EUROLITE IR-35 remote control

The IR remote control has the following functions:
_
+
OFF ON
Pty1
Pty2
Pty3
Pty4
FADE CC
STROBE COLOR
JUMP
FLASH
WHITE
Notes:
• When actuating a button, always direct the remote control towards the sensor. There must be no obstacles
between remote control and the sensor.
• The remote control is supplied with a battery inserted. An insulating foil between the battery and the battery
contacts prevents the battery from being discharged during storage. Prior to the first operation remove the
foil from the battery support on the rear side of the remote control. Otherwise operation of the remote
control is not possible.
• If the range of the remote control decreases, replace the battery. For this purpose,
on the rear side of the remote control press the small bar with the groove to the
right and at the same time remove the battery support. For operation, one 3 V
button cell type CR 2032 is required. When inserting, pay attention that the
positive pole of the button cell shows upwards in the support.
• Remove the battery from the remote control as a precaution if the device is not used for a longer period of
time.
Buttons Function
IR remote control
OFF ON
onoff
_
Dimmer intensity of the LED colors /
+
stepless RGBAW+UV color mixture,
brightness with + and -
Preset colors,
brightness with + und -
turquoise, magenta, yellow,
amber, cold white, warm white
Internal program Pty 1,
Pty1
Switching colors, speed with + and -
Internal program Pty 2,
Pty2
Switching colors, speed with + and -
Internal program Pty 3,
Pty3
Switching colors, speed with + and -
Internal program Pty 4,
Pty4
Switching colors, speed with + and -
Preset colors 01-63 (s. control board),
CC
selection with + and -
Internal programs from
FADE
JUMP
preset colors from CC,
speed with + and -
Strobe effect only for white,
STROBE
WHITE
speed with + and -
Strobe effect 6 preset colors and 6
COLOR
colors from color mixture,
FLASH
speed with + and -
28/32
Pty1-4 and
