OWNER'S MANUAL
Network Dome Camera
Please read this manual carefully before operating
your set and retain it for future reference.
MODEL
LW5224R
1110 (V1.0)

Advertisement

Table of Contents
loading

Related Manuals for LG LW5224R

Summary of Contents for LG LW5224R

  • Page 1 OWNER'S MANUAL Network Dome Camera Please read this manual carefully before operating your set and retain it for future reference. MODEL LW5224R 1110 (V1.0)
  • Page 2 Cautions for Safe Operation REGULATORY INFORMATION: FCC Part 15 CAUTION This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC RISK OF ELECTRIC SHOCK Rules. These limits are designed to provide reasonable protection DO NOT OPEN against harmful interference when the equipment is operated in a commercial environment.
  • Page 3 Warning: Do not install this equipment in a confined space such as LG Electronics hereby declares that this/these a bookcase or similar unit. product(s) is/are in compliance with the essential Warning: Wiring methods shall be in accordance with the National requirements and other relevant provisions of Electric Code, ANSI/NFPA 70.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS 1. Read these instructions. 12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold with the apparatus. When a cart is 2. Keep these instructions. used, use caution when moving the cart/apparatus combination 3.
  • Page 5 Handling of the unit Operating and storage location Be careful not to spill water or other liquids on the unit. Be cautious Avoid viewing a very bright object (such as light fittings) during not to get combustible or metallic material inside the body. If used an extended period.

  • Page 6: Table Of Contents

    Connecting Microphone and Speaker Device ......14 Mounting the camera ...............15 Operation and settings ............... 22 Before using the system ..............22 Recommended PC Requirements ..........22 Accessing the LG IP device..............23 LG Smart Web Viewer Overview ...........24 Configuring the LG Network camera ..........25 OSD Menu Setup ................39...

  • Page 7: Introduction

    Introduction The LG Network Dome Camera is designed to use on an Ethernet Accessories network and must be assigned an IP address to make it accessible. • Program CD This manual contains instructions on how to install and manage the •...

  • Page 8: Part Names And Functions

    Part names and Functions Azimuth angle assembly Adjusting the azimuth angle to obtain a level image. a b c Zoom lock lever Fixes the zoom position after adjusting. Focus lock lever Fixes the focus position after adjusting. Fall Prevention rubber band Fixes the rubber band into the dome cover.
  • Page 9 l m n o ETHERNET/POE Port Connects to a PC or a network via a hub with a 10 BASE-T/100 BASE-TX cable attached RJ-45 connector. Note: Power over Ethernet (PoE) is a technology that integrates power into a standard LAN infrastructure. It enables power to be provided to the network device, such as a network camera, using the same cable as that used for network connection.

  • Page 10: Connections

    Connections Precautions • Be sure to switch off the unit before installation and connection. • The installation should be made by qualified service personnel or system installers. • Do not expose the power and connection cables to moisture, which may cause damage to the unit. Connection Overview PoE Device PoE Device...

  • Page 11: Connecting Network

    Connecting Network You can control and monitor the system via network. With the remote control (monitoring), you can change the system configuration or monitor the image via network. After the installation, check the network settings for the remote control and monitoring work. Connect the IP camera to your network using a standard RJ-45 network cable as shown below.

  • Page 12: Connecting Power Source

    Connecting Power Source Connect power, using one of the methods listed below: To use the power adapter Connect a DC 12 V / AC 24 V power source to the power input terminal as shown below. (Connect to the DC 12 V / AC 24 V UL Listed, Class 2 Power Supply only on the unit. ) To use the PoE (Power over Ethernet) device Connect the PoE cable to the LAN port on the unit.

  • Page 13: Connecting Alarm Device

    Connecting Alarm Device Alarm terminals are used to connect the alarm (relay) devices such as sensors, door switches, etc. ALARM IN / ALARM IN RETURN (Sensor Input) Connect the sensor device to the sensor input terminal. GREEN Sensor Device BLACK ALARM OUT / ALARM OUT RETURN (Relay Output) Connect the alarm (relay) device to the relay output terminal.

