ABSCO SHEDS 23081SK-PTX Assembly Instructions Manual

We thank you for choosing an Australian Made Shed. For further assistance please
visit our detailed instructional video library at http://www.absco.com.au/videos.php
At ABSCO Industries we are always looking to be number ONE, so please let us
know what you think of our instructions. Feedback makes us better.
feedback@absco.com.au.
ABSCO INDUSTRIES
ABSCO INDUSTRIES
Space Saver Shed
Absco Space Saver Shed
Assembly Instructions
Assembly Instructions
Model: 23081SK-PTX
Model: 23081S
ASSEMBLY INSTRUCTION - MODEL: 23081S 14/12/10 USA CANADA
ASSEMBLY INSTRUCTION - MODEL: 23081SK-PTX
WHEN LAYING YOUR CONCRETE SLAB,
CHAMFER THE 50mm (1.97") EDGES
DOWNWARDS BY 10mm (0.39").
50mm (1.97")
THIS WILL ENSURE THAT
WATER RUN OFF IS KEPT
CLEAR FROM YOUR SHED
FRONT BASE
LENGTH:
2.26m (88.98")
SIDE BASE
LENGTH:
0.75m (29.53")
FRONT WALL
HEIGHT:
1.95m (76.77")
REAR WALL
HEIGHT:
2.08m (81.89")
10mm (0.39")
PAGE 1
16/07/19 PAGE
1
