Axis 2N Indoor Touch 2.0 User Manual

Hide thumbs Also See for 2N Indoor Touch 2.0:
Table of Contents

Advertisement

Quick Links

Download this manual
®
2N Indoor Touch 2.0
User guide
Version:
4.0.x
www.2n.cz

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2N Indoor Touch 2.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Axis 2N Indoor Touch 2.0

Summary of Contents for Axis 2N Indoor Touch 2.0

  • Page 1 ® 2N Indoor Touch 2.0 User guide Version: 4.0.x www.2n.cz...
  • Page 2 The 2N TELEKOMUNIKACE a.s. is a Czech manufacturer and supplier of telecommunications equipment. The product family developed by 2N TELEKOMUNIKACE a.s. includes GSM gateways, private branch exchanges (PBX), and door and lift communicators. 2N TELEKOMUNIKACE a.s. has been ranked among the Czech top companies for years and represented a symbol of stability and prosperity on the telecommunications market for almost two decades.

  • Page 3: Table Of Contents

    Content: 1. Product Overview 1.1 Product Description 1.2 Differences between Models 1.3 Terms and Symbols 1.4 Safety Precautions 2. Description and Installation 2.1 Before You Start 2.2 Brief Installation Guide 2.3 Installation Conditions 2.4 Status LED 2.5 First Startup 2N TELEKOMUNIKACE a.s., www.2n.cz 3/135...
  • Page 4 3. 2N® Indoor Touch 2.0 Configuration 3.1 Factory Reset 3.2 Home Screen 3.3 Device Configuration 3.3.1 User Settings 3.3.1.1 Device 3.3.1.2 Personal 3.3.1.2.1 Security 3.3.1.2.2 Language and Input Methods 3.3.1.3 System 3.3.1.3.1 Date & Time 3.3.1.3.2 Backup & Reset 3.3.2 Administrator Settings 3.3.2.1 Device 3.3.2.2 Wireless &...
  • Page 5 4. Intercoms Applications Configuration 4.1 Application Description 4.2 Application Environment and Configuration 4.2.1 Device 4.2.2 Call Log 4.2.3 Dial Pad 4.2.4 Settings 4.3 Notifications in 2N® Indoor Touch Environment 4.4 Application Use 4.4.1 LAN Calls 4.4.2 SIP Proxy Server Calls 4.4.3 2N®...

  • Page 6: Product Overview

    1. Product Overview ® In this section, we introduce the Indoor Touch 2.0 product, outline its application options and highlight the advantages following from its use. The section also includes safety precautions. Here is what you can find in this section: 1.1 Product Description 1.2 Differences between Models 1.3 Terms and Symbols...

  • Page 7: Product Description

    1.1 Product Description ® Based on the Android OS, Indoor Touch 2.0 helps load third party applications to a device (if enabled so in the device configuration), thus improving its flexibility. It contains a 7" colour LCD display with a capacitive touch layer, loudspeaker, microphone and Ethernet and WiFi interfaces (depending on the Part No.) for LAN connection.

  • Page 8: Differences Between Models

    1.2 Differences between Models ® This manual is valid for all the Indoor Touch 2.0 types. Therefore, please note that several features described in this document are only available in selected models or need to be activated with a licence key. If a feature is not available in all the models, a note is added to the respective subsection.
  • Page 9 Accessories Part No.: ® Indoor Touch desk stand black 91378382, 01425-001 Part No.: ® Indoor Touch desk stand white 91378382W, 01426-001 Part Nos.: Stabilised 12 V / 0,75 A source to be used where PoE supply is unavailable. 91378381E The part numbers differ in their electric socket 91378381GB markings (E/GB/US).
  • Page 10 Licence Part No. Description 91378395 HTTP API – the licence unlocks the HTTP API functions 2N TELEKOMUNIKACE a.s., www.2n.cz 10/135...

  • Page 11: Terms And Symbols

    1.3 Terms and Symbols The following symbols and pictograms are used in the manual: Safety Always abide by this information to prevent persons from injury. Warning Always abide by this information to prevent damage to the device. Caution Important information for system functionality. Useful information for quick and efficient functionality.

  • Page 12: Safety Precautions

    1.4 Safety Precautions The manufacturer reserves the right to modify the product in order to improve its qualities. The manufacturer continuously responds to the clients' requirements by ® improving the software. Refer to the www.2n.cz company websites for the latest Indoor Touch 2.0 firmware and User Manual.

  • Page 13: Description And Installation

    2. Description and Installation ® This section describes the Indoor Touch 2.0 installation and correct connection. Here is what you can find in this section: 2.1 Before You Start 2.2 Brief Installation Guide 2.3 Installation Conditions 2.4 Status LED 2.5 First Startup The device is designed solely for wall mounting.

