Chapter 1. What’s new in Managing devices See what is new and what has changed in Managing devices since the last edition of this topic. April 2010 ™ ™ v Added information for IBM Power Systems servers that contain the POWER7 processor.
Chapter 2. Managing tape drives Learn about using and managing removable media devices. Find specifications and installation notes for specific drives. Tape drives Learn general information about tape drives. Select the appropriate information from this list: v Tape drive overview v Tape drive environment and use v Tape handling and storage v Environmental issues...
Page 16
Tape handling and storage Most tape is supplied in a sealed cartridge so that the tape will remain clean. Opening the cartridge allows dirt and airborne particles to enter and then become a source of contamination. The cartridge should only be opened by the tape drive and not an operator. The tape also is held under proper tension inside the cartridge.
Tape drive media Learn about using the different types of tape drive media. Attention: Your system supplier might support only the media that it sells. If the supplier’s analysis indicates that the problem is caused by using inferior media, it is the customer’s responsibility to replace the inferior media.
Page 18
v Make sure the environment is kept clean and constant. Do not operate in a dusty environment and always maintain a constant environment. A consistent storage and operating environment reduces media exposure to climatic stress. Use only the recommended cleaning cartridge to clean the tape drive. Use of other than recommended cleaning cartridges can damage your drive and might void the warranty.
v Always store tape cartridges in their protective cases. The storage case helps prevent damage from dust and physical misuse. When the tape cartridges are not in use or being stored, keep them in their storage cases and stand on edge in a designated storage location. Do not stack cartridges on the flat side or stack other items on top of the tape cartridges.
Page 20
Table 2. Recommended test, cleaning, and 4mm data cartridges for the specific type of tape drive (continued) Tape Drive Part Number Type of Cartridge DAT72 59H4457 Test Cartridge 11.5m 21F8763 Cleaning Cartridge 50 cleanings 18P7912 Data Cartridge 36 GB DAT160 23R5636 Test Cartridge 155m...
Table 6. LTO Ultrium data cartridges Part Number Type of Cartridge Length 08L9120 100/200GB LTO Ultrium 1 Data 610 m (2000 ft ) Cartridge 08L9870 200/400GB LTO Ultrium 2 Data 610 m (2000 ft ) Cartridge 24R1922 LTO-3 Data Cartridge (400GB/800GB) 96P1203 LTO-3 Worm Data Cartridge 95P4436...
Configuring the tape drive To configure the drive after installation, boot your system unit. Device drivers are provided in the operating systems that support the drive. Your operating system recognizes the drive and automatically updates your system unit configuration. Updating microcode levels Media devices contain microcode that you can update.
Related information Your package contains the following items: v The tape drive v Media kit containing: – One cleaning cartridge – One test tape v Specific hardware for attaching the drive to your specific system, as detailed on the parts listing provided with your drive.
Status lights (FC 5746) You might need to read the status lights on your tape drive to determine the operating status of the drive. Use the information in this topic to perform this task. The following illustration shows a front view of the tape drive: Figure 1.
Page 25
Table 8. Definition of Status Light Combinations (continued) Operation Ready Fault Single character Response display Maximum operating Reduce drive temperature exceeded temperature. Input voltage failure Check input power connections. Drive firmware Flashing Update to latest level failure firmware. Drive firmware or Flashing Clean drive, replace hardware failure...
Table 8. Definition of Status Light Combinations (continued) Operation Ready Fault Single character Response display When used in this table, flashing refers to a 1 Hz flash rate (1 flash per second), and flashing rapidly refers to a 4 Hz flash rate (4 flashes per second).
Setting the write-protect switch (FC 5746) You might need to set the write-protect switch on your tape drive. Use the information in this topic to perform this task. Attention: Do not attempt to change the write-protect settings after the tape cartridge is loaded in the drive because this might cause unpredictable results and might damage the tape or the drive.
was in the SCD prior to the cleaning process, the indicators will stay on after the depleted cleaning cartridge is removed. If these indicators were off prior to inserting the depleted cleaning cartridge, they will turn off once the depleted cleaning cartridge is removed from the drive. To clean the tape drive, complete the following steps: 1.
