Page 1 E2-700, E2-700T, E2-705, E2-705T, E4- 700, E4-700T or E4-705 Managing devices REFERENCE 86 A1 74FG 03...
Page 3 - Bull Escala E1-700 (Power 710 / 8231-E2B) - Bull Escala E1-705 (Power 710 / 8231-E1C) - Bull Escala E2-700 / E2-700T (Power 720 / 8202-E4B) - Bull Escala E2-705 / E2-705T (Power 720 / 8202-E4C) - Bull Escala E3-700 (Power 730 / 8231-E2B)
Page 4 Quoting of brand and product names is for information purposes only and does not represent trademark misuse. The information in this document is subject to change without notice. Bull will not be liable for errors contained herein, or for incidental or consequential damages in connection with the use of this material.
Page 5: Table Of Contents
Contents Safety notices ....... . vii Managing devices ....... 1 Managing tape drives .
Page 6 Resetting the tape drive . . 56 60/150 GB 16-bit 8-mm internal tape drive (FC 6134) . 57 Cleaning the tape drive (FC 6134) . . 57 Loading and unloading cartridges . . 59 Loading a cartridge. . 59 Unloading a cartridge . .
Page 7 Status lights (FC EU16) . . 103 Tape cartridges (FC EU16) . . 105 Resetting the tape drive . . 105 Managing DVD drives ......107 IDE Slimline DVD-ROM Drive (FC 5756) .
Page 8 Managing devices...
Page 9: Safety Notices
Safety notices Safety notices may be printed throughout this guide. v DANGER notices call attention to a situation that is potentially lethal or extremely hazardous to people. v CAUTION notices call attention to a situation that is potentially hazardous to people because of some existing condition.
Page 10 DANGER When working on or around the system, observe the following precautions: Electrical voltage and current from power, telephone, and communication cables are hazardous. To avoid a shock hazard: v Connect power to this unit only with the provided power cord. Do not use the provided power cord for any other product.
Page 11 Observe the following precautions when working on or around your IT rack system: v Heavy equipment–personal injury or equipment damage might result if mishandled. v Always lower the leveling pads on the rack cabinet. v Always install stabilizer brackets on the rack cabinet. v To avoid hazardous conditions due to uneven mechanical loading, always install the heaviest devices in the bottom of the rack cabinet.
Page 12 CAUTION: Removing components from the upper positions in the rack cabinet improves rack stability during relocation. Follow these general guidelines whenever you relocate a populated rack cabinet within a room or building: v Reduce the weight of the rack cabinet by removing equipment starting at the top of the rack cabinet.
Page 13 (L003) All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class 1 laser products. Outside the U.S., they are certified to be in compliance with IEC 60825 as a class 1 laser product.
Page 14 CAUTION: Data processing environments can contain equipment transmitting on system links with laser modules that operate at greater than Class 1 power levels. For this reason, never look into the end of an optical fiber cable or open receptacle. (C027) CAUTION: This product contains a Class 1M laser.
Page 15: Managing Devices
Managing devices Learn about managing media and communications devices. The topic contains reference information that information technology (IT) personnel and service representatives can use to learn about using and managing the following removable media devices and communication devices. You can also find specifications and installation notes for specific devices. Note: The following features are the electromagnetic compatibility (EMC) Class B features.
Page 16 Managing devices...
Page 17: Managing Tape Drives
Managing tape drives Learn about using and managing removable media devices. Find specifications and installation notes for specific drives. Tape drives Learn general information about tape drives. Select the appropriate information from this list: v Tape drive overview v Tape drive environment and use v Tape handling and storage v Environmental issues v Tape drive cleaning...
Page 18 Tape handling and storage Most tape is supplied in a sealed cartridge so that the tape will remain clean. Opening the cartridge allows dirt and airborne particles to enter and then become a source of contamination. The cartridge should only be opened by the tape drive and not an operator. The tape also is held under proper tension inside the cartridge.
Page 19: Tape Drive Media
Tape drive media Learn about using the different types of tape drive media. Attention: Your system supplier might support only the media that it sells. If the supplier's analysis indicates that the problem is caused by using inferior media, it is the customer's responsibility to replace the inferior media.
Page 20 v Make sure the environment is kept clean and constant. Do not operate in a dusty environment and always maintain a constant environment. A consistent storage and operating environment reduces media exposure to climatic stress. Use only the recommended cleaning cartridge to clean the tape drive. Use of other than recommended cleaning cartridges can damage your drive and might void the warranty.
Page 21 storage cases and stand on edge in a designated storage location. Do not stack cartridges on the flat side or stack other items on top of the tape cartridges. Handle your tape cartridges with care to reduce archival problems. v Keep protective cases for tape cartridges closed except when inserting or removing a cartridge. Contamination can build up and be transferred to the tape cartridge if the protective case is left open.
Page 22 Table 2. Recommended test, cleaning, and 4mm data cartridges for the specific type of tape drive (continued) Tape drive Part number Type of cartridge Capacity DAT160 23R5636 Test Cartridge 155m 23R5638 Cleaning Cartridge 25 cleanings (minimum) 23R5635 Data Cartridge 80 GB DAT320 46C1938 Test Cartridge...
Page 23: Preparing The Tape Drive For Installation
Table 6. LTO Ultrium data cartridges (continued) Part number Type of cartridge Length 24R1922 LTO-3 Data Cartridge (400GB/800GB) 96P1203 LTO-3 Worm Data Cartridge 95P4436 LTO-4 Data Cartridge (800GB/1.6TB) 95P4450 LTO-4 Worm Data Cartridge 45E1129 LTO-4 Test Cartridge 24R0395 LTO Gen-2 Test Cartridge 610 m (2000 ft ) 35L2086 Universal Cleaning Cartridge...