  • Page 14: Before You Start

    2.1 Before You Start Product Completeness Check ® Please check the Indoor Touch 2.0 delivery before starting installation: ® Indoor Touch 2.0 Quick Start manual Wall holder (screwed to device) Installation fittings (2 screws, 2 plugs for flush mounting) Microfiber screen cleaning cloth Front Layout 2N TELEKOMUNIKACE a.s., www.2n.cz 14/135...
  • Page 15 Glass frame LCD display with capacitive touch layer Status RGB LED Loudspeaker Microphone Micro SD card slot Backside Connectors 2N TELEKOMUNIKACE a.s., www.2n.cz 15/135...
  • Page 16 RJ-45 LAN 10/100BaseT connector 12 V / 0,75 A DC supply terminal board (only if PoE is not used) Restart/Factory reset button Binary input/output terminal board (for application control) Micro SD card slot Logic inputs and outputs External doorbell button or Relay connection guides are available at faq. 2n.cz Warning Do not remove the backside rubber sealing as it improves the accoustic...

  • Page 17: Brief Installation Guide

    2.2 Brief Installation Guide Install the device holder onto a vertical wall. The recommended installation height is 120 cm above the floor. The product package includes screws and plugs for mounting into classic bricks. Use appropriate installation fittings for a different type of wall material! Feed the device via an Ethernet PoE adapter (or PoE supporting Ethernet switch /router) or a 12 V / 0,75 A DC power adapter.

  • Page 18: Installation Conditions

    2.3 Installation Conditions ® Make sure that the following Indoor Touch 2.0 installation conditions are met: There must be enough space for device installation. Device is designed for vertical wall mounting (perpendicular to the floor) in the height of up to 120 cm above the floor. If necessary, operate device in a position other than as aforementioned for a short time only, for quick testing purposes in a servicing centre, for example.
  • Page 19 Put the device on the holder and tighten the safety screws. Follow the installation instructions printed on the device package. Power Supply Connection ® You can feed Indoor Touch 2.0 as follows: Use 12 V / 0,75 A DC power adapter (order no. 91378381E/91378381GB /91378381US)connected to the terminal board (see the figure).
  • Page 20 Ethernet cable connector Ethernet port Licence Limitations ® Indoor Touch 2.0 can contain time-limited software licences. Refer to 3.3 Device Configuration for details. Firmware Upgrade We recommend you to upgrade the device firmware during installation. Refer to www. 2n.cz for the latest FW version. Refer to 3.4.

  • Page 21: Status Led

    2.4 Status LED Status LED indicates the device states when the LCD display is switched off or the device is in the service mode. See the table below for the LED colours and states: Device Startup: Colour State Blue is on Device initialisation Red is on First boot phase...

  • Page 22: First Startup

    2.5 First Startup When you start the device for the first time, the initial initialisation (longer start) is performed and indicated by the following LED notification sequence: Blue Green Boot animation on the screen Introductory system screen. The introductory screen provides essential information for User Manual saving ®...
  • Page 23 Parameter Value (or according to the Part No.) Caution Change the access password while configuring the device for the first time to avoid unauthorised access to configuration! System Licence ® Indoor Touch 2.0 has a factory licence key, which can be time-limited (depending on the Part No.).
  • Page 24 3. 2N® Indoor Touch 2.0 Configuration ® This section describes the Indoor Touch 2.0 configuration. Here is what you can find in this section: 3.1 Factory Reset 3.2 Home Screen 3.3 Device Configuration 3.4 Device Upgrade 2N TELEKOMUNIKACE a.s., www.2n.cz 24/135...

  • Page 25: Factory Reset

    3.1 Factory Reset ® Follow the steps below to reset the Indoor Touch 2.0 factory values: Press the Factory Data Reset button in Settings / Administrator mode – ON / Backup & reset. Press and hold the Reset button on the device backside: Remove the device from the installation holder.

  • Page 26: Home Screen

    3.2 Home Screen The Home Screen is divided into three subsections: Current time and date, Weather widget and five configurable application positions. The Setting and Information buttons are also available here. Factory settings: Time/Date tiles Weather tile File Manager – standard file system application Browser –...
  • Page 27 The lower graphic bar includes five graphic controls: Back icon (triangle) – return one level higher or one step back (depending on the application type). Home icon (circle) – return to the introductory screen. Square icon – switch the currently launched applications. Speaker icons –...

  • Page 28: Device Configuration

    3.3 Device Configuration Click the Settings button on the introductory page to access the configuration section. Complete the correct access password. Caution The factory access password is "2n“. If you lose the access data, you will have to factory reset the device! Change the password in the Settings / Personal / Language &...

  • Page 29: User Settings

    3.3.1 User Settings This subsection describes the settings that can be accessed without the administrator password. The subsection contains the following parts: 3.3.1.1 Device 3.3.1.2 Personal 3.3.1.3 System 2N TELEKOMUNIKACE a.s., www.2n.cz 29/135...