  • Page 14: Connecting Microphone And Speaker Device

    Connecting Microphone and Speaker Device Optionally connect an active speaker and/or external microphone with a built-in amplifier. AUDIO OUT AUDIO IN Note: Keep the microphone away from the speaker to avoid howling.

  • Page 15: Mounting The Camera

    Mounting the camera 3. Install the camera bracket to the ceiling. Before you install the camera bracket, turn the camera bracket counterclockwise while You can mount the camera on a ceiling or wall. pulling the locking knob to disassemble the camera bracket from the camera body.
  • Page 16 4. Connect the cables to the cable jacks of the camera body. 5. Turn the camera body clockwise while the locking knob is pressed to fasten the camera body to the assembly bracket. The locking knob...
  • Page 17 Wall mount (Optional) 3. Install the camera installation bracket as shown below. Follow the instructions below to install the camera with a wall mount. 1. Drill holes in the wall where you want to install the wall mount. 2. Install the wall mount as shown below. “A”...
  • Page 18 4. Connect the cables to the camera jack and attach the camera to 5. Attach the camera cover to the camera. the installation bracket.
  • Page 19 Pendant mount (Optional) Follow the instructions below to install the camera with a pendant mount. 1. Install the pipe and camera installation bracket as shown below.
  • Page 20 Note: Pipe threads should be clean and rust-free. Use a sealer such as tape and silicone sealer on the threads “A”. Teflon 2. Connect the cables to the camera jack and attach the camera to the installation bracket. “A”...
  • Page 21 3. Attach the camera cover to the camera. Note: Specifications of LG Standard pipe. • Add thread ceiling tape to end of pipe. • Pipe threads should be clean and rust-free. Use a sealer such as Teflon™ tape and silicone sealer on the threads.

  • Page 22: Operation And Settings

    Microsoft Internet Explorer above the The LG Smart Station and the LG Smart Web Viewer program Web Browser version 6.0 and below the version 8.0. are the network program of the LG Video Server and the LG IP cameras. DirectX DirectX 9.0 or above •...

  • Page 23: Accessing The Lg Ip Device

    IP devices on your network. The IP Utility shows the MAC 3.1 Start your Web browser. address, IP address, Model name and so on. 3.2 Enter the IP address of the LG IP device in the address Note: bar of the browse.