Page 29
Scrolling through maintenance options With the drive in maintenance mode, press the eject push button at a rate of once per second. The single-character display code increments by one each time you press the eject push button. Note: Do not press the eject push button more frequently than once per second or the selected maintenance function will occur instead of the desired scrolling operation.
Running a maintenance function To run the maintenance function indicated by the character on the single-character display, press and hold the eject button for 2 seconds. The single digit flashes the selected maintenance function code during the running of the operation. If the drive runs the function successfully, the single-character display indicates 0.
Page 31
Performing the test Follow these steps to perform the test: Attention: Use a blank data cartridge to perform the test. During the test, the tape will be overwritten with a test pattern and all data on the tape will be destroyed. 1.
Table 11. Interpreting the results of the self-test (continued) Result Description Incorrect cartridge When an incorrect tape cartridge is used for the test, the cartridge is unloaded, the yellow Fault LED remains on, and a P, 7, or J is displayed in the SCD. This can happen if the cartridge is: v Write-protected (P is displayed in the SCD.) v Damaged (7 is displayed in the SCD.)
Clean the device whenever the Fault status light comes on or a system I/O error related to the device occurs. Attention: Use only the recommended cleaning cartridge to clean the tape drive. Use of other than recommended cleaning cartridges can damage your drive and might void the warranty. The tape drive will turn on the cleaning indication for several reasons: v - The tape drive exceeds internal preset error thresholds in the drive.
Attention: Do not attempt to change the write-protect settings after the tape cartridge is loaded in the drive because this might cause unpredictable results and might damage the tape or the drive. The position of the write-protect switch on the tape cartridge determines when you can write to the tape. Before loading cartridges into magazines, set the write-protect switch of each cartridge to enable or disable data recording.
Page 35
Figure 2. Front view of tape drive Eject button Ready (green) Active (green) Cleaning (amber) Fault (amber) The status lights and their ISO symbols are on the device as follows: Ready (green) (green) Activity Cleaning (amber) Fault (amber) The combinations of the lights and their definitions are shown in the following table. Table 12.
Page 36
Table 12. Definition of Status Light Combinations (continued) Operation Ready Activity Cleaning Fault Cartridge loaded, no /Off activity Data cartridge Flashing /Off loaded, activity Cleaning cartridge Flashing loaded, activity Cleaning cartridge loaded, cleaning failed Cartridge is loading Flashing /Off or unloading Unrecoverable drive On/Off /Off...
Table 12. Definition of Status Light Combinations (continued) Operation Ready Activity Cleaning Fault All 4 LEDs will be on solid for 2 seconds. If the drive completes Power-On Self-Test (POST) within 2 seconds, no POST in progress indication is required. A solid amber Clean LED indicates that the drive needs cleaning.
Attention: Do not attempt to bulk erase an LTO data cartridge for reuse. Bulk eraser devices cannot properly erase an LTO data cartridge and will permanently damage the cartridge. Resetting the tape drive (FC 5755) You might need to reset your tape drive. Use the procedure in this topic to perform this task. Use this information to reset your half-high LTO-2 tape drive, without impacting server operation.
Page 39
a. Verify that a tape cartridge is not loaded in the drive. To unload a cartridge, press the eject button on the front of the drive. b. Press and hold the eject button for 7 seconds, until the green Ready LED starts flashing rapidly, and then release the button.
Table 14. Interpreting the results of the self-test (continued) Result Description Incorrect cartridge When an incorrect tape cartridge is used for the test, the cartridge is unloaded and both the Activity and Clean LEDs will flash. This can happen if the cartridge is: v Write-protected v Damaged v Not write-compatible with the drive...
Related information Check that your package contains the following items: v The device v Media kit containing: – 1 cleaning cartridge – 1 test tape – Jumpers (located in a plastic bag) v Specific hardware for attaching the device to your specific system, as detailed on the parts listing provided with your device Cleaning the tape drive (FC 6120 and 6279) You will need to clean your tape drive.
