of each, M8) for this. In doing this, insert the screw at the side of
the connection flange ·.
³
·
Screw the connector flange for wall and mast mounting
wall. Materials for fixing the wall mounting are not included in the
package.
Firmly screw (max. torque 24 Nm) the mounting arm
connector flange for wall and mast mounting ¿. Use the screw (M8
x 40), washer, locking washer and hexagonal nut (1 of each, M8) for
this. In doing this, insert the screw at the side of the mounting arm
·.
¿

Pole mounting

Mount the mast bracket as shown in the diagram. Proceed as follows:
Carefully screw the antenna connector flange
Nm) to the rear of the antenna ³. Use the washers, locking
washers and hexagonal nuts (4 of each, M5) for this.
Attach the connector flange for wall and mast mounting
(max. torque 24 Nm) to the antenna connector flange ·. Use the
screw (M8 x 40), washer, locking washer and hexagonal nut (1 of
each, M8) for this. In doing this, insert the screw at the side of the
connection flange ·.
·
Firmly screw (max. torque 14 Nm) the clamp profile
connector flange for wall and mast mounting ¿. Use the screw (M8
x 40 or M8 x 70), washer, locking washer and hexagonal nut (1 of
www.lancom.eu
LANCOM Systems GmbH I Adenauerstr. 20/B2 I 52146 Wuerselen I Deutschland I E-Mail info@lancom.eu I Internet www.lancom.eu
. . . c o n n e c t i n g
™
AirLancer
Installation instructions
·
»
¿
to the
»
to the
¿
»
·
(max. torque 5.7
¿
·
³
¿
´
to the
Extender O-9a and O-D9a
each, M8) for this. In doing this, insert the screw at the side of the
clamp profile ·.
This profile can be used for masts of different diameters by
mounting the clamp profile
appropriate screw.
´
¿

Connecting to the access point

Antennas of the AirLancer Extender O-D9a model feature two antenna
connectors for the parallel transmission of two data streams in
combination with a LANCOM 802.11n MIMO Access Point. In this case,
the following description applies to each of the antenna connectors.
When connecting to an Access Point you first connect one end of
the supplied cable to the AirLancer Extender SA-5L. Then connect
the other end to the Access Point's antenna output.
LANCOM L-310agn Wireless
Ant 1 Ant 2
ETH
firmly
AirLancer Extender SA-5L
For connection to the antenna, first connect the end of the antenna
cable (making sure that this is long enough) to the AirLancer
Extender SA-5L. Then connect the other end of the antenna cable
to the antenna's input. You may require an adapter or adapter cable
depending on the type of connector.
When mounting outdoors, ensure that the screw connections

are waterproof. A secure seal will be provided by teflon tape or
self-vulcanizing tape, for instance.
y o u r b u s i n e s s
²
a different way up and by using the
²
AirLancer Extender O-D9a
Ant 3