Page 24: 800/1600 Gb Ultrium 4 Sas Tape Drive (Fc 5746)
Configuring the tape drive To configure the drive after installation, boot your system unit. Device drivers are provided in the operating systems that support the drive. Your operating system recognizes the drive and automatically updates your system unit configuration. Updating microcode levels Media devices contain microcode that you can update.
Page 25: Eject Button Functions On The Tape Drive (Fc 5746)
Related information Your package contains the following items: v The tape drive v Media kit containing: – One cleaning cartridge – One test tape v Specific hardware for attaching the drive to your specific system, as detailed on the parts listing provided with your drive.
Page 26: Status Lights (Fc 5746)
Table 8. Eject button functions on the tape drive (continued) Function How to start the function Force a drive dump (part of the maintenance mode) Attention: If the tape drive detects a permanent error and displays an error code, it automatically forces a drive dump.
Page 27 Table 9. Definition of Status Light Combinations (continued) Operation Ready Fault Single character Response display No cartridge is Off or on Off or C Wait 30 to 60 seconds. loaded Cartridge is loading Flashing Off or on Off or C Wait 30 to 60 seconds.
Page 28: Tape Cartridges (Fc 5746)
Table 9. Definition of Status Light Combinations (continued) Operation Ready Fault Single character Response display Write operation was Use media that is not attempted and media write protected. is write-protected Drive is in service Flashing rapidly mode Self-test is in progress Flashing The number 1 is Wait for test to...
Page 29: Setting The Write-Protect Switch (Fc 5746)
Table 10. LTO Ultrium data cartridges (continued) Part number Type of cartridge 95P4450 LTO-4 Worm Data Cartridge Attention: Do not attempt to bulk erase an LTO data cartridge for reuse. Bulk eraser devices cannot properly erase an LTO data cartridge and cause permanent damage to the cartridge. Setting the write-protect switch (FC 5746) You might need to set the write-protect switch on the media.
Page 30: Maintenance Mode (Fc 5746)
v The tape drive exceeds internal preset error thresholds in the drive. v The tape drive exceeds the maximum recommended time between cleaning. This is an internal drive calculation where the drive maintains information on the amount of data written and read and when this value reaches a total of approximately 20 full tape writes or reads the drive will request cleaning.
Page 31 Performing operations using the front panel Perform maintenance operations by pushing the eject button while observing the status LED and the single-character display. Entering maintenance mode To enter maintenance mode (if the drive is not already in maintenance mode and no cartridge is loaded), press and hold the eject button for 6 seconds.
Page 32: Resetting The Tape Drive
Table 11. Maintenance functions (continued) Maintenance functions Display code Clear error code log Insert cartridge into tape drive Test cartridge and media Write performance test Test head Fast write test Load/unload test Enable post-error reporting Disable post-error reporting Running a maintenance function To run the maintenance function indicated by the character on the single-character display, press and hold the eject button for 2 seconds.
Page 33: Performing The Internal Self-Test (Fc 5746)
Procedure 1. Press and hold the eject button for 20 seconds, and then release the button. The LEDs on the drive will be flashing while the reset function is in process. 2. When the LEDs stop flashing, wait approximately one minute for the drive to complete the reset operation.
Page 34 Interpreting the results Table 12. Interpreting the results of the self-test Result Description Test passed When self-testing has completed successfully and no problems were detected, the cartridge is unloaded from the drive and all LEDs are off. Proper function of both the drive and tape cartridge have been verified.
Page 35: 3.0 Tb Ultrium 5 Sas Tape Drive (Fc 5638)
1.5/3.0 TB Ultrium 5 SAS tape drive (FC 5638) Learn about the features of this media device. Description The Ultrium 5 serial attached SCSI (SAS) tape drive is a half-high tape drive designed for Open Systems backup and restore applications. These files can include multimedia, imaging, transaction processing, large databases, and other storage-intensive applications.
Page 36: Eject Button Functions On The Tape Drive (Fc 5638)
Related information Your package contains the following items: v The tape drive v Media kit containing: – One cleaning cartridge – One test tape v Specific hardware for attaching the drive to your specific system, as detailed on the parts listing provided with your drive.
Page 37: Status Lights (Fc 5638)
Table 13. Eject button functions on the tape drive (continued) Function How to start the function Force a drive dump (part of the maintenance mode) Attention: If the drive detects a permanent error and displays an error code, it automatically forces a drive dump (also known as a save of the firmware trace).
Page 38 1. The recommended preventative maintenance cleaning frequency is approximately 100 tape motion hours or when the drive indicates cleaning is required. Tape motion hours are defined as the time the tape drive is moving tape. 2. When a fault occurs, the drive causes AIX to log an information error (TAPE_ERR6) in the AIX log, indicating that the tape drive needs to be cleaned.
Page 39 Table 15. Meaning of Status Lights and Single-character Display (SCD) (continued) If the green and the amber and the SCD is... and the SCD Dot Meaning Ready Status Fault Status is... Light is... Light is... Amber/Solid Displaying an On/Off The drive is displaying error code(s) error code or from the error code log on the SCD.
Page 40: Tape Cartridges (Fc 5638)
Table 15. Meaning of Status Lights and Single-character Display (SCD) (continued) If the green and the amber and the SCD is... and the SCD Dot Meaning Ready Status Fault Status is... Light is... Light is... Flashing Amber Displaying error An error occurred and the drive or (once per second) code media may require service, or it may...
Page 41: Cleaning The Tape Drive (Fc 5638)
Cleaning the tape drive (FC 5638) You will need to clean your tape drive. Use the procedure in this topic to perform this task. About this task Clean the LTO-5 tape drive whenever C displays on the Single-character Display and the Status Light is flashing amber once per second or when a system I/O error related to the device occurs.
