Table of Contents 1 Important information Safety information General 2 Delivery and handling Delivery Handling Components included in PV Solar package 3 Installation General Installation and positioning 4 Mounting Installing solar panels in several groups 5 Electrical connection Outline diagram...
. Caution This symbol indicates important information about what you should consider when installing or servicing the installation. This symbol indicates tips on how to facilitate using the product. NIBE PV Solar cell pack- Chapter 1 | Important information...
These instructions may only be distributed, translated or copied with the written permission of the manufac- turer. We reserve the right to make changes to the specifications or illustrations in this manual without prior notification. NIBE PV Solar cell pack- Chapter 1 | Important information...
Do not lift the solar panels by the connections. Do not place the solar panels on objects that can damage them, nor pull or drag them over anything that can damage them. NIBE PV Solar cell pack- Chapter 2 | Delivery and handling...
EME 20 1 pcs Universal for aluminium rails PRM 51-20 Lower section for the ceiling bracket is not supplied by NIBE Additional fastening for the relevant ceiling type is re- quired NIBE PV Solar cell pack- Chapter 2 | Delivery and handling...
(pre- depth of more than 30 cm on the solar panels (NOTE! completed form is available on www.nibe.se) Please If the snow has melted, been packed down and then note that the installation must not be put into use until more snow has fallen and so the density has increased, the power supplier has given its approval.
(with a reserva- tion for shade, dirt and snow coverage). Example: Stockholm, 6 kW, 45°, installation south. 1000 x (112/100) x 6 x 0.9 = 6048 kWh/year NIBE PV Solar cell pack- Chapter 3 | Installation...
If you need a larger installation, it is perfectly possible to expand it. In this case, you simply select multiples of e.g. 24 kW, producing an installation of e.g. 240 kW. NIBE PV Solar cell pack- Chapter 4 | Mounting...
Page 11
Mark out the positions for the roof brackets using chalk. Remove or slide up the marked roof tiles. Assembly clamp Caution Illustration only, dimensions between roof brackets according to section “Before installing solar panels” on page 11. NIBE PV Solar cell pack- Chapter 4 | Mounting...
Page 12
The roof bracket must not be pressed directly against into the roof truss. the roof tile. Use a spacer plate if necessary? The spacer plate must be made of a water and weather- resistant material (not supplied). NIBE PV Solar cell pack- Chapter 4 | Mounting...
Page 13
2. Install the L profile on the protruding coach bolt with M10 nuts. Caution The coach bolt should be installed from under- neath before the plate is mounted on the roof. NIBE PV Solar cell pack- Chapter 4 | Mounting...
Page 14
Position the first solar panel on the mounting rail. Click the assembly clamp into the first (bottom) row 5 mm from the end of the mounting rail. NIBE PV Solar cell pack- Chapter 4 | Mounting...
The inverter includes a factory-fitted 300 mA earth-fault breaker. If the inverter is to be connected to an external earth-fault breaker, this must be 300 mA or larger. NIBE PV Solar cell pack- Chapter 5 | Electrical connection...
Page 16
(3-4 Nm) 3 - 4 Nm Caution Check that the polarity is correct when connect- ing to the inverter. NIBE PV Solar cell pack- Chapter 5 | Electrical connection...
Page 17
4 mm² copper wire Tighten anticlockwise. Inverter side Pin 1 L1 Pin 2 N Pin 3 PE Copper wire Three- 10~12mm phase Crimp onto the cable 40~45mm NIBE PV Solar cell pack- Chapter 5 | Electrical connection...
Page 18
Set time and date. Single- 1234567890 phase Normal 20 s Set Language 2000-00-00 00:00 2018-09-07 Three- phase Normal Error log Set Time Date & Time 11:20:25 Language 2018-09-07 Histogram 2018-09-07 NIBE PV Solar cell pack- Chapter 5 | Electrical connection...
Page 19
This is included if you already have a NIBE machine that can handle NIBE Uplink. If you want to use NIBE Uplink but do not already have a NIBE machine, SMO 20 can be used.
Check that the glass, reverse and aluminium frame are undamaged. Check that all electrical wiring and connections are intact and not coated with anything. Mechanical cleaning is not usually required and is not recommended. NIBE PV Solar cell pack- Chapter 6 | Maintenance...
PRM 31-20 (Roof bracket, seamed sheet metal roof) Part No. 057 210 PRM 51-20 (Ceiling bracket universal for aluminium rails). Lower section for the ceiling bracket is not supplied by NIBE Part No. 057 227 NIBE PV Solar cell pack-...
Part no. 057 184 1 x PRM 51-1 Ceiling bracket universal for aluminium rails Part no. 057 228 1 x Cable for docking between EME 20 and SMO 20 Part no. 718 576 NIBE PV Solar cell pack- Chapter 8 | Accessories...
Tel: +46 (0)433-27 3000 kuzmin@evan.ru info@nibe.se nibe-evan.ru nibe.se SWITZERLAND NIBE Wärmetechnik c/o ait Schweiz Industriepark, CH-6246 Altishofen Tel. +41 (0)58 252 21 00 info@nibe.ch nibe.ch For countries not mentioned in this list, contact NIBE Sweden or check nibe.eu for more information.
Page 28
WS release date: 2018-12-21 17:49 Publish date: 2019-01-02 08:53 This manual is a publication from NIBE Energy Systems. All product illustrations, facts and data are based on the available information at the time of the publication’s approval. NIBE Energy Systems makes reservations for any factual or printing errors in this manual.
