- Page 1 B r o a d c a s t A / V D i v i s i o n CV630-IP CV630-IPW 30x UHD30 IP (HEVC) PTZ Camera User Manual...
-
Page 2: Table Of Contents
CV630-IP Manual Copyright Information Copyright 2020 Marshall Electronics, Inc. All rights reserved. 1. Safety Instructions Copying, reproducing or transmitting this file is not allowed if a license is not provided by 2. Package Contents Marshall Electronics, Inc., unless copying this file is for the purpose of backup after purchasing this product. -
Page 3: Safety Instructions
CV630-IP Manual Chapter 1 Safety Instructions ■ Precautions Always follow these safety instructions when using the product: Warning: To reduce the risk of fire or electric shock, do not expose this appliance to rain 1 Operation or moisture. If Camera will not be used for an extended time, unplug it from the power socket. -
Page 4: Package Contents
CV630-IP Manual ay vary Chapter 2 Package Contents Chapter 3 Function Introduction gion 3.1 I/O functions Introduction Metal Plate B CV630-IP M3 Screws Remote Control Silver x8 / Black x2 Power Cord Power Adapter RS-422 Connector Item Function Descriptions Tally indicator light... -
Page 5: Description Of Led Indicator
4.1 Preparation before installation Startup in progress Green light Orange light Installation and setup of CV630-IP cameras requires special skills. To install by yourself, (initialization) please follow necessary steps, ensure steady and secure mounting of the device, and pay In use... - Page 6 CV630-IP Manual 4.2.2.2 Camera Size 4.2.2.4 Size Diagram L x W x H : 174 x 186.1 x 189.7 mm Bottom of camera base Weight: 2.0 Kg The camera can be mounted on a 1/4”, -20 UNC PTZ tripod deck by using the lock holes on the bottom for the tripod 4.2.2.3 Max.
- Page 7 CV630-IP Manual Metal Plate size diagram Metal plate A – camera base side ■ Metal plate B - ceiling side ■ www.marshall-usa.com...
- Page 8 CV630-IP Manual 4.2.2.5 Precautions for installation 4. Combine the metal plate A and the metal plate B 1. Prior to installation, please confirm the orientation of the camera relative to the (1) Push the metal plate A up to the ceiling and then to the right to latch the metal object to be captured to ensure Horizontal and Vertical integrity axis.
-
Page 9: Connecting Devices
CV630-IP Manual 4.3 Connecting devices 4.3.3 Connecting to Internet 4.3.1 Connecting to PC (video conference) For details of web page setup and description, please refer to Chapter 6 Network 3G/HD-SDI supports the audio output of 48 KHz only Function Settings Description 4.3.4 Connecting AUDIO IN... - Page 10 CV630-IP Manual ras can be connected with RS232 daisy chain 4.3.6 Connecting RS-422 4.3.5 Connecting RS-232 connected with RS232 daisy chain Up to 7 Marshall cameras can be connected via RS422 daisy chain method. Up to 7 Marshall PTZ cameras can be connected with RS232 daisy chain When RS-422 connection is being used, keep RS-232 connections vacant.
-
Page 11: Remote Control And Setting Menu
CV630-IP Manual Chapter 5 Remote Control and Setting Menu ■ RS-422 connection instructions 1. Hold the two sides of RS-422 connector and pull out in the direction shown by the 5.1 Functions of remote control arrow in the figure below <Remark>... -
Page 12: Setting Menu
CV630-IP Manual 3. F2.2 Iris Pri 5.2 Setting Menu 4. F2.7 <Remark> Press [Menu] on the remote control to enter the setting menu; the bold underlined 5. F3.2 values in the following table are defaults. 6. F3.8 1st Level 2nd Level... - Page 13 CV630-IP Manual 1/30 1/25 5. ATW 3. 5800k 6. Manual 1/15 1/12 4. 1700k ~ 10000k 7. Sodium Lamp 5. 1700k ~ 10000k 6. Custom 7. 2800k One Push ENTER One push trigger Trigger 1. F1.6 Adjustable when the white 2.
- Page 14 CV630-IP Manual Tilt Down Limit -30 ~ 0 Limit the downward angle right keys or the numeric keys. Activate the reverse Pan Pan Flip On / Off command Press [ENTER] to be in modify mode; select the item Activate the reverse Tilt...
- Page 15 2. To connect directly through network cable, the IP address of the computer should be changed so that it is on the same network segment as the camera e.g.: The factory-preset default IP address of CV630-IP is 192.168.100.100. The computer IP address must be set with the same network segment, such as 192.168.100.101, so that the computer can be connected correctly with the camera...
-
Page 16: Web Page Function Description
CV630-IP Manual 6.1.2 Using the Browser to View the Images 6.2 Web Page Function Description ■ Open the browser, and enter the URL of CV630-IP in the IP address bar 6.2.1 Login Screen e.g.: http://192.168.100.100 (default IP address) ■ Enter administrator’s account and password... - Page 17 CV630-IP Manual 6.2.2 Viewing In Real Time Set the new account management permissions User Type Admin Operator Viewer View images Settings Permission setting Account management Applying setting Add the newly created user to the list of account Edit: Modify the user password and permissions...
- Page 18 Do not use “/” and “space” or special symbols WDR: Set the level of wide dynamic range (WDR) in order to ■ Streaming 1/ obtain better images CV630-IP supports 3 streaming outputs. Please refer to 6.2.5.1 Streaming 2/ Shutter Speed: The shutter speed is adjustable when the ■...
- Page 19 Please use a camera name by mixing uppercase and lowercase letters or numbers. Do not use “/” and “space” or special symbols Soundtrack effect Set MIC In/Line In Streaming 1/ setting CV630-IP supports 3 streaming outputs. Please refer to 6.2.5.1 Item Function Descriptions Streaming 2/ Streaming Parameter Setting...
- Page 20 CV630-IP Manual 6.2.10 Setting-Time 6.2.9 Setting - Network Item Function Descriptions Camera Time Display the date and time of the camera ■ Manually: Set time manually ■ Synchronize with computer time: Set the camera time according to the computer time Set the Time ■...
- Page 21 Firmware Update method, please download the FW upgrade manual from Marshall official website CV630-IP Manual 6.2.12 Maintenance - Incident Log About 6.2.14 English - 38 Item Function Descriptions Item Function Descriptions Camera name Display the camera name Event Logs If the camera encounters errors, an error code log will be established...
- Page 22 Chapter 7 DIP Switch Setting Chapter 8 Troubleshooting 7.1 DIP SWITCH This chapter describes problems you may encounter while using CV630-IP. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem 7.1.1 OUTPUT Switch still occurred, please contact your distributor or Marshall IP technical support.
- Page 23 Warranty Marshall Electronics warranties to the first consumer that this device will, under normal use, be free from defects in workmanship and materials, when received in its original container, for a period of three years from the purchase date. This warranty is extended to the first consumer only, and proof of purchase is necessary to honor the warranty.
