EuroLite Akku IP UP-4 Plus HCL Spot WDMX User Manual page 25

Unlink
Red – 000 - 255
Color Set
Green – 000 - 255
(Master
Blue – 000 - 255
mode)
White – 000 - 255
Amber – 000 - 255
UV – 000 - 255
Col Mac
Mac 01 - 63
(Master
mode)
Col Progr
(Master
Black - UW
mode)
Connect/disconnect
Press ENTER for 3 seconds to delete the wireless connection or to build
up a wireless connection.
Dimmer intensity of the LED colors /
stepless RGBAW+UV color mixture 000 – 255 (increasing)
Dimmer intensity red
Dimmer intensity green
Dimmer intensity blue
Dimmer intensity white
Dimmer intensity amber
Dimmer intensity UV
Preset colors
Mac 1 R Mac 22
Mac 2 G Mac 23
Mac 3 B Mac 24
Mac 4 W Mac 25
Mac 5 A Mac 26
Mac 6 UV Mac 27
Mac 7 R+G Mac 28
Mac 8 R+B Mac 29
Mac 9 R+W Mac 30
Mac 10 R+A Mac 31
Mac 11 R+UV Mac 32
Mac 12 G+B Mac 33
Mac 13 G+W Mac 34
Mac 14 G+A Mac 35
Mac 15 G+UV Mac 36
Mac 16 B+W Mac 37
Mac 17 B+A Mac 38
Mac 18 B+UV Mac 39
Mac 19 W+A Mac 40
Mac 20 W+UV Mac 41
Mac 21 A+UV Mac 42 R+G+B+W Mac 63 R+G+B+W+A+UV
Internal programs / blackout
Progr 1 Blackout
Progr 2 Party 1 Red Green Blue
Progr 3 Party 2 Cyan Magenta Yellow
Party 3 Red Green Blue Cyan
Progr 4
Magenta Yellow
Party 4 Red Green Blue Amber
Progr 5
White UV
Rainbow Red, Amber, Yellow,
Progr 6
Green, Cyan, Blue, Magenta
25/32
R+G+B Mac 43
R+G+W Mac 44
R+G+A Mac 45
R+G+UV Mac 46
R+B+W Mac 47
R+B+A Mac 48
R+B+UV Mac 49
R+W+A Mac 50
R+W+UV Mac 51
R+A+UV Mac 52
G+B+W Mac 53
G+B+A Mac 54
G+B+UV Mac 55
G+W+A Mac 56
G+W+UV Mac 57
G+A+UV Mac 58 R+G+B+W+UV
B+W+A Mac 59 R+G+B+A+UV
B+W+UV Mac 60 R+G+W+A+UV
B+A+UV Mac 61 R+B+W+A+UV
W+A+UV Mac 62 G+B+W+A+UV
Progr 27
Progr 28
Progr 29
Progr 30
Progr 31
Progr 32
00124275, Version 1.0
R+G+B+A
R+G+B+UV
R+G+W+A
R+G+W+UV
R+G+A+UV
R+B+W+A
R+B+W+UV
R+B+A+UV
R+W+A+UV
G+B+W+A
G+B+W+UV
G+B+A+UV
G+W+A+UV
B+W+A+UV
R+G+B+W+A
Blue White
Amber Dark
Amber Yellow
Amber Cyan
Amber Magenta
Amber White