  • Page 30: Device

    3.3.1.1 Device This section helps you set the first menu level and quick navigation parameters (click any subsection) into selected device configuration sections. Do Not Disturb Mode Do Not Disturb (DND) – disable any notification while DND is active. While activating DND you can set any interval in the range between 15 minutes and 24 hours, or permanently.
  • Page 31 Repeat – set the days on which the DND Night mode is to be applied repeatedly. Home Screen Time – click to move the user to the section for setting the time, time format and time zone. Automatic date & time –...
  • Page 32 The weather forecast location includes the town and abbreviated country name. If typed incorrectly, the weather forecast will not be displayed. make sure that the Internet is connected while setting the location. refer to http://openweathermap.org/ for location codes . Pre-Installed Applications File manager –...
  • Page 33 Sound & Notification Media volume – set the media volume. Alarm volume – set the alarm clock volume. Notification volume – set the default notification ringtone volume. Default notification ringtone – set the default notification ringtone. Other sounds – enable/disable sound signalling. Screen locking sound –...
  • Page 34 Display Brightness level – set the backlight brightness values. Sleep – set the maximum user idle timeout after which the sleep mode is automatically switched on. Select a value between 15 seconds and 30 minutes or never. Font size – set the font size: Small / Normal / Large / Very large. 2N TELEKOMUNIKACE a.s., www.2n.cz 34/135...
  • Page 35 Storage & USB Internal storage – display the internal storage state for downloaded files and photos. Click to display the storage details. Portable storage – display the external storage state for downloaded files and photos. 2N TELEKOMUNIKACE a.s., www.2n.cz 35/135...
  • Page 36 Advanced The Advanced subsection is only available when the administrator mode is active. Application to be launched on startup – display the list of available applications. Select the application to be launched upon startup. URL to be opened on startup –...
  • Page 37 Licence The Licence subsection is only available when the administrator mode is active. Licence key – display the licence key used. Available functions – display the list of available functions depending on the licence type purchased. Status – display the licence type (limited, unlimited). Remaining hours –...
  • Page 38 Warning ® licence unlocks Indoor Touch 2.0 for loading user applications from a microSD card (SDHC), up to 16 GB. If, however, any user applications are installed, 2N TELEKOMUNIKACE a.s. does not guarantee a proper function and stability of such user applications and ®...

  • Page 39: Personal

    3.3.1.2 Personal The Personal section helps you set the device security and language parameters. 3.3.1.2.1 Security 3.3.1.2.2 Language and Input Methods 2N TELEKOMUNIKACE a.s., www.2n.cz 39/135...

  • Page 40: Security

    3.3.1.2.1 Security Set the device security parameters. PASSWORD Settings password – set the setting access password. Administrator and web access password – set the administrator access password. SCREEN SECURITY Screen lock – select the screen lock type: PIN, Character or None. UNKNOWN SOURCES Allow installation of apps from unknown sources –...

  • Page 41: Language And Input Methods

    3.3.1.2.2 Language and Input Methods Set the language parameters and text input methods. Language – set the system language. Spell checker – enable/disable the spell checker for the defined language. Personal dictionary – click Add (+) to add a word to your personal dictionary. KEYPAD &...

  • Page 42: System

    3.3.1.3 System This section helps you set the system parameters. 3.3.1.3.1 Date & Time 3.3.1.3.2 Backup & Reset 2N TELEKOMUNIKACE a.s., www.2n.cz 42/135...

  • Page 43: Date & Time

    3.3.1.3.1 Date & Time This section helps you set the device date and time parameters. Set the time, time format and time zone. Automatic date & time – activate the use of date and time from the network. Set date –...

  • Page 44: Backup & Reset

    3.3.1.3.2 Backup & Reset This section helps you set the device data backup and reset parameters. Restart – restart the device. Factory data reset – delete all data from the internal storage including: system and application settings and data, downloaded applications, music, photographs and other user data.

  • Page 45: Administrator Settings

    3.3.2 Administrator Settings This subsection describes the settings that can be accessed after the administrator password in entered. The subsection has the following parts: 3.3.2.1 Device 3.3.2.2 Wireless & Networks 3.3.2.3 Security 3.3.2.4 Backup & Reset 2N TELEKOMUNIKACE a.s., www.2n.cz 45/135...

  • Page 46: Device

    3.3.2.1 Device Advanced The Advanced subsection is available in the administrator mode only. Application to be launched on startup – display the list of available applications. Select an application to be launched on startup. URL to be launched on startup –...
  • Page 47 Licence The Licence subsection is available in the administrator mode only. Licence key – display the licence key used. Available function – display the list of available functions depending on the licence type purchased. Status – display the license status (limited, unlimited). Remaining hours –...
  • Page 48 Warning ® licence unlocks Indoor Touch 2.0 for uploading custom applications from microSD card (SDHC). TELEKOMUNIKACE a.s. cannot guarantee functionality and stability of custom applications or proper function of applications pre-installed in 2N ® Indoor Touch 2.0 once custom applications are installed. In case of troubles, remove the custom applications or reset the factory values to get rid of the custom applications and settings.

