FIGURE 1-2
AC power connector
AC power switch
Keyboard Mouse
connector connector
Back Panel of the Sun Fire V20z Server
FIGURE 1-2

Ethernet Port Labelling

It is important to note the labelling of the ethernet ports on the back panel of the Sun
Fire V20z server. As shown on the far right side of the server illustrated in
FIGURE 1-2
the bottom port, respectively.

PCI Slot Labelling

The PCI slots are labelled on the server back panel as PCI O (next to the power
supply) and PCI 1 (between the SP and platform ethernet ports). See
The slot on the motherboard that corresponds to PCI 0 is identified by the
■
silkscreen label "Slot 2 133MHz".
The slot on the motherboard that corresponds to PCI 1 is identified by the
■
silkscreen label "Slot 1 66MHz".
shows the back panel of the Sun Fire V20z server:
AC power indicator LED
Locate button
and LED
, interfaces eth1 and eth0 are labelled as "1" on the upper port and "0" on
Chapter 1 Introduction to the Sun Fire™ V20z and Sun Fire V40z Servers
SP 10/100
Ethernet
connectors
SP reset Video
button connector
Platform Gigabit
Ethernet
connectors
Serial port
USB
connector connector
.
FIGURE 1-2
1-5
