27. Error Number Values (continued) Error Number Error Template Description of Error Reset Adapter failed. Adapter reported Fatal Error 0xD1 ICS_ERR2 Reset Adapter failed. Adapter self test did not complete 0xD2 ICS_ERR2 All retries of adapter reset failed. 0xDEAD ICS_ERR1 Failed to allocate iSCSI entry list.
  • Page 135 Table 28. Detail Sense Data AAAA AAAA is the general error field. XXXX VVVV AAAA AAAA BBBB BBBB CCHH RRRR YYYY YYYY TTTT TTTT LLLL LLLL LLLL LLLL IIII IIII IIII IIII IIII IIII IIII IIII EEEE EEEE EEEE EEEE EEEE EEEE EEEE EEEE QQQQ QQQQ QQQQ QQQQ QQQQ QQQQ QQQQ QQQQ ZZZZ ZZZZ ZZZZ ZZZZ ZZZZ ZZZZ ZZZZ ZZZZ NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN NNNN...
  • Page 136 Table 29. Detail sense data descriptions (continued) Data Description Bus real address of SCSI CDB Bus real address of Auto sense buffer Bus real address of DSD list scsi_buf version q_tag_msg cmd_type Variable CDB len Port Number num_start_LUNs for this target This is used for the address of the failing scsi_info structure.
  • Page 137 Table 30. Error number values (continued) Error Number Error Template Description of Error Only logged when debug is turned on . An LUN reset (SCIOLRESET) ioctl 0x10 ISCSI_ERR13 call failed with EINVAL, most likely because LUN reset is not supported for this device, so a target reset was issued instead.
  • Page 138 Table 30. Error number values (continued) Error Number Error Template Description of Error Only logged when debug is turned on . Async status received from adapter 0x31 ISCSI_ERR2 driver indicating link is dead Only logged when debug is turned on. Async status received from adapter 0x32 ISCSI_ERR4 driver indicating link is down.
  • Page 139 Table 30. Error number values (continued) Error Number Error Template Description of Error IOCB failed because device indicated the device has a duplicate tag. Cmd 0x4E ISCSI_ERR10 included. IOCB failed with unknown error status, cmd included. 0x4F ISCSI_ERR6 Could not issue Cancel for above failing a command which has not received 0x51 ISCSI_ERR6 an interrupt.
  • Page 140 Table 30. Error number values (continued) Error Number Error Template Description of Error Unknown Async IOCB received. Control element included. 0x9A ISCSI_ERR13 Only displayed with debug driver. Check condition with autosense data 0x9B ISCSI_ERR10 length returned from a SCSI command, but the key fields of the autosense data are all 0.

  • Page 141: Chapter 32. Power Gxt145 Pci Express Graphics Accelerator (Fc 5748)

    Chapter 32. POWER GXT145 PCI Express Graphics Accelerator (FC 5748) ™ Learn about the features, requirements, installation notes, and troubleshooting tips for the POWER GXT145 PCI Express Graphics Accelerator. Overview The POWER GXT145 graphics adapter is a PCI Express (PCIe) adapter that accelerates and enhances the system unit video.
  • Page 142 custom card identification number field-replaceable unit (FRU) part feature code (FC) (CCIN) number Designed to comply with RoHS requirement This adapter provides the following features: v 8-bit indexed or 24-bit true color. v 32 MB SDRAM frame buffer. v x1 PCIe bus interface. v Two DVI-I analog or digital connectors.
  • Page 143 Installing the device driver software This section explains how to install device driver software for the adapter. The device driver is provided for the AIX 5L operating system. To install device driver software, do the following steps: 1. Log in to the system unit as root user. 2.
  • Page 144 The POWER GXT145 graphics adapter has an x1 PCIe connector and can be placed in a PCIe x1, x4, x8 or x16 slot. See the PCI adapter placement or PCI adapter placement for information about the PCIe slots on your system unit. 2.
  • Page 145 Checking the adapter installation Verify that the system unit recognizes the POWER GXT145 adapter. At the AIX command line type lsdev -Cs pci. If the POWER GXT145 adapter is correctly installed, the following is an example of the data that appears: cor0 Available 0K-00 GXT145 Graphics Adapter If the message indicates the adapter is DEFINED instead of AVAILABLE, shut down the system unit and check the GXT145 adapter to ensure it is installed correctly.
  • Page 146 Managing PCI Adapters...

