USB-1208FS User's Guide

4-channel differential mode

Pin Signal Name
1 CH0 IN HI
2 CH0 IN LO
3 AGND
4 CH1 IN HI
5 CH1 IN LO
6 AGND
7 CH2 IN HI
8 CH2 IN LO
9 AGND
10 CH3 IN HI
11 CH3 IN LO
12 AGND
13 D/A OUT 0
14 D/A OUT 1
15 AGND
16 CAL
17 GND
18 TRIG_IN
19 SYNC
20 CTR

8-channel single-ended mode

Pin Signal Name
1 CH0 IN
2 CH1 IN
3 AGND
4 CH2 IN
5 CH3 IN
6 AGND
7 CH4 IN
8 CH5 IN
9 AGND
10 CH6 IN
11 CH7 IN
12 AGND
13 D/A OUT 0
14 D/A OUT 1
15 AGND
16 CAL
17 GND
18 TRIG_IN
19 SYNC
20 CTR
Pin Signal Name
21 Port A0
22 Port A1
23 Port A2
24 Port A3
25 Port A4
26 Port A5
27 Port A6
28 Port A7
29 GND
30 PC+5V
31 GND
32 Port B0
33 Port B1
34 Port B2
35 Port B3
36 Port B4
37 Port B5
38 Port B6
39 Port B7
40 GND
Pin Signal Name
21 Port A0
22 Port A1
23 Port A2
24 Port A3
25 Port A4
26 Port A5
27 Port A6
28 Port A7
29 GND
30 PC+5V
31 GND
32 Port B0
33 Port B1
34 Port B2
35 Port B3
36 Port B4
37 Port B5
38 Port B6
39 Port B7
40 GND
31
Specifications
