- Page 1 Pine Ridge Fire Pit Table Installation Instructions for Pine Ridge fire pit models PR-1242-K and PR-2424-K...
- Page 2 Contents Required Tools…………………………….…..2 Placing and assembling the Table.………3 Gas Connection………………………….…….4 Igniter Installation…………….……………...6 Locating Propane tank………………………7 Finishing Touches……………………………7 Required Tools Utility Knife To cut and remove packaging 2 Open Ended Wrenches To secure gas connections Leather Gloves To protect hands from rough edges found on coffee table during installation.
-
Page 3: Assembly Instructions
Assembly Instructions Open packaging and remove the access door before removing the fire pit base from the box. Set the base in the desired location and set concrete top onto base Replace access door. - Page 4 Gas Connections Read and understand your Crystal Fire owner’s manual before beginning burner hookups or using the device. Do not use Teflon tape or pipe dope on flare fittings. 1. Reach inside the burner cut-out and attach natural gas supply line using a 3/8”...
- Page 5 Set the burner into the fire pit exactly as shown and make final gas connection to the control panel. Igniter Access Door Access Door TIGHTEN CONNECTION SECURELY WITH WRENCH Metal flex line to burner ONLY...
- Page 6 Igniter Installation Make sure the valve is in the OFF position before beginning. Install sparker as shown, using an AAA battery (not included). Sparker will not operate correctly without an ignition and ground wire attached. Plug both BLACK wires hanging from the burner into the back of the sparker box.
- Page 7 After installing igniter and making gas connections, verify that they are tight and that no leaks are present using a solution of soapy water or a commercially available leak-check solution. Position Your Tank (if applicable) Remove door, connect the propane hose/regulator to the propane tank and hand-tighten (DO NOT USE A WRENCH) and slide the propane tank past the dotted line to ensure the door closes properly.
- Page 8 IMPORTANT Please consult your Crystal Fire instruction manual for detailed instructions and important information related to hooking up your linear burner, including safety information, proper tightening of connections with two wrenches and full burner setup and lighting instructions. DO NOT ATTEMPT TO INSTALL CF-1242 or CF-2424 BURNER WITHOUT FIRST CONSULTING THE CRYSTAL FIRE OWNER’S MANUAL.
