Models:
57610 – Basic Wet
57611 – Deluxe Wet
95626 Retaining Ring
01206 Bearing
54679 Rear Bearing Plate
95865 Line-up Pin
54670
Cylinder Assembly
(Inc. 95865 Line-up Pin)
54674 Blade (5)
(5/pkg.)
54671 Rotor
54680
Front Bearing Plate
02695 Bearing
56046 Lock Ring
L
T
2
5
95343 Set Screw
L
2
54672 Motor Shaft
54673 Rotor Key
54685 Retainer
57398 Gear
96017 V-Ring
95886 Washer (4)
01211 Washer (4)
01788 Screw (4)
T
L
2
2
56052 Bearing
1
96129 Spacer Pak (3)
54627 Mounting Plate
01678 Screw (3)
T
L
2
2
Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools
(ANSI B186.1) and any other applicable safety codes and regulations. Please refer to Dynabrade's
Warning/Safety Operating Instructions for more complete safety information.
01494 Inlet Bushing
Adapter
57373 - Basic
57651 - Deluxe
* 57344 Lever
** 57396 Valve Stem
97010 Screw (4)
01211 Washer (4)
95886 Washer (4)
Handle
57361 - Basic
57652 - Deluxe
57362 Gasket
Housing
57653 - Basic
57654 - Deluxe
95887 Screw
L
2
(If so it must be retained and replaced during disassembly.)
* 01089 Optional Safety-lock Lever. **57375 Valve Stem (For use in with 01089 Safety-lock Lever)
See page 2 for Important Operating, Maintenance and Safety Instructions.
8" Wet Dynorbital
Random Orbital Sander
Air Powered , Random Orbital Sander, 10,000 RPM
54194 Muffler Cap
T
L
54195 Muffler (3)
6
2
95558 Retaining Ring
01017 Pin
01464 Seal
96123 Screw
57382 Gasket
57599 Valve
95074 Fitting
57395 Overskirt
54628 Counter Balance
Loctite/Hernon:
L
L
= Loctite #271
2
Torque: N•m x 8.85 = In. - lbs.
T
T
= 2.82 N•m, T
2
T
= 12.42 N•m, T
4
T
= 23 N•m
6
95898 Screw
T
L
4
2
56236 Hook and Loop Pad
95886 Washer (5)
97010 Screw (5)
T
3
Shaded parts included with deluxe models only.
1
This spacer pak may be included in your tool.
Parts Page Reorder No. PD96•86
Effective December, 1996
(Non-Vac Only)
(Non-Vac Only)
Muffler Seat
(Non-Vac only)
97010 Screw (2)
01211 Washer (2)
95955 Water Hose
57346 Gasket
01468 Spring
01472 Tip Valve
57343 Speed Regulator
95816 Air Line
95717 Hose Clamp
95956 Cuff
95958 Over Hose
KEY
95962 Male
Disconnect
= 3.38 N•m,
3
= 34 N•m,
5
95963 Female
Disconnect
95965 Valve
95964 Hose Bib
®
54199
T
3
01024 O-Ring
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dynabrade Dynorbital 57610
Summary of Contents for Dynabrade Dynorbital 57610
- Page 1 57611 – Deluxe Wet Always operate, inspect and maintain this tool in accordance with the Safety Code for portable air tools (ANSI B186.1) and any other applicable safety codes and regulations. Please refer to Dynabrade's Warning/Safety Operating Instructions for more complete safety information.
-
Page 2: Operating Instructions
Dynabrade, Inc. 1. All Dynabrade air motors should be lubricated. Dynabrade recommends one drop of air lube per minute for each 10 SCFM (example : if the tool specification state 40 SCFM, set the drip rate of your filter-lubricator at 4 drops per minute). Dynabrade Air Lube (P/N 95842: 1pt. 473ml.) is recommended. - Page 3 Motor Disassembly/Assembly Instructions Important: Manufacturers warranty is void if tool is disassembled before warranty expires. A complete tune-up kit, part number 96200, is available which includes assorted parts to help maintain motor in tip-top shape. These instructions are for use in conjunction with Part Number 57325 Repair Kit, which includes special tools for proper disassembly/assembly of tool.
- Page 4 ® DYNABRADE DYNABRADE, INC., 8989 Sheridan Drive • Clarence, NY 14031-1490 • Phone: (716) 631-0100 • Fax: 716-631-2073 • International Fax: 716-631-2524 DYNABRADE EUROPE S.àr.l., Zone Artisanale • L-5485 Wormeldange—Haut, Luxembourg • Telephone: 352 76 84 94 • Fax: 352 76 84 95 ©...