  • Page 147: Chapter 33. Power Gxt135P Graphics Pci Adapter (Fc 2848)

    Chapter 33. POWER GXT135P graphics PCI Adapter (FC 2848) Learn about specifications for the POWER GXT135P graphics PCI Adapter. The POWER GXT135P graphics PCI Adapter is a high-performance PCI graphics adapter that accelerates and enhances your system unit video. This adapter has no hardware switches to set. Mode selection is made through the software.
  • Page 148 One 15-pin D-shell connector and one 28-pin DVI connector Optional 28-pin DVI to 15-pin D-shell convertor Managing PCI Adapters...

  • Page 149: Chapter 34. Power Gxt135P Graphics Pci Adapter (Fc 2849; Ccin 2849)

    Chapter 34. POWER GXT135P graphics PCI Adapter (FC 2849; CCIN 2849) Learn about specifications for the POWER GXT135P graphics PCI Adapter. The POWER GXT135P graphics PCI Adapter is a high-performance PCI graphics adapter that accelerates and enhances your system unit video. This adapter has no hardware switches to set. Mode selection is made through the software.
  • Page 150 1024x768 at 60 Hz vertical refresh 1280x1024 at 60 Hz vertical refresh 1600x1200 at 30 Hz vertical refresh Display power management Supports VESA and DPMS Connectors 15-pin D-shell connector 28-pin DVI-I connector Managing PCI Adapters...

  • Page 151: Chapter 35. Pci Iop (Fc 2843, Ccin 2834)

    Chapter 35. PCI IOP (FC 2843, CCIN 2834) Learn about the features of the PCI IOP. The 2843 is a PCI I/O processor with 64MB of memory which drives PCI IOA adapters. 2843 can drive a maximum of four IOAs. FRU number 039J3247** ** Not designed to comply with the RoHS requirement.
  • Page 152 Managing PCI Adapters...

  • Page 153: Chapter 36. Pci Iop (Fc 2844, Ccin 2844)

    Chapter 36. PCI IOP (FC 2844, CCIN 2844) Learn about the features of the PCI IOP. 2844 is a PCI I/O processor that drives PCI IOA adapters in the system unit and in HSL attached PCI or PCI-X I/O expansion units. A 2844 can drive a maximum of four IOAs, subject to configuration restrictions.
  • Page 154 Managing PCI Adapters...

  • Page 155: Chapter 37. Pci Iop For San Load Source (Fc 2847, Ccin 2847)

    Chapter 37. PCI IOP for SAN Load Source (FC 2847, CCIN 2847) Learn about the features of the PCI IOP for SAN Load Source. This adapter provides the specialized function required to attach a operating system load source by way of a Fibre Channel adapter and boot from that load source.
  • Page 156 Managing PCI Adapters...

  • Page 157: Chapter 38. Pci Audio Adapter (Fc 8244)

    Chapter 38. PCI Audio Adapter (FC 8244) Learn about specifications for the PCI Audio Adapter. The PCI Audio Adapter provides audio playback and recording capability for your system. External jacks allow you to connect speakers, microphone, or other audio devices to your system. An internal connector and cable are provided for connection to your system’s CD-ROM or DVD-ROM drive.
  • Page 158 Managing PCI Adapters...

  • Page 159: Chapter 39. 2-Port Usb Pci Adapter (Fc 2738; Ccin 28Ef)

    Chapter 39. 2-port USB PCI Adapter (FC 2738; CCIN 28EF) Learn about the specifications for the 2-port USB PCI Adapter. The 2-port USB PCI Adapter is a 32-bit, 33 MHz high-performance expansion adapter that provides the following features: v 32-bit, 33MHz PCI Local Bus Specification Revision 2.2 v Single-slot, half-size PCI card v +5V or +3.3V signaling v FCC Class B...
  • Page 160 Maximum number and adapter slots For system-specific adapter placement information, see the PCI adapter placement or the PCI adapter placement. . Connector Standard USB single pin-type series ″A″ receptacle Wrap plug None Cables None Managing PCI Adapters...

