Riso ComColor 9150 Safety Information Manual

Hide thumbs Also See for ComColor 9150:

Advertisement

Safety Information
Applicable Printer models
9150/9150R/9110/9110R
7150/7150R/7110/7110R
3150/3150R/3110/3110R
2150
052-36047-506

Advertisement

Table of Contents
loading

Summary of Contents for Riso ComColor 9150

  • Page 1 Safety Information Applicable Printer models 9150/9150R/9110/9110R 7150/7150R/7110/7110R 3150/3150R/3110/3110R 2150 052-36047-506...
  • Page 2: Safety Precautions

    CAUTION To ensure safety precautions, be sure to read this guide before using the product. After reading this guide, keep it in handy for future reference. ComColor Series Safety Information 07...
  • Page 3 Index Safety Precautions ....................4 Warning Symbols Power Plug Installation Location Power Connection Handling Ink Cartridge Before Use ......................... 6 Installation Location Power Connection Connecting to a Computer Required Spacing Handling Originals Printable Area Printing Paper Printouts Materials Not to Be Printed Ink Cartridge Storage and Handling Precautions Disposing of Used Ink Cartridges and Cleaning Tanks Specifications ......................
  • Page 4 Perchlorate Material-special handling may apply, See www.dtsc.ca.gov/hazardouswaste/perchlorate This product may contain certain substances which are restricted when disposed. Therefore, be sure to consult your contracted service dealer. R&TTE directive Class1 device Copyright © 2014 RISO KAGAKU CORPORATION ComColor Series Safety Information 07...
  • Page 5 Safety Precautions This section describes the items that should be followed for safe use of this machine. Be sure to read this section before using the machine. Warning Symbols To use the machine properly and to prevent human injury and damage to properties, the following warning symbols are used.
  • Page 6 CAUTION ■ Connect the plug securely to the electrical outlet to avoid a loose connection. ■ Do not pull the power cord when unplugging it. Otherwise, it could become damaged and a fire or an electric shock might occur. Be sure to hold on to the plug when unplugging the power cord. ■...
  • Page 7 Before Use This section describes the precautions that must be observed before using the machine. Installation Location Observe the following precautions. ■ Your dealer will help you to determine a proper location for the machine at the time of delivery. ■...
  • Page 8 Connecting to a Computer ■ Connecting to Multiple Computers Ethernet shielded cable (straight-through cable) ■ Connecting to One Computer Ethernet shielded cable (crossover cable) The maximum allowable voltage for all input/output connection is 5V. ● Use a commercially available ethernet shielded cable. It is recommended that you use one of the following types of ethernet shielded cables according to your network environment.
  • Page 9 Required Spacing ■ Main Unit Provide sufficient space for the front cover to open. ● As seen from the front ● As seen from the side 1030 (40 9/16") 705 (27 3/4") 1220 (48 1/32") 1240 (48 13/16") (3 15/16") Units: mm (inch) ■...
  • Page 10: Table Of Contents

    ● As seen from the side 1615 (63 19/32") 830 (32 11/16") 1345 (52 31/32")* 100 (3 15/16") Units: mm (inch) The size varies depending on the optional equipment used. Main unit only 1,220 mm (48 1/32") Width Main unit and Scanner (when using special scanner stand) 1,225 mm (48 7/32") Main unit and Face Down Offset Stapler 1,440 mm (56 11/16")
  • Page 11: Comcolor Series Safety Information 07

    Main unit and High Capacity Stacker 1,320 mm (51 31/32") The ComColor 9150 is used in the illustration of this machine. Handling ■ Do not use the main power switch to turn the machine OFF or unplug the machine during operation.
  • Page 12: Mm (124

    Maximum Print Area Print Area (Margin) Model Printing Copying Standard Maximum ComColor 9150/9150R/9110/9110R 314 mm × 548 mm 295 mm × 430 mm* 7150/7150R/7110/7110R 3 mm (1/8") 1 mm (0.04") (12 3/8" × 21 9/16") (11 5/8" × 16 15/16") 2150 210 mm ×...
  • Page 13: Mm (48

    ● When [Printable area] is set to [Maximum] in [Admin. Settings], the printable area can be changed to 1 mm (0.04") from the edge of the paper. Depending on the content of the original, text or images may be lost or bleeding may occur.
  • Page 14: Mm (56

    Printing Paper ■ If you use paper that is not compatible with this machine, it may result in problems such as paper jamming, soiling or malfunctions. ■ The specifications for the paper that can be loaded in the feed tray and standard tray differ. Paper Basic Specifications The paper type you can use depends on the unit you load paper in.
  • Page 15: Before Use

    ● The feed tray is not available for ComColor 9110/9110R/7110/7110R/3110/3110R. ● Depending on the type of paper, operating environment, and storage conditions, even paper meeting these size and weight specifications may not be able to pass through the machine in some cases. ■...
  • Page 16 Materials Not to Be Printed ■ Do not use the machine in any manner which violates the law or infringes on established copyrights, even when making copies for personal use. Consult your service representatives for further details. In general, use discretion and common sense.
  • Page 17: Specifications