Note: If the cleaning operation completes but the Cleaning light remains on, repeat the cleaning procedure with a new cleaning cartridge. If the light still remain on, contact your authorized service representative. To determine how many times a cleaning cartridge may be used, check the information printed on the cartridge.
Attention: Do not attempt to change the write-protect settings after the tape cartridge is loaded in the drive because this might cause unpredictable results and might damage the tape or the drive. The position of the write-protect switch on the tape cartridge determines when you can write to the tape. When the switch is set to the left, data can be written to and read from the tape.
Page 44
Eject button The status lights and their ISO symbols are on the device as follows: Ready (green) Activity (green) (amber) Cleaning Fault (amber) The combinations of the lights and their definitions are shown in the following table. Table 15. Definition of Status Light Combinations Activity Fault Ready...
intervention is applied. An unrecoverable drive failure is usually the result of a hardware error condition. One of the following actions will be needed to clear the flashing Fault LED: v Hard SCSI Reset v Cartridge Eject v Power Cycle v Retry microcode download An unrecoverable cartridge (media) failure is usually the result of a defective cartridge, media, or cartridge state and will require the drive to eject the cartridge (if possible) to clear the flashing LED.
Resetting the tape drive You might need to reset your tape drive. Use the procedure in this topic to perform this task. Use this information to reset your tape drive, without affecting server operation. Allow up to 2 minutes for the entire tape drive process to complete. Attention: Resetting a tape drive before the current backup operation has completed can cause loss of customer data.
Related information Check that your package contains the following items: v The device v Media kit containing: – 1 data cartridge – 1 cleaning cartridge – 1 test tape – Jumpers (located in a plastic bag) v Specific hardware for attaching the device to your specific system, as detailed on the parts listing provided with your device Cleaning the tape drive (FC 6120 and 6279) You will need to clean your tape drive.
v Indicates a successful cleaning operation by turning off the Cleaning status light (if the Cleaning light was on prior to the cleaning process. Otherwise, the Cleaning light remains solid to indicate that the cleaning cartridge is no longer usable. Obtain a new cleaning cartridge and repeat the process.) Note: If the cleaning operation completes but the Cleaning light remains on, repeat the cleaning procedure with a new cleaning cartridge.
Setting the write-protect switch (FC 6120) You might need to set the write-protect switch on your tape drive. Use the information in this topic to perform this task. Attention: Do not attempt to change the write-protect settings after the tape cartridge is loaded in the drive because this might cause unpredictable results and might damage the tape or the drive.
Page 51
Figure 4. Front view of tape drive Ready (green) Active (green) Cleaning (amber) Fault (amber) Eject button The status lights and their ISO symbols are on the device as follows: Ready (green) Activity (green) Cleaning (amber) Fault (amber) The combinations of the lights and their definitions are shown in the following table. Table 19.
Performing the test Follow these steps to perform the internal self-test: Attention: Use a blank tape to perform the test. During the test, the tape is overwritten with a test pattern and all data on the tape is destroyed. 1. Clean the tape drive. 2.
The V and X cartridges have similar shells and come in a variety of tape lengths. Both cartridges utilize AME media and offer the similar read/write speeds and capacities. Note: 1. To use X cartridges, the tape drive must have a minimum microcode level of 2105. To display the microcode level of the tape drive in the AIX operating system, do the following steps: a.
2. When the LEDs stop flashing, wait approximately one minute for the drive to complete the reset operation. The drive will then be ready to use. 60/150 GB 16-bit 8-mm internal tape drive (FC 6134) Learn about the features of this media device. Description The 60/150GB 16-bit 8-mm Internal Tape Drive consists of a 5.25-inch half-high, 16-bit tape drive.
Page 56
Clean the device whenever the Fault status light comes on or a system I/O error related to the device occurs. Attention: Use only the recommended cleaning cartridge to clean the tape drive. Use of other than recommended cleaning cartridges can damage your drive and might void the warranty. The tape drive will turn on the cleaning indication for several reasons: v The tape drive exceeds internal preset error thresholds in the drive.
