ELECTRIC TOILET
FLUSH PUMP
A dual-function pump eliminates the need for hand pumps and dry-bowl valves. With the push of a
button, the self-priming flush pump rinses the bowl as the Macerator and high-capacity scavenger
pump grind up waste and pump it out.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SFMTP1-01 and is the answer not in the manual?

Questions and answers

Related Manuals for Seaflo SFMTP1-01

Summary of Contents for Seaflo SFMTP1-01

  • Page 1 ELECTRIC TOILET FLUSH PUMP A dual-function pump eliminates the need for hand pumps and dry-bowl valves. With the push of a button, the self-priming flush pump rinses the bowl as the Macerator and high-capacity scavenger pump grind up waste and pump it out.
  • Page 2 The SEAFLO electric marine toilet will provide 1 year of trouble free service if properly used. It will Connect inlet hose using either 5/8" or 3/4" ID hose (a sleeve is included to adapt pump inlet from handle waste and toilet tissue.
  • Page 3 DISASSEMBLY SWITCHCONNECTIONDRAWRING Disconnect pump inlet and discharge hoses. Remove four screws, Key No. 11, pull out complete motor, pump and macerator assembly. Remove macerator housing from base. Remove discharge port, and inspect joker valve. Unscrew chopper plate lock nut, Key No. 10, by turning counterclockwise, facing plate and remove chopper.
  • Page 4 DIMENSIONALDRAWING EXPLODEDVIEW 5" 127mm 2.67" 67.6mm 0.77" ∅ 19.5mm 3.29" 2.67" 83.5mm 67.6mm Seal Impeller casing Spring pad Oil seal Blade Screw Shaft seal Cover Screw O-ring Motor Drainage impeller Impeller cover seal Pump knob O-ring Screw Pumping impeller Pump knob 2.18"...

This manual is also suitable for:

Sfmtp2-01