  • Page 161: Chapter 40. 4-Port Usb Pci Express Adapter (Fc 2728; Ccin 57D1)

    Chapter 40. 4-Port USB PCI Express Adapter (FC 2728; CCIN 57D1) Learn about the specifications for the 4-Port USB PCI Express (PCIe) Adapter. The 4-Port USB PCIe Adapter is a 32-bit, 33 MHz high-performance expansion adapter that provides the following features and support: v 32-bit, 33MHz PCI Local Bus Specification Revision 2.2 v Single-slot, full-size PCIe card v +5V or +3.3V signaling...
  • Page 162 Maximum number and adapter slots For system-specific adapter placement information, see the PCI adapter placement or the PCI adapter placement. . Connector Standard USB single pin-type series ″A″ receptacle Wrap plug None Cables None Managing PCI Adapters...

  • Page 163: Chapter 41. Artic960Hx 4-Port Selectable Pci Adapter (Fc 2947)

    Chapter 41. ARTIC960Hx 4-Port Selectable PCI Adapter (FC 2947) Learn about the specifications for the ARTIC960Hx 4-Port Selectable PCI Adapter. Overview The ARTIC960Hx 4-Port Selectable PCI Adapter consists of an ARTIC960Hx Base PCI Adapter, an ARTIC960 4-Port Selectable PCI Mezzanine Card (PMC), and an 8MB DRAM Memory card. The Base PCI Adapter provides high-function control of I/O operations and serves to off-load input/output tasks from the system microprocessor.
  • Page 164 Figure 35. 4-Port Selectable PMC Adapter specifications Item Description FRU numbers Base adapter, 87H3427 8 MB memory module, 87H3621 4-Port selectable mezzanine card, 87H3413 I/O bus architecture PCI, 32-bit, 33-MHz The 2947 can be installed in supported 32-bit or 64-bit, 33-MHz, 66-MHz, 133-MHz, and 266-MHz PCI and PCI-X bus slots.
  • Page 165 Wrap plugs FRU number Description of wrap plug 87H3311 120-pin connector 87H3439 25-pin wrap plug (EIA-232 (ISO 2110) or EIA-530 (ISO 2110)) 87H3442 34-pin wrap plug (V.35 DTE (ISO 2593) 34-pin male block) 87H3440 37-pin wrap plug (RS-449 (ISO 4902)) 53G0638 15-pin wrap plug (X.21 (ISO 4903)) Port speeds...
  • Page 166 Managing PCI Adapters...

  • Page 167: Chapter 42. 2-Port Asynchronous Eia-232 Pci Adapter (Fc 5723)

    Chapter 42. 2-Port Asynchronous EIA-232 PCI Adapter (FC 5723) Learn about the specifications for the 2-Port Asynchronous EIA-232 PCI Adapter. This adapter provides connection for two (2) asynchronous EIA-232 devices. Ports are programmable to support asynchronous protocols over an EIA-232 interface at line speeds up to 128 Kbps. Figure 36.
  • Page 168 Red Hat Enterprise Linux version 4 SUSE Linux Enterprise Server 9 SP1 Note: If you are installing a new feature, ensure that you have the software required to support the new feature and that you determine if there are any existing prerequisites. Managing PCI Adapters...

  • Page 169: Chapter 43. 8-Port Asynchronous Eia-232E/Rs-422A Pci Adapter (Fc 2943)

    Chapter 43. 8-Port asynchronous EIA-232E/RS-422A PCI Adapter (FC 2943) Learn about the specifications for the 8-Port asynchronous EIA-232E/RS-422A PCI Adapter. The 8-Port asynchronous EIA-232E/RS-422A PCI adapter is a multi-channel intelligent serial communications feature that supports speeds of up to 230 Kbps for each asynchronous port and is run by a 32-bit, 20 MHz, IDT 3041 processor.
  • Page 170 Maximum number Connector 78-pin D-shell female Wrap plug EIA-232 25-pin, part number 6298964. This wrap plug tests all of the adapter functions for both EIA-232 and RS-422. Cable 8-Port DB-25 connector box, part number 11H5967 included with adapter Modem cable EIA-232 modem cable, part number 6323741, feature code 2936, length 3 meters or 10 feet RS-422 modem cable, customer supplied (must meet RS-422 requirements) Terminal/printer cable...

