HEADSET INFORMATION
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM1P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Sensear SM1P

Summary of Contents for Sensear SM1P

  • Page 1 HEADSET INFORMATION ENGLISH...
  • Page 2 Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.  Consult the dealer or an experienced radio/TV technician for help. DOC00079 SM1P Headset Information rev 01.1...

  • Page 3: Specifications

    Housing Material PC, ABS + TPE RoHS Compliant NRR AND SLC80 The SM1P has been certified to International hearing protection standards including AS/NZS 1270-2002, ANSI S3.19-1974, ANSI S12.6-2008, EN352-1, EN352-3, EN352-4, and EN352-6. The following passive attenuation ratings were observed:...

  • Page 4: Standard Deviation

    PASSIVE ATTENUATION (ANSI S3.19 -1974) SM1P measured in accordance with ANSI S3.19 -1974. Headband mount-SM1PB001 Frequency (Hz) 1000 2000 3150 4000 6300 8000 Mean 22.1 24.4 31.1 35.1 35.8 37.0 39.9 40.7 40.7 attenuation (dB) 27 dB Standard deviation (dB)

  • Page 5: Behind The Neck Mount-Sm1Pe001

    PASSIVE ATTENUATION (ANSI S12.6 - 2008) SM1P measured in accordance with ANSI S12.6 - 2008. Headband mount-SM1PB001 Frequency (Hz) 1000 2000 4000 8000 NRR (SF) Mean 21.4 21.9 29.8 33.7 35.8 37.2 38.5 attenuation (dB) Standard 27 dB deviation (dB) APV 80 18.9...
  • Page 6 PASSIVE ATTENUATION (AS/NZS 1270:2002) SM1P measured in accordance with AS/NZS 1270:2002. Headband mount-SM1PB001 Frequency (Hz) 1000 2000 4000 8000 SLC (80) Mean attenuation 20.3 21.7 30.3 33.2 35.2 36.6 37.3 (dB) Standard deviation 31dB, (dB) Class 5 Mean attenuation–...

  • Page 7: Doc00079 Sm1P Headset Information Rev

    PASSIVE ATTENUATION (EN352-1 AND EN352-3) SM1P measured in accordance with EN352-1 and EN352-3. Headband mount-SM1PB001 (EN352-1) Frequency (Hz) 1000 2000 4000 8000 H (dB) Mean attenuation (dB) 22.5 24.5 31.5 34.9 35.8 38.0 39.8 35 30 24 Standard deviation (dB) Mean attenuation –...

  • Page 8: Standard Deviation

    The SM1P has level dependent facilities and the criterion levels as defined in EN352-4 are displayed below: Model (dBA) SM1P 108.6 104.6 103.4 TWO-WAY RADIO INPUT (EN352-6) The electrical input level for which the mean plus one standard deviation A-weighted diffused-field related sound pressure level is equal to 82 dB(A) is an RMS voltage U = 108 mV.
  • Page 9 This product is provided with level-dependent in-ear audio playback. The wearer should check correct operation before use. If distortion, or failure is detected. The wearer should refer to the manufacturer’s advice for maintenance and/or replacement. Warning: DOC00079 SM1P Headset Information rev 01.1...
  • Page 10  The output of the level-dependent circuit of this hearing protector may exceed the daily limit sound level. This limit can be adjusted with a Sensear programming tablet.  This headset has been tested and approved according to the methods described in the EN352 series of standards.
  • Page 11 CLAMPING FORCE The clamping force of the SM1P has been measured in accordance with AS/NZS 1270: Initial Post-flex measurements measurements Model Part # Units SM1P - SM1PB001 Newtons 11.6 11.1 11.1 11.1 10.7 11.1 Headband mount Pounds (lbs) SM1P - SM1PE001 14.2 14.7 14.2 14.2...
  • Page 12 Replacement cushions may be pushed into the clips around the baseplate. The headset should be stored at room temperature (between 15°C/59°F and 25°C/77°F). DOC00079 SM1P Headset Information rev 01.1...

  • Page 13: Accessories And Spare Parts

    COPYRIGHT NOTICE This document remains the property of Sensear Pty. Ltd. All rights reserved. No part of this document may be reproduced in any form, either in an electronic retrieval system or otherwise, without the prior written consent of Sensear Pty. Ltd.

  • Page 14: Declaration Of Conformity

    6104 Country Australia Telephone +61 8 9277 7332 Number Fax Number +61 8 9277 7338 http://www.sensear.com Email info@sensear.com Declare that: Model SM1P in accordance with the following directives:  89/686/EEC  2014/53/EU  2006/95/EC  2004/108/EC  2006/42/EC been designed...
  • Page 15  ETSI EN 352-1, EN352-3, EN352-4 and EN 352-6  ETSI EN 301 489  EN 55022  EN 60950 DOC00079 SM1P Headset Information rev 01.1...
