- Page 1 B r o a d c a s t A / V D i v i s i o n CV420-30X-NDI 30X NDI®|HX Camera User Manual...
-
Page 2: Table Of Contents
CV420-30X-NDI Manual Copyright Information Table of Contents Copyrights © Marshall Electronics Incorporated. All rights reserved. Marshall Electronics is a trademark of Marshall Electronics Incorporated NDI Instruction Safety Instructions Copying, reproducing or transmitting this file is not allowed if a license is not provided by Marshall Electronics Inc. -
Page 3: Safety Instructions
1.3 Do not place the product on an unstable cart, stand or table. 1.4 Do not use this product near water, extreme humidity or high heat. This section explains how to quickly configure the Marshall CV420-30X-NDI camera with NDI®|HX. 1.5 Use recommended ¼”-20 mounts and attachments. -
Page 4: Package Contents
CV420-30X-NDI Manual Precautions 1. Package Contents Warning: To reduce the risk of fire or electric shock, do not expose this camera to rain, moisture, debris or liquids. CV420-30X-NDI Power Cord Power Adapter If the HD camera will not be used for an extended time, unplug it from the power socket. -
Page 5: Tally Indicator Light Function Description
The setting method is as follows: Tally Mode : 8x 01 7E 01 0A 01 0p FF p = 0 : OFF p = 4 : On (half-brightness) p = 5 : On (full-brightness) 3. Installation Instructions 3.1 Installation Basics 3.1.1 CV420-30X-NDI Dimensions www.marshall-usa.com... - Page 6 CV420-30X-NDI Manual 3.2.2 Connecting to Internet 3.2.4 Connecting RS-232 CV420 camera includes a RS232 IN and OUT for Daisy Chain style connections, or can be setup via home run using splitters (use CV620-CABLE-07 extenders to convert to CAT RJ45 cables for longer runs).
-
Page 7: Network Function Settings
2. If the camera is connected to the computer directly, the computer IP address must be modified to have the same network segment as the camera For example, the factory-preset default IP address of CV420-30X-NDI is 192.168.100.100. The computer IP address must be set with the same subnet, such as 192.168.100.101, so that the computer can be connected correctly with the camera •... -
Page 8: Web Page Function Description
CV420-30X-NDI Manual 4.2.2 Using the Browser to View the Images 4.3 Web Page Function Description • Open the browser, and enter the URL of CV420-30X-NDI in the IP address bar 4.3.1 Login Screen e.g.: http://192.168.100.100 (default IP address) • Enter administrator’s account and password... - Page 9 CV420-30X-NDI Manual 4.3.2 Viewing In Real Time 4.3.3 Account Management CV420-30X-NDI CV420-30X-NDI Item. Function Descriptions Add user account Enter a username and password to add a new user Permission setting Set the new account management permissions User Type Admin Operator Viewer Item.
- Page 10 CV420-30X-NDI Manual 4.3.4 System Configurations 4.3.5 Video Settings CV420-30X-NDI CV420-30X-NDI CV420-30X-NDI Item. Function Descriptions Resolution Set the resolution of the camera. Resolutions supported by the camera are as follows: 3840x2160P 59.94/50/29.97 fps 1080P 59.94/50/29.97/25 fps Item. Function Descriptions 720P 59.94/50/29.97/25 fps After switching to the resolution, the camera will restart.
- Page 11 CV420-30X-NDI Manual 4.3.6 Camera Settings 4.3.7 Picture Settings CV420-30X-NDI CV420-30X-NDI Item. Function Descriptions Zoom ratio Adjust the zoom-in or zoom-out ratio via scroll bar Exposure • Mode: Select exposure mode (Automatic/Shutter Priority/Aperture Priority/Manual ) • Exposure Comp. Level: Select exposure compensation level •...
- Page 12 CV420-30X-NDI Manual 4.3.8 Camera Settings 4.3.9 Time Settings CV420-30X-NDI CV420-30X-NDI Item. Function Descriptions Item. Function Descriptions Camera Time Display the date and time of the camera Open audio Turn on / off sound Set the Time • Set Manually: Set time manually •...
- Page 13 CV420-30X-NDI Manual 4.3.10 Network Settings 4.3.11 Maintenance and Updating Firmware CV420-30X-NDI CV420-30X-NDI Item. Function Descriptions Network Network setting of camera. Change of setting is available only when DHCP function is closed. Item. Function Descriptions SNTP Setting Set SNTP Server IP Firmware Update The camera firmware may be upgraded via web page.
-
Page 14: Specifications
CV420-30X-NDI Manual 4.3.13 Additional Maintenance Settings 5. Specifications CV420-30X-NDI Sensor 1/2.5" 8MP CMOS Video Format "Resolution: 3840x2160p (UHD), 1920x1080p (HD), 1280x720p Frame-rate : 59.94/50/29.97/25 fps" Optical Zoom Focal Length 4.6mm ~ 135mm Angle-of-View (Horizontal) 68° ~ 3.5° Aperture F1.5 ~ F3.4... -
Page 15: Troubleshooting
Sharpness Configurable Noise Reduction 2D/3D NR This chapter describes problems you may encounter while using CV420-30X-NDI. If you have Dynamic Range questions, please refer to related chapters and follow all the suggested solutions. If the problem Video Orientation OFF, Flip, Mirror, Both remains, please contact your distributor or the service center. -
Page 16: Warranty
Warranty Marshall Electronics warranties to the first consumer that this device will, under normal use, be free from defects in workmanship and materials, when received in its original container, for a period of two years from the purchase date. This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the warranty.
