- Page 1 Color Video Camera Instruction Manual Models: LV300N-C LV300P-C Before installing, operating or adjusting this product, please read this instruction booklet carefully and completely. V300N_P-C.CSAUBLB_ENG_MFL404661 1 010.6.11 11:46:1 AM...
- Page 2 CAUTION: The apparatus should not be CAUTION exposed to water (dripping or splashing) and no RISK OF ELECTRIC SHOCK objects filled with liquids, such as vases, should DO NOT OPEN be placed on the apparatus. CAUTION: This installation should be made by CAUTION: TO REDUCE THE RISK OF a qualified service person and should conform ELECTRIC SHOCK...
- Page 3 REGULATORY INFORMATION: FCC provided with brushings. Part 15 This equipment has been tested and LG Electronics hereby declares found to comply with the limits for a that this/these product(s) Class A digital device, pursuant to Part is/are in compliance with the 15 of the FCC Rules.
-
Page 4: Important Safety Instructions
Important Safety Instructions 1. Read these instructions. - All these 7. Do not block any ventilation open- ings. Install in accordance with safety and operating instructions the manufacturer’s instructions. should be read before the product is - Slots and openings in the cabinet operated. - Page 5 Important Safety Instructions Do not defeat the safety purpose of the polarized or grounding- type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for your safety.
-
Page 6: Safety Precautions
Safety Precautions Do not attempt to disassem- Avoid the camera with direct ble the camera sunlight To prevent electric shock, do not remove Do not aim the camera at bright objects. screws or covers. There are no user Never face it with direct sunlight or other serviceable parts inside. -
Page 7: What's In The Box
What's in the box Video Cable Camera Body M4 Tapping Screws (EA) (Pan Lock Screw) Optional Adapter (DC 1V, 300mA) V300N_P-C.CSAUBLB_ENG_MFL404667 7 010.6.11 11:46:50 AM... -
Page 8: Front View
Construction Front View Pan Base 6-pin Dip Switch Tilt Base Zoom Lever Tilting Lock Screw Focus Lever Side View Lens Tilting Lock Screw Dome Cover Separatory Spring V300N_P-C.CSAUBLB_ENG_MFL40466 010.6.11 11:47:1 AM... -
Page 9: Camera Installation
Installation Camera Installation 1. Aim the LG logo of the Dome Camera to face the place that you wish to watch. . Tighten the M4 Tapping Screws to fix the Dome Camera on the ceiling, then adjust the Pan (Left /Right) by moving the Pan Base. Tighten the M4 Tapping Screws after adjustment. -
Page 10: Camera Connection
Installation Camera Connection Connect the Power Adapter (1V, 300mA; optional) to the Power Input Jack of the camera as shown below. Power Adapter Adapter Power Input (Not supplied) Jack Jack Monitor V300N_P-C.CSAUBLB_ENG_MFL4046610 10 010.6.11 11:47: AM... - Page 11 Installation NOTES: When you disassemble the Dome Cover, lift the Dome Cover • Separatory Spring on the opposite side of LG Logo and turn the Dome Cover clockwise simultaneously. Dome Cover Separatory Spring When you install the camera, handle with care. The camera could •...
- Page 12 Setup 6-pin Dip Switch Setting 3. AWB/HOLD AWB (Auto White Balance), HOLD (White Balance Hold). This camera has the 6-pin Dip The default setting is AWB. Switch for setting. 4. BLC Backlight compensation elimi- nates strong background light which makes the camera pic- ture dark such as a spotlight.
-
Page 13: Troubleshooting
Troubleshooting Contrast of the screen is not Check the following guide for the clear. possible cause of a problem before contacting service. Check the condition of the monitor. A light source such as a spot light causes burn-in on the display The picture is poor screen. - Page 14 Dimension ø100 91mm 10mm 31mm ø11.5 ø90 V300N_P-C.CSAUBLB_ENG_MFL4046614 14 010.6.11 11:47:3 AM...
-
Page 15: Specifications
Specifications Model LV300N-C LV300P-C Signal System NTSC Total / Effective Pixels 410K/30K 470K/440K Pick-Up Device 1/3-Inch Interline Color CCD (Super HAD) Lens Vari-Focal Lens (f=.6 ~ 6.0mm / F=1.6) Iris DC Iris Signal Process Digital Signal Process (SS11X) Scanning System : 1 Interlace Sync. - Page 16 P/NO: MFL4046631 V300N_P-C.CSAUBLB_ENG_MFL4046616 16 010.6.11 11:47:33 AM...