  • Page 24: Lg Smart Web Viewer Overview

    LG Smart Web Viewer Overview Click to save the current image in JPEG format on your computer. 1. Click the [Snapshot] button and then the Snapshot window is displayed. 2. Click the [Save] button in the Snapshot window. me (JPEG format) and select the folder to save it.
  • Page 25 Provides all the necessary tools for setting up the device to your The features and options of the LG IP camera are configured requirements. The user will need through the Configuration menu. administrator level to do this. Only administrator-level users have permission to access the Note: Configuration menu.
  • Page 26 Date & Time Main Menu Sub Menu Basic RTP stream Network TCP/IP DDNS IP filtering User Basic Event schedule Event Event server Time zone Sensor & Relay Set the time difference from GMT in the area where the IP device is installed. Select the time zone in the area where the IP device is System settings installed from the drop down list.
  • Page 27 Notes: Restore and backup • When system reboot after time setting, time of system > Backup: To take a backup all of the settings. could be delayed. If you set the time correctly, set the 1. Click the [Backup] button. The Warning window is [Synchronize with NTP server] option.
  • Page 28 (Except for the Network settings, PTZ Protocol and Preset settings. The option depends on the model.) Log & Report Language list Select a language for the LG Smart Web Viewer c ration menu and information display. Save: Click this button to c rm the settings.
  • Page 29 Audio & Video settings Stream Camera Master/Slave > Enable: Click to activate the stream function. > Video codec: Select the video mode (Codec) from the drop- down list. The viewer can choose between MJPEG and H.264. > Resolution: Select the output image size of the camera. Preview >...
  • Page 30 Audio > Stream quality: If the [Quality] option set to VBR, this option is displayed. Select the stream quality from the drop down box, the camera supports five types. (Highest, High, Medium, Low and Lowest) > Bit rate: If the [Quality] option set to CBR, this option is displayed.
  • Page 31 Motion detect Notes: You can reset the window size. Click one of the window edge or coner and drag & drop to reset the motion detection area. Motion detection function is available for H.264 codec. Network settings Basic Preview You can preview the motion detection window on the preview window.
  • Page 32 ARP Ping > RTP multicast: When enabled it reduces the transmission load on the camera by making the > Enable ARP Ping to configure IP address: Check to computer of the same segment network receive the enable ARP ping. same transmission data. When multicast option is Save: Click this button to confirm the settings.
  • Page 33 DDNS > Statically set: Select this option when you set a xed This free service is very useful when combined with the LG IP address, with this setting, specify the IP address, DDNS Server. It allows the user to connect the IP device using Subnet mask and default gateway manually.
  • Page 34 DDNS status > Don’t use DDNS server: Disable the DDNS function. > Use DDNS server: Enable the DDNS function. IP list Provider: Displays the DDNS provider. > Basic policy: Select the basic policy type. Hostname: Enter the hostname you want to use. Allow all: Allow all the IP address basically, but the IP •...
  • Page 35 3. Click the [Save] button. 4. Repeat the steps from 1 to 3 to add additional IP address. Remove: Click this button to delete the IP address. 1. Select the alias from the list. 2. Click the [Remove] button. The IP address will be deleted.
  • Page 36 User settings 4. Select the authority from the drop down list to provide the access rights to each user and then Basic click the [Save] to con rm your selection. The IP device is shipped with the login rights of administrator Administrator: Allows you to operate setup only.
  • Page 37 Anonymous Event schedule list > Enable anonymous login > To edit the Event Schedule Check the box to enable anonymous user login 1. Select the Trigger event and click the [Edit] - allows the user access for only viewing the live button.
  • Page 38 Event Server Folder: Type the path with the folder that is shared in the FTP server. Event Servers are used to receive the recorded video clip and/or noti cation messages. Test: Select [Test] to test the FTP server. 3. Click the [Save] button to con rm the settings. >...
  • Page 39 Sensor & Relay Enable SSL: Check when use the SSL (Secure Socket Layer) protocol. SSL protocol is cryp- tographic protocols that provide secure com- munication on a network. Receiving address: Type the recipients e-mail address. You can specify only one recipient e-mail address.

  • Page 40: Osd Menu Setup

    OSD Menu Setup 3D-DNR The following table shows the list of menu items and options. MIDDLE You can adapt the camera to your requirements by setting up the HIGH respective items in these menus. PRIVACY Main Menu Sub Menu Contents COLOR RED, GREEN, 0 to 255...
  • Page 41 General Operation POLYGON MASK MASK1 to NUMBER MASK2 1. Click the [OSD control] button on the LG Smart Web Viewer. POLY. ON/OFF 2. Click button on the OSD control window. DISPLAY The camera setting menu appears on the live view window.
  • Page 42 WDR/BLC • button: Used to decrease the value selected in the menu. Use WDR/BLC option to view the object clearly in backlight • button: Executes selections and displays a submenu for an item with the mark. conditions. 1. Select [WDR/BLC] option on the [EXPOSURE] menu. 2.
  • Page 43 SENS-UP > MASK: Use button to select [ON] or [OFF]. If you set the MASK to ON, the mask function is activated If pictures are not clear due to darkness, this SENS-UP operation only when the HSBLC is activated by auto mode. would increase the sensitivity of picture.
  • Page 44 Day/Night settings 1. Select the [WHITE BAL] option. 2. Use button to select a mode then click button. • ATW (Auto-Tracing White Balance): In this mode, the color temperature range for the proper white balance is approximately from 1700 ºK to 11 000 ºK. Proper white balance may not be obtained under the following conditions: >...
  • Page 45 SmartIR setting 3D-DNR setting This function is used to protect the image saturation when the object is detected at close range. 1. Select [3D-DNR] option. If pictures are not clear due to noise, this option would reduce 1. Select the [SmartIR] option. the noise of picture.
  • Page 46 Privacy Mask setting > Use to select an option then use button to adjust the option. This function is aiming at the protection of personal privacy. The HEIGHT: Increase or decrease the vertical size of the selected part is not displayed on the screen. mask.
  • Page 47 • POLYGON : 3. Use button to select an option then use button to select a level. > Use button to select a mask on the [MASK NUMBER]. • ZOOM: Use button to enlarge the screen. > Use button to set up the [ON] or [OFF] on the •...
  • Page 48 STABILIZER A (Blank): Insert a space at the cursor position. The image stabilizer function minimizes the appearance of shaky • : Moves cursor to left or right. images caused by low-frequency vibration. LANGUAGE This function is useful for outdoor surveillance. Select the viewer language for the camera setup menu and OSD Select the [STABILIZER] option and set to ON or OFF.

