B.1 Physical Characteristics
B.2 Power Requirements
B.3 Performance Specifications
Specifications
Length
5.78 in. (147.70 mm)
Width
3.3 in. (83.82 mm)
Weight
4.0 oz. (113.40 g)
Maximum Power Dissipation 9.5 Watt
Voltage Tolerance
Ripple
Operational Current
Maximum Ethernet Transfer Rate 10/100 Mbps
Network Interface
Ethernet Version
SCSI Interface
SBus Clock
SBus Burst Sizes
SBus Modes
SBus Parity
SBus Version
5V +/- 5%
Maximum 100 mV
1.9A
100BASE-TX using Category 5 (data-grade) cable;
10BASE-T using Category 3 (voice-grade) cable or
better
Conforms to IEEE 802.3u
20 Mbytes/s, 16-bit single-ended
16.67 MHz to 25 MHz
16/32/64 bytes
Master/Slave, 64-bit support
Yes
Conforms to IEEE 1496
B
B-1