  • Page 49: Wireless & Networks

    3.3.2.2 Wireless & Networks This section helps you set the network connection parameters. Connection can be set via the Ethernet or Wi-Fi (depending on the Part No., refer to Subs. 1.2 Differences between Models and Associated Products Wi-Fi – disable/enable the Wi-Fi connection. Ethernet –...
  • Page 50 Enabled – enable/disable the adapter. Use DHCP – enable/disable the DHCP client. IP Address – display the IP address. MAC Address – display the MAC address. Configuration – configure the Ethernet manually. 2N TELEKOMUNIKACE a.s., www.2n.cz 50/135...

  • Page 51: Security

    3.3.2.3 Security This subsection describes the administrator security settings. PASSWORD Setting password – set the access password type for the Settings: None – no access password is required. Password – set a password containing at least four letters. – set a code containing at least four digits. Administrator and web access password –...
  • Page 52 SCREEN LOCK Screen lock – set the screen lock password type The screen lock is activated after the sleep mode timeout set in the Device / Screen / Sleep mode menu elapses. None – no screen lock. Pattern – set the screen lock deactivation gesture. –...

  • Page 53: Backup & Reset

    3.3.2.4 Backup & Reset This subsection describes the administrator options. Language – set the language for the texts to be displayed. Spell checker – enable/disable the spell checker function. Personal directory – add terms of your own including optional abbreviations to the dictionary.

  • Page 54: Intercoms

    3.3.3 Intercoms This subsection describes how to configure the pre-installed Intercoms application. 3.3.3.1 General Settings 3.3.3.2 Call Settings 3.3.3.3 My2N/SIP Configuration 3.3.3.4 Video 3.3.3.5 Recorder 3.3.3.6 Input and Output 2N TELEKOMUNIKACE a.s., www.2n.cz 54/135...

  • Page 55: General Settings

    3.3.3.1 General Settings This section helps you set the Intercoms general parameters. GENERAL ® Device Name – set the device name for IP Mobile identification to other LAN devices. Password – set the application setting password via link click from the application.
  • Page 56 intercom to be monitored and periodically to all the 2N IP intercoms included in the LAN device list. The info packets are sent in unicast to the 2N IP intercoms ® only, not to other Indoor Touch 2.0 LAN devices. LOCALIZATION Custom language –...
  • Page 57 – text string key (replaces name in strings.xml). hint_string – text meaning. translated_string – custom translation. Example: {"title_call_declined":{"hint":"Call declined","value":"Call declined"}} You are recommended to edit translated_string only and not modify hint_string unless necessary. Warning We do not advise you to edit the text string to avoid unexpected actions of the application.

  • Page 58: Call Settings

    3.3.3.2 Call Settings This section helps you set the call parameters. CALL ® Call ringtone – select the IP Mobile default ringtone. Custom ringtone file – load an audio file to be used as the ringtone. The supported format is .wav, 15 MB, shortened to 15 s, PCM8/PCM16. Automatic call pickup –...

  • Page 59: My2N/Sip Configuration

    3.3.3.3 My2N/SIP Configuration This section helps you set the My2N and SIP Proxy parameters. MY2N ® My2N Mobile Video – enable/disable IP Mobile ® Device ID – set the device ID assigned by IP Mobile ® Password – set the device password for IP Mobile connection, generated automatically.
  • Page 60 SIP PROXY SIP Proxy – enable/disable the SIP Proxy. Display name – set the account name to be displayed in the application. Username – set the SIP Proxy server username. Password – set the SIP Proxy server user password. Server –...
  • Page 61 SIP REGISTRAR Registrar – set the SIP Proxy IP address or domain name. Address – set the SIP Registrar IP address or domain name. Port – set the SIP Proxy port (typically 5060). Registration Expiry – define the registration expiry, which affects the network and SIP Registrar load by periodically sent registration requirements.
  • Page 62 Warning The SIP Proxy and My2N modes cannot be operated at the same time. 2N TELEKOMUNIKACE a.s., www.2n.cz 62/135...

  • Page 63: Video

    3.3.3.4 Video This section helps you set the video parameters. VIDEO Multicast – select the video stream transmission type from a 2N IP intercom Automatic video stream deactivation – set the time during which the video stream preview of the 2N IP intercom selected in the Device section is displayed.

  • Page 64: Recorder

    3.3.3.5 Recorder This section helps you set the recorder parameters. RECORDER Recorder – enable/disable the recorder function. Recorder activation timeout – the recorder is activated after the set incoming ringing timeout elapses. Recorder announcement – set the announcement to be played. ®...
  • Page 65 Caution If you enable the Recorder , the call is answered and recorded via 1 device only . If you set the Recorder for two or more devices in one LAN or called group, the call is answered and recorded via the device that was the first to pick up the call (if the same Recorder activation timeout is set for all the devices), or via the device that is assigned the lowest Recorder activation timeout...