  • Page 49: Reference

    • IP Con icts: If the LG network device is set with a static IP address and if the DHCP option is set then there may be IP’s same as the net- work device and other network partner. Hence set the static IP address to 0.0.0.0 to resolve this con ict.
  • Page 50 After the factory settings login using the default user name and password. Video Streaming problems • If the video streaming does not start on the Web browser, install the LG Web Client ActiveX program on your computer following the instructions on the Web browser. •...
  • Page 51 • If we obtain lower frame rate than set we need to check from the system administrator for su cient bandwidth available or reduce the number of applications running on the client computer. • If the client PC’s are unable to access the multicast stream, check with the system administrator for the use of a valid multicast address or check if the router is supporting multicasting.

  • Page 52: Open Source Software Notice

    Glibc, libelf, libesmtp, live.media LG Electronics o ers to provide source code to you on CD-ROM for a charge covering the cost of performing such distribution, such as the cost of media, shipping and handling upon e-mail request to LG Electronics at: opensource@lge.com...
  • Page 53 This product includes • dhcp client : Copyright © 2004-2008 by Internet Systems Consortium, Inc. (“ISC”) Copyright © 1995-2003 by Internet Software Consortium • expat library : Copyright © 2006 expat maintainers. • libcap • libjpeg : Independent JPEG Group Copyright © 1991 1998, Thomas G. Lane. •...
  • Page 54 • Zlib : Copyright © 1995-2002 Jean-loup Gailly and Mark Adler. All rights reserved. Permission is hereby granted, free of charge, to any person obtaining a copy of this software and associated documentation les (the “Software”), to deal in the Software without restriction, including without limitation the rights to use, copy, modify, merge, publish, distribute, sublicense, and/or sell copies of the Software, and to permit persons to whom the Software is furnished to do so, subject to the following conditions: THE SOFTWARE IS PROVIDED “AS IS”, WITHOUT WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE...
  • Page 55 Image Device 6 mm 760H Super HAD CCD II Lens Type 2.8 mm to 11 mm vari-focal Video Out 1.0 Vp-p Composite Signal (75 ) Auto Gain Control OFF/ LOW / MIDDLE / HIGH Exposure ALC / ELC Electronic Shutter 1/50 to 1/120 000(PAL), 1/60 to 1/120 000(NTSC) Day &...
  • Page 56 ID / Password Multi level user ID (Admin, Power, Normal, Customer)/password Encryption HTTPS (SSL, TLS) Physical Layer 10/100base TX Ethernet TCP/IP, HTTP, HTTPS, RTP, RTSP, UDP, DHCP, FTP, SMTP, NTP, ARP, ICMP, DNS(LG), ONVIF 2.0, Protocol PSIA1.1 IP support Dynamic, Static Users 10 users Operation Temp.
  • Page 57 AB28...