Loading and unloading cartridges Learn about loading and unloading tape cartridges from this drive. To avoid problems with loading and unloading, use only one label on a cartridge. If the cartridge has too many or poorly-placed labels, the drive-load mechanism might clog. Loading a cartridge To load a cartridge, complete the following steps: 1.
When the switch is set to the left in the SAVE position 1 , data cannot be written to or read from the tape (data is saved). When the switch is set to the right in the REC (Record) position 2 , data can be written to and read from the tape. Status lights (FC 6134) You might need to read the status lights on your tape drive to determine the operating status of the drive.
Figure 5. Front view of tape drive Unload button Status lights Liquid crystal display (LCD) The status lights and their ISO symbols are on the device as follows: Ready (green) Activity (green) Fault (amber) The combinations of the lights and their definitions are shown in the following table. Table 23.
Available tape cartridges Table 24. 8-mm data cartridges Part Number Type of Cartridge Length 35L1044 20 GB AME with SmartClean Data Cartridge 75 m (246 ft) 09L5323 40 GB AME with SmartClean Data Cartridge 150 m (492 ft) 18P6484 60 GB AME with SmartClean Data Cartridge 225 m (738 ft) 35L1409 Cleaning Cartridge...
Tools The following tools and documentation are needed to complete the installation: v A flat-blade screwdriver (if this device is not an auto-docking feature on your system) v Your system unit documentation, including any service documentation v Your operating system documentation Contact the place of purchase if an item is missing or damaged.
LED to indicate the drive needs cleaning. The tape drive will continue to operate but the tape drive should be cleaned at the next opportunity to insert a cleaning cartridge. To clean the tape drive, complete the following steps: 1. Make sure that the power is on to the tape drive. 2.
Unloading a cartridge To unload a cartridge, complete the following steps: 1. Make sure that the tape device power is on. 2. Press the Unload button. The device rewinds, unloads, and ejects the tape cartridge. The process might take from 15 seconds to several minutes, depending on the position of the tape and the amount of data written.
Status lights (FC 6258 or 5907) You might need to read the status lights on your tape drive to determine the operating status of the drive. Use the information in this topic to perform this task. The following illustration is a front view of the tape drive: Figure 6.
Page 65
Table 25. Definition of status light combinations (continued) Ready Activity Fault Ready (green) Fault (amber) Activity (green) Definition The tape drive requires cleaning. See Cleaning the tape drive. v If the Ready light is on, a tape cartridge is in the drive. If the light is off, a cartridge is Off or On Off or Flashing not in the drive.
v When the tape drive indicates that the drive needs to be cleaned, it is the customer’s responsibility to clean the tape drive with the recommended cleaning cartridge. v If a tape cartridge that is not DDS-3, DDS-4, or DAT72 format is used, that cartridge will be immediately ejected as an incorrect cartridge type.
Description The 80/160 GB DAT160 SAS Tape Drive is a 5.25-inch, half-high, SAS drive, which provides a high capacity for save/restore and achieve functions. To see an illustration of this drive, see Figure 7 on page 58. This tape drive uses IBM DAT160, 4 mm data cartridges and is compression capable, providing a capacity of up to 160 GB with 2:1 compression ratio.
Page 68
Clean the device whenever the Fault status light comes on or a system I/O error related to the device occurs. Attention: Use only the recommended cleaning cartridge to clean the tape drive. Use of other than recommended cleaning cartridges can damage your drive and might void the warranty. The cleaning cartridge for this drive is P/N 23R5638.
If a system error occurs, clean the drive and retry the operation. If the operation fails, replace the data cartridge, clean the drive again, then retry the operation. Loading and unloading cartridges Learn about loading and unloading tape cartridges from this drive. To avoid problems with loading and unloading, use only one label on a cartridge.
When the switch is set to the right, data can be written to and read from the tape. When the switch is set to the left, data can only be read. Status lights (FC 5619) You might need to read the status lights on your tape drive to determine the operating status of the drive.