  • Page 66: Input And Output

    3.3.3.6 Input and Output This section helps you set the input/output parameters. DOOR BUTTON Door button – enable/disable the function. Inverted input mode – ON by default. Define the pulse rise/fall time detection and application response. With ON, the application does not start ringing until the fall time is detected whenever the button is released.
  • Page 67 EXTERNAL RINGING External ringing notification – enable the relay activation. If enabled, the application will close the given output at an incoming call. OFF is set by default. Inverted relay output – ON/OFF (ON by default). Define the pulse rise/fall time detection and application response.
  • Page 68 Refer to FAQ, Relay – How to connect relay to 2N® Indoor Touch 2.0 details . 2N TELEKOMUNIKACE a.s., www.2n.cz 68/135...

  • Page 69: Device Upgrade

    3.4 Device Upgrade ® There are two ways how to upgrade Indoor Touch 2.0 : using an SD card or via the device web interface. The firmware package always includes the current Android ® version, Launcher and IP Mobile application. SD card upgrade procedure: ®...
  • Page 70 Warning Never remove the SD card during upgrade to avoid device damage. If you want to interrupt the upgrade process, do it within the first 10 seconds as invited. Upgrade cannot be aborted later. Remember to remove the SD card after upgrade abort to avoid upgrade re-attempt upon the next startup! Web interface upgrade procedure: ®...

  • Page 71: Intercoms Applications Configuration

    4. Intercoms Applications Configuration This section describes configuration of the pre-installed Intercoms application. Here is what you can find in this section: 4.1 Application Description 4.2 Application Environment and Configuration 4.2.1 Device 4.2.2 Call Log 4.2.3 Dial Pad 4.2.4 Settings 4.3 Notifications in 2N®...

  • Page 72: Application Description

    4.1 Application Description ® IP Mobile is an application designed for video calls between the 2N IP intercoms ® Indoor Touch 2.0 devices. ® ® IP Mobile is part of the Indoor Touch 2.0 firmware. ® ® IP Mobile sets up calls between the Indoor Touch 2.0 devices.

  • Page 73: Application Environment And Configuration

    4.2 Application Environment and Configuration ® Once launched, IP Mobile displays the Device screen: The main menu includes the following items: ® ® Device – list of added devices: 2N IP intercoms 2N IndoorTouch 2.0 Mobile Video or, if SIP Proxy is used, any other SIP supporting device. Call Log –...

  • Page 74: Device

    4.2.1 Device ® The Device section helps you add the 2N IP intercoms 2N Indoor Touch 2.0 devices, ® Mobile Video devices and devices registered with the same SIP Proxy server. The ® 2N IP intercoms Indoor Touch devices are detected in the LAN automatically ®...
  • Page 75 LAN Devices ® All the 2N IP intercoms Indoor Touch 2.0 devices detected automatically in the same LAN are displayed in the Device/LAN main window. Click a row to remove the selected device. Each device is identified by a name and IP address. The selected device is marked .
  • Page 76 Proxy Devices To become a SIP Proxy device, the device has to be registered with a SIP Proxy server. Note The application does not allow you to add, create or edit a SIP Proxy device unless correctly connected to a SIP Proxy server. Proxy Registration ®...
  • Page 77 – The SIP Proxy server registration is inactive due to the SIP Proxy server rejection or unavailability. Caution ® IP Mobile application requires 60 s as the minimum registration expiry time. If the expiry time is shorter, the application may keep disconnecting from the SIP Proxy server.
  • Page 78 Proxy Device Adding ® Once IP Mobile is successfully connected to and registered with the SIP Proxy server, you can add SIP Proxy devices to the list manually. Again, click in the right- hand bottom corner of the Device main window to enter the device adding mode. Then use the tab below the application title row to switch the window to Proxy devices.
  • Page 79 Enabled/Disabled IP/domain – set the Axis camera IP address/domain name. Username – set the Axis camera video stream login username. Password – set the Axis camera video stream login password. Primary – select the primary display: external camera or default video stream.
  • Page 80 The selected device is marked . Click to the right in the application upper toolbar to select all the devices listed. Click to edit the device name. Click save the selected Proxy devices. The application moves to the Device menu to display the selected devices.
  • Page 81 Note ® Make sure that a web account and one Indoor Touch 2.0 device at ® least have been created to make use of the Mobile Video functions. Refer to faq.2n.cz for more details. Warning When the 30-day Trial licence expires, purchase a licence corresponding to the count of created devices.
  • Page 82 ® The application indicates the Mobile Video server connection using an icon next to the devices tab: – The application has successfully downloaded all the data and is registered ® with a Mobile Video SIP Proxy server. – The application has successfully downloaded all the data and is trying to ®...
  • Page 83 The selected device is marked . Click to the right in the application upper toolbar to select all the devices listed. Click to edit the device name. Click save the selected My2N devices. The application moves to the Device menu to display the selected devices.