Page 42: Loading And Unloading Cartridges
4. Slide the cartridge into the opening on the front of the LTO tape drive, as indicated by the arrow on the cartridge. Push the cartridge fully into the drive until the cartridge is engaged and the activity LED flashes green. Results After the cleaning cartridge has been inserted, the remainder of the cleaning process is automatic.
Page 43: Unloading A Cartridge
Unloading a cartridge About this task To unload a cartridge, complete the following steps: Procedure 1. Make sure that the tape device power is on. 2. Press the Unload button. The device rewinds, unloads, and ejects the tape cartridge. The process might take from 15 seconds to several minutes, depending on the position of the tape and the amount of data written.
Page 44 Note: Do not press the eject push button more frequently than once per second or the selected maintenance function will occur instead of the desired scrolling operation. After the last maintenance function is reached, the display code wraps to 0. Unassigned digits (B, D, and G) are not displayed when the options are incremented.
Page 45: Resetting The Tape Drive
the running of the operation. If the drive runs the function successfully, the single-character display indicates 0. If the function fails, the status LED indicates continuous yellow and the single-character display indicates the reason for the error by displaying an error code. For a list of error codes, see Table 9 on page 12.
Page 46 Prerequisites In order to perform the test you need a blank LTO-5 (Ultrium 5) data cartridge. If an Ultrium-5 data cartridge is not available, an Ultrium-4 cartridge can be substituted. Performing the test Follow these steps to perform the test: Attention: Use a blank data cartridge to perform the test.
Page 47: 200/400 Gb Half High Ultrium 2 Tape Drive (Fc 5755)
Table 18. Interpreting the results of the self-test (continued) Result Description Media failure When a media problem is detected, the cartridge remains loaded inside the drive, the yellow Fault LED remains on, and a 7 is displayed in the SCD. Repeat the self-test using another blank tape cartridge and discard the defective media.
Page 48: Cleaning The Tape Drive (Fc 5755)
Cleaning the tape drive (FC 5755) You will need to clean your tape drive. Use the procedure in this topic to perform this task. About this task Clean the device whenever the Fault status light comes on or a system I/O error related to the device occurs.
Page 49: Setting The Write-Protect Switch (Fc 5755)
If a system error occurs, clean the drive and retry the operation. If the operation fails, replace the data cartridge, clean the drive again, then retry the operation. Setting the write-protect switch (FC 5755) You might need to set the write-protect switch on the media. Use the information in this topic to perform this task.
Page 50 Figure 3. Front view of tape drive Eject button Ready (green) Active (green) Cleaning (amber) Fault (amber) The status lights and their ISO symbols are on the device as follows: Ready (green) (green) Activity Cleaning (amber) Fault (amber) The combinations of the lights and their definitions are shown in the following table. Table 19.
Page 51 Table 19. Definition of Status Light Combinations (continued) Operation Ready Activity Cleaning Fault Cartridge loaded, no /Off activity Data cartridge Flashing /Off loaded, activity Cleaning cartridge Flashing loaded, activity Cleaning cartridge loaded, cleaning failed Cartridge is loading Flashing /Off or unloading Unrecoverable drive On/Off /Off...
Page 52: Tape Cartridges (Fc 5755)
Table 19. Definition of Status Light Combinations (continued) Operation Ready Activity Cleaning Fault All 4 LEDs will be on solid for 2 seconds. If the drive completes Power-On Self-Test (POST) within 2 seconds, no POST in progress indication is required. A solid amber Clean LED indicates that the drive needs cleaning.
Page 53: Resetting The Tape Drive (Fc 5755)
Attention: Do not attempt to bulk erase an LTO data cartridge for reuse. Bulk eraser devices cannot properly erase an LTO data cartridge and will permanently damage the cartridge. Resetting the tape drive (FC 5755) You might need to reset your tape drive. Use the procedure in this topic to perform this task. About this task Use this information to reset your half-high LTO-2 tape drive, without impacting server operation.
Page 54 Performing the test Follow these steps to perform the test: Attention: Use a test tape or blank (scratch) tape to perform the test. During the test, the tape will be overwritten with a test pattern and all data on the tape will be destroyed. 1.
Page 55: 160/320 Gb Internal Tape Drive Vxa-320 (Fc 6279)
Table 21. Interpreting the results of the self-test (continued) Result Description Incorrect cartridge When an incorrect tape cartridge is used for the test, the cartridge is unloaded and both the Activity and Clean LEDs will flash. This can happen if the cartridge is: v Write-protected v Damaged v Not write-compatible with the drive...
Page 56: Cleaning The Tape Drive (Fc 6120 And 6279)
Related information Check that your package contains the following items: v The device v Media kit containing: – 1 cleaning cartridge – 1 test tape – Jumpers (located in a plastic bag) v Specific hardware for attaching the device to your specific system, as detailed on the parts listing provided with your device Cleaning the tape drive (FC 6120 and 6279) You will need to clean your tape drive.
Page 57: Loading And Unloading Cartridges
v Loads the cleaning cartridge into the tape drive. v Cleans the drive by moving the cleaning tape forward for approximately 30 seconds. v Unloads the cleaning cartridge when the cleaning operation is complete. v Indicates a successful cleaning operation by turning off the Cleaning status light (if the Cleaning light was on prior to the cleaning process.
Page 58: Setting The Write-Protect Switch (Fc 6279)
The process might take from 15 seconds to several minutes, depending on the position of the tape and the amount of data written. During this task, the status lights do the following sequence: v The Ready status light turns off. v The Activity status light flashes during the unload operation.
Page 59 Figure 4. Front view of tape drive Ready (green) Active (green) Cleaning (amber) Fault (amber) Eject button The status lights and their ISO symbols are on the device as follows: Ready (green) Activity (green) Cleaning (amber) Fault (amber) The combinations of the lights and their definitions are shown in the following table. Table 22.
