Parts List - EWM Tetrix 351 AC/DC Conversion Instructions

3.1

Parts list

Before conversion, check that the retrofit kit is complete (see parts list).
Tetrix 351 AC/DC as an example:
Item 0 Quantity
1 1
2 1
3 4
4 4
5 4
6 1
7 1
8 1
9 1
10 1
11 4
12 1
13 1
14 1
15 4
none 1
099-008212-EW501
14.03.2011
Description
PCB TSYN1
Flat band cable D-SUB
Thread bolt M4 x 8 mm
Spacer M4 x 35 mm
M4 expanding anchor
PCB holder
Adhesive base
Edge protection
Earthing cable (PE)
Toroidal ferrite core (interference suppression)
Cable binder
Flat band cable
Rotary switch (assembly)
Adhesive film (rotary switch)
Oval-head screw M3x10
Circuit diagram
NOTE
Figure 3-1
Conversion
Parts list
Item number
040-000676-00000
094-007494-00002
044-003002-00000
044-002151-00000
094-006502-00000
094-016978-00000
074-000159-00000
094-007643-00000
094-016979-00000
034-000157-00000
044-001275-00000
094-000003-00000
092-008178-00000
094-009599-00000
044-001414-00001
7