  • Page 84: Call Log

    4.2.2 Call Log ® IP Mobile Call Log section displays the records of outgoing/incoming calls. The following values are available: outgoing – outgoing call incoming – incoming call missed – missed call The call icon is either a snapshot from the device or an avatar. The avatar is displayed when the Autosnapshot parameter is inactive for cameraless devices or when no snapshot was made due to a short video preview –...
  • Page 85 Select a record to be shown. The records include the call length and an enlarged snapshot. Play the missed call record if available. Click in the right-hand upper corner to export a record to a storage. Caution Unanswered outgoing/incoming calls have a 0:00 call duration. Refer to faq.2n.cz for the recorder instructions for use .

  • Page 86: Dial Pad

    4.2.3 Dial Pad The Dial Pad menu helps you call SIP devices by dialling the called number via a SIP ® Proxy server. When IP Mobile is not registered with the SIP Proxy, the dial pad is inactive. ® Once IP Mobile gets registered with the SIP Proxy, the Dial Pad function becomes active.
  • Page 87 Caution The Dial Pad does not allow tone signalling (DTMF) to be sent during a call. 2N TELEKOMUNIKACE a.s., www.2n.cz 87/135...

  • Page 88: Settings

    4.2.4 Settings Refer to 3.3.3 Intercoms for application settings. 2N TELEKOMUNIKACE a.s., www.2n.cz 88/135...

  • Page 89: Notifications In 2N® Indoor Touch Environment

    4.3 Notifications in 2N® Indoor Touch Environment ® ® IP Mobile uses a Indoor Touch 2.0 notification LED. The LEd starts flashing red to indicate that: There is an unread incoming call in the application. 2N TELEKOMUNIKACE a.s., www.2n.cz 89/135...

  • Page 90: Application Use

    4.4 Application Use This subsection provides basic instructions on how to put the application in operation for typical use. 4.4.1 LAN Calls 4.4.2 SIP Proxy Server Calls 4.4.3 2N® Mobile Video Calls 2N TELEKOMUNIKACE a.s., www.2n.cz 90/135...

  • Page 91: Lan Calls

    4.4.1 LAN Calls To communicate with an 2N IP intercom , it is necessary to change a setting in the door communicator to be connected. Refer to the online Configuration manual for 2N IP intercoms ® IP Mobile v4 – How to set communication between Indoor Touch/IP Mobile and 2N IP intercom? 2N TELEKOMUNIKACE a.s., www.2n.cz 91/135...

  • Page 92: Sip Proxy Server Calls

    4.4.2 SIP Proxy Server Calls To make calls via a SIP Proxy server set the application server connection correctly in the SIP Proxy section of the Settings menu. Get the login data from the SIP Proxy server provider. Once connected, you can dial other devices directly from the application Dial Pad or create a SIP Proxy device, click it to display the device card and start calling.
  • Page 93 Caution It is impossible to send the DTMF code from the application outside a call for technical reasons. Therefore, if you press the lock outside a call in the SIP Proxy mode, a call is set up first during which the DTMF is sent automatically.

  • Page 94: Mobile Video Calls

    4.4.3 2N® Mobile Video Calls ® It is very easy to set the application for calling via Mobile Video . All you have to do is set correct login data in the application settings: Having completed the login data, press the Log in button for the application to log in and download contacts.
  • Page 95 Press and hold the lock button to display the lock list (locks 1–4) to control all the locks (not only the default one). Click the name of the 2N IP intercom added using Phonebook via My2N to set up a call with the device immediately. During the call, the microphone on the application side is muted so that the visitor cannot hear you.

  • Page 96: Supplementary Information

    4.5 Supplementary Information ® This subsection provides supplementary information on the IP Mobile product. Here is what you can find in this subsection: 4.5.1 Troubleshooting 2N TELEKOMUNIKACE a.s., www.2n.cz 96/135...

  • Page 97: Troubleshooting

    4.5.1 Troubleshooting Question: The application cannot see any devices in the LAN mode. Answer: Make sure that you are really connected to the LAN where the other devices are installed. If you are, then check the settings of the other devices, particularly the 2N IP Group Authentication password.

  • Page 98: Web Interface Configuration

    5. Web Interface Configuration ® ® Indoor Touch allows the user to configure a majority of launcher and 2N Mobile parameters via the web interface. Here is what you can find in this section: 5.1 Login 5.2 System Info 5.3 Device 5.4 Application 5.5 Limitations 2N TELEKOMUNIKACE a.s., www.2n.cz...

  • Page 99: Login

    5.1 Login ® Enter the Indoor Touch 2.0 IP address into the web browser address row to connect to the web interface. The currently supported browsers are Internet Explorer, Google Chrome, Firefox and Opera. Then enter the user name and password to access the configuration section. The default values are as follows: User Name: Admin ®...