Page 60: Performing The Internal Self-Test (Fc 6120 Or 6279)
Table 22. Definition of Status Light Combinations (continued) Activity Fault Ready Cleaning Operation Cartridge loading or Flashing /Off unloading Unrecoverable drive On/Off /Off Flashing failure Firmware Download Flashing /Off Firmware Update Flashing Flashing /Off Microcode Download /Off Flashing failure Over Temperature /Off Notes: 1.
Page 61: Tape Cartridges (Fc 6279)
Performing the test Follow these steps to perform the internal self-test: Attention: Use a blank tape to perform the test. During the test, the tape is overwritten with a test pattern and all data on the tape is destroyed. 1. Clean the tape drive. 2.
Page 62: Resetting The Tape Drive
The V and X cartridges have similar shells and come in a variety of tape lengths. Both cartridges use Advanced Metal Evaporated (AME) media and offer the similar read/write speeds and capacities. Available tape cartridges Table 24. X tape cartridges Part Number Description Type...
Page 63: 80/160 Gb Internal Tape Drive Vxa-2 (Fc 6120)
80/160 GB internal tape drive VXA-2 (FC 6120) Learn about the features of this media device. Description The 80/160 GB Internal Tape Drive with VXA Technology is a 5.25-inch, half-high, Ultra2 LVD 16-bit tape drive, which provides a high capacity for save/restore and achieve functions.
Page 64: Loading And Unloading Cartridges
v The tape drive exceeds internal preset error thresholds in the drive. v A cleaning cartridge that has been used the maximum number of times is inserted in the drive. The cleaning indicator is turned on to indicate that the cleaning process was not done and the cleaning cartridge is no longer usable.
Page 65: Loading A Cartridge
About this task To avoid problems with loading and unloading, use only one label on a cartridge. If the cartridge has too many or poorly-placed labels, the drive-load mechanism might clog. Loading a cartridge About this task To load a cartridge, complete the following steps: Procedure 1.
Page 66: Status Lights (Fc 6120)
The position of the write-protect switch on the tape cartridge determines when you can write to the tape. When the switch is set to the left, data can be written to and read from the tape. When the switch is set to the right, data can only be read. Status lights (FC 6120) You might need to read the status lights on your tape drive to determine the operating status of the drive.
Page 67 Cleaning (amber) Fault (amber) Eject button The status lights and their ISO symbols are on the device as follows: Ready (green) Activity (green) Cleaning (amber) Fault (amber) The combinations of the lights and their definitions are shown in the following table. Table 26.
Page 68: Performing The Internal Self-Test (Fc 6120 Or 6279)
3. The Fault LED will flash to indicate an unrecoverable error. An unrecoverable error is an error condition that results in the drive not being able to function unless initiator, operator, or service intervention is applied. An unrecoverable drive failure is usually the result of a hardware error condition.
Page 69: Tape Cartridges (Fc 6120)
Table 27. Internal self-test status light combinations Activity Fault Ready Cleaning Internal self-test Media status operation Initiated Flashing rapidly Unloaded Running Flashing rapidly Flashing Loaded Passed Unloaded Passed, cleaning Unloaded needed Media failure Flashing Loaded Media Flashing Flashing Unloaded write-protected Internal self-test media not Flashing...
Page 70: Resetting The Tape Drive
Available tape cartridges Table 28. X tape cartridges Part Number Description Type Other information 24R2137 230m 80/160GB X23 Data Cartridge Green accent 24R2136 124 m 40/80GB X17 Data Cartridge Green accent 24R2134 20/40GB X6 Data Cartridge Green accent 24R2135 62m 20/40GB X6 Test Cartridge Green accent 24R2138...
Page 71: 60/150 Gb 16-Bit 8-Mm Internal Tape Drive (Fc 6134)
60/150 GB 16-bit 8-mm internal tape drive (FC 6134) Learn about the features of this media device. Description The 60/150GB 16-bit 8-mm Internal Tape Drive consists of a 5.25-inch half-high, 16-bit tape drive. This drive provides a high capacity tape drive for save/restore and archiving functions.
Page 72 Attention: Use only the recommended cleaning cartridge to clean the tape drive. Use of other than recommended cleaning cartridges can damage your drive and might void the warranty. The tape drive will turn on the cleaning indication for several reasons: v The tape drive exceeds internal preset error thresholds in the drive.
Page 73: Loading And Unloading Cartridges
Loading and unloading cartridges Learn about loading and unloading tape cartridges from this drive. About this task To avoid problems with loading and unloading, use only one label on a cartridge. If the cartridge has too many or poorly-placed labels, the drive-load mechanism might clog. Loading a cartridge About this task To load a cartridge, complete the following steps:...
Page 74: Status Lights (Fc 6134)
The position of the write-protect switch on the tape cartridge determines when you can write to the tape. When the switch is set to the left in the SAVE position 1 , data cannot be written to or read from the tape (data is saved).
Page 75: Tape Cartridges (Fc 6134)
Figure 6. Front view of tape drive Unload button Status lights Liquid crystal display (LCD) The status lights and their ISO symbols are on the device as follows: Ready (green) Activity (green) Fault (amber) The combinations of the lights and their definitions are shown in the following table. Table 30.
Page 76: Resetting The Tape Drive
Available tape cartridges Table 31. 8-mm data cartridges Part Number Type of Cartridge Length 35L1044 20 GB AME with SmartClean Data Cartridge 75 m (246 ft) 09L5323 40 GB AME with SmartClean Data Cartridge 150 m (492 ft) 18P6484 60 GB AME with SmartClean Data Cartridge 225 m (738 ft) 35L1409 Cleaning Cartridge...
