B r o a d c a s t A / V D i v i s i o n
CV420-30X-IP
30X IP Zoom Camera
User Manual
[Firmware Version 0.43]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CV420-30X-IP and is the answer not in the manual?

Questions and answers

Related Manuals for Marshall Amplification CV420-30X-IP

Summary of Contents for Marshall Amplification CV420-30X-IP

  • Page 1 B r o a d c a s t A / V D i v i s i o n CV420-30X-IP 30X IP Zoom Camera User Manual [Firmware Version 0.43]...

  • Page 2: Table Of Contents

    CV420-30X-IP Manual Table of Contents Safety Instructions 1. Operation Safety Instructions 1.1 Use camera in the recommended operating environments. 1.2 Do not place the camera in tilted position. 1. Package Contents 1.3 Do not place the product on an unstable cart, stand or table.

  • Page 3: Package Contents

    CV420-30X-IP Manual Precautions 1. Package Contents Warning: To reduce the risk of fire or electric shock, do not expose this camera to rain, moisture, debris or liquids. CV420-30X-IP Power Cord Power Adapter If the HD camera will not be used for an extended time, unplug it from the power socket.

  • Page 4: Tally Indicator Light Function Description

    = 0 : OFF p = 4 : On (half-brightness) p = 5 : On (full-brightness) 3. Installation Instructions 3.1 Installation Basics 3.1.1 CV420-30X-IP Dimensions Length x Width x Height : 168.3 x 67.0 x 67.0 mm Weight 0.5 Kg...
  • Page 5 CV420-30X-IP Manual 3.2.2 Connecting to Internet 3.2.4 Connecting RS-232 CV420 camera includes a RS232 IN and OUT for Daisy Chain style connections, or can be setup via home run using splitters (use CV620-CABLE-07 extenders to convert to CAT RJ45 cables for longer runs).

  • Page 6: Network Function Settings

    4. Network Function Settings 4.2.2 Using Marshall VMS Software to View the Images • The CV420-30X-IP DHCP initial setting is ON. If it is connected to the local area network (LAN), 4.1 Web System Requirements the camera IP can be retrieved via the following methods 4.1.1 Web Browser:...

  • Page 7: Web Page Function Description

    CV420-30X-IP Manual 4.2.3 Using the Browser to View the Images 4.3 Web Page Function Description • Open the browser, and enter the URL of CV420-30X-IP in the IP address bar 4.3.1 Login Screen e.g.: http://192.168.100.100 (default IP address) • Enter administrator’s account and password...
  • Page 8 CV420-30X-IP Manual 4.3.2 Viewing In Real Time 4.3.3 Account Management Item. Function Descriptions Add user account Enter a username and password to add a new user Permission setting Set the new account management permissions User Type Admin Operator Viewer Item.
  • Page 9 Do not use “/” and “space” or special symbols Resolution Available output modes Streaming 1 / The CV420-30X-IP supports 3 streaming outputs. Please refer to 5.3.5.1 Streaming 3840x2160/59.94p HDMI or streaming single output Streaming 2 / Parameter Setting for relevant settings...
  • Page 10 CV420-30X-IP Manual 4.3.6 Camera Settings 4.3.7 Picture Settings Item. Function Descriptions Zoom ratio Adjust the zoom-in or zoom-out ratio via scroll bar Exposure • Mode: Select exposure mode (Automatic/Shutter Priority/Aperture Priority/Manual ) • Exposure Comp. Level: Select exposure compensation level •...
  • Page 11 CV420-30X-IP Manual 4.3.8 Camera Settings 4.3.9 Time Settings Item. Function Descriptions Item. Function Descriptions Camera Time Display the date and time of the camera Open audio Turn on / off sound Set the Time • Set Manually: Set time manually •...
  • Page 12 CV420-30X-IP Manual 4.3.10 Network Settings 4.3.11 Maintenance and Updating Firmware Item. Function Descriptions Firmware Update The camera firmware may be upgraded via web page. For the upgrade method, please download the FW upgrade manual from Marshall website Item. Function Descriptions Network Network setting of camera.

  • Page 13: Specifications

    CV420-30X-IP Manual 4.3.13 Additional Maintenance Settings 5. Specifications Sensor 1/2.5" 8MP CMOS Video Format "Resolution: 3840x2160p (UHD), 1920x1080p (HD), 1280x720p Frame-rate : 59.94/50/29.97/25 fps" Optical Zoom Focal Length 4.6mm ~ 135mm Angle-of-View (Horizontal) 68° ~ 3.5° Aperture F1.5 ~ F3.4...

  • Page 14: Troubleshooting

    Sharpness Configurable Noise Reduction 2D/3D NR This chapter describes problems you may encounter while using CV420-30X-IP. If you have Dynamic Range Ture WDR, 120dB questions, please refer to related chapters and follow all the suggested solutions. If the problem Privacy Mask Spherical Privacy Zone Mask remains, please contact your distributor or the service center.
  • Page 15 Warranty Marshall Electronics warranties to the first consumer that this device will, under normal use, be free from defects in workmanship and materials, when received in its original container, for a period of two years from the purchase date. This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the warranty.