  • Page 100: System Info

    5.2 System Info This subsection includes relevant system information. Contents: 5.2.1 Status 2N TELEKOMUNIKACE a.s., www.2n.cz 100/135...

  • Page 101: Status

    5.2.1 Status The Status screen displays a list of basic parameters. Information on Device System – device name HW version – device HW board version FW version – device firmware version Up time – total time since the first startup Serial number –...
  • Page 102 IP gateway – IP gateway IP address LAN MAC – Ethernet module MAC address Wi-Fi support – Wi-Fi module availability in the device Storage – information on the installed, available and used RAM Internal storage – information on the total and free capacity of the device internal storage SD card –...
  • Page 103 Warning ® licence unlocks Indoor Touch 2.0 for loading user applications from a microSD card (SDHC), up to 16 GB. If, however, any user applications are installed, 2N TELEKOMUNIKACE a.s. does not guarantee a proper function and stability of such user applications and ®...
  • Page 104 5.3 Device ® This subsection describes how to configure the Indoor Touch launcher via the web interface. Contents: 5.3.1 Network 5.3.2 Home Screen 5.3.3 Local Settings 5.3.4 Display 5.3.5 Audio 5.3.6 System Administration 2N TELEKOMUNIKACE a.s., www.2n.cz 104/135...

  • Page 105: Network

    5.3.1 Network ® The Network section describes how to configure the Ethernet adapter in 2N IndoorTouch 2.0 DHCP ON – Yes/No – enable/disable obtaining settings from DHCP IP address – current IP address IP mask – IP mask address DNS IP –...
  • Page 106 DHCP – enable/disable obtaining of settings from DHCP. If disabled, the remaining IP address settings become available. IP address – device IP address IP mask – IP mask address IP gateway – IP gateway IP address DNS IP – DNS IP address 2N TELEKOMUNIKACE a.s., www.2n.cz 106/135...

  • Page 107: Home Screen

    5.3.2 Home Screen The Home Screen tab helps you set positions for applications and their icons and includes the list of all available applications in the system. Click a position to display a position setting window: 2N TELEKOMUNIKACE a.s., www.2n.cz 107/135...
  • Page 108 Name – application name to be displayed at the given position Application – display the list of applications installed in the device. Select an application to set the home screen position for launch. Icon – select the application icon. Change icon –...

  • Page 109: Local Settings

    5.3.3 Local Settings The tab helps you change the language, time zone and weather settings. System language – change the language for most of the applications (Gallery, etc.). Language – English is used by default. Date and time – select the date, time and time zone. Time zone –...

  • Page 110: Display

    5.3.4 Display The Display tab helps you change the display turn-off and brightness as well as LED notifications. Display – display settings Switch off display in – turn off the display in 1 to 30 minutes Brightness – set the display brightness: 10–100 % Notification LED –...

  • Page 111: Audio

    5.3.5 Audio This tab helps you set the volume of ringing, notifications, applications and others. Application volume – set the music, video, game and audio volumes: 0–100 %. Notification volume – set the ringing and notification volumes: 0–100 %. Alarm volume –...

  • Page 112: System Administration

    5.3.6 System Administration The System Administration tab helps you upgrade firmware, back up/upload configuration and change the password. System administration Enable service mode – enable access to the device via a web interface. Welcome screen – display the welcome screen on every startup. Restart device –...
  • Page 113 Configuration Download configuration – download the current configuration into a PC. Upload configuration – upload configuration from a PC file to the device. Click to display a window to select whether the whole configuration is to be uploaded or the part containing IP addresses should be omitted. Password Use separate web access password –...
  • Page 114 Screen security Screen lock – display the current screen security details. Activate the function on the device display only. Logs Select the log type to download Basic logs – basic system information (dmesg, logcat, 2N_info, getprop). All logs – complete logs for troubleshooting purposes. All available logs will be downloaded.
  • Page 115 Network trace ® Indoor Touch 2.0 communicates with a 2N IP intercom or a third-party device, the network trace can be a very useful diagnostic and troubleshooting tool should the communication fail. Refer to the section for how to download the network trace and ®...

  • Page 116: Application

    5.4 Application ® This subsection describes how to change the IP Mobile configuration via a web interface. Contents: 5.4.1 Intercoms 5.4.2 Settings 2N TELEKOMUNIKACE a.s., www.2n.cz 116/135...