  • Page 171: Chapter 44. 64-Bit/66Mhz Pci Atm 155 Utp Adapter (Fc 4953)

    Chapter 44. 64-bit/66MHz PCI ATM 155 UTP Adapter (FC 4953) Learn about the specifications for the 64-bit/66MHz PCI ATM 155 UTP Adapter. The 64-bit/66MHz PCI ATM 155 UTP Adapter provides the interface between the ATM 155 Mb/sec unshielded twisted pair network and the 64-bit/66 MHz PCI bus in your system. Figure 40.
  • Page 172 Managing PCI Adapters...

  • Page 173: Chapter 45. Pci-X Cryptographic Coprocessor (Fc 4764; Ccin 4764)

    Chapter 45. PCI-X Cryptographic Coprocessor (FC 4764; CCIN 4764) Learn about the specifications, requirements, and installation notes for the 4764 PCI-X Cryptographic Coprocessor. The adapter for the PCI-X Cryptographic Coprocessor provides applications with cryptographic processing capability and a means to securely store cryptographic keys. Cryptographic functions available include encryption for keeping data confidential, message digests and message authentication codes for ensuring that data has not been changed, and digital signature generation and verification for authentication.
  • Page 174 Temperature while operating: +50 degrees F (+10 degrees C) to +104 degrees F (+40 degrees Humidity while operating: 8% to 80% RH Altitude while operating: maximum 7000 feet, equivalent to 768 mbar Handling requirements Each PCI-X Cryptographic Coprocessor is shipped from the factory with a certified device key. This electronic key, which is stored in the adapter’s battery-powered and protected memory, digitally signs status messages to confirm that the PCI Cryptographic Coprocessor is genuine and that no tampering has occurred.
  • Page 175 PKCS11 support program installation The 4764 PCI-X Cryptographic Coprocessor PKCS#11 Support Program Installation Manual is included on the CD that is shipped with the adapter. The manual is contained in the csufx.xcrypto.man file set. CCA support program installation The 4764 PCI-X Cryptographic Coprocessor CCA Support Program Installation Manual is included on the CD that is shipped with the adapter.
  • Page 176 v After a successful installation, SUCCESS displays in the Result column of the Installation Summary at the bottom of the display. 14. Remove the installation media from the drive. 15. Press F10 to exit SMIT. 16. Verify the device driver. See “Verifying the device driver” 17.
  • Page 177 installed correctly. The adapters appear as Crypt0, Crypt1, and so on. Running coprocessor diagnostics Diagnostics are provided with the device driver software. If you remove a cryptographic adapter and do not replace it, and you run diagnostics on the remaining cryptographic adapters, the results might not be correct.
  • Page 178 Attention: Any loss of power erases data stored in the card’s protected memory. To prevent loss, ensure that the battery tray contains a fresh battery and is attached to the J10 connector. 7. Remove the battery attention labels from the battery holders on the card. These labels can be torn off and discarded.
  • Page 179 Figure 41. Front side of the adapter Figure 42. Back side of the adapter Chapter 45. PCI-X Cryptographic Coprocessor (FC 4764; CCIN 4764)
  • Page 180 Managing PCI Adapters...

  • Page 181: Chapter 46. Cryptographic Accelerator (Fc 4960; Ccin 2058)

    Chapter 46. Cryptographic Accelerator (FC 4960; CCIN 2058) Learn about the specifications for the cryptographic Accelerator. The cryptographic accelerator provides high cryptographic performance through hardware acceleration by offloading computationally intensive public-key processing from a host processor. The overall operation control, including command decoding, is implemented in hardware. As a result, e-business applications requiring Public Key Cryptography might experience an increase in performance.
  • Page 182 Cryptographic accelerator specifications The following items are requirements and specifications for this adapter. FRU part number 11P3106 (Not designed to comply with RoHS requirement.) Power consumption Typical, 20 watts Voltage +5.0 Vdc ±10 percent Temperature Operating, +10 to +40 degrees C (50 to 104 degrees F) Storage, +1 to +40 degrees C (5 to 104 degrees F) Relative humidity 8 to 80 percent...