Page 77: 36/72 Gb Data72 4 Mm Internal Tape Drive (Fc 6258 Or 5907)
36/72 GB Data72 4 mm internal tape drive (FC 6258 or 5907) Learn about the features of this media device. Description The 36/72 GB Data72 4 mm Internal Tape Drive is a 5.25-inch, half-high, LVD or SAS drive, which provides a high capacity for save/restore and achieve functions. This tape drive uses 4 mm data cartridges and is capable of compression, providing a capacity of up to 72 GB.
Page 78: Cleaning The Tape Drive (Fc 6258 Or 5907)
Related information Your package contains the following items: v The tape drive v Media kit containing: – 1 cleaning cartridge – 1 test tape – Jumpers (located in a plastic bag) v Specific hardware for attaching the drive to your specific system, as detailed on the parts listing provided with your drive.
Page 79: Loading And Unloading Cartridges
v Cleans the drive by moving the cleaning tape forward for approximately 30 seconds. v Unloads the cleaning cartridge when the cleaning operation is complete. v Indicates a successful cleaning operation by turning off the Fault status light (if the Fault light was on prior to the cleaning process.
Page 80: Setting The Write-Protect Switch (Fc 6258 Or 5907)
v The Activity status light flashes during the unload operation. v The Activity status light turns off when the cartridge is ejected from the tape drive. Results Attention: An emergency eject and reset feature can be used to release the tape cartridge and reset the drive.
Page 81 Figure 7. Front view of tape drive Tape drive door Status lights Ready (green) Active (green) Fault (amber) Unload/Reset button The status lights and their ISO symbols are on the device as follows: Ready Ready (green) Activity Activity (green) Fault Fault (amber) The combinations of the lights and their definitions are shown in the following table.
Page 82: Tape Cartridges (Fc 6258 Or 5907)
Table 32. Definition of status light combinations (continued) Ready Activity Fault Ready (green) Fault (amber) Activity (green) Definition One of the following conditions exists: v The power is off (Fault light is off). v The POST completed successfully, but no Off or On tape cartridge has been inserted.
Page 83: Resetting The Tape Drive
Available tape cartridges Table 33. 4-mm Data Cartridges Part Number Type of Cartridge Native (uncompressed) Capacity 18P7912 DAT 72 Data Cartridge 36 GB 59H4456 4-mm Test Cartridge 21F8763 4-mm Cleaning Cartridge 59H3465 Data Cartridge DDS3 12 GB 59H4458 Data Cartridge DDS4 20 GB Most bulk eraser devices do not have the capability to erase the 4mm data cartridge.
Page 84: 80/160 Gb Dat160 Sas Tape Drive (Fc 5619)
80/160 GB DAT160 SAS Tape Drive (FC 5619) Learn about the features of this media device. Description The 80/160 GB DAT160 SAS Tape Drive is a 5.25-inch, half-high, SAS drive, which provides a high capacity for save/restore and achieve functions. To see an illustration of this drive, see Figure 8 on page 74.
Page 85: Cleaning The Tape Drive (Fc 5619)
Cleaning the tape drive (FC 5619) You will need to clean your tape drive. Use the procedure in this topic to perform this task. About this task Clean the device whenever the Fault status light comes on or a system I/O error related to the device occurs.
Page 86: Loading And Unloading Cartridges
Note: If the cleaning operation completes but the Cleaning light remains on, repeat the cleaning procedure with a new cleaning cartridge. If the light still remain on, contact your authorized service representative. If you attempt to use a depleted cleaning cartridge, the drive automatically detects the error and ejects the cartridge.
Page 87: Setting The Write-Protect Switch (Fc 5619)
Results Attention: An emergency eject and reset feature can be used to release the tape cartridge and reset the drive. Use the emergency eject feature if the cartridge does not move correctly or if the unload process fails. The emergency eject and reset feature procedure might result in loss of data. To perform an emergency eject operation of the tape cartridge or a reset operation of the drive, press and hold the Unload button for at least 10 seconds.
Page 88 Figure 8. Front-view of tape drive Cleaning LED (amber) Media fault LED (amber) Drive fault LED (amber) Ready/Activity LED (green) Unload/Reset button The combinations of the lights and their definitions are shown in the following table. Table 34. Definition of status light combinations Ready/Activity Media fault (amber) Drive fault (amber)
Page 89: Tape Cartridges (Fc 5619)
Table 34. Definition of status light combinations (continued) Ready/Activity Media fault (amber) Drive fault (amber) Cleaning (amber) (green) Activity Unrecoverable media Flashing, on, or off failure Firmware download: download and Flashing Flashing reprogram Firmware download: See Data cartridge unloading possible unload Firmware download: reset in 1 second Firmware download:...
Page 90: Resetting The Tape Drive
Available tape cartridges Table 35. 4 mm data cartridges part number Type of cartridge 23R5635 (cartridge feature code 5689) DAT160 80 GB Data Cartridge 23R5636 4 mm Test Cartridge 23R5638 4 mm Cleaning Cartridge (Only use the DAT160 cleaning cartridge on the DAT160 tape drive) Most bulk eraser devices do not have the capability to erase the 4 mm data cartridge.
Page 91 The 80/160 GB DAT160 SAS Tape Drive (FC 1124) information applies only to 31E/2B, 31E/1C, or 31E/2C system. Table 36. 80/160 GB DAT160 SAS Tape Drive Description The 80/160 GB DAT160 SAS Tape Drive is a 3.5-inch, half-high, SAS drive, which provides a high capacity for save/restore and achieve functions.
Page 92: Cleaning The Tape Drive (Fc 1124)
Cleaning the tape drive (FC 1124) You will need to clean your tape drive. Use the procedure in this topic to perform this task. About this task Clean the device whenever the Fault status light comes on or a system I/O error related to the device occurs.