Page 71
Table 27. Definition of status light combinations Ready/Activity Media fault (amber) Drive fault (amber) Cleaning (amber) (green) Activity Power on LED test (2.0 seconds) Power on self-test Flashing (POST) activity POST failed Flashing POST passed or off Data cartridge loading or off Flashing Data cartridge loaded,...
Table 27. Definition of status light combinations (continued) Ready/Activity Media fault (amber) Drive fault (amber) Cleaning (amber) (green) Activity See Data cartridge loading and then: Tape diagnostics test in progress Flashing Flashing Flashing Tape diagnostics test passed, tape ejected After data cartridge ejects, see Data cartridge ejected. Flashing Tape diagnostics test failed, tape ejected...
To reset the tape drive, follow these steps: 1. Press and hold the eject button for 20 seconds, and then release the button. The LEDs on the drive will be flashing while the reset function is in process. 2. When the LEDs stop flashing, wait approximately one minute for the drive to complete the reset operation.
Related information Your package contains the following items: v The tape drive v Media kit containing: – One cleaning cartridge – One test cartridge v Specific hardware for attaching the drive to your specific system, as detailed on the parts listing provided with your drive.
v Cleans the drive by moving the cleaning tape forward for approximately 30 seconds. v Unloads the cleaning cartridge when the cleaning operation is complete. v Indicates a successful cleaning operation by turning off the Cleaning status light (if the Cleaning light was on prior to the cleaning process.
Setting the write-protect switch (FC 5661) You might need to set the write-protect switch on your tape drive. Use the information in this topic to perform this task. Attention: Do not attempt to change the write-protect settings after the tape cartridge is loaded in the drive because this might cause unpredictable results and might damage the tape or the drive.
Page 77
Drive fault LED (amber) Encrypt LED (blue) Ready/Activity LED (green) Unload/Reset button The combinations of the lights and their definitions are shown in the following table. Table 29. Definition of status light combinations Ready/ Tape fault Drive fault Cleaning Encrypt fault Activity (amber) (amber)
Page 78
Table 29. Definition of status light combinations (continued) Ready/ Tape fault Drive fault Cleaning Encrypt fault Activity (amber) (amber) (amber) (blue) (green) Activity In progress See Data cartridge: Loaded, activity Initiated by SCSI Passed See Data cartridge: Loaded, no activity diagnostic using Failed Normal...
Table 29. Definition of status light combinations (continued) Ready/ Tape fault Drive fault Cleaning Encrypt fault Activity (amber) (amber) (amber) (blue) (green) Activity CLEAN_LED activation in this state means the drive needs cleaning. It will be set due to hard or soft errors. It is cleared upon successful cleaning cartridge usage.
Resetting the tape drive You might need to reset your tape drive. Use the procedure in this topic to perform this task. Use this information to reset your tape drive, without affecting server operation. Allow up to 2 minutes for the entire tape drive process to complete. Attention: Resetting a tape drive before the current backup operation has completed can cause loss of customer data.
Chapter 3. Managing DVD drives Learn about using and managing removable media devices. Find specifications and installation notes for specific drives. IDE Slimline DVD-ROM Drive (FC 5756) Learn about the specifications of this DVD-ROM drive. The IDE Slimline DVD-ROM drive is an internal DVD-ROM drive. This drive can read type II (removable from cartridge) DVD-RAM discs at 2x speeds.
– Writes 4.7 GB DVD-RAM discs v Interface: IDE/ATAPI v Interface: parallel IDE v Connector: Ultraslim enhanced (USE) v Loading tray: supports 12 cm and 8 cm discs v Operating positions: vertical or horizontal (8 cm discs require horizontal operation) v Form factor: 12.7 mm Slimline v DVD video: not supported v AIX 5.1 only reads CD-type formatted DVD media...
Related reference “Opening a DVD tray manually” Under usual conditions, the tray automatically opens when you press the Load/Unload button. If it does not automatically open, you can use the emergency eject feature to open the tray manually. “DVD-RAM type II disc” on page 72 The DVD-RAM type II disc can be removed from its cartridge and played in a DVD-ROM or DVD-RAM drive that is compatible with the DVD-RAM type II disc.
