Limited Warranty - Permobil ROHO MOSAIC Operation Manual

Product Specifications
Materials:
- Cushion: Flame-retardant PVC film (made without DEHP). Inflation valve: nickel-plated brass.
- Standard Cover: two-way stretch top, spacer fabric sides, with a zipper located in the back of the cover; and a non-skid
bottom with hook and loop fasteners to help secure the cushion in the chair. Refer to cover care label for material content.
- Heavy Duty Cover: two-way stretch, fluid-resistant top and sides, with a zipper located in the front of the cover; and a
non-skid bottom with hook and loop fasteners to help secure the cushion in the chair. Refer to cover care label for material
content.
Sizing (all measurements are approximate)
MOSAIC 1616
MOSAIC 1618
MOSAIC 1717
MOSAIC 1816
MOSAIC 1818
MOSAIC 2018
Cell Height Range: 2½ - 3 in. (6.5 - 7.5 cm)
Cushion expected lifetime: 5 years

Limited Warranty

Limited Warranty Term from the date the product was originally purchased: MOSAIC, 12 months. The warranty does
not apply to punctures, tears, burns, or misuse, nor does it apply to the removable cover. See also the Limited Warranty
supplement provided with your product, or contact Customer Care.
ROHO MOSAIC Cushion Operation Manual
W x D in. W x D cm
16¼ x 16¼ 41.5 x 41.5
16¼ x 18¼ 41.5 x 46.5
17¼ x 17¼ 44.0 x 44.0
18¼ x 16¼ 46.5 x 41.5
18¼ x 18¼ 46.5 x 46.5
20¼ x 18¼ 51.5 x 46.5
8
W
Width (W) and Depth (D) measured edge to edge;
includes a ½ in. (1 cm) perimeter
D