Page 93: Loading And Unloading Cartridges
Note: If the cleaning operation completes but the Cleaning light remains on, repeat the cleaning procedure with a new cleaning cartridge. If the light still remain on, contact your authorized service representative. If you attempt to use a depleted cleaning cartridge, the drive automatically detects the error and ejects the cartridge.
Page 94: Setting The Write-Protect Switch (Fc 1124)
Results Attention: An emergency eject and reset feature can be used to release the tape cartridge and reset the drive. Use the emergency eject feature if the cartridge does not move correctly or if the unload process fails. The emergency eject and reset feature procedure might result in loss of data. To perform an emergency eject operation of the tape cartridge or a reset operation of the drive, press and hold the Unload button for at least 10 seconds.
Page 95 Figure 9. Front-view of tape drive Cleaning LED (amber) Media fault LED (amber) Drive fault LED (amber) Ready/Activity LED (green) Unload/Reset button The combinations of the lights and their definitions are shown in the following table. Table 37. Definition of status light combinations Ready/Activity Media fault (amber) Drive fault (amber)
Page 96: Tape Cartridges (Fc 1124)
Table 37. Definition of status light combinations (continued) Ready/Activity Media fault (amber) Drive fault (amber) Cleaning (amber) (green) Activity Unrecoverable media Flashing, on, or off failure Firmware download: download and Flashing Flashing reprogram Firmware download: See Data cartridge unloading possible unload Firmware download: reset in 1 second Firmware download:...
Page 97: Resetting The Tape Drive
Available tape cartridges Table 38. 4 mm data cartridges part number Type of cartridge 23R5635 (cartridge feature code 5689) DAT160 80 GB Data Cartridge 23R5636 4 mm Test Cartridge 23R5638 4 mm Cleaning Cartridge Most bulk eraser devices do not have the capability to erase the 4 mm data cartridge. Resetting the tape drive You might need to reset your tape drive.
Page 98: 160/320 Gb Dat320 Sas Tape Drive (Fc 5661)
160/320 GB DAT320 SAS tape drive (FC 5661) Learn about the features of this media device. Description The 160/320 GB DAT320 SAS Tape Drive is a 5.25-inch, half-high, SAS drive, which provides a high capacity for save/restore and achieve functions. To see an illustration of this drive, see Figure 10 on page 88.
Page 99: Cleaning The Tape Drive (Fc 5661)
Cleaning the tape drive (FC 5661) You will need to clean your tape drive. Use the procedure in this topic to perform this task. About this task Clean the device whenever the Fault status light comes on or a system I/O error related to the device occurs.
Page 100: Loading And Unloading Cartridges
v Indicates a successful cleaning operation by turning off the Cleaning status light (if the Cleaning light was on prior to the cleaning process. Otherwise, the Cleaning light remains solid to indicate that the cleaning cartridge is no longer usable. Obtain a new cleaning cartridge and repeat the process.) Note: If the cleaning operation completes but the Cleaning light remains on, repeat the cleaning procedure with a new cleaning cartridge.
Page 101: Setting The Write-Protect Switch (Fc 5661)
v The Activity status light turns off when the cartridge is ejected from the tape drive. Results Attention: An emergency eject and reset feature can be used to release the tape cartridge and reset the drive. Use the emergency eject feature if the cartridge does not move correctly or if the unload process fails.
Page 102 Figure 10. Front view of tape drive Cleaning LED (amber) Media fault LED (amber) Drive fault LED (amber) Encrypt LED (blue) Ready/Activity LED (green) Unload/Reset button The combinations of the lights and their definitions are shown in the following table. Table 39.
Page 103 Table 39. Definition of status light combinations (continued) Ready/ Tape fault Drive fault Cleaning Encrypt fault Activity (amber) (amber) (amber) (blue) (green) Activity Flash_2Hz or Unrecoverable media failure on or off Firmware download Unload (if cartridge present) See: Data Cartridge Unloading Download and reprogram Flash_8Hz Flash_8Hz...
Page 104: Tape Cartridges (Fc 5661)
Table 39. Definition of status light combinations (continued) Ready/ Tape fault Drive fault Cleaning Encrypt fault Activity (amber) (amber) (amber) (blue) (green) Activity CLEAN_LED activation in this state means the drive needs cleaning. It will be set due to hard or soft errors. It is cleared upon successful cleaning cartridge usage.
Page 105: 160/320 Gb Dat320 Usb Tape Drive (Fc 5673)
About this task Use this information to reset your tape drive, without affecting server operation. Allow up to 2 minutes for the entire tape drive process to complete. Attention: Resetting a tape drive before the current backup operation has completed can cause loss of customer data.
Page 106: Cleaning The Tape Drive (Fc 5673)
Media This tape drive uses 4 mm data cartridges for saving and restoring system data. It is designed to use only DDS (Digital Data Storage) data cartridges. The cartridges are identified by one of the following DDS symbols: The tape drive reads and writes data to tape cartridges that are in the DAT160 or DAT320 format.
Page 107: Loading And Unloading Cartridges
To clean the tape drive, complete the following steps: Procedure 1. Make sure that the power is on for the tape drive. 2. If a tape cartridge is in the tape drive, eject and remove the cartridge. 3. Grasp the cleaning cartridge by the outer edges, with the window-side up and the write-protect switch facing you.
Page 108: Unloading A Cartridge
Results To indicate that the load operation was successful, the Ready status light comes on. Unloading a cartridge About this task To unload a cartridge, complete the following steps: Procedure 1. Make sure that the tape device power is on. 2.
Page 109: Status Lights (Fc 5673)
When the switch is set to the right, data can be written to and read from the tape. When the switch is set to the left, data can only be read. Status lights (FC 5673) You might need to read the status lights on your tape drive to determine the operating status of the drive.
