DESCRIPTION OF THE DEVICE

1
2
3
4
5
6
13 14
(16) Battery fixation/slide locks
(17) Rechargeable battery
15
(1) Carrying handle
(2) Lens/LED
(3) Infrared sensor for the remote
(4) Thread for fixing the diffuser
(5) Menu button
(6) Enter button
(7) Up button
7
(8) Down button
(9) Fixation screw folding foot
8
(10) Folding foot
9 (11) Kensington security slot
(12) Rubber foot
10
(13) Charger input with protective
11
(14) Display
(15) Power button
12
22/32
control
via knurled screws
cap
AKKU IP UP-4 Plus HCL Spot WDMX
IP65
No. 41700580 EAN 4026397657623
12.6V /3A via Charger 35W 2.4 GHz
+
T =45°C
0.3m a
T =60°C
c