  • Page 183: Chapter 47. Pci Cryptographic Coprocessor (Fc 4963)

    Chapter 47. PCI Cryptographic Coprocessor (FC 4963) Learn about the specifications for the PCI Cryptographic Coprocessor. The PCI Cryptographic Coprocessor is designed to provide data security functions for PCI bus systems. The PCI cryptographic coprocessor provides high-performance secure hardware engines, including methods of transmitting data, verifying electronic signatures, bulk data encryption, and decryption.
  • Page 184 Battery kit 09J8199, Kit contains two batteries and a battery tray. Two kits are required for battery replacement. Bus architecture PCI version 2.1 Adapter slots For system-specific adapter placement information, see the PCI adapter placement or the PCI adapter placement. Temperature range, stored +33.8 degrees F (+1 degree C) to +140 degrees F (+60 degrees C) Temperature range, operating...

  • Page 185: Chapter 48. Replacing Raid Disk-Controller Cache Battery Packs

    Chapter 48. Replacing RAID disk-controller cache battery packs You might need to remove or replace the cache battery from its controller. This section includes procedures so that you can perform these tasks. Replacing this feature is a customer task. You can perform this task yourself, or contact an authorized service provider to perform the task for you.

  • Page 186: Replacing The Cache Battery Pack On The 571F And 575B Adapters

    Feature CCIN Description 2757 2757 PCI-X Ultra RAID controller 5581 2757 2757 Controller with Auxiliary Write Cache 5591 Replacing this feature is a customer task. You can perform this task yourself, or contact an authorized service provider to perform the task for you. You might be charged a fee by the authorized service provider for this service.

  • Page 187: Replacing The Cache Battery Pack On The 571E, 574F, 2780, Or 5708 Adapters

    Replacing the cache battery pack on the 571E, 574F, 2780, or 5708 adapters You might need to replace the cache battery pack. Use the procedure in this section to perform this task. About this task This procedure describes how to replace the cache battery pack on the adapters listed in the following table Feature CCIN...
  • Page 188 Managing PCI Adapters...

  • Page 189: Appendix. Accessibility Features

    Appendix. Accessibility features...
  • Page 190 Managing PCI Adapters...

  • Page 191: Notices

    Notices This information was developed for products and services offered in the U.S.A. The manufacturer may not offer the products, services, or features discussed in this document in other countries. Consult the manufacturer’s representative for information on the products and services currently available in your area.

  • Page 192: Trademarks

    The manufacturer’s prices shown are the manufacturer’s suggested retail prices, are current and are subject to change without notice. Dealer prices may vary. This information is for planning purposes only. The information herein is subject to change before the products described become available. This information contains examples of data and reports used in daily business operations.
  • Page 193 Federal Communications Commission (FCC) statement Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 194 VCCI Statement - Japan The following is a summary of the VCCI Japanese statement in the box above. This product is a Class A Information Technology Equipment and conforms to the standards set by the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.
  • Page 195 Electromagnetic Interference (EMI) Statement - Korea Please note that this equipment has obtained EMC registration for commercial use. In the event that it has been mistakenly sold or purchased, please exchange it for equipment certified for home use. Germany Compliance Statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse A EU-Richtlinie zur Elektromagnetischen Verträglichkeit Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG zur Angleichung der...

  • Page 196: Terms And Conditions

    Electromagnetic Interference (EMI) Statement - Russia Terms and conditions Permissions for the use of these publications is granted subject to the following terms and conditions. Personal Use: You may reproduce these publications for your personal, noncommercial use provided that all proprietary notices are preserved. You may not distribute, display or make derivative works of these publications, or any portion thereof, without the express consent of the manufacturer.
  • Page 198 BULL CEDOC 357 AVENUE PATTON B.P.20845 49008 ANGERS CEDEX 01 FRANCE REFERENCE 86 A1 58EV 04...

Table of Contents