Page 110 Table 41. Definition of status light combinations Ready/ Tape fault Drive fault Cleaning Encrypt fault Activity (amber) (amber) (amber) (blue) (green) Activity Power on LED test (5 seconds) Power on self-test (POST) activity Flash_2Hz POST failed Flash_2Hz POST passed or off Data cartridge Loading or off...
Page 111 Table 41. Definition of status light combinations (continued) Ready/ Tape fault Drive fault Cleaning Encrypt fault Activity (amber) (amber) (amber) (blue) (green) Activity In progress See Data cartridge: loading Flash_4Hz Normal Flash_4Hz Using tape with Passed , tape Normal Flash_4Hz diagnostic tape ejected See Data cartridge: ejected...
Page 112: Tape Cartridges (Fc 5673)
Table 41. Definition of status light combinations (continued) Ready/ Tape fault Drive fault Cleaning Encrypt fault Activity (amber) (amber) (amber) (blue) (green) Activity CLEAN_LED activation in this state means the drive needs cleaning. It will be set due to hard or soft errors. It is cleared upon successful cleaning cartridge usage.
Page 113: 80/160 Gb Dat160 Usb Tape Drive (Fc Eu16)
About this task Use this information to reset your tape drive, without affecting server operation. Allow up to 2 minutes for the entire tape drive process to complete. Attention: Resetting a tape drive before the current backup operation has completed can cause loss of customer data.
Page 114: Cleaning The Tape Drive (Fc Eu16)
Media This tape drive uses 4 mm data cartridges for saving and restoring system data. It is designed to use only DDS (Digital Data Storage) data cartridges. The cartridges are identified by one of the following DDS symbols: The tape drive reads and writes data to tape cartridges that are in the DDS4, DAT72, or DAT160 format.
Page 115: Loading And Unloading Cartridges
Procedure 1. Make sure that the power is on for the tape drive. 2. If a tape cartridge is in the tape drive, eject and remove the cartridge. 3. Grasp the cleaning cartridge by the outer edges, with the window-side up and the write-protect switch facing you.
Page 116: Unloading A Cartridge
Results To indicate that the load operation was successful, the Ready status light comes on. Unloading a cartridge About this task To unload a cartridge, complete the following steps: Procedure 1. Make sure that the tape device power is on. 2.
Page 117: Status Lights (Fc Eu16)
When the switch is set to the right, data can be written to and read from the tape. When the switch is set to the left, data can only be read. Status lights (FC EU16) You might need to read the status lights on your tape drive to determine the operating status of the drive.
Page 118 Table 43. Definition of status light combinations Ready/Activity Media fault (amber) Drive fault (amber) Cleaning (amber) (green) Activity Power on LED test (2.0 seconds) Power on self-test Flashing (POST) activity POST failed Flashing POST passed or off Data cartridge loading or off Flashing Data cartridge loaded,...
Page 119: Tape Cartridges (Fc Eu16)
Table 43. Definition of status light combinations (continued) Ready/Activity Media fault (amber) Drive fault (amber) Cleaning (amber) (green) Activity See Data cartridge loading and then: Tape diagnostics test in progress Flashing Flashing Flashing Tape diagnostics test passed, tape ejected After data cartridge ejects, see Data cartridge ejected. Flashing Tape diagnostics test failed, tape ejected...
Page 120 Attention: Resetting a tape drive before the current backup operation has completed can cause loss of customer data. To reset the tape drive, follow these steps: Procedure 1. Press and hold the eject button for 20 seconds, and then release the button. The LEDs on the drive will be flashing while the reset function is in process.
Page 121: Managing Dvd Drives
Managing DVD drives Learn about using and managing removable media devices. Find specifications and installation notes for specific drives. IDE Slimline DVD-ROM Drive (FC 5756) Learn about the specifications of this DVD-ROM drive. The IDE Slimline DVD-ROM drive is an internal DVD-ROM drive. This drive can read type II (removable from cartridge) DVD-RAM discs at 2x speeds.
Page 122: Sata Slimline Dvd-Rom Drive (Fc 5743)
v Form factor: 12.7 mm Slimline v DVD video: not supported v AIX 5.1 only reads CD-type formatted DVD media v Requirements: 1 Slimline media bay SATA Slimline DVD-ROM Drive (FC 5743) Learn about the specifications of this DVD-ROM drive. The serial advanced technology attachment (SATA) Slimline DVD-ROM Drive is an internal tray loading DVD-ROM drive.
Page 123: Sata Slimline Dvd-Ram Drive (Fc 5771)
v Form factor: 12.7 mm Slimline v DVD video: not supported v AIX 5.1 only reads CD-type formatted DVD media v Requirements: 1 Slimline media bay SATA Slimline DVD-RAM Drive (FC 5771) Learn about the specifications of this DVD-RAM drive. The serial advanced technology attachment (SATA) Slimline DVD-RAM Drive is an internal, low profile DVD-RAM drive that is capable of reading and writing 4.7 GB DVD-RAM discs, as well as reading a multitude of other optical media discs.
Page 124: Opening A Dvd Tray Manually
5. Remove dirt, foreign materials, fingerprints, smudges, and liquids by wiping with a clean cotton fabric in a straight line from the center of the disc toward the outer edge. 6. Check the media surface before recording. Incorrect ways to handle DVD media: 1.
Page 125 drive. Only for playback in DVD-ROM drives compatible with DVD-RAM. drive. Only for playback in DVD-ROM drives compatible with DVD-RAM. The DVD-RAM T The DVD-RAM T Locking Pin Lock Button Cartridge Lid Returning a disc to the cartridge To return a disc to the cartridge, do the following steps: Notes: Both the disc label and the cartridge label should be facing up.