3. Continue to push in the paper clip while you pull out the tray with your fingernail. 4. Pull the tray completely open and remove the disc. It is usual for the tray to make a clicking sound while you are pulling it open. DVD-RAM type II disc The DVD-RAM type II disc can be removed from its cartridge and played in a DVD-ROM or DVD-RAM drive that is compatible with the DVD-RAM type II disc.
Page 85
Returning a disc to the cartridge To return a disc to the cartridge, do the following steps: Notes: Both the disc label and the cartridge label should be facing up. Handle the disc only by its edges. 1. Slide the disc into the cartridge. 2.
Chapter 4. Managing diskette drives Learn about the features of specific diskette drives. External USB 1.44 MB diskette drive (FC 2591) Learn about the features of this media device. The following provides information about the external USB 1.44 MB diskette drive. Installation To install this external USB 1.44 MB diskette drive, complete the following steps: 1.
Chapter 6. Managing removable disk drives Learn about using and managing removable disk drives. Find specifications and installation notes for specific drives. USB Removable Disk Drive (FC 1103, 1104, 1106, 1107) Learn about the features of this drive. Description The USB Removable Disk Drive consists of a docking station, which holds a removable disk drive. The docking station is available as an internal or external device.
Page 92
Write-protect switch Figure 11. Internal drive, rear view, and connectors Power connector USB connector Figure 12. External drive, rear view, and connectors Power Systems: Managing devices...
Page 93
Power connector USB connector Feature codes and part numbers Learn about the feature codes (FCs) and part numbers for the USB Removable Disk Drive. FC 1103 - USB Internal Docking Station for Removable Disk Drive FC 1103 uses an internal USB cable to connect to the internal USB port on the control panel of a system that supports this feature.
The removable disk drives are a supply item that can be ordered as a feature code. To order in the United States and Canada, call 1-888-IBM-MEDIA. To order drives in other locations, contact your local provider of IBM storage products or visit the following Web site: http://www.storage.ibm.com/media/. Removable disk drives are not a service item and IBM service representatives are not dispatched to service or replace removable disk drives.
Page 95
v AIX Version 6.1 with the 6100-04 Technology Level, or later v Red Hat Enterprise Linux version 3 Update 7, or later v SUSE Linux Enterprise Server 10, or later Using the USB Removable Disk Drive for backup and restore The disk drive is a backup and restore device that can be used as an alternative to tape drives.
Page 96
Status lights Learn about the power indicator and drive indicator status lights on the USB Removable Disk Drive. Power indicator The eject button is illuminated by a power indicator light. The following table describes the operation of the power indicator. Table 32.
Chapter 7. Managing communications devices Learn about the LAN-Attached Remote Asynchronous Node (RAN) 16 (model 7036-P16). LAN-Attached Remote Asynchronous Node 16 (model 7036-P16) Learn about installing, removing, replacing and managing the LAN-Attached Remote Asynchronous Node (RAN) 16 (model 7036-P16). Note: Additional information can be found on the software CD provided with this device. 7036-P16 description and overview Learn about the product description, characteristics, and throughput considerations for this device.
Page 98
Environmental Limits: v Operating – Temperature: 0 to 40 C (ambient air temperature) – Humidity: 5% to 95% (non-condensing) – Wet Bulb: 29 C – Altitude: 0 - 7000 ft v Storage – Temperature: 1 to 60 C – Humidity: 5% to 80% (non-condensing) –...
Installing 7036-P16 hardware You might need to install this hardware. Use the procedure in this section to perform this task. The following information describes the materials and procedures for installing this device. A Phillips screwdriver is required to complete the installation of this unit. Before you install the 7036-P16 unit, verify that the hardware package contains the following items: v 7036-P16 unit v 7036-P16 software and documentation CD...