    Specifications ■ ComColor 9150/9150R/7150/7150R/2150 Specifications Basic Functions and Print Functions ComColor 9150/9150R: 59A01 Model ComColor 7150/7150R: 59A03 ComColor 2150: 60A01 Type Console ComColor 9150/9150R/7150/7150R: Full color Color Support ComColor 2150: Dual-color (Red, Black) Print Type Line-type inkjet system ComColor 9150/9150R/7150/7150R:...
  • Page 18: Mm (110

    ComColor 9150/2150: Simplex: 80 ppm Duplex: 40 sheets/minute (80 ppm) ComColor 7150: Simplex: 66 ppm Duplex: 33 sheets/minute (66 ppm) Continuous Print *2*6 Speed ComColor 9150/2150: Simplex: 78 ppm Duplex: 39 sheets/minute (78 ppm) Ledger ComColor 7150: Simplex: 66 ppm Duplex: 33 sheets/minute (66 ppm) Maximum: 340 mm ×...
  • Page 19 6 The continuous print speed varies depending on the type of optional output equipment connected. Multifunction finisher: Max. 120 sheets/minute (A4-LEF Simplex) Face down offset stapler: ComColor 9150/2150: Max. 150 sheets/minute (A4-LEF Simplex) ComColor 7150: Max. 120 sheets/minute (A4-LEF Simplex) 7 When setting [Power consumption (in sleep)] to [Low].
  • Page 20 ■ ComColor 9110/9110R/7110/7110R Specifications Basic Functions and Print Functions ComColor 9110/9110R: 59A02 Model ComColor 7110/7110R: 59A04 Type Console Color Support Full color Print Type Line-type inkjet system Ink Type Oil-based pigment ink (Cyan, Magenta, Yellow, Black) Standard: 300 dpi (main scanning direction) × 300 dpi (sub-scanning direction) Resolution Fine: 300 dpi (main scanning direction) ×...
  • Page 21 Page Description Language RISORINC/CIII TCP/IP, HTTP, HTTPs (SSL), DHCP, ftp, lpr, IPP, SNMP, Supported Protocols Port 9100 (RAW port), IPv4, IPv6, IPsec ® ® Microsoft Windows XP (32-bit) ® ® Microsoft Windows Server 2003 (32-bit/64-bit) ® ® Microsoft Windows Server 2003 R2 (32-bit/64-bit) ®...
  • Page 22: Mm (81

    ■ ComColor 3150/3150R/3110/3110R Specifications Basic Functions and Print Functions ComColor 3150/3150R: 59A05 Model ComColor 3110/3110R: 59A06 Type Console Color Support Full color Print Type Line-type inkjet system Ink Type Oil-based pigment ink (Cyan, Magenta, Yellow, Black) Standard: 300 dpi (main scanning direction) × 300 dpi (sub-scanning direction) Resolution Fine: 300 dpi (main scanning direction) ×...
  • Page 23 Operating System Linux Power Source AC 100-240 V, 10.0-5.0 A, 50-60 Hz Max. 1,000 W Ready : 150 W or less Power Consumption Sleep : 5 W or less Stand-by: 0.5 W or less Max. 66 dB A4-LEF (one-sided/two-sided) at the maximum print Operating Noise speed Temperature: 15ºC to 30ºC (59ºF to 86ºF)
  • Page 24 (A4-LEF/Letter-LEF) Scanning Gray Levels 10-bit input and 8-bit output for each RGB color Monochrome/Color: 50 ppm Original Source ∗ RISO KAGAKU standard original (A4-LEF/Letter-LEF), 200 dpi, Scanning Speed when stored to main unit hard drive Scan Functions Network Interface Ethernet 1000BASE-T/100BASE-TX/10BASE-T...
  • Page 25 ■ Multifunction Finisher II (Optional) Top Tray Collating, stacking Tray Type Stacking Tray Collating, stacking (offset) Booklet Tray Booklet, Paper folding Maximum: 330 mm × 488 mm (13" × 19 3/16") Top Tray Minimum: 100 mm × 148 mm (3 15/16" × 5 13/16") Maximum: 330 mm ×...
  • Page 26: Mm (48

    ■ Face Down Offset Stapler (Optional) Type External Unit Finishing Functions Offset output, staple Without offset Maximum: 340 mm × 550 mm (13 3/8" × 21 5/8") Minimum: 90 mm × 148 mm (3 9/16" × 5 13/16") Usable Paper Size Offset output Paper width: 131 mm - 305 mm (5 3/16"...
  • Page 27 ■ High Capacity Stacker (Optional) Type External Unit Finishing Functions Collating, stacking (offset) Maximum: 340 mm × 460 mm (13 3/8" × 18 1/8") Minimum: 90 mm × 148 mm (3 9/16" × 5 13/16") Paper Size Offset: 90 mm × 182 mm - 340 mm × 432 mm (3 9/16"...
  • Page 28 Notice for European Union Member States RISO, the environment and the Waste Electrical and Electronic Equipment Directive "WEEE Directive" What is the WEEE Directive? The purpose of the WEEE Directive is to reduce waste and ensure Electrical and Electronic Equipment is recycled at the end of its useful life.
  • Page 29 ComColor Series Safety Information 07...