Page 126 Managing devices...
Page 127: Managing Diskette Drives
Managing diskette drives Learn about the features of specific diskette drives. External USB 1.44 MB diskette drive (FC 2591) Learn about the features of this media device. The following provides information about the external USB 1.44 MB diskette drive. Installation To install this external USB 1.44 MB diskette drive, complete the following steps: 1.
Page 128 Managing devices...
Page 129: Managing Removable Disk Drives
Managing removable disk drives Learn about using and managing removable disk drives. Find specifications and installation notes for specific drives. RDX USB Internal Dock (1103, 1123, EU03, and EU23) and RDX Removable Disk Drives (1106, 1107, EU01, and EU08) Learn about the features of this drive. Description The feature code (FC) 1123 and FC EU23 information applies only to the 31E/2B, 31E/1C, or 31E/2C system.
Page 130 Power connector USB connector Feature codes and part numbers Learn about the feature codes (FCs) and part numbers for the USB Removable Disk Drive. FC 1103 - USB Internal Docking Station for Removable Disk Drive FC 1103 uses an internal USB cable to connect to the internal USB port on the control panel of a system that supports this feature.
Page 131 FC EU03 provides the following parts: 46C2332 (FRU: 46C2346) - Internal RDX USB 3.0 Dock 46K7435 - Internal USB cable (12 inch) 46K7434 - Internal power cable (11 inch) with right angle power connector 44V3429 - Two drive slide assembly rails 1621187 - Four flat blade screws FC EU23 - USB Internal Docking Station for Removable Disk Drive FC EU23 uses an internal USB cable to connect to the internal USB port on the control panel of a...
Page 132 Specifications Interface USB 2.0 Mksysb Bootable Physical form factor (internal docking station) 5.25 inch half high 3.5 inch half high for the 31E/2B, 31E/1C, or 31E/2C system (FC 1123) Environmental USB Removable Disk Drive Operating conditions Non-operating conditions Temperature 5 to 55 C –40 to 65 C Relative humidity 8 - 90% noncondensing...
Page 133 The AIX tar, backup, restore, dd, and cpio commands can write to the removable disk drive as a raw device or nonraw device. You might get improved performance by using the device as a raw device. See the AIX documentation for additional information. Using the drive with IBM i IBM i configures the drive as a removable media drive with a name in the format RMSxx, for example, RMS01.
Page 134 Table 46. Power indicator (continued) Indicator status Meaning Description Steady green Ready Power is on and the docking station is working correctly. Flashing green Ejecting Cartridge is ejecting. Flashing amber Fault Docking station has detected a fault condition with the docking station. Removable disk drive indicator The disk drive has an indicator light that displays the status of the drive.
Page 135: Notices
Notices This information was developed for products and services offered in the U.S.A. The manufacturer may not offer the products, services, or features discussed in this document in other countries. Consult the manufacturer's representative for information on the products and services currently available in your area.
Page 136: Trademarks
This information is for planning purposes only. The information herein is subject to change before the products described become available. This information contains examples of data and reports used in daily business operations. To illustrate them as completely as possible, the examples include the names of individuals, companies, brands, and products.
Page 137 harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference, in which case the user will be required to correct the interference at his own expense.
Page 138 This is a Class A product based on the standard of the VCCI Council. If this equipment is used in a domestic environment, radio interference may occur, in which case, the user may be required to take corrective actions. Japanese Electronics and Information Technology Industries Association (JEITA) Confirmed Harmonics Guideline (products less than or equal to 20 A per phase) Japanese Electronics and Information Technology Industries Association (JEITA) Confirmed Harmonics Guideline with Modifications (products greater than 20 A per...
Page 139 Electromagnetic Interference (EMI) Statement - Korea Germany Compliance Statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse A EU-Richtlinie zur Elektromagnetischen Verträglichkeit Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG zur Angleichung der Rechtsvorschriften über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse A ein.
Page 140: Class B Notices
Generelle Informationen: Das Gerät erfüllt die Schutzanforderungen nach EN 55024 und EN 55022 Klasse A. Electromagnetic Interference (EMI) Statement - Russia Class B Notices The following Class B statements apply to features designated as electromagnetic compatibility (EMC) Class B in the feature installation information. Federal Communications Commission (FCC) statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 141 European Community Compliance Statement This product is in conformity with the protection requirements of EU Council Directive 2004/108/EC on the approximation of the laws of the Member States relating to electromagnetic compatibility. IBM cannot accept responsibility for any failure to satisfy the protection requirements resulting from a non-recommended modification of the product, including the fitting of non-IBM option cards.
Page 142: Terms And Conditions
Germany Compliance Statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse B EU-Richtlinie zur Elektromagnetischen Verträglichkeit Dieses Produkt entspricht den Schutzanforderungen der EU-Richtlinie 2004/108/EG zur Angleichung der Rechtsvorschriften über die elektromagnetische Verträglichkeit in den EU-Mitgliedsstaaten und hält die Grenzwerte der EN 55022 Klasse B ein. Um dieses sicherzustellen, sind die Geräte wie in den Handbüchern beschrieben zu installieren und zu betreiben.
Page 143 these publications, or reproduce, distribute or display these publications or any portion thereof outside your enterprise, without the express consent of the manufacturer. Rights: Except as expressly granted in this permission, no other permissions, licenses or rights are granted, either express or implied, to the Publications or any information, data, software or other intellectual property contained therein.
Page 144 Managing devices...
Page 146 Printed in USA...

Bull Escala E2-700T Manual

Quick Links

Related Manuals for Bull Escala E2-700T

Summary of Contents for Bull Escala E2-700T

This manual is also suitable for:

Table of Contents