  • Page 117: Intercoms

    5.4.1 Intercoms ® The Intercoms tab helps you display the devices added to IP Mobile and new LANs and SIP Proxy devices. ® Restart – restart the IP Mobile application. The pencil icon helps you edit the device name. Recorder Settings ON/OFF –...
  • Page 118 Door Button Settings ON/OFF – enable/disable the door button function. Invert input – set the input response to the pulse rise/fall time (button press /release, e.g.). Ignore DND setting – indicate the door button activation in the DND mode. Used input –...
  • Page 119 External Ringing Settings ON/OFF – enable/disable the external ringing function. Invert relay input – set the input response to the pulse rise/fall time. Ignore DND setting – indicate an incoming call by an output in the DND mode. Used output –...
  • Page 120 Do Not Disturb mode setting Do Not Disturb mode – activate the one-time DND mode. Do Not Disturb activation time – set a time interval in which the DND mode is active: from 15 minutes to 24 hours or permanently. Night Do Not Disturb mode...
  • Page 121 My2N Settings ON/OFF – enable/disable the My2N connection. Device ID – set the device ID. Password – set the My2N login password. Info ® Refer to faq.2n.cz for a separate Mobile Video document where you find how to obtain data for login to the service servers. 2N TELEKOMUNIKACE a.s., www.2n.cz 121/135...
  • Page 122 SIP Proxy settings – set the data necessary for the SIP Proxy server connection. ON/OFF – enable/disable the SIP Proxy connection and set the details. ® Device name – set the device/ IP Mobile name to be displayed for the SIP Proxy purposes.
  • Page 123 Call Settings Automatic call pickup – activate automatic call answering. Video display before call pickup – enable video preview before call pick up. Automatic call pickup delay – set the automatic call pickup timeout: from 0 to 30 s. Call ringtone –...
  • Page 124 Application Settings Automatic call screenshot – enable automatic call screenshots. Push to talk – enable Push to talk. Logging – enable/disable extended logging. Multicast Discovery – set the background communication between the 2N devices. ® Custom language localization – activate custom localization for IP Mobile Local video preview –...

  • Page 125: Settings

    5.4.2 Settings This tab helps you set other functions related to applications. Enable application installation – enable installation of third party applications. ® Return to application after call end – set this option to move IP Mobile the background again after an incoming call is ended. Launch application on startup –...

  • Page 126: Limitations

    5.5 Limitations The web interface is always available to 1 user at a time. This applies to more tabs on 1 PC too. Therefore, remember to log in to each tab every time. Caution Once a new user logs in to the web interface, the previous user will be logged out automatically.

  • Page 127: Technical Parameters

    6. Technical Parameters Power Supply Type: external power adapter part no. 91378381E, 91378381GB, 91378381US (SELV type with LPS) 90–230 V, 50–60 Hz to 12 V DC 0,75 A or Power over Ethernet (PoE 802.3af) Power input: up to 10 W User Interface Control: capacitive touch panel Display size: 7"...
  • Page 128 Relative humidity: 10% – 90% (non-condensing) Storing temperature: -20 °C – 70 °C Recommended altitude: 0–2000 m I/O Description HW v2 Signification Name Restriction REL1/2 Relay contact data: max 30 V DC 1 A DC 12 V +/- IN = power input: Vinmax = 12 V DC Imax = 1 A DC 12 V + OUT = power output: Vout = 12 V DC Imax = 100 mA...
  • Page 129 Signification Name Restriction DC12V+ OUT +12 V output Imax = 100 mA DC12V+ IN +12 V input Imin = 1000 mA Ground (-12 V input)   2N TELEKOMUNIKACE a.s., www.2n.cz 129/135...

  • Page 130: Supplementary Information

    7. Supplementary Information ® This section provides supplementary information on the 2N Indoor Touch 2.0 product. Here is what you can find in this section: 7.1 Troubleshooting 7.2 Directives, Laws and Regulations - General Instructions and Cautions 2N TELEKOMUNIKACE a.s., www.2n.cz 130/135...

  • Page 131: Troubleshooting

    7.1 Troubleshooting Trouble: The device always switches off the display before timeout. ® Advice: Check the device temperature. If improperly installed, 2N Indoor Touch automatically turns into the stand-by mode to reduce the device temperature if critical to avoid forced turn-off / reset in extreme cases. The user is notified of this problem by a short display of the notification window.

  • Page 132: Directives, Laws And Regulations - General Instructions And Cautions

    7.2 Directives, Laws and Regulations - General Instructions and Cautions ® Indoor Touch 2.0 conforms to the following directives and regulations: 2014/35/EU on the harmonisation of the laws of the Member States relating to the making available on the market of electrical equipment designed for use within certain voltage limits 2014/30/EU on the harmonisation of the laws of the Member States relating to electromagnetic compatibility...
  • Page 133 Please read this User Manual carefully before using the product. Follow all instructions and recommendations included herein. Any use of the product that is in contradiction with the instructions provided herein may result in malfunction, damage or destruction of the product. The manufacturer shall not be liable and responsible for any damage incurred as a result of a use of the product other than that included herein, namely undue application and disobedience of the recommendations and warnings in contradiction...
  • Page 134 Electric Waste and Used Battery Pack Handling Do not place used electric devices and battery packs into municipal waste containers. An undue disposal thereof might impair the environment! Deliver your expired electric appliances and battery packs removed from them to dedicated dumpsites or containers or give them back to the dealer or manufacturer for environmental-friendly disposal.
