Append; Return To Last Recorded Data; Tasks - Parceltools C190 CubetapePRO Technical Manual

2.
2.3.5 Append ( if activated in Settings )
The Append function enables the operator to add up to three length
measurements together, useful when the item length is longer than the
3 meter tape.
• The append function enables the operator to sum three measurements of length
together, especially when the item length is longer than the 3 meter tape.
• When in Length measurement position - Press
• Measure length 2 and if needed length 3;
• Record appended measurement by pressing
• The length recorded will be the sum of length 1, 2 and length 3.

2.3.6 Return to Last Recorded Data

• Press
several times until the cursor is in the length field;
• Press
will display the last recorded measurement on screen.

2.4 Tasks

The CubetapePRO provides five different tasks, which can be directly accessed on
the device. When the device is turned on, it will be set up for the Task last used.
If a different task is needed, the operator has to access the menu to load a different task.
Enter the Tasks menu from current operation by pressing
The four buttons on the front panel can be used for navigation and selection.
See Section 1.7.2 for more details.
whiles take your last measurement ;
Figure 2-3
to Append measurement 1;
and together.
Technical manual-C190CubetapePRO
11