Installing Digi RealPort software for the 7036-P16 device You might need to install the Digi RealPort software on an AIX or Linux host server. Use the procedure in this section to perform this task. Digi RealPort software-support packages The following is a list of the software packages available on the software CD provided with the 7036-P16 unit: v The Digi RealPort software package for AIX supports the following AIX levels: ™...
Page 101
When installation commences, do not interfere until the installation completes. A successful installation will return an OK message. An unsuccessful installation will return a FAILED message. If you receive an OK message, continue to the next step. If you receive a failed message, review the smit.log file to determine why the installation failed.
10. Type: rpm -qa | grep dgr If the Digi RealPort Package installed correctly, the following is an example of the return message: dgr-1.9.6 11. Afer the Digi RealPort software is installed, the user may configure the 7036-P16 onto the network, if it is not already configured.
Page 103
6. Use the cursor to select: cts_16_r, then press Enter. 7. Move the cursor to the IP Address box and type: [IP Address], then press Enter. This is the [IP Address of the target 7036-P16] used in Step 1. Upon successful completion of this command the user will see the following on the screen: Command: OK stdout: yes stderr: no Before command completion, additional instructions may appear.
10. Press F10 to exit from smitty and return to the server’s command line. This concludes the system port tty configuration on an AIX Server. Configuring the 7036-P16 as a tty device on a Linux host server Assumptions: v The target 7036-P16 and the host server are configured on an Ethernet network. v The target 7036-P16 and the host server are attached to an Ethernet network.
Page 105
Configuring the 7036-P16 onto an Ethernet network If the 7036-P16 is to be used in a network that supports Dynamic Host Configuration Protocol (DHCP), then the configuration will be performed by simply connecting to the network and powering up the 7036-P16.
Page 106
set config dns=[Name Server Address] set config dhcp=off set config hostname=[Host Name] set config domain=[Domain Name] 13. As a precaution, you can deactivate the ping-ARP and RARP options. To deactivate the ping-ARP and RARP options type the following commands: set config Ping-ARP=off set config RARP=off 14.
8. As a precaution, you can deactivate the Ping-ARP and RARP options. To deactivate the Ping-ARP and RARP options type the following commands: set config Ping-ARP=off set config RARP=off 9. If you plan to use the Digi RealPort software on the host server to control all the 7036-P16 ports, then the system ports must be configured for use with the Digi RealPort software.
8. To select a different tty port, use the cursor keys to either increment or decrement the port number. 9. Once a tty port is selected, then select one of the following items: a. Wrap data by typing a T. If this option is chosen, use wrap plug part number 43G0928. Insert the wrap plug into the tty port.
Page 109
v Replacing a 7036-P16 Creating a 7036-P16 configuration file Create a copy of the 7036-P16 configuration and to store it on the host server. Hardware requirements: v AIX or Linux host server with Web access v 7036-P16 attached to an Ethernet network Gather the following information: v IP Address of the target 7036-P16: [7036-P16 IP Address] IP Address of the host server: [Host Server IP Address]...
Page 110
cpconf tohost=[Host Server IP Address]:/tmp/backup_[IP Address].txt The complete IP and terminal type (tty) port configuration information is now captured in the backup_[IP Address].txt file. If the user changes the configuration, the user is strongly advised to recreate the backup_[IP Address].txt file. The user should make a note of the file name created. Reconfiguring a 7036-P16 from a stored configuration file Use a stored configuration file when replacing a 7036-P16.
Replacing a 7036-P16 Attention: Before replacing a 7036-P16, create a 7036-P16 configuration file. You need a Phillips screwdriver to replace this unit. To replace a 7036-P16 unit, do the following steps: 1. Gather the following IP information for the 7036-P16 unit to be replaced: v MAC Address: [MAC Address] (MAC Address label is on the back of the 7036-P16) IP Address: [IP Address] v Default Gateway: [IP Gateway Address]...
Page 112
Table 35. FRUs for the 7036-P16 (continued) Part number Description 39J5823 RJ-45 to DB09 (male) cable 12H1204 DB25 to DB25 (male) cable Power Systems: Managing devices...
